MICRO-EPSILON thermoMETER CTL Series User manual

Operating Instructions
thermoMETER CTL
CTL
CTLF
CTLG
CTLM-1
CTLM-2
CTLM-3
CTLM-5
CTLC

MICRO-EPSILON
MESSTECHNIK
GmbH & Co. KG
Koenigbacher Str. 15
94496 Ortenburg / Germany
Tel. [phone] / 168-0
Fax [phone] / 168-90
e-mail [email protected]
www.micro-epsilon.com
Infrared sensor

thermoMETER CTL
Contents
1. Safety ........................................................................................................................................ 7
1.1 Symbols Used ................................................................................................................................................. 7
1.2 Warnings.......................................................................................................................................................... 7
1.3 Notes on CE Marking ...................................................................................................................................... 8
1.4 Intended Use ................................................................................................................................................... 9
1.5 Proper Environment......................................................................................................................................... 9
2. Laser Safety............................................................................................................................ 10
3. Technical Data ........................................................................................................................ 12
3.1 Functional Principle ....................................................................................................................................... 12
3.2 Sensor Models............................................................................................................................................... 13
3.3 General Specifications................................................................................................................................... 14
3.4 Electrical Specifications................................................................................................................................. 15
3.5 Measurement Specifications ........................................................................................................................ 16
3.5.1 CTL, CTLF Models........................................................................................................................ 16
3.5.2 CTLM-1 and CTLM-2 Models ...................................................................................................... 17
3.5.3 CTLM-3 Models ............................................................................................................................ 18
3.5.4 CTLM-5 Model .............................................................................................................................. 19
3.5.5 CTLC Models................................................................................................................................ 20
3.5.6 CTLG Models................................................................................................................................ 21
4. Delivery ................................................................................................................................... 22
4.1 Unpacking, Included in Delivery.................................................................................................................... 22
4.2 Storage .......................................................................................................................................................... 22
5. Optical Charts......................................................................................................................... 23
6. Mechanical Installation .......................................................................................................... 37
6.1 Sensor............................................................................................................................................................ 37
6.2 Controller ....................................................................................................................................................... 38
6.3 Mounting Bracket .......................................................................................................................................... 39

thermoMETER CTL
7. Electrical Installation.............................................................................................................. 40
7.1 Cable Connections ........................................................................................................................................ 40
7.1.1 Basic Version ................................................................................................................................ 40
7.1.2 Connector Version........................................................................................................................ 40
7.2 Power Supply................................................................................................................................................. 44
7.3 Cable Assembling.......................................................................................................................................... 45
7.4 Ground Connection ....................................................................................................................................... 46
7.4.1 CTLM-5, CTLM-1, CTLM-2, CTLM-3L, CTLM-3H, CTLM-3H1 to -3H3 Models ............................ 46
7.4.2 CTL, CTLF, CTLC-4, CTLC-2, CTLC-6, CTLG Models ................................................................. 47
7.5 Exchange of the Sensor ................................................................................................................................ 48
7.5.1 Entering of the Calibration Code.................................................................................................. 49
7.5.2 Exchange of the Sensor Cable .................................................................................................... 50
8. Outputs and Inputs................................................................................................................. 51
8.1 Analog Outputs.............................................................................................................................................. 51
8.1.1 Output Channel 1 ......................................................................................................................... 51
8.1.2 Output Channel 2 [only for CTL, CTLG] ...................................................................................... 51
8.2 Digital Interfaces ............................................................................................................................................ 52
8.2.1 USB Interface ............................................................................................................................... 53
8.2.1.1 Installation ................................................................................................................... 53
8.2.1.2 Driver Installation of Interface...................................................................................... 53
8.2.2 RS232 Interface ............................................................................................................................ 54
8.2.2.1 Installation ................................................................................................................... 54
8.2.2.2 Software Installation.................................................................................................... 54
8.2.3 RS485 Interface ............................................................................................................................ 55
8.2.3.1 Installation ................................................................................................................... 55
8.2.3.2 Sensor Installation....................................................................................................... 56
8.2.4 Profibus Interface ......................................................................................................................... 57
8.2.4.1 Installation ................................................................................................................... 57
8.2.4.2 Commissioning Profibus............................................................................................. 58
8.2.5 CAN BUS Interface ....................................................................................................................... 59
8.2.6 Modbus RTU................................................................................................................................. 62
8.2.6.1 Serial Interface Parameters......................................................................................... 62
8.2.6.2 Protocol ....................................................................................................................... 62
8.2.6.3 Installation Overview ................................................................................................... 62
8.2.6.4 Connection of More than one Device (Synchronisation) ........................................... 65
8.2.6.5 Overview of Digital Commands for Modbus RTU Digital Interfaces for CT and
CTLaser Sensors......................................................................................................... 65

thermoMETER CTL
8.2.7 Ethernet Interface ......................................................................................................................... 66
8.2.7.1 Installation ................................................................................................................... 66
8.2.7.2 Installation of the Ethernet Adapter in a Network ....................................................... 67
8.2.7.3 Deinstallation of an Ethernet Interface in a Network .................................................. 68
8.2.7.4 Direct Connection to a PC .......................................................................................... 71
8.2.7.5 Settings inside the CompactConnect Software.......................................................... 76
8.2.7.6 Resetting the Ethernet Adapter................................................................................... 77
8.3 Relays Outputs .............................................................................................................................................. 78
8.4 Functional Inputs ........................................................................................................................................... 79
8.5 Alarms ............................................................................................................................................................ 80
8.5.1 Output Channel 1 and 2 (Channel 2 on CTL, CTLG)................................................................... 80
8.5.2 Visual Alarms ................................................................................................................................ 80
8.5.3 Open-collector Output / AL2 ........................................................................................................ 81
9. Operation ................................................................................................................................ 82
9.1 Sensor Settings ............................................................................................................................................. 82
9.2 Explanation to the Menu Items...................................................................................................................... 85
9.3 Digital Command Set .................................................................................................................................... 87
9.4 Laser Sighting................................................................................................................................................ 88
9.5 Error Messages.............................................................................................................................................. 89
9.5.1 CTL, CTLF, CTLC-4, CTLC-2, CTLC-6, CTLG Models ................................................................. 89
9.5.2 CTLM-5, CTLM-1, CTLM-2, CTLM-3L, CTLM-3H, CTLM-3H1 bis -3H3 Models .......................... 89
10. Instructions for Operation...................................................................................................... 90
10.1 Cleaning......................................................................................................................................................... 90
11. CompactConnect Software.................................................................................................... 91
11.1 System Requirements ................................................................................................................................... 91
11.2 Main Features ................................................................................................................................................ 91
12. Communication Settings........................................................................................................ 92
12.1 Serial Interface ............................................................................................................................................... 92
12.2 Protocol.......................................................................................................................................................... 92
12.3 ASCII Protocol ............................................................................................................................................... 92
12.4 Saving of Parameter Settings........................................................................................................................ 93
13. Basics of Infrared Thermometry............................................................................................ 94

thermoMETER CTL
14. Emissivity................................................................................................................................ 95
14.1 Definition ........................................................................................................................................................ 95
14.2 Determination of Unknown Emissivity........................................................................................................... 95
14.3 Characteristic Emissivity................................................................................................................................ 96
15. Liability for Material Defects.................................................................................................. 97
16. Service, Repair ....................................................................................................................... 98
17. Decommissioning, Disposal .................................................................................................. 98
Appendix
A 1 Optional Accessories............................................................................................................. 99
A 1.1 Air Purge Collar.............................................................................................................................................. 99
A 1.2 Mounting Bracket ........................................................................................................................................ 100
A 1.3 Water Cooled Housing ................................................................................................................................ 101
A 1.4 High Temperature Cable.............................................................................................................................. 102
A 1.5 Rail Mount Adapter for Controller................................................................................................................ 102
A 2 Factory Settings ................................................................................................................... 103
A 3 Emissivity Table Metals........................................................................................................ 106
A 4 Emissivity Table Non Metals................................................................................................ 109
A 5 Smart Averaging................................................................................................................... 111

Page 7
Safety
thermoMETER CTL
1. Safety
System operation assumes knowledge of the operating instructions.
1.1 Symbols Used
The following symbols are used in these operating instructions.
Indicates a hazardous situation which, if not avoided, may result in minor or moder-
ate injury.
Indicates a situation that may result in property damage if not avoided.
Indicates a user action.
iIndicates a tip for users.
Measure Indicates hardware or a software button/menu.
1.2 Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Switch off the sensor for cleaning and maintenance.
Switch off the sensor for system maintenance and repair if the sensor is integrated into a system.
Caution - use of controls or adjustments or performance of procedures other than those specified may cause
harm.
Connect the power supply and the display/output device according to the safety regulations for electrical
equipment.
> Risk of injury
> Damage to or destruction of the sensor and/or controller
Avoid shocks and impacts to the sensor and the controller.
> Damage to or destruction of the sensor and/or controller

Page 8
Safety
thermoMETER CTL
The supply voltage must not exceed the specified limits.
> Damage to or destruction of the sensor and/or controller
Protect the sensor cable against damage.
> Destruction of the sensor, Failure of the measuring device
Do not kink the sensor cable and bend the sensor cable in tight radius. The minimum bending radius is
14 mm (static). A dynamic movement is not allowed.
> Damage to the sensor cable, failure of the measuring device
No solvent-based cleaning agents may have an effect on the sensor (neither for the optics nor the housing)
> Damage to or destruction of the sensor
Avoid static electricity and keep away from very strong EMF (electromagnetic fields) e.g. arc welders or
induction heaters.
> Damage to or destruction of the sensor
1.3 Notes on CE Marking
The following apply to the thermoMETER CTL:
- EU Directive 2004/108/EU
- EU Directive 2011/65/EU, “RoHS”, category 9
Products which carry the CE mark satisfy the requirements of the EU directives cited and the European
harmonized standards (EN) listed therein. The EU Declaration of conformity is available to the responsible
authorities according to the EU Directive, article 10, at:
MICRO-EPSILON MESSTECHNIK
GmbH & Co. KG
Koenigbacher Str. 15
94496 Ortenburg / Germany
The measuring system is designed for use in industrial environments and meets the requirements.

Page 9
Safety
thermoMETER CTL
1.4 Intended Use
- The thermoMETER CTL is designed for use in industrial and laboratory areas. It is used for non-contact
temperature measurement.
- The system must only be operated within the limits specified in the technical data, see 3.
- The system must be used in such a way that no persons are endangered or machines and other material
goods are damaged in the event of malfunction or total failure of the sensor.
- Take additional precautions for safety and damage prevention in case of for safety-related applications.
1.5 Proper Environment
- Protection class:
Sensor: IP 65 (NEMA 4)
Controller: IP 65 (NEMA 4)
- Ambient temperature:
Sensor 1: -20 ... +85 °C (-4 ... +185 °F), see also Chapter Measurement
Specification, see 3.3
Controller 2: 20 ... +85 °C (-4 ... +185 °F), see also Chapter Measurement
Specification, see 3.3
Avoid abrupt changes of the ambient temperature of both the sensor and the controller.
> Inaccurate measuring values
- Storage temperature:
Sensor: See also Chapter Measurement Specification, see 3.3
Controller: -40 ... +85 °C (-40 ... +185 °F)
- Humidity: 10 ... +95 %, non-condensing
1) The sensor can be used at ambient temperatures up to +85 °C without cooling. For applications, where
the ambient temperature can reach higher values, the usage of the optional water cooled housing, see Chap.
A 1.3, is recommended (ambient temperature up to +175 °C). The sensor should be equipped with the op-
tional high temperature cable (ambient temperature up to +180 °C), see A 1.4
2) With temperatures < 0 °C (+32 °F), display function is not guaranteed any more.

Page 10
Laser Safety
thermoMETER CTL
2. Laser Safety
The thermoMETER CTL sensors operate with a double laser sight with a wavelength of 635 nm (visible/red),
see 9.4. The sensors fall within laser class 2 (II). The maximum optical power is ≤ 1 mW.
i
Observe the laser protection regulations!
Although the laser output is low, directly looking into the laser beam must be avoided. Close your eyes or
immediately turn away if the laser beam hits the eye. The housing of the optical sensors may only be opened
by the manufacturer, see 15. For repair and service purposes, the sensor must always be sent to the manu-
facturer.
Lasers of class 2 (II) are not subject to notification and a laser protection officer is not required.
The following warning label must be attached to the cover (front side) of the controller housing.
THIS PRODUCT COMPLIES WITH
21 CFR 1040.10AND 1040.11
EXCEPT FOR CONFORMANCE
WITH IEC 60825-1 ED. 3.,
AS DESCRIBED IN LASER NOTICE NO. 56,
DATED MAY 8, 2019.
COMPLIES WITH 21 CFR 1040.10 AND
1040.11 EXCEPT FOR CONFORMANCE
WITH IEC 60825-1 ED. 3.,
AS DESCRIBED IN LASER NOTICE NO. 56,
DATED MAY 8, 2019.
LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER
< 1 mW / 500 - 650 nm
EN 60825 1: 2014
COMPLIES WITH 21 CFR 1040.10 AND
1040.11 EXCEPT FOR CONFORMANCE
WITH IEC 60825-1 ED. 3.,
AS DESCRIBED IN LASER NOTICE NO. 56,
DATED MAY 8, 2019.
LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER
< 1 mW / 500 - 650 nm
EN 60825 1: 2014
COMPLIES WITH 21 CFR 1040.10 AND
1040.11 EXCEPT FOR CONFORMANCE
WITH IEC 60825-1 ED. 3., AS
DESCRIBED IN LASER NOTICE NO. 56,
DATED MAY 8, 2019.
LASER LIGHT
DO NOT STARE INTO BEAM
CLASS 2 LASER
< 1 mW / 500 - 650 nm
EN 60825 1: 2014
Fig. 1 Laser warning sign and laser label
During operation of the sensor, the pertinent regulations according to IEC 60825-1 on “Safety of laser prod-
ucts” must be fully observed at all times. The sensor complies with all applicable laws for the manufacturer of
laser devices. Laser operation is indicated by LED.
Laser radiation.
Irritation or injury of the
eyes possible. Close
your eyes or immedi-
ately turn away if the
laser beam hits the eye.

Page 11
Laser Safety
thermoMETER CTL
Fig. 2 Controller with laser labels
iIf the warning label is covered over when the unit is installed, the user must ensure that supplementary
label is applied.

Page 12
Technical Data
thermoMETER CTL
3. Technical Data
3.1 Functional Principle
The sensors of the thermoMETER CTL series are non-contact measuring infrared temperature sensors. They
calculate the surface temperature based on the emitted infrared energy of objects, see Chap. 12. An inte-
grated double laser aiming marks the real measurement spot location and spot size at any distance on the
object surface.
The sensor housing of the thermoMETER CTL is made from stainless steel (protection class IP 65/ NEMA 4),
the controller is placed in a separate box made of die casting zinc.
i
The thermoMETER CTL sensor is a sensitive optical system. Please only use the thread for mechanical
installation.
Avoid mechanical violence on the sensor.
> Destruction of the system

Page 13
Technical Data
thermoMETER CTL
3.2 Sensor Models
Model Model codes Spectral response Typical applications
CTL -50 to 975 °C 8 - 14 μm Non-metallic surfaces
CTLF -50 to 975 °C 8 - 14 μm Fast processes
CTLM-1 485 to 2200 °C 1 μm Metals and ceramic surfaces
CTLM-2 250 to 2000 °C 1.6 μm Metals and ceramic surfaces
CTLM-3 50 to 1800 °C 2.3 μm Metals and composite materials at low object tempera-
tures (from 50 °C)
CTLG 100 to 1650 °C 5.0 μm Measurement of glass
CTLC-2
200 to 1450 °C
4.24 μm
Through flames and of CO2- / CO- flame gases
CTLC-4 3.9 μm
CTLC-6 4.64 μm
CTLM-05 100 to 2000 °C 525 nm Metals and ceramic surfaces
On the CTLM-1, CTLM-2 and CTLM-3 and CTLG models the whole measuring range is split into three sub
ranges (L, H and H1).

Page 14
Technical Data
thermoMETER CTL
3.3 General Specifications
Sensor Controller
Protection class IP 65 (NEMA-4)
Ambient temperature 1) -20 ... +85 °C (-4 ... +185 °F) (-20) 0 ... +85 °C
-4 (+32 °F ... +185 °F) 2
Storage temperature -40 ... +85 °C (-4 ... +185 °F)
Relative humidity 10 ... 95 %, non condensing
Material Stainless steel Zinc, cast
Dimensions 100 mm x 50 mm, M48x1.5 89 mm x 70 mm x 30 mm
Weight 600 g 420 g
Cable length 3 m (standard), 8 m, 15 m
Cable diameter 5 mm
Ambient temperature cable max. 105 °C (High temperature cable (optional): 180 °C)
Vibration IEC 68-2-6: 3 g, 11 – 200 Hz, any axis
Shock IEC 68-2-27: 50 g, 11 ms, any axis
Electromagnetic
compatibility (EMC)
EN 61326-1: 2006 / EN 61326-2-3: 2006 / EN 61010-1: 2010
1) Laser will turn off automatically at ambient temperatures > 50 °C.
2) Bei Temperaturen < 0 °C ist die Funktion des Displays nicht mehr gewährleistet.

Page 15
Technical Data
thermoMETER CTL
3.4 Electrical Specifications
Power supply 8 – 36 VDC
Power consumption Max. 160 mA
Aiming laser 635 nm, 1 mW, On/ Off via programming keys or software
Outputs/ analog
Channel 1 Selectable: 0/ 4 – 20 mA, 0 – 5/ 10 V, thermocouple
(J or K) or alarm output (signal source: Object temperature
Channel 2
(only CTL/CTLF/
CTLC/CTLG)
Sensor temperature [-20 ... 180 °C] as 0 – 5 V or
0 – 10 V respectively alarm output (signal source switch-
able to object temperature or controller temperature if
used as alarm output)
Alarm output Open collector output at Pin AL2 (24 V/ 50 mA)
Output impedances
mA max. loop resistance 500 Ω (at 8 - 36 VDC),
mV min. 100 KΩ load impedance
Thermocouple 20 Ω
Digital interfaces USB, RS232, RS485, CAN, Profibus DP, Ethernet
(via optional plug-in modules)
Relay output 2 x 60 VDC/ 42 VACRMS, 0.4 A; optically isolated
(optional plug-in module)
Functional inputs F1 to F3; software programmable for the following func-
tions:
- External emissivity adjustment,
- Ambient temperature compensation,
- Trigger (reset of hold functions)

Page 16
Technical Data
thermoMETER CTL
3.5 Measurement Specifications
3.5.1 CTL, CTLF Models
Model CTL CTLF
Temperature range (scalable) -50 ... 975 °C
Spectral range 8 ... 14 μm
Optical resolution 75:1 50:1
System accuracy 1 2 ±1 °C or ±1 % 3±1,5 °C or ±1,5 % 4
Repeatability 1±0.5 °C or ±0.5 % 3±1 °C or ±1 % 4
Temperature resolution (NETD) 0.1 °C 30.5 °C 4
Response time (90 % signal) 120 ms 9 ms
Warm-up time 10 min
Emissivity/ Gain 0.100 … 1.100 (adjustable via programming keys or software)
Transmissivity 0.100 … 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
Software CompactConnect
1) At ambient temperature 23 ±5 °C; whichever is greater.
2) Accuracy for thermocouple output: ±2.5 °C or ±1 %
3) At object temperatures > 0 °C
4) At object temperatures ≥ 20 °C

Page 17
Technical Data
thermoMETER CTL
3.5.2 CTLM-1 and CTLM-2 Models
Model M-1L M-1H M-1H1 M-2L M-2H M-2H1
Temperature range (scalable) 485/1050 °C 650/1800 °C 800/2200 °C 250/800 °C 385/1600 °C 490/2000 °C
Spectral range 1 μm 1.6 μm
Optical resolution 150:1 300:1 150:1 300:1
System accuracy 1 2 ±(0.3 % T of reading +2 °C) 3
Repeatability 1±(0.1 % T of reading +1 °C) 3
Temperature resolution (NETD) 0.1 °C
Exposure time (90 % signal) 1 ms 4
Emissivity/ Gain 0.100 … 1.100 (adjustable via programming keys or software)
Transmissivity 0.100 … 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
Software CompactConnect
1) At ambient temperature 23 ±5 °C; whichever is greater.
2) Accuracy for thermocouple output: ±2,5 °C or ±1 %
3) e= 1/ Response time 1 s
4) With dynamic adaptation at low signal levels

Page 18
Technical Data
thermoMETER CTL
3.5.3 CTLM-3 Models
Model M-3L M-3H M-3H1 M-3H2 M-3H3
Temperature range (scalable) 1 2 50/400 °C 100/600 °C 150/1000 °C 200/1500 °C 250/1800 °C
Spectral range 2.3 μm
Optical resolution 60:1 100:1 300:1
System accuracy 3 5 ±(0.3 % of reading +2 °C) 3
Repeatability 3±(0.1 % of reading +1 °C) 3
Temperature resolution (digital) 0.1 °C
Exposure time (90 % signal) 41 ms 4
Emissivity/ Gain 10.100…1.100 (adjustable via programming keys or software)
Transmissivity/ Gain 10.100…1.100 (adjustable via programming keys or software)
Signal processing 1Average, peak hold, valley hold
(adjustable via programming keys or software)
Software CompactConnect
1) Adjustable via controller or software
2) Target temperature > sensor temperature +25 °C
3) E = 1, response time 1 s; ambient temperature 23 ±5 °C
4) With dynamic adaptation at low signal levels
5) Accuracy for thermocouple output: ±2,5 °C or ±1 %

Page 19
Technical Data
thermoMETER CTL
3.5.4 CTLM-5 Model
Model M-5
Temperature range 11000/2000 °C
Spectral range 525 nm
Optical resolution 150:1
System accuracy 2 4 ±(0.3 % of reading +2 °C) 2
Repeatability 2±(0.1 % of reading +1 °C) 2
Temperature resolution 0.2 °C
Response time (90 % signal) 31 ms 3
Emissivity/ gain 10.100…1.100
Transmissivity/ gain 10.100…1.100
Signal processing 1Peak hold, valley hold, average; extended hold function with
threshold and hysteresis
Software CompactConnect
1) Adjustable via controller or software
2) E = 1, response time 1 s; ambient temperature 23 ±5 °C
3) With dynamic adaptation at low signal levels
4) Accuracy for thermocouple output: ±2,5 °C or ±1 %

Page 20
Technical Data
thermoMETER CTL
3.5.5 CTLC Models
Model C-2 6C-4 6C-6 6
Temperature range 1200/1450 °C
Spectral range 4.24 μm 3.9 μm 4.64 μm
Optical resolution 45:1
System accuracy 3 4 5 ±1 %
Repeatability 3±0.5 % or ±0.5 °C
Temperature resolution (digital) 0.1 °C
Response time (90 % signal) 210 ms
Emissivity/ gain 10.100…1.100
Transmissivity/ gain 10.100…1.100
Signal processing 1Peak hold, valley hold, average;
extended hold function with threshold and hysteresis
Software CompactConnect
1) Adjustable via programming keys or software
2) With dynamic adaptation at low signal levels
3) At ambient temperature 23 ±0.5 °C; whichever is greater; temperature of the object ≥ 0 °C
4) e = 1, response time 1 s
5) Accuracy for thermocouple output: ±2,5 °C or ±1 %
6) Models C-2, C-4, C-6 also known as H-models with 400 ... 1650 °C.
