La Crosse Technology, Ltd. Page 1
308-147 _L78601 FAQS
The links below will work in most PDF viewers and link to the topic area by clicking the
link. We recommend Adobe Reader version 10 or greater available at:
http://get.adobe.com/reader
CONTENTS
308-147 _L78601 FAQS ........................................................................................................ 1
Batteries .................................................................................................................................. 2
Temperature Station Factory Restart.......................................................................................... 2
Outdoor Temperature Transmitter ...................................................................................... 2
Compatible Outdoor Transmitters ........................................................................................... 2
Flashing Outdoor Temperature ............................................................................................... 3
Dashes shown for Outdoor Temperature ................................................................................ 3
Inaccurate Outdoor Temperature Reading.............................................................................. 3
Intermittent Outdoor Temperature ......................................................................................... 3
Outdoor Temperature Is Stuck or HHH or LLL ........................................................................ 4
HI/LO Temperature readings .................................................................................................. 4
Temperature Trend Arrows..................................................................................................... 4
Sensor Search......................................................................................................................... 4
Outdoor Transmitter Fell and No Longer Works...................................................................... 5
Outdoor Transmitter Drains Batteries Quickly ......................................................................... 5
Mounting/Positioning Outdoor Transmitter ............................................................................. 5
Distance/Resistance/Interference ........................................................................................... 6
Temperature station .............................................................................................................. 7
Power Requirements............................................................................................................... 7
Does the Temperature station Have a Backlight?.................................................................... 7
Manual Set Time..................................................................................................................... 7
Dashes, HHH, LLL, or Stuck Indoor Temperature ................................................................... 7
Inaccurate Indoor Temperature Reading ................................................................................ 8
Temperature station Has Missing Segments ........................................................................... 8
Temperature station Has Distorted Display
............................................................................. 8
Temperature station is Blank: No Letters, Numbers or Dashed Lines...................................... 8

La Crosse Technology, Ltd. Page 2
Batteries
•Half of all warranty issues can be resolved with fresh batteries of the appropriate
voltage.
•We suggest name brand alkaline batteries for indoor displays such as temperature
stations.
•Use batteries dated at least six years in advance of the current year. Batteries dated
earlier than six years from now may still work but may be unstable in performance.
•Alkaline batteries manufactured this year will have an expiration date 10 years in the
future. Battery technology has improved, and batteries will maintain voltage longer
in storage. However, the environment the batteries reside in for the 10 years can
deplete the power.
•Good name brand batteries make less noise, which reduces the chance of RF (radio
frequency) interference from the battery compartment. A minimum voltage of
1.48V for each battery is necessary for proper performance.
•Outdoor Transmitters: Use Alkaline batteries (or Lithium for temperatures below -
20°F/-28.8°C)
•Temperature station: Use Alkaline batteries. Overpowered or underpowered
batteries may cause loss of indoor readings, missing segments, dim display etc.
Temperature Station Factory Restart
•Remove all batteries from outdoor sensor and temperature station.
•Press one of the buttons on the temperature station at least 20 times to clear all
memory.
•Verify that the temperature station is blank before proceeding (there may be lines
painted on the screen).
•Leave both units without power for 15 minutes (very important).
•Insert fresh batteries into the outdoor sensor.
•Insert fresh batteries into the temperature station.
•Keep the outdoor sensor 5-10 feet from the temperature station.
•When RF connection is established, the temperature will appear on the station.
Allow the outdoor sensor and temperature station to sit together for 15 minutes to
establish a strong connection.
•Do not press buttons for 15 minutes.
•For optimum 433MHz transmission, the outdoor transmitter should be no more than
330 feet (100 meters, open air) from the Temperature station.
•See the section on mounting and distance/resistance/interference for details on
mounting the outdoor transmitter.
Outdoor Temperature Transmitter
Compatible Outdoor Transmitters
•A TX147 outdoor transmitter comes packaged with this Temperature station.

La Crosse Technology, Ltd. Page 3
Flashing Outdoor Temperature
•The outdoor Temperature reading will flash when the connection is first lost or
intermittent between the temperature station and the outdoor transmitter.
•Distance/Resistance is generally the cause of intermittent connection or loss of
connection between the transmitter and the temperature station.
•Check the position of the temperature station. Turn the temperature station 90
degrees towards the outdoor transmitter for better reception.
•Try the quick connect or factory restart.
•Batteries often resolve the connection issue.
Dashes shown for Outdoor Temperature
•Dashes means the connection is lost between the temperature station and the
outdoor transmitter.
•Batteries often resolve the connection.
•Distance/Resistance can cause loss of connection between the transmitter and the
temperature station.
•Reorientation of the temperature station 90 degrees towards the outdoor transmitter
may provide better reception.
•Try the quick connect or factory restart.
Inaccurate Outdoor Temperature Reading
•The outdoor transmitter reads the environment. When mounted in the home it will
read inside temperature.
•When the transmitter reads high during the day but not at night it is a positioning
problem.
•Side-by-side test: Bring the outdoor transmitter in the house and place it next to
the temperature station for 2 hours.
•Compare indoor and outdoor temperature. The temperatures should be within 4
degrees to be within tolerance. See the section on accuracy for details.
•If the transmitter reads correctly when next to the temperature station then try a
different location outside.
•Look for heat sources such as sunlight, door, or window frames, or reflected heat.
Intermittent Outdoor Temperature
•RF (radio frequency) communication may come and go occasionally. This can be
normal in some environments (e.g. moister climates). If transmitter signal is lost,
please wait 2-4 hours for the signal to reconnect on its own.
•Move the outdoor transmitter to a closer location.
•Freezer test: Confirm the temperature station is reading the correct outdoor
transmitter. Place the transmitter in the freezer for an hour and watch the
temperature drop on the temperature station.
•Indoor distance test: Please complete the restart with transmitter and
temperature station 5-10 feet apart and inside to establish a strong connection.

La Crosse Technology, Ltd. Page 4
•After 15 minutes if there is a reading in the outdoor temperature area, move the
transmitter to another room with one wall between the transmitter and the
temperature station. Observe to see if the Temperature remains on consistently for
1-hour.
•If the temperature remains on while in the house then it is likely a
distance/resistance issue. Move the transmitter to different locations outside to find
a location where the temperature reading will hold.
•Distance/Resistance can cause loss of transmitter signal.
•Check Batteries.
Outdoor Temperature Is Stuck or HHH or LLL
•The last outdoor reading may remain (not change) for several hours when
connection is lost.
•The outdoor temperature reading will flash when the connection is first lost or
intermittent between the temperature station and the outdoor transmitter.
•Check batteries. Overpowered or underpowered batteries can cause this reading.
•Replace outdoor transmitter.
HI/LO Temperature readings
From normal display, press and release the button to view HI then LO Temperature
records since midnight.
Reset HI | LO Readings:
•Press the button to view records
•Hold the button for five seconds to reset all records at one time.
•HI | LO readings will reset to current temperature.
Note: The unit will automatically reset daily temperature record on the 12:00AM
Temperature Trend Arrows
The temperature trend indicators will update every 15 minutes or less. These trends
represent temperature changes over the past three hours. Example: At 12:00 the
arrows will reflect the trend since 9:00. At 12:30 the arrows will indicate the trend
since 9:30.
•UP ARROW: Temperature rising more than 1°C/ 2°F in the past three hours
•DOWN ARROW: Temperature falling more than 1°C/ 2°F in the past three hours
Sensor Search
1. Hold the button to search for outdoor sensor.
2. Reception Icon will flash while searching and be solid when sensor signal is
received.
IF the signal is lost, the RX will display the LAST DATA recorded for 10 minutes, after that
10 mins if the signal does not come back then display dashes "--". After 30 minutes start
looking for the RF signal automatically.

La Crosse Technology, Ltd. Page 5
Outdoor Transmitter Fell and No Longer Works
•If there is no physical damage to the outdoor transmitter, the fall may not have
caused internal damage.
•An outdoor transmitter that has fallen into a puddle or other standing water or snow
may have water damage.
•Transmitters are water resistant, not waterproof.
•A fall can shock the transmitter or the batteries in the transmitter.
•Batteries that have fallen on a hard surface may be damaged and unable to function
properly.
•Complete a restart with fresh batteries.
•Use batteries dated at least six years in advance of the current year.
Outdoor Transmitter Drains Batteries Quickly
•Test a new set of alkaline batteries. Write down the date of installation and the
voltage of the batteries.
•When the batteries fail, please note the date and voltage again. This is helpful in
determining the problem.
•Check the distance and resistance between the transmitter and temperature station.
Transmitters at the end of the range may work while batteries are fresh but not
after they drain a bit.
•Check for leaking batteries, which may damage the transmitter.
Mounting/Positioning Outdoor Transmitter
•Mount outdoor temperature transmitters vertically and under a bit of an overhang.
•Protect the outdoor transmitter from standing rain or snow, and from the overhead
sun, which can cause it to read incorrectly. Generally, mounting under an eave or
deck rail works well.
•Construct a small roof or box for the transmitter if you do not have an overhang.
Please be sure the box is vented.
•Mount the transmitter on the North side to prevent sun from causing incorrect
readings.
•Mount at least 6 feet in the air for a strong signal.
•Outdoor transmitters are water resistant but not waterproof.
•Avoid more than one wall between the transmitter and the Temperature station.
•Do not mount near electrical wires, transmitting antennas or other items that will
interfere with the signal.
•RF (radio frequency) signals do not travel well through moisture or dirt.
•Place the outdoor transmitter and the Temperature station in the desired shaded
locations and wait approximately 1-hour before permanently mounting the
transmitter to ensure that there is proper reception.
•Do not mount the transmitter on a metal fence. This significantly reduces the
effective range.

La Crosse Technology, Ltd. Page 6
MOUNT
•Choose a location for the transmitter that is within range of the temperature station
and under an overhang for accuracy.
•Install one mounting screw into a wall leaving approximately ½ inch (12.7mm)
extended.
•Place the transmitter onto the screw, using the hanging hole on the backside.
•Gently pull the transmitter down to lock the screw into place.
Note: Always ensure that the transmitter locks onto the screw before releasing.
Distance/Resistance/Interference
Distance:
•The maximum transmitting range in open air is over 330-feet (100 meters)
between the outdoor transmitter and the temperature station.
•Consider what is in the signal path between the temperature station and the
transmitter.
•Consider the distance the temperature station is located away from other electronic
in the home.
Resistance:
•Obstacles such as walls, windows, stucco, concrete, and large metal objects can
reduce the range.
•When considering the distance between the transmitter and the temperature station
(330 feet open air) cut that distance in half for each wall, window, tree, bush, or
other obstruction in the signal path.
•Closer is better.
•Do not mount the transmitter on a metal fence. This significantly reduces the
effective range.
Interference:
•Consider items in the signal path between the transmitter and the temperature
station.
•Sometime a simple relocation of the transmitter or the temperature station will
correct the interference issue.
•Windows can reflect the radio signal.
•Metal will absorb the RF (radio frequency) signal.
•Stucco is held to the wall by a metal mesh.
•Transmitting antennas (ham radio, emergency dispatch center, airports, military
base etc.)
•Electrical wires (utilities, cable etc.)
•Vegetation is full of moisture and reduces signal.
•Dirt: Trying to receive a signal through a hill is difficult.

La Crosse Technology, Ltd. Page 7
Temperature station
Power Requirements
•2-AAA alkaline batteries power the temperature station
Does the Temperature station Have a Backlight?
•No, this temperature station does not have a backlight.
•Generally, an a/c power cord is required for products to have a backlight.
•This temperature station does not use a/c power cord.
Manual Set Time
1. Hold the button 3 seconds to enter settings mode.
2. Press the button to adjust the flashing values. Hold the button to adjust quickly.
3. Press the button to confirm adjustments and move to the next item or exit.
Settings order:
1. 12/24 Hour Time
2. Hour
3. Minutes
4. Fahrenheit/Celsius
SETTINGS:
1. Hold button. The 12Hr will flash Press the button to choose 24 hour time format.
2. Press to confirm and move to the hour. The HOUR will flash. Press the button to choose
the hour.
3. Press to confirm and move to the minutes. The MINUTES will flash. Press the button to
choose the minutes.
4. Press to confirm and move to select Fahrenheit or Celsius. The °Fwill flash. Press the
button if you prefer Celsius °C.
5. Press to confirm and exit.
Note: If no buttons are pressed in a 10 seconds period, set mode will time out and return to live
display mode, reflecting whatever adjustments were made by user before timed out
Dashes, HHH, LLL, or Stuck Indoor Temperature
•This is generally a power related issue.
•Batteries may be overpowered or underpowered. Remove batteries from
temperature station.
•Press any button 20 times. Leave the temperature station unpowered for 1-2 hours.
•Insert fresh alkaline batteries with correct polarity.
•If the indoor temperature is still dashes or LLL, the temperature station may need
replacement.

La Crosse Technology, Ltd. Page 8
Inaccurate Indoor Temperature Reading
•Side-by-side test: Bring the outdoor transmitter in the house and place it next to
the temperature station for 2 hours.
•Compare indoor and outdoor temperature. The temperature should be within 4
degrees to be within tolerance. See the section on accuracy for details.
•Look for heat sources such as sunlight, door, or window frames, or reflected heat of
cold.
Temperature station Has Missing Segments
•This is generally a power related issue.
•Batteries may be overpowered or underpowered. Remove batteries from
temperature station.
•Press any button 20 times. Leave the temperature station unpowered for 1-2 hours.
•Insert fresh alkaline batteries with correct polarity.
Temperature station Has Distorted Display
•On a brand new temperature station, check for thin plastic films of printed scratch
guard that may be on the upper and lower screen of the temperature station. This
thin piece of plastic has printed numbers for store displays.
•This film will be easy to peel off the LCD.
•With all power removed the temperature station should be blank.
•If numbers still appear, please check for scratch guard.
•Check that the batteries are installed correctly.
•This is generally a power related issue.
•Batteries may be overpowered or underpowered. Remove batteries from the
temperature station.
•Press any button 20 times. Leave the batteries out of the display for 2 hours.
•Insert fresh alkaline batteries into the temperature station.
Temperature station is Blank: No Letters, Numbers or Dashed Lines
•Check that the batteries are installed correctly.
•Batteries may be overpowered or underpowered. Remove batteries from
temperature station.
•Press any button 20 times. Leave the batteries out of the display for 2 hours.
•Insert fresh alkaline batteries into the temperature station.
