This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or qualified persons in order to
avoid a hazard.
Be aware that high humidity levels may encourage the growth of
biological organisms in the environment.
Do not permit the area around the humidifier to become damp or
wet. If dampness occurs, turn the output of the humidifier down. If
the humidifier output volume cannot be turned down, use the
humidifier intermiently. Do not allow absorbent materials, such as
carpeting, curtains, drapes, or tablecloths, to become damp.

2
Unplug the appliance during filling and cleaning.
Never leave water in the reservoir when the appliance is not in use.
Empty and clean the humidifier before storage. Clean the
humidifier before next use.
WARNING: Micro-organisms that may be present in the water or
in the environment where the appliance is used or stored, can grow
in the water reservoir and be blown in the air causing very serious
health risks when the water is not renewed and the tank is not
cleaned properly every 3 days.
Care should be taken when using the appliance due to the
emission of hot water vapour.
Clean the water tank every 3 days.
This appliance contains a UV emier. Do not stare at the light
source.
Under normal use of condition, this equipment should be kept a
separation distance of at least 20cm between the antenna and the
body of the user.

All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU)
which should not be mixed with unsorted household
waste. Instead, you should protect human health and the
Hereby, Guangdong Deerma Technology Co., Ltd. declares
that the radio equipment type ZNJSQ01DEM is in
compliance with Directive 2014/53/EU. The full text of
environment by handing over your waste equipment to a designated
collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities.
Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health.
Please contact the installer or local authorities for more information
about the location as well as terms and conditions of such
collection points.
the EU declaration of conformity is available at the following
internet address:
hp://www.mi.com/global/service/support/declaration.html
3

4
Safety Instructions
Do not plug in or unplug the humidifier with wet hands so as to avoid the risk of electric shocks.
Do not aempt to disassemble, repair, or modify the humidifier by yourself.
Do not touch the vaporizer once the humidifier is turned on. Otherwise, you may feel a sting.
Do not tangle, damage, or place heavy objects on the power cord so as to avoid the risk of electric shocks, short
circuits, or fire.
Immediately unplug the humidifier if there is an error during use, and contact aer-sales service.
To avoid safety hazards, the power cord must be replaced by the manufacturer or the aer-sales department if
it is damaged or broken.
During the working of the humidifier, do not remove the water tank from the base, and never touch the water
conduits or any components inside the reservoir.
This humidifier is intended for indoor use only.
Unplug the humidifier during thunderstorms or when you do not plan to use it for an extended period of time.
Do not turn the humidifier upside down when it is working or there is water in the tank so as to avoid damage to
the internal electronic components.
This humidifier is not intended for use by people (including children) with reduced physical, sensory, or mental
capabilities, or a lack of experience and knowledge, unless they are under the supervision of or have been given
instructions concerning the use of the humidifier by a person responsible for their safety.
- Clean the water tank every 3 days.
Illustrations of product, accessories, and user interface in the user manual are for reference purposes only.
Actual product and functions may vary due to product enhancements.

5
Product Overview
Operating Process:
Features:
With high-frequency ultrasonic waves of 1.7 million vibrations per second, the humidifier vaporizes water into
ultra-fine particles of 1–5 μm (micron), which will then be diffused into the air via a pneumatic unit. The humidifier
can help to maintain an ideal humidity in the room and prevent the generation of static electricity.
Trendy appearance and exquisite crasmanship
Microcomputer controlled, safe, and accurate
Constant humidity, mist adjustment, and UV light sterilization
Smart Wi-Fi connection and simple to use
Easy-to-fill and easy-to-remove water tank
Humidifier Status
Standby
Speed mode
Awaiting Wi-Fi
connection…
Wi-Fi
connected
successfully
Out of water or
the water tank is
not installed
Constant
humidity mode
Mode Indicator
White quarters
Full white circle
Full red circle
Blinking white
White
Wi-Fi Indicator
——
——
——
——
——
——
——

6
Product Overview
1 Water Tank Lid
2 Mist Outlet
3 Water Tank
4 UV Light Cover
5 Air Outlet
6 Base
7 Mode Buon/Indicator
8 On/Off Buon
9 Air Inlet
10 Silicone Base
11 Power Cord
12 Wi-Fi Buon
13 Wi-Fi Indicator
14 Vaporizer
15 Water Conduits
16 UV Light
1
2
3
4
5
9
15
16
11
10
12
13
14
8
7
6

Installation
7
1. Remove the water tank lid, and add water up to the maximum water level mark.
2. Place the water tank back onto the base.
3. You can start using the humidifier once the installation is completed.
maximum
water level
The humidifier must be placed on a level surface.
Add a suitable amount of clean tap water or distilled water, and make sure not to exceed the
maximum water level mark.
Notes:

How to Use
8
1. Before plugging in the humidifier, ensure its operating voltage matches the voltage of the power outlet. The
humidifier will beep once it turns on, then enters standby mode with the Wi-Fi indicator blinking.
2. Turn on the humidifier: Press the on/off buon, the humidifier will beep and start humidifying. The default speed
mode is low, with 1/4 of the circular indicator lighting up. The humidifier will remember the last used mode when it is
turned off, and start in that mode when it is turned on.
3. Turn off the humidifier: Press the on/off buon, the humidifier will beep and turn off. Then its indicator and water
tank light will go off.
4. Switch the mode: Press the mode buon to cycle through the mode of low speed, medium speed, high speed, and
constant humidity mode, with 1/4, 1/2, 3/4, and the complete of the corresponding circular indicator lighting up.
Note: By default, the humidifier will maintain a relative humidity of 60% while in constant humidity mode.
5. Wi-Fi buon: Press and hold the Wi-Fi buon for three seconds when the humidifier is working. The humidifier will
beep twice and the Wi-Fi indicator will start blinking white to indicate it is awaiting a connection. Once the humidifier
successfully connects with your phone, the Wi-Fi indicator will turn white. You can press the Wi-Fi buon to turn on
or off the Wi-Fi function and the Wi-Fi indicator. When the Wi-Fi function is disabled, the network between the
humidifier and your phone is disconnected.
6. Light control: To turn on or off the water tank light and the mode indicator, press and hold the mode buon for
three seconds when the humidifier is working.
Note: The humidifier is working normally if the water tank light is off. Touch sounds can be enabled/disabled via the
Mi Home/Xiaomi Home app.
7. Dry-run protection: If the water tank is out of water or removed from the base, the humidifier will beep three times.
Then the humidifier enters standby mode, and the circular indicator will turn red. By refiling the water or replacing
the water tank back onto the base, the humidifier can resume working.

Daily Care & Maintenance
Precautions
Transportation
9
1. Always unplug the humidifier before cleaning it.
2. The water conduits can be cleaned directly with a clean, so, damp cloth.
3. It is recommended to clean the water conduits and the vaporizer once a week. If there is limescale in the
conduits, you can pour some citric acid into the conduits to dissolve it. Then use coon swabs or a so brush to
remove the limescale and rinse the conduits with water aerward.
Note: Too much dirt or dust in the water conduits will cause the humidifier in low humidity. If this happens, please
clean the conduits to resume the humidifier working normally.
Turn off and unplug the humidifier before moving it.
When transporting or moving the humidifier, please empty the water tank first.
Installation
To avoid electric shocks, fire, personal injury, or other damage, make sure the humidifier is properly installed
according to the instructions.
Do not plug the humidifier into a power outlet if it is not completely assembled.
Do not disassemble the humidifier.
Placement
To avoid damage to the water tank due to sudden temperature changes, please leave the humidifier at room
temperature for 30 minutes before using it.
Place the humidifier on a flat, level surface.
Do not place the humidifier directly on wooden floors so as to prevent damage to the floor caused by moisture.
To prevent damage caused by moisture, do not place the humidifier within a distance of 2 meters from furniture
and appliances.
Keep the humidifier away from heat sources and avoid exposing it to direct sunlight.

10
Precautions
Do not place the water tank directly on a table or floor. Empty it before placing it separately.
Water Tank
Do not add essential oil, perfume, or disinfectant into the water tank to avoid causing damage to the product or
personal injury.
Do not add any water over 40°C into the water tank and water conduits so as to avoid damage to the humidifier.
Do not allow water to flow into the base via the air outlet. If there is water on the base, wipe it off with a dry cloth
so as to avoid damage to the humidifier.
Do not use the humidifier in environments where the temperature is below 0°C, as the water in the tank may
freeze and cause damage to the humidifier. Always empty the water from the water tank and the water conduits
in such harsh environments.
Do not place any metal objects, nor add chemicals or detergent into the water conduits. Otherwise, it will cause
unhealthy vaporization.
Always turn off and unplug the humidifier before pouring out the water from the water conduits.
Adding Water
Unplug the humidifier when adding water or cleaning it.
Do not add water via the mist outlet and the air outlet.
Do not exceed the maximum water level mark when adding water.
Power Cord
To avoid fire, electric shocks, or other damage, use the power cord and power outlet as instructed below:
The power cord must be plugged into a suitable power outlet.
Do not pull the power cord.
Always unplug the humidifier before carrying out any maintenance or moving it.
During Use
Once the humidifier is turned on, the UV light is on and the sterilization function is enabled. Once the
humidifier is turned off, the UV light is off and the sterilization function is disabled.
The UV light is equipped with a cover so as to prevent UV light leakage during use. The cover can be
removed for cleaning.
Immediately stop using the humidifier if it makes unusual sounds, gives off bad odors, or overheats.

Precautions
11
Keep hair and fabrics away from the humidifier so as to prevent them from falling into or blocking the inlets
and outlets.
Do not sit on, lean on or tilt the humidifier.
When using the humidifier in conjunction with gas-fueled appliances including gas stoves, gas heaters, make
sure there is sufficient ventilation to avoid carbon monoxide poisoning.
Do not move the humidifier during use. Turn off and unplug the humidifier before moving it, cleaning it, or
adding water.
Usage Restrictions
Do not use the humidifier in the following circumstances so as to avoid electric shocks, fire, or other damage:
Always place the humidifier on a level surface. Otherwise, the water level reading may be incorrect or the water
tank may overflow.
The voltage of the power outlet must be the same as the voltage of this humidifier. Do not use the humidifier if
the voltages do not match and please contact your dealer.
Only use the humidifier in normal room temperatures (5°C to 40°C).
Cleaning
Avoid geing water into the humidifier while cleaning.

12
Specifications
Connect with Mi Home/Xiaomi Home App
This product works with Mi Home/Xiaomi Home app *. Control your device, and interact it and other smart home
devices with Mi Home/Xiaomi Home app.
Scan the QR code to download and install the app. You will be directed to the connection setup page if the app is
installed already. Or search "Mi Home/Xiaomi Home" in the app store to download and install it.Open Mi
Home/Xiaomi Home app, tap "+" on the upper right, and then follow prompts to add your device.
* The app is referred to as Xiaomi Home app in Europe (except for Russia). The name of the app displayed on your
device should be taken as the default.
Note: The version of the app might have been updated, please follow the instructions based on the current app
version.
For detailed e-manual, please go to www.mi.com/global/service/userguide
Name: Mi Smart Antibacterial Humidifier
Model: ZNJSQ01DEM
Rated Input: 25 W
Rated Voltage: 220-240 V~
Rated Frequency: 50/60 Hz
Water Tank Capacity: 4.5 L
RF Specification: 2.4 G Wi-Fi
Maximum Output Power: <20 dBm
Net Weight: 1.9 kg
Noise Emission: ≤38 dB
Max. Humidifying Capacity: 300 mL/h
Item Dimensions: 190 × 190 × 353 mm
Materials: ABS, PC & PA
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Working Frequency: 2412-2472 MHz
CID: WFA97113

13
Este dispositivo solo puede ser utilizado por niños de 8 años o más,
y aquellas personas con capacidades psíquicas, sensoriales o
mentales reducidas, o que carezcan de la experiencia y
conocimientos necesarios, si han recibido supervisión o
instrucciones en relación con el uso del aparato de forma segura y
comprenden los riesgos que comporta. Los niños no deberán jugar
con el dispositivo. La limpieza y mantenimiento del usuario no
deberá efectuarse por niños sin supervisión.
Este dispositivo no está diseñado para personas (incluidos niños)
con capacidades sicas, sensoriales o mentales reducidas, o con
falta de experiencia y conocimientos, a menos que estén bajo
supervisión o que la persona responsable de su seguridad les haya
proporcionado instrucciones sobre el uso del producto.
Los niños deberán estar bajo supervisión para asegurarse de que
no jueguen con el aparato.
Si el cable de alimentación está dañado, debe ser reemplazado por
el fabricante, su agente de servicio o personas con una
cualificación similar para evitar riesgos.
Tenga en cuenta que niveles de humedad elevados podrían
potenciar la aparición de organismos biológicos en el entorno.
No permita que la zona alrededor del humidificador este húmeda o
mojada. De ser así, reduzca la potencia de salida del humidificador.
Si el volumen de salida del humidificador no puede modificarse,
utilícelo de forma intermitente. No permita que se humedezcan
materiales absorbentes como alfombras, cortinas,

14
paños o manteles se empapen.
Desenchufe el dispositivo durante su llenado y limpieza.
Nunca deje agua en la reserva cuando el dispositivo no esté
en uso.
Vacíe y limpie el humidificador antes de su almacenaje. Limpie el
humidificador antes de su próximo uso.
ADVERTENCIA: Los microorganismos que pudieran estar
presentes en el agua o en el entorno en el que se utilice el
dispositivo o se almacene pueden crecer en la reserva de agua y
ser liberados al aire, causando complicaciones graves de salud
cuando el agua no se renueva y el tanque no se limpia
correctamente cada 3 días.
Deberá tenerse cuidado al usar el dispositivo debido a la emisión
de vapor de agua caliente.
Limpie el tanque de agua cada 3 días.
El dispositivo contiene un emisor de rayos UV. No mire fijamente a
la fuente de luz.
En condiciones normales de uso, este equipo debe mantenerse a
una distancia de, al menos, 20 cm entre la antena y el cuerpo del
usuario.

15
Todos los productos que llevan este símbolo son residuos
de aparatos eléctricos y electrónicos (RAEE según la
directiva 2012/19/UE) que no deben mezclarse con
residuos domésticos sin clasificar.En su lugar,
Por la presente, Guangdong Deerma Technology Co., Ltd.
declara que el tipo de equipo radioeléctrico ZNJSQ01DEM
cumple con la Directiva 2014/53/UE.
debe proteger la salud humana y el medio ambiente entregando sus
equipos de desecho a un punto de recogida para el reciclaje de
residuos de equipos eléctricos y electrónicos, designado por el
gobierno o las autoridades locales. La eliminación y el reciclado
correctos ayudarán a evitar posibles consecuencias negativas para
el medio ambiente y la salud humana. Póngase en contacto con el
instalador o con las autoridades locales para obtener más
información sobre la ubicación y las condiciones de dichos puntos
de recogida.
Encontrará el texto completo de la declaración de conformidad de
la UE en esta dirección de Internet:
hp://www.mi.com/global/service/support/declaration.html

Instrucciones de Seguridad
16
No enchufe o desenchufe el humidificador con las manos mojadas para evitar el riesgo de descargas eléctricas.
No intente usted mismo(a) desmontar, reparar o modificar el humidificador.
No toque el vaporizador una vez que el humidificador esté encendido. De lo contrario, puede sentir un toque
eléctrico.
No enrede, dañe o coloque objetos pesados sobre el cable de alimentación para evitar el riesgo de descargas
eléctricas, cortocircuitos o incendios.
Desenchufe inmediatamente el humidificador si hay un desperfecto durante su uso y póngase en contacto con
el servicio posventa.
Para evitar riesgos de seguridad, si el cable de alimentación está dañado o roto debe ser reemplazado por el
fabricante o el departamento de postventa.
Durante el funcionamiento del humidificador, no retire el tanque de agua de su base, y nunca toque los
conductos de agua ni ningún componente dentro del depósito.
Este producto es exclusivo para uso en interiores.
Desenchufe el humidificador durante tormentas eléctricas o cuando no planee usarlo durante un período de
tiempo prolongado.
No ponga el humidificador boca abajo cuando esté funcionando o cuando haya agua en el tanque para evitar
daños en los componentes electrónicos internos.
Este dispositivo no está diseñado para personas (incluidos niños/as) con capacidad sica, sensorial o mental
reducida, o con falta de experiencia y conocimientos, a menos que estén bajo supervisión o que la persona
responsable de su seguridad les haya proporcionado instrucciones sobre el uso del producto.
- Limpie el tanque de agua cada 3 días.
Las ilustraciones de producto, accesorios e interfaz de usuario(a) en el manual de usuario son solo como
referencia. El producto y las funciones actuales pueden variar debido a mejoras en el producto.

Descripción del Producto
17
Proceso Operativo:
Características:
Con ondas ultrasónicas de alta frecuencia de 1,7 millones de vibraciones por segundo, el humidificador vaporiza
el agua en partículas ultrafinas de una a cinco micras (1-5 μm), que luego se difundirán en el aire a través de una
unidad neumática. El humidificador puede ayudar a mantener una humedad ideal en la habitación y evitar la
generación de electricidad estática.
Aspecto moderno y habilidad técnica exquisita
Microcomputadora controlada, segura y precisa
Humedad constante, ajuste de vapor y esterilización con luz ultravioleta
Conexión WiFi rápida y fácil de usar
Tanque de agua fácil de llenar y de quitar
Estado del
Humidificador
Espera
Modo de velocidad
Esperando conexión
delWiFi…
WiFi conectado
correctamente
El tanque de agua no
está instalado o está
sin agua
Modo de humedad
constante
Indicador de modo
Cuartos blancos
Círculo blanco completo
Círculo rojo completo
——
——
——
Parpadeo rápido blanco
Blanco
Indicador del WiFi
——
——
——
——

18
Descripción del Producto
6 Base
5 Salida de aire
7 Botón/Indicador de modo
8 Botón de encendido/
apagado
9
10
11
12
Botón del WiFi
13 Indicador del WiFi
14 Vaporizador
15 Conductos de Agua
16 Luz ultravioleta
1 Tapa del Tanque de Agua
2 Salida de Vapor
3 Depósito de agua
4 Cubierta de Luz Ultravioleta
1
2
3
4
5
9
15
16
11
10
12
13
14
8
7
6
Entrada de aire
Base de silicona
Cable de alimentación

Instalación
19
1. Retire la tapa del tanque de agua y agregue agua hasta la marca de nivel máximo.
2. Coloque el tanque de agua nuevamente en la base.
3. Usted puede comenzar a usar el humidificador una vez que se complete la instalación.
Nivel máximo
de agua
El humidificador se debe colocar en una superficie nivelada.
Agregue una cantidad adecuada de agua del grifo o agua destilada, y asegúrese de no exceder la marca de
nivel máximo de agua.
Notes:
