Boneco U310 User manual

U 310
MANUAL
READ AND SAVE THESE INSTRUCTIONS

Instructions for use 3
Instructions d’utilisation 15
Instrucciones de uso 27

3
en
INSTRUCTIONS FOR USE
BONECO U310

1
2
5
7
6
8
9
3
1
2
4
6
5
7
8
3
4
en
1Cover
2Nozzle
3Flue
4Main switch / controller
5Cleaning brush
6A250
7Fragrance container
8Power supply
OVERVIEW AND PART NAMES

5
en
TABLE OF CONTENTS
Introduction 6
Introduction 6
A250 6
Items included 6
Start-up 7
Preparation of the A250 9
A250 preparation 9
On water hardness 9
Determining water hardness 9
The right location 10
The right location 10
Functions and indicators 10
Water level 10
Fragrance container 10
Notes on care 11
Care instructions 11
Cleaning agent 11
Cleaning and descaling 12
Descaling 12
Removing mineral deposits 13
Technical data 14

6
en
ITEMS INCLUDED
BONECO U310 “A7417 EZCal” cleaning and
descaling powder
A250
INTRODUCTION
Congratulations on your purchase of the BONECO U310.
This high-performance humidifier keeps the humidity at
a comfortable level at all times. No longer will you have
to contend with itchy eyes, dry skin and dry mucous
membranes. This helps make you and your family less
susceptible to colds and other infectious diseases.
You will not want to give up your newly gained com-
fort.
INTRODUCTION
A250
Please refer to the enclosed manual for putting the A250
into operation.
ON WATER HARDNESS
The BONECO U310 is supplied with an A250. The granu-
late contained in it filters the lime out of the tap water so
that it is not released into the room air. Hard tap water
accelerates saturation of the granulate so that the A250
must be replaced earlier.
Dispose of the saturated A250 with your regular house-
hold waste.
The A250 should not be used longer than specified. White
dust around the appliance is a sure indication that the
A250 has run its course. You can obtain replacements
from your BONECO specialist dealer or our online store at
www.shop.boneco.us.
Water hardness test strips

7
en
START-UP
1 2
5
Connect the BONECO U310 to the power outlet.
Rinse the A250 for 2 minutes under cold
running water.
Screw the A250 to the BONECO U310.
6
Use the control knob to switch on the BONECO U310.
4
Warning: Do not exceed the maximum fill level.
3
Fill the tank with cold tap water.

8
en START-UP
7
Set the intensity of the mist you want.
8
Do not place the BONECO U310 directly on the floor.

9
en
A250 PREPARATION
1. Remove the packaging of the BONECO A250.
2. Rinse the A250 for 2 minutes under cold running
water.
3. Screw the A250 to the BONECO U310.
ON WATER HARDNESS
The BONECO U310 is supplied with an A250. The granu-
late contained in it filters the lime out of the tap water so
that it is not released into the room air. Hard tap water
accelerates saturation of the granulate so that the A250
must be replaced earlier.
DETERMINING WATER HARDNESS
1. Dip the enclosed test strip into a glass of cold tap
water for 1 second.
2. Read the water hardness after a few seconds.
3. Refer to the table to determine the duration of effect
of the A250:
Dispose of the saturated A250 with your regular house-
hold waste.
The A250 should not be used longer than specified. White
dust around the appliance is a sure indication that the
A250 has run its course. You can obtain replacements
from your BONECO specialist dealer or our online store at
www.shop.boneco.us
= 6 months
= 6 months
= 5 months
= 4 months
= 3 months
= 2 months
PREPARATION OF THE A250

10
en
WATER LEVEL
The LED lighting on the switch indicates the operating
status and water level.
• Blue (lights up): The appliance is switched on and in
operation. A sufficient amount of water is in the tank.
• Red (blinking): The appliance is switched on, but the
water tank is empty. Switch off the appliance or refill
the tank with fresh water.
• No display: The appliance is switched off or discon-
nected from the power outlet.
FRAGRANCE CONTAINER
Commercially available fragrances can be inserted into
the fragrance container on the rear side.
1. Press down on the fragrance container to unlock the
drawer.
2. Sprinkle the cotton insert in the drawer with the fra-
grance of your choice.
Never add the fragrance directly to the water tank;
doing so will damage the BONECO U310 and void the
warranty!
FUNCTIONS AND INDICATORS
THE RIGHT LOCATION
The BONECO U310 releases more than half a liter of water
into the air per hour. This makes it important to set up the
appliance in the right location.
Do not place the BONECO U310 directly on the floor,
since the moisture from the mist can damage floor
surfaces such as parquet or delicate carpeting.
• Make sure that the appliance stands about 1 ft (30 cm)
away from the closest wall.
• The unit should be placed in an elevated position,
e.g. on a table, chest of drawers, etc.
• Do not direct the mist toward the wall, plants, furniture
or other objects in order to prevent water condensation
from damaging them. Maintain a distance of at least
20 inches (50 cm).
THE RIGHT LOCATION

11
en
FUNCTIONS AND INDICATORS
CARE INSTRUCTIONS
With increasing time and use, the performance of the
A250 decreases. The inside of the BONECO U310 be-
comes coated with limescale. Stagnant water can also
impair cleanliness and lead to unpleasant odors.
This means regular maintenance and cleaning is neces-
sary to ensure clean and unimpaired operation.
Always unplug the unit from the power outlet before
cleaning. Failure to do so can result in electric shock
and pose the risk of severe or fatal injury!
CLEANING AGENT
Clean the housing of the BONECO U310 with a soft cloth.
Use warm tap water with a small amount of dishwashing
detergent.
Interval* Task
Daily Check the water level; add water if necessary
After 1 week without operation Empty and clean the BONECO U310
Every 2 weeks Clean and descale the water tank
Every 2 to 6 months Replacing the A250
NOTES ON CARE
* Effective time intervals vary depending on air and water quality and the length of operation.
For this reason, the information here should be viewed as a recommendation.

12
en
DESCALING
If stubborn limescale deposits form at the bottom of the
BONECO U310, the appliance must also be descaled in
addition to the cleaning. For this process, use the pro-
vided “EZCal” descaling agent. You can get replacement
parts at your BONECO specialist dealer or at the online
store under shop.boneco.us
1. Disconnect the BONECO U310 from the power outlet.
The unit must always be unplugged from the power
outlet before draining it. Failure to do so can result in
electric shock and pose the risk of severe or fatal
injury!
2. Empty the water tank.
Tip the long side of the BONECO U310 towards the
sink (with the viewing window facing down). This
prevents water from getting into the air outlet and
damaging the unit.
3. Remove the A250.
4. Mix 1 bag of EZCal with 32 oz. (1 liter) of water and
pour the mixture into the water tank, one half to the
left and right each.
5. Wait 30 minutes to allow the solution to take effect.
6. Rinse the water tank with tap water. Remove re-
maining lime residue, if any, using a scrub brush.
7. Rinse the inside of the water tank with fresh tap water.
8. Reinsert the A250.
CLEANING AND DESCALING

13
en
REMOVING MINERAL DEPOSITS
Mineral deposits on the membrane can be removed using
the yellow cleaning brush attached to the cover of the
BONECO U310.
Never clean the membrane using sharp objects or
aggressive cleaning agents; doing so can damage
the BONECO U310 and voids the warranty!
CLEANING AND DESCALING
REPLACING THE A250
The A250 must be replaced every 2 to 6 months. In cases
of very hard water, it may have to be replaced sooner.
White dust around the appliance is a sure indication that
the A250 has run its course.
Please refer to the enclosed manual for putting the A250
into operation.
The used A250 can be disposed of with your regular
household waste.
REPLACING THE A250

14
en
Mains voltage 120 V / 60 Hz
Power consumption 115 W
Humidity output 3.17 gal / 24h (500 g/h)
For rooms up to 860 sqft / (80 m2)
Water capacity 1.30 gallons (5.0 Liter)
Dimensions L×W×H 12.12×6.49×12.79 in / (308×165×325 mm)
Weight (empty) 6 lbs / (2.74 kg)
Operating noise level < 45 dB (A)
TECHNICAL DATA

15
fr
INSTRUCTIONS D’UTILISATION
BONECOU310

16
fr VUE D’ENSEMBLE ET NOM DES PIÈCES
1
2
5
7
6
8
9
3
1
2
4
6
5
7
8
3
1Couvercle
2Buse
3Conduit
4Interrupteur principal/
régulateur
5Brosse
6 A250
7Récipient pour
substances odorantes
8Alimentation électrique

17
fr
Introduction 17
Introduction 17
A250 17
Éléments inclus 17
Mise en marche 18
Préparation de l‘A250 20
Préparatifs concernant l‘A250 20
Informations concernant la dureté de l’eau 20
Mesure de la dureté de l’eau 20
Le bon endroit 21
Le bon endroit 21
Fonctions et indicateurs 21
Niveau de l’eau 21
Récipient pour parfum 21
Remarques sur l’entretien 22
Consignes d’entretien 22
Produit de nettoyage 22
Nettoyage et détartrage 23
Détartrage 23
Élimination des dépôts minéraux 24
Caractéristiques techniques 25
SOMMAIRE

18
fr
ÉLÉMENTS INCLUS
BONECOU310 Poudre de nettoyage et
détartrage «A7417 EZCal»
A250
INTRODUCTION
Félicitations pour votre achat du BONECO U310. Cet
humidificateur d’air très performant maintient constam-
ment l’humidité à un niveau agréable. Vous n’aurez plus
à subir picotements dans les yeux, peau et muqueuses
sèches. Vous et votre famille serez ainsi moins vulné-
rables aux rhumes et aux autres maladies infectieuses.
Vous ne pourrez plus vous passer de ce nouveau
confort.
INTRODUCTION
A250
Consultez le manuel fourni pour mettre en service l’A250.
INFORMATIONS CONCERNANT LA DURETÉ DE L’EAU
Le BONECO U310 est livré avec la cartouche de dé-
tartrage «A250». Les granulés qu’elle contient filtrent le
calcaire présent dans l’eau du robinet, afin qu’il ne soit
pas diffusé dans l’air ambiant. Quand l’eau du robinet est
dure, la saturation des granulés est plus rapide, de sorte
qu’il faut remplacer la cartouche plus tôt.
Jetez la cartouche de détartrage saturée avec les déchets
ordinaires.
La cartouche de détartrage ne devrait pas être utilisée
au-delà de la durée indiquée. Un dépôt blanc tout autour
de l’appareil est un signe sûr que la cartouche est usagée.
Vous trouverez une pièce de rechange auprès de votre
revendeur spécialisé BONECO ou dans notre boutique en
ligne à l’adresse www.shop.boneco.us.
Bandes de test de la dureté
de l’eau

19
fr
MISE EN MARCHE
12
5
Branchez le BONECOU310 sur une prise électrique.
Mouillez la cartouche en laissant couler dessus l’eau
froide du robinet pendant 2 minutes.
Vissez la cartouche au BONECO U310.
6
Utilisez le bouton de commande pour allumer
le BONECOU310.
4
Avertissement: Ne dépassez pas le niveau maximal
de remplissage.
3
Remplissez le réservoir avec de l’eau du robinet
froide.

20
fr
7
Définissez l’intensité du brouillard que vous souhaitez
atteindre.
8
Ne posez pas le BONECO U310 directement sur le sol
MISE EN MARCHE
