Micasa MA0237AF-W User manual

AIR FRYER
Instruction Manual
Models MA0237AF-W and MA0238AF-B
Read in full and retain for future use

2
MICASA branded product provides an affordable range of well presented, elegant home ware and appliances.
Products which are ranged and selected are chosen to suit your contemporary lifestyle and cater for your home
ware needs today. Micasa aims to provide products which are fashionable, affordable, and reliable to meet your
home ware demands.
MICASA will provide value for money products to make every day home life more enjoyable and convenient.
The MICASA range of products is continually developing and new products will be introduced with expansion of
the range. So keep in touch for further news on new products in the future.
We hope you enjoy your experience with MICASA
Contact [e-mail]
Visit www.micasa-appliances.com
Helpline
New Zealand call toll free 0508-274-2722
Australia call [phone]
Distributed by
Asia Pacific Brands Limited
PO Box 113001 Broadway
Newmarket, 1149
Auckland, New Zealand
FEATURES
1500 Watt Class1 appliance
Thermostat Control
30 Minute timer
Power ON indicator lamp
Power and temperature indicator light
Overheat protection
A new healthier way to cook your favourite foods. No need to deep fry anymore. Most foods do not require oils
at all. The air fryer uses hot air circulated by high speed fan and heat from an overhead grill element.

3
PARTS DETAILS

4
1. Cooking basket
2. Cooking pan assembly
3. Cook assembly handle
4. Cooking basket release button
5. Heat cycle ON indicator
6. Power On indicator
7. Timer control (0-30minutes)
8. Temperature control
9. Air inlet
10. Air outlet
11. Supply cord entry
Accessories
Cake baking pan - Low level pan - Stand - Silicone heat resistant mat - Tongs
BEFORE FIRST USE
Before first use remove any stickers or similar from the appliance. Dispose of any plastic bags as they pose a
risk to young children of suffocation.
Wash the cooking basket and cooking accessories. Wash in hot soapy water, dry with a dry towel.
OPERATION
Note. Appliance will not operate unless the cooking pan assembly is fitted correctly.
Prepare the food item to be cooked
Place the appliance on a heat resistant level surface away from combustible materials. Allow a gap, do not
block air vents. Air vents are located on the rear and around the top.
Connect the supply plug to a suitable 230-240V ~ 50Hz outlet. This appliance is designed to work in New
Zealand and Australia safely.
Remove the cooking pan assembly by pulling outwards (picture 4)
Place food items into the cooking basket and place into the cooking pan assembly (picture 3). Do not overfill
the cooking basket. This will affect the cooking abilities.
Place the cooking pan assembly into the cooking chamber fully (picture 5).
Once connected to the power supply the POWER ON light will illuminate
Select the desired heat setting on the thermostat control knob (picture 6).
Select the desired cooking time on the timer (picture 7)
The heating indicator will glow when the heat cycle is on. When the lamp goes off the selected temperature
has been reached.
At the completion of the cooking time carefully remove the cooking pan assembly and serve.
Warning! Do not use without the cooking basket.
Warning! Do not touch hot metal surfaces. Use the handles.

5
COOKING GUIDE
A new healthier way to cook your favourite foods. No need to deep fry anymore. Most foods do not require oils
at all. The air fryer uses hot air circulated by high speed fan and heat from an overhead grill element.
Tips
1. When cooking large quantities smaller sized ingredients are best producing shorter cooking time and
more consistent finished product.
2. Do not over fill the baskets. Overfilling the basket with food will lengthen the cooking time and effect the
air circulation, hindering consistent cooking.
3. When cooking items such as fries shake the basket once or twice during cooking. This ensures even
cooking
4. Warning! Do not place oils into the cooking bowls. Apply oils, cooking sprays to food item if required
pre-cooking. There is no need to cook with oils in the pan. Apply a small amount to the bottom of basket
if required to stop food sticking only.
5. If there is a large amount of smoke remove the cooking pan assembly and drain excess oils that may
have occurred. If using foods that are high in fat reduce the amount in the basket.
6. When first using always undercook until you are familiar with the appliance.
Times are a guide only dependent on size and freshness of food choice. If cooking from cold it is recommended
to add 2-3 minutes to the cooking time also or alternatively pre-heat the appliance before cooking by heating for
2-3 minutes.
Warning! Handle hot surfaces with care use heat protectant gloves or similar.
Food Item
Min
–
Max
grams
Time
(min)
Temperature
ºC
Mid c
ooking option
Notes
Fries (thin cut) 300-700 9-16 200 Remove and shake basket
Fries (thick cut) 300-700 11-20 200 Remove and shake basket
Fries
(homemade) 300-800 16-20 200 Remove and shake basket Add ½ teaspoon oil
Potato Wedges 300-800 18-22 180 Remove and shake basket Add ½
teaspoon oil
Steak 200-500 8-12 180
Chops 200-500 10-14 180
Drumsticks 200-500 18-20 180
Chicken breast 200-500 10-15 180
Cake 300 20-25 160 Use baking
tin
Muffin 300 15-18 200 Use baking
tin

6
RECIPE SUGGESTIONS
Crumbed chicken
You need
2-3 tablespoons of vegetable oil or butter
100g of bread crumbs
1 egg
8 chicken pc
To cook
Preheat air fryer to 180ºC
Mix the oil and breadcrumbs together thoroughly in a bowl
Whisk the egg mix in a separate bowl
Dip the chicken pieces into the egg mix
Dip the chicken into the breadcrumb mix and evenly coat
Place food stand into cooking basket
Place chicken pieces onto stand and place into air fryer
Cook for 12-14 minutes at 180ºC.
Beef Schnitzel
You need
2 tablespoons vegetable oil
50g breadcrumbs
1 egg
1 large thin beef schnitzel
Serve with sliced lemon
To cook
Pre-heat air fryer to 180ºC
Mix the bread crumbs and oil together thoroughly in a bowl
Whisk the egg in a separate bowl
Dip the schnitzel into the egg mix
Coat in breadcrumbs evenly
Cook in air fryer for 10-12 minutes at 180ºC
Homemade fries
You need
2 large potatoes
1 tablespoon vegetable oil
Sea salt to taste
To cook
Peel the potatoes and cut into even slices (size to suit). Keep as regular as possible across the potatoes. Soak
for 15-20 minutes then pat dry.

7
Place the fries into a bowl (or bag) and add the vegetable oil. Mix together so that the fries receive a thin coating
of oil
Place into air fryer and cook for 20 minutes on 200ºC
Shake basket half way thru cooking cycle
Crumbed Fish
You need
4 tablespoons vegetable oil
100g breadcrumbs
1 egg
4 fish fillets of choice
1 lemon
To cook
Preheat oven to 180ºC
Mix vegetable oil and breadcrumbs thoroughly
Whisk the egg in a bowl
Dip fish fillets into egg mixture
Coat fillets with breadcrumb mix
Place fillets onto rack in baking dish and cook for 10-12 minutes
Serve immediately with sliced lemon
Banana Cake
You need
50g butter
1/3 cup brown sugar
1 egg
1 large mashed banana
2 tablespoons of honey
1 cup self-rising flour
½ teaspoon of cinnamon
Salt to taste (if required)
Cooking spray
To cook
Preheat air fryer to 160ºC
Spray the cake baking tin insides with a small coating of cooking spray
In a large bowl beat the butter and brown sugar until smooth and creamy.
Add the egg, banana, honey, cinnamon, salt (if required), flour and whisk until mixture is smooth.
Place into cake bake dish.
Place into air fryer and cook for 30 minutes on 160ºC.
Insert a toothpick into the cake to test. When it is removed clean the cake should be cooked.

8
Chocolate Cake
You need
50g caster sugar
50g butter
1 tablespoon apricot jam (or similar)
50g plain flour
1 Egg
1 tablespoon cocoa
Salt to taste
Icing sugar
To Cook
Pre heat air fryer to 160ºC
Spray a thin layer of cooking spray onto the cake tin
In a large bowl beat sugar and softened butter until creamy.
Add the jam and whisked egg
Sift flour, cocoa and salt into mix and stir thoroughly
Place into cake tin and level
Bake for 15 minutes at 160ºC
When a toothpick can be inserted and removed clean the cake should be cooked properly.
Serve dusted with icing sugar.
CLEANING GUIDE
Warning! Disconnect from the power supply before cleaning.
Warning! Allow to cool before cleaning.
Warning! Do not place in a dishwasher.
Step 1. Remove the cooking pan assembly.
Remove the cooking basket and wash in hot soapy water, dry with a dry towel.
Wash the cooking pan assembly in hot soapy water, dry with a dry towel.
Step 2. Carefully wipe with a damp cloth any residual spillages from inside the appliance.
Step 3. Wipe the outer surface of the appliance with a soft damp cloth, dry with a dry towel.
Warning! Do not immerse the appliance in liquids
Warning! Do not use harsh chemicals, wire wool or scouring pads to clean the cooking surface. This will
damage the non-stick cooking surface.

9
SAFETY
To avoid any risk of risk of fire, shock hazard or personal injury, follow these guidelines.
Warning! When not in use or before cleaning, always disconnect the appliance from the mains supply
Warning! Do not splash with liquids. Do not allow the appliance supply plug and cord to get wet or be immersed
in any liquid.
Warning! Disconnect from the mains supply and switch off when not in use.
Warning! In order to avoid overheating, do not cover the appliance.
Warning! Children
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of knowledge, unless they have been given supervision or instruction concerning safe use of
the appliance by a person responsible for their safety. Young children must be supervised to ensure that they do
not play with the appliance.
Warning! Safely dispose of any plastic bags or other packaging that may present a hazard to young children of
suffocation or choke hazard.
Warning! For household indoor use only, do not use outdoors. Not for commercial use.
Warning! Do not abuse or damage the supply cord. If for any reason the cord is damaged, it must be replaced
by the manufacturer, its service agent or a similarly qualified person in order to avoid hazard. A replaceable cord
must be replaced with an authorised replacement from an authorized service agent.
Warning! This appliance must only be used with a genuine replacement cord set marked with the same
markings as the one supplied
Warning! Keep the appliance and supply cord away from other heat sources.
Warning! Do not allow the supply cord to hang over the edge of any table. Young children may pull the
appliance of causing a risk of burns, shock or fire hazard.
Warning! This appliance must not be mounted or located below or directly in front of a socket outlet.
Warning! The appliance must not be used if the appliance is damaged.
Warning! Do not leave this appliance unattended while in use. This appliance must not be used by means of an
external timer or separate remote-control system.
Warning! Do not allow the appliance to come into contact with curtains, walls, clothing, dishcloths or other
flammable materials.
Use
This appliance is intended to be used in household and similar applications such as:
Staff kitchen areas in shops, offices and other working environments;
Farm houses
By clients in hotels, motels and other residential type environments;
Bed and breakfast type environments
Warning! Do not place the appliance on a gas or electric burner, or inside an oven or any other heat source.
Warning! Do not tip over.
Warning! Do not move when in operation.
Warning! Do not cover this appliance.
Warning! Fire risk exists if any appliance is covered by or positioned near curtains or other combustible
materials

10
Smoke. During first use there may be a small amount of smoke, this is normal. This is only the oils used in
production to protect the heating elements from rust being burned off from the hot element.
Warning! Heat. Always use on a flat stable heat resistant surface.
Warning! High temperatures. Metal components will reach very high temperatures in use. Always handle with
care, use oven gloves or similar when handling. Allow to cool before store.
Warning! Hot steam. May be expelled when opening. During cooking process hot steam will be expelled
through the air vents. Keep hands and face away.
Warning! Air vents! Do not place any object onto the top. Do not block the rear air vents. Keep a gap aroun d
the appliance of at least 10cm.
WARRANTY
Retain your receipt as proof of purchase.
If for any reason the appliance does not function correctly or shows signs of damage please stop using
immediately and return it immediately to the retailer.
This product is covered by a 12 month warranty by Harvey Norman (NZ) PTY Ltd. This warranty does not
exclude any obligations to the consumer covered by the NZ Consumers guarantee act.
