Michell Instruments HygroSmart I7000XP User manual

HygroSmart I7000XP
Interchangeable Sensor for RH
& Temperature
User’s Manual
97481 Issue 1
January 2015

Please ll out the form(s) below for each instrument that has been purchased.
Use this information when contacting Michell Instruments for service purposes.
Sensor
Code
Serial Number
Invoice Date
Location of Instrument
Tag No
Sensor
Code
Serial Number
Invoice Date
Location of Instrument
Tag No
Sensor
Code
Serial Number
Invoice Date
Location of Instrument
Tag No

© 2015 Michell Instruments
This document is the property of Michell Instruments Ltd. and may not be copied or
otherwise reproduced, communicated in any way to third parties, nor stored in any Data
Processing System without the express written authorization of Michell Instruments Ltd.
HygroSmart I7000XP
Interchangeable Sensor
For Michell Instruments' contact information please go to
www.michell.com

HygroSmart I7000XP User’s Manual
iv 97481 Issue 1, January 2015
Contents
Safety ................................................................................................................................ v
Electrical Safety ........................................................................................................... v
Toxic Materials ............................................................................................................. v
Repair and Maintenance ............................................................................................... v
Calibration ................................................................................................................... v
Safety Conformity ........................................................................................................ v
Abbreviations ......................................................................................................................vi
Warnings ............................................................................................................................vi
1 INTRODUCTION ................................................................................................1
2 INSTALLATION ..................................................................................................2
2.1 Unpacking the Instrument ................................................................................... 2
2.2 Choice of the Site of Installation .......................................................................... 2
2.3 Connections ....................................................................................................... 3
2.3.1 Electrical Connections .................................................................................... 3
2.3.2 Power Supply ................................................................................................ 3
3 MAINTENANCE ..................................................................................................4
3.1 Replacing the HygroSmart I7000XP Interchangeable Sensor .................................. 4
3.2 Recalibration Service ........................................................................................... 4
Figures
Figure 1 Operating Graph .........................................................................................2
Figure 2 Electrical Connections .................................................................................3
Figure 3 HygroSmart I7000XP Sensor Pin Connector ..................................................4
Figure 4 Hygrosmart I7000XP Operating Conditions ...................................................7
Figure 5 Hygrosmart I7000XP Dimensions .................................................................7
Appendices
Appendix A Technical Specications ...............................................................................6
A.1 Operating Conditions .....................................................................7
A.2 Dimensions ...................................................................................7
Appendix B Quality, Recycling & Warranty Information .....................................................9
B.1 Pressure Equipment Directive (PED) 97/23/EC .................................9
B.2 Recycling Policy ............................................................................9
B.3 WEEE Compliance ..........................................................................9
B.4 RoHS2 Compliance ......................................................................10
B.5 Warranty .....................................................................................10
B.6 REACH Compliance ...................................................................... 11
B.7 Calibration Facilities .....................................................................11
B.8 Return Policy ...............................................................................12
B.9 Manufacturing Quality .................................................................. 12
Appendix C Recommended Practices in Humidity Measurements..................................... 14
Appendix D Return Document & Decontamination Declaration ........................................19

HygroSmart I7000XP User’s Manual
Michell Instruments v
Safety
The manufacturer has designed this equipment to be safe when operated using the procedures
detailed in this manual. The user must not use this equipment for any other purpose than that
stated. Do not apply values greater than the maximum value stated.
This manual contains operating and safety instructions, which must be followed to ensure the safe
operation and to maintain the equipment in a safe condition. The safety instructions are either
warnings or cautions issued to protect the user and the equipment from injury or damage. Use
competent personnel using good engineering practice for all procedures in this manual.
Electrical Safety
The instrument is designed to be completely safe when used with options and accessories supplied
by the manufacturer for use with the instrument.
Toxic Materials
The use of hazardous materials in the construction of this instrument has been minimized. During
normal operation it is not possible for the user to come into contact with any hazardous substance
which might be employed in the construction of the instrument. Care should, however, be exercised
during maintenance and the disposal of certain parts.
Repair and Maintenance
The instrument must be maintained either by the manufacturer or an accredited service agent. For
Michell Instruments’ contact information please go to www.michell.com.
Calibration
Refer to details in Section 3.2 regarding recalibration of the HygroSmart 17000XP interchangeable
sensor.
Safety Conformity
This product meets the essential protection requirements of the relevant EU standards and directives.

HygroSmart I7000XP User’s Manual
vi 97481 Issue 1, January 2015
Abbreviations
The following abbreviations are used in this manual:
A ampere
°C degrees Celsius
°F degrees Fahrenheit
mA milliampere
mm millimeter
m/sec meters per second
RH relative humidity
s second
T temperature
V volt
Warnings
The following general warning listed below is applicable to this instrument. It is repeated
in the text in the appropriate locations.
Where this hazard warning symbol appears in the following
sections it is used to indicate areas where potentially hazardous
operations need to be carried out.
Where this symbol appears in the following sections it is used to
indicate areas of potential risk of electric shock.

HygroSmart I7000XP User’s Manual
Michell Instruments 1
INTRODUCTION
1 INTRODUCTION
The HygroSmart I7000XP sensor is designed to accurately and reliably measure
relative humidity and temperature in a wide spectrum of industrial and heavy industrial
applications.
The sensor incorporates the latest HygroSmart 3 technology, providing excellent
performance across a wide customer measurement range and giving rapid eld
interchangeability to minimize customer maintenance costs, on all Michell HygroSmart
based probes and transmitters.

HygroSmart I7000XP User’s Manual
297481 Issue 1, January 2015
INSTALLATION
2 INSTALLATION
2.1 Unpacking the Instrument
On delivery please check that all the following components are present in the packing
box:
• HygroSmart I7000XP interchangeable sensor
• Certicate of calibration
• User’s manual
2.2 Choice of the Site of Installation
The installation site choice for the sensor, or the transmitter which incorporates the
sensor, must be made bearing in mind the effectiveness of air circulation. The point at
which the sensor is installed must be typical of the surrounding environment where the
measurements of relative humidity are to be taken.
The following should be avoided in keeping with good instrumentation practice:
• Installation location not representative of measuring conditions
• Installation location adjacent to high power sources
The operating envelope of the measurement probe is detailed in the following operating
graph:
25
-40 0 5025 70 85
75
50
100
RH%
Temp °C
Maximum mixing ratio
250g water/kg dry air
Figure 1 Operating Graph

HygroSmart I7000XP User’s Manual
Michell Instruments 3
INSTALLATION
2.3 Connections
2.3.1 Electrical Connections
HygroSmart I7000XP
Pin
1Not Connected
2 Power Supply -
3 Power Supply +ve
4Output Voltage RH
5 Output Temperature PT100
6Output Temperature PT100
7Output Temperature PT100
PT100
5
1 2 3 4
6 7
PT1000
PT100
PT100
PT100
Figure 2 Electrical Connections
2.3.2 Power Supply
The power supply required to power the system is:
• 5 V DC ± 0.1 V

HygroSmart I7000XP User’s Manual
497481 Issue 1, January 2015
MAINTENANCE
3 MAINTENANCE
3.1 Replacing the HygroSmart I7000XP Interchangeable Sensor
Figure 3 HygroSmart I7000XP Sensor Pin Connector
The following steps should be taken to carry out the replacement of the HygroSmart
I7000XP sensor:
1. Switch off the power supply to the transmitter.
2. Unscrew the protection lter mounted on the measurement probe body.
NOTE: Be careful not to apply any force to the lter protection
cage.
3. Taking care not to bend the male pins on the sensor electrical connector,
remove the HygroSmart I7000XP to be replaced and insert the new
component.
3.2 Recalibration Service
The HygroSmart I7000XP interchangeable sensor can be returned to any Michell Service
Center (see www.michell.com for details) for recalibration. Alternatively, an optical
advanced RH & temperature calibration system can be provided for on-site recalibration.

HygroSmart I7000XP User’s Manual
Michell Instruments 5
APPENDIX A
Appendix A
Technical Specications

HygroSmart I7000XP User’s Manual
697481 Issue 1, January 2015
APPENDIX A
Appendix A Technical Specications
Performance Specications
RH Measurement Range 0 to 100% RH
RH Accuracy at 23°C (73°F) ±1% RH (5 to 95% RH)
RH Resolution 0.1% RH
RH Measurement Response Time <10 seconds
RH Element & Hybrid Technology HygroSmart 3
RH Long Term Stability ±1% RH per year
Temperature Technology PT100 1/3 DIN
Temperature Measurement Range -40 to +85°C (-40 to +185°F)
Temperature Accuracy ±0.2°C
Temperature Resolution Innite
Electrical Specications
Output Signal White housing: 0-1 V
Black housing: 0.2-1 V
Temperature Output Signal Standard: 3-wire PT100
Optional: no output
Digital Output Signal I2C interface
Supply Voltage Range +5 V DC ±1 V
Power Consumption 300uA @ 5 V
Operating Specications
Operating Temperature -40 to +85°C (-40 to +185°F)
Storage Temperature -40 to +85°C (-40 to +185°F)
Mechanical Specications
Housing Material NORYL PPO UL94 V0
Dimensions L=33mm, ø14mm (L=1.3”, ø0.5”)
Weight 3g (0.1oz)
Electrical Connections 7 pins

HygroSmart I7000XP User’s Manual
Michell Instruments 7
APPENDIX A
A.1 Operating Conditions
25
-40 0 5025 70 85
75
50
100
RH%
Temp °C
Maximum mixing ratio
250g water/kg dry air
Figure 4 Hygrosmart I7000XP Operating Conditions
A.2 Dimensions
17.5mm
(0.69”)
12mm
(0.47”)
14mm
(0.55”)
33mm
(1.30”)
Figure 5 Hygrosmart I7000XP Dimensions

HygroSmart I7000XP User’s Manual
897481 Issue 1, January 2015
APPENDIX B
Appendix B
Quality, Recycling
& Warranty
Information

HygroSmart I7000XP User’s Manual
Michell Instruments 9
APPENDIX B
Appendix B Quality, Recycling & Warranty Information
B.1 Pressure Equipment Directive (PED) 97/23/EC
The above Directive has been implemented in United Kingdom Law by the Pressure Equipment
Regulations 1999.
The Regulations require that all pressure equipment and assemblies within the scope of the Pressure
Equipment Directive must be safe when placed on the market or put into service.
Michell Instruments’ products have been assessed and, as referenced against the Classication Charts
detailed in Annex II of the Directive, do not fall into the requirements for CE marking compliance
with the Pressure Equipment Directive.
Article 3, paragraph 3 states that any product containing a pressurized uid that does not qualify for
compliance should, nevertheless, be constructed with Sound Engineering Practice (SEP).
Michell Instruments attests here that its products have been designed, manufactured & tested to
assure safe operation, and in accordance with Sound Engineering Practices.
B.2 Recycling Policy
Michell Instruments is concerned with the protection of the environment. It is our commitment to
reduce and eliminate from our operations, wherever possible, the use of substances which may be
harmful to the environment. Similarly, we are increasingly using recyclable and/or recycled material
in our business and products wherever it is practical to do so.
To protect natural resources and to promote material reuse, please separate batteries from other
types of waste and recycle responsibly. If batteries are not properly disposed of, these substances
can cause harm to human health and the environment.
The product that you have purchased may contain recyclable and/or recycled parts and we will be
happy to provide you with information on these components if required. For further information
please see the following sections.
B.3 WEEE Compliance
Directive 2012/19/EU 4 July 2012 on Waste Electronic and Electrical Equipment (WEEE)
The Waste Electronic and Electrical Equipment (WEEE) Directive places rules upon European
manufacturers of electrical and electronic equipment. The directives’ aim is to reduce the impact
that electronic devices have on the environment.
Michell Instruments is in full compliance with the WEEE Directive and is registered with an approved
recycler (Registration No. WEE/JB0235YW) and treats the requirement of the directive and the
protection of the environment with the utmost importance. All Michell Instruments’ products are
appropriately marked indicating their requirement for recycling.
It may be required to return certain instruments for treatment at the end of their working life.
Feb 2013

HygroSmart I7000XP User’s Manual
10 97481 Issue 1, January 2015
APPENDIX B
B.4 RoHS2 Compliance
Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011
The Restriction of Hazardous Substances (RoHS) Directive places rules upon European manufacturers
of electrical and electronic equipment. The directives’ aim is to reduce the impact that electronic
devices have on the environment.
According to the EC Directive 2002/95/EC, Michell Instruments’ products qualify as Category 9,
Control and Monitoring Equipment. Under the 2002/95/EC Directive, Category 9 products are exempt
from compliance with the Directive.
However, the careful design of all Michell Instruments’ products takes into consideration the
requirements of the Directive and, wherever possible, compliance is achieved. All future products
will be developed entirely using compliant materials. Furthermore, Michell Instruments is taking
active steps to remove non-compliant materials and components from existing products wherever
these may occur. Presently, none of the non-compliant materials are known to occur in Michell
Instruments’ products.
The new Directive 2011/65/EU (RoHS2) entered into force on 21 July 2011 and required all Member
States to transpose the provisions into their respective national laws by 2 January 2013.
Under the provisions of the RoHS2 EU Directive 2011/65/EU (Article 3, [24]) denes ‘Control and
Monitoring Equipment’ specically as ‘monitoring and control instruments designed exclusively for
industrial or professional use’.
RoHS2 EU Directive 2011/65/EU states the closing date for compliance of any Control and Monitoring
Equipment product sold into the EU market place as 22nd July 2017.
However, the careful design policy of all Michell Instruments’ products continues to attain compliance
in the shortest practical timescales and strives to ensure that less than 0.1% of total mass per
product, of all non-compliant materials, appear within them. Michell Instruments continues to
monitor suppliers and material sources to ensure that compliance of goods provided is maintained.
January 2013
B.5 Warranty
Unless otherwise agreed, the Supplier warrants that, as from the date of delivery for a period of 12
months, the goods and all their component parts, where applicable, are free from any defects in
design, workmanship, construction or materials.
The Supplier warrants that the services undertaken shall be performed using reasonable skill and
care, and be of a quality conforming to generally accepted industry standards and practices.
Except as expressly stated, all warranties whether express or implied, by operation of law or
otherwise, are hereby excluded in relation to the goods and services to be provided by the Supplier.
All warranty services are provided on a return to base basis. Any transportation costs for the return
of a warranty claim shall reside with the Customer.

HygroSmart I7000XP User’s Manual
Michell Instruments 11
APPENDIX B
B.6 REACH Compliance
Regulation (EC) No. 1907/2006
Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH)
Michell Instruments is a manufacturer of moisture measurement and gas analysis instrumentation
and is a ‘downstream’ user of chemicals, as described by the EU Council Directive 76/769/EEC. The
products we supply are not raw chemical products (goods).
Under normal and reasonably foreseeable circumstances of application, the goods supplied to you
shall not contain or release any prohibited chemicals. No listed SVHC (Substances of Very High
Concern) appear within products manufactured by Michell Instruments. Therefore the 0.1% mass
per product, or total usage of 1 tonne/year, will never be exceeded. For these reasons we are neither
required by obligation for registration nor for the creation of material safety data sheets (MSDS) for
our products.
Our continued review of the SVHC Candidate List and latest additions is to ensure we remain
compliant.
Michell Instruments maintains a hazardous material register in which MSDS data sheets are collated,
and we will check that our suppliers will comply to REACH requirements for all materials and
substances we use in the processes of our manufacturing.
In the unlikely event that any chemicals of concern appear in our products in quantities greater than
0.1% of total mass per product we will immediately inform you by correspondence according to the
REACH Article 33 requirements. Our current appraisal is, however, that we do not expect or foresee
such an incidence.
January 2013
B.7 Calibration Facilities
Michell Instruments’ calibration facilities are among the most sophisticated in the world and have
been recognized for their excellence.
Traceability to the National Physical Laboratory (NPL) UK is achieved through our UKAS Accreditation
(Number 0179). This covers dew point over the range -90 to +90°C (-130 to +194°F) and also
Relative Humidity.
Dew-point calibrations are also traceable to the National Institute for Standards & Technology (NIST)
USA over the range -75 to +20°C (-103 to +68°F).
NOTE: Standard traceable calibration certicates for instruments and sensors are not
issued under our UKAS accreditation. UKAS certicates are usually to special order and
are clearly identied.

HygroSmart I7000XP User’s Manual
12 97481 Issue 1, January 2015
APPENDIX B
B.8 Return Policy
If a Michell Instruments’ product malfunctions within the warranty period, the following procedure
must be completed:
1. Notify a Michell Instruments’ distributor, giving full details of the problem, the
model variant and the serial number of the product.
2. If the nature of the problem indicates the need for factory service then the
instrument should be returned to Michell Instruments, carriage prepaid, preferably
in the original packaging, with a full description of the fault and the customer
contact information.
3. Upon receipt, Michell Instruments will evaluate the product to determine the cause
of the malfunction. Then, one of the following courses of action will be taken:
• If the fault is covered under the terms of the warranty, the instrument will
be repaired at no cost to the owner and returned.
• If Michell Instruments determines that the fault is not covered under the
terms of the warranty, or if the warranty has expired, an estimate for the
cost of the repairs, at standard rates, will be provided. Upon receipt of the
owner’s approval to proceed, the product will be repaired and returned.
B.9 Manufacturing Quality
Michell Instruments is registered with the British Standards Institute for Quality Assurance to:
BS EN ISO 9001: 2008
Rigorous procedures are performed at every stage of production to ensure that the materials of
construction, manufacturing, calibration and nal test procedures meet the requirements laid down
by our BSI approved Quality System.
Please contact Michell Instruments (www.michell.com) if the product does not arrive in perfect
working order.

HygroSmart I7000XP User’s Manual
Michell Instruments 13
APPENDIX C
Appendix C
Recommended Practices
in Humidity Measurements

HygroSmart I7000XP User’s Manual
14 97481 Issue 1, January 2015
APPENDIX C
Appendix C Recommended Practices in Humidity Measurements
The following text is reproduced with kind permission from the National Physical Laboratory. It is originally published in
the booklet, A Guide to the Measurement of Humidity.
Denition of Relative Humidity
Relative Humidity – The ratio of the actual vapor pressure to the saturation vapor pressure over a plane
liquid water surface at the same temperature, expressed as a percentage. This is commonly understood when
the term ‘X percent relative humidity’ is used.
For actual vapor pressure, e, and saturation vapor pressure, es
e
relative humidity (in %) = ––– x 100
es
USAGE: The phrase ‘relative humidity’ is commonly abbreviated RH although this is not a recognized
abbreviation. Values of relative humidity are commonly expressed in units of percent relative humidity (% RH).
Recommended practices in humidity measurements
General practical recommendations
• Where relative humidity is of interest, a direct measurement of relative humidity is usually
best. Where an absolute measure of humidity is needed, choose dew point, vapor pressure
or similar measurements.
• Establish the measurement requirements at the purchasing stage in order to have the
right instrument for the job.
• Allow hygrometers to equilibrate in any new environment. This is particularly necessary
after changes in temperature due to transportation or storage. Depending on the instrument
and on how great the change in conditions, this may require from only a few minutes to
many hours.
• Follow Michell Instruments’ care instructions for the instrument. Some instruments need
routine cleaning or other maintenance. Before using any solvent cleaner, check with Michell
Instruments that this will not harm the sensor or other materials of construction.
• Wherever possible, ensure that hygrometers are calibrated under the conditions of use,
i.e. at similar values of humidity and temperature, and (if relevant) in similar conditions of
pressure, airow, etc.
• Keep a record of calibrations and any adjustments to the hygrometer. This will show the
long-term stability of the instrument and allow the associated uncertainty to be assessed.
• Check instruments, if possible, at intervals between calibrations, by comparison with
another (stable) instrument, to monitor for long-term drift. Routine checks are also useful
before and after subjecting an instrument to transportation or other stress, which might
lead to a shift in its performance. Where the check is against two (or more) instruments
this is even better: not only does this add condence, but in the event of one instrument
drifting among a set of three, it can be seen which reading is most suspect.
• Cleanliness of the environment will affect different hygrometers in different ways. Dust
and airborne droplets should be avoided or ltered out if possible. Contaminants can come
from the most surprising sources, ordinary urban pollution, for example.
• The readings given by some types of hygrometer are sensitive to gas type. For any
Instrument which reads in terms of mass per unit volume, e.g. in grams per cubic metre,
it must be conrmed whether the calibration is valid for the gas in use.
• Avoid using instruments in direct sunlight or near any other source of heat, unless they
are suitably shielded to prevent measurement errors.
