16-Bit Sigma-Delta
A/D Converter
66
Section 66. 16-Bit Sigma-Delta A/D Converter
HIGHLIGHTS
This section of the manual contains the following major topics:
66.1 Introduction .................................................................................................................66-2
66.2 Registers.....................................................................................................................66-4
66.3 SD A/D Module Configuration.....................................................................................66-8
66.4 Interrupt Modes.........................................................................................................66-14
66.5 Offset Calibration ......................................................................................................66-14
66.6 Gain Error Calibration ...............................................................................................66-15
66.7 Operation During Sleep and Idle Modes...................................................................66-21
66.8 Effects of a Reset......................................................................................................66-21
66.9 Register Map.............................................................................................................66-22
66.10 Design Tips ...............................................................................................................66-23
66.11 Related Application Notes.........................................................................................66-24
66.12 Revision History........................................................................................................66-25

PIC24F Family Reference Manual
DS30687A-page 66-2 © 2013 Microchip Technology Inc.
66.1 INTRODUCTION
The PIC24F 16-bit Sigma-Delta Analog-to-Digital (SD A/D) Converter has the following key
features:
• Sigma-Delta Conversion
• Programmable Data Rate up to 62.5 ksps
• Differential inputs with Gain Settings
• Dithering Option and Adjustable Oversampling Ratios
• Independent Module Reset Option
The SD A/D Converter module accepts the analog signal and converts it to a corresponding
digital value. The 16-bit SD A/D Converter can have up to eight differential analog inputs
(channels). Some of the channels can be configured as single-ended inputs or can be used for
the external voltage reference connection. The actual number of analog inputs and the external
voltage reference input configuration can vary withthe device. For more informationon the actual
number and type of channels available in the device, refer to the specific device data sheet.
The SD A/D Converter contains the following sections:
• Analog Input Selection
• Output Buffer
• Timing and Control Functions
The 16-bit SD A/D Converter samples an input signal less than Nyquist Frequency. The analog
input multiplexer selects the signal to be converted from multiple analog input pins. The
differential analog input signal can be positive or negative (i.e., bipolar). The sampled voltage is
converted to a digital value, which represents the ratio of input voltage to a reference voltage.
The reference voltages can be configured to either external references or SVDD and SVSS.
The input signal can be amplified up to 32 times using the gain settings. Dithering averages the
nonlinearity of the Digital-to-Analog Converter (DAC) and thereby reduces harmonic distortion.
The bandwidth of the input amplifier can be selected using the power level option.
A simplified block diagram for the SD A/D Converter is shown in Figure 66-1.
Note: The Nyquist Frequency is half the sampling frequency of the SD A/D Converter.

© 2013 Microchip Technology Inc. DS30687A-page 66-3
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Figure 66-1: 16-Bit Sigma-Delta A/D Converter Block Diagram
CH1+
CHn+
Clock
Generation
SINC3
PGA Modulator
SVREF-
VREF-
-
Filter/Sample
Control and
Interrupt Logic
SDAxIF
SDxRESH
SDxRESL
Low-Pass
Primary OSC
FRC
FcY
DITHER<1:0>
SDGAIN<2:0>
SDDIV<2:0>
SDCS<1:0>
FILTDIS
SDINT<1:0>
SDWM<1:0>
RNDRES<1:0>
Filter
CH0-
CH1-
CHn-
VREF-
SDCH<2:0>(1)
SVSS
SDREFN
SVREF+
SVDD
VREF+
SDREFP
CH0+
VREF+
Note 1: Refer to the specific device data sheet for more information on the actual number and type of channels available.
—
—
–
+

PIC24F Family Reference Manual
DS30687A-page 66-4 © 2013 Microchip Technology Inc.
66.2 REGISTERS
The 16-bit SD A/D Converter uses five registers for its operation:
• SDxCON1: SD A/Dx Control Register 1
• SDxCON2: SD A/Dx Control Register 2
• SDxCON3: SD A/Dx Control Register 3
• SDxRESH: SD A/Dx Result Register High Word
• SDxRESL: SD A/Dx Result Register Low Word
All registers are mapped in the data memory space. The SDxCON1, SDxCON2 and SDxCON3
registers (Register 66-1, Register 66-2 and Register 66-3) control the overall operation of the SD
A/D module. This includes enabling the module, configuring the conversion clock and voltage
reference sources, setting dithering scheme, gain of the input amplifier, oversampling frequency
and so on.

© 2013 Microchip Technology Inc. DS30687A-page 66-5
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Register 66-1: SDxCON1: SD A/Dx Control Register 1
R/W-0 U-0 R/W-0 R/W-0 r-0 R/W-0 R/W-0 R/W-0
SDON — SDSIDL SDRST r SDGAIN2 SDGAIN1 SDGAIN0
bit 15 bit 8
R/W-0 R/W-0 U-0 R/W-0 U-0 R/W-0 R/W-0 R/W-0
DITHER1 DITHER0 —VOSCAL— SDREFN SDREFP PWRLVL
bit 7 bit 0
Legend: r = Reserved bit
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15 SDON: SD A/D Module Enable bit
1= Sigma-Delta A/D module is enabled
0= Sigma-Delta A/D module is disabled
bit 14 Unimplemented: Read as ‘0’
bit 13 SDSIDL: SD A/D Stop in Idle Mode bit
1= Discontinues module operation when device enters Idle mode
0= Continues module operation in Idle mode
bit 12 SDRST: SD A/D Reset bit
1= Resets all SD A/D module circuitry (analog section remains in Reset as long as SDRST bit is set)
0= Releases from Reset (Run mode)
bit 11 Reserved: Always maintain as ‘0’ for proper A/D operation
bit 10-8 SDGAIN<2:0>: SD A/D Gain Control bits
11x = Reserved; do not use
101 = 1:32
100 = 1:16
011 = 1:8
010 = 1:4
001 = 1:2
000 = 1:1
bit 7-6 DITHER<1:0>: Dithering Mode Select bits
11 = High Dither mode (preferred with higher Oversampling Ratio (OSR) and positive reference
below SVDD)
10 = Medium Dither mode (preferred for low-to-medium OSR and positive reference below SVDD)
01 = Low Dither mode (preferred when the positive reference is at or near SVDD)
00 = No Dither mode
bit 5 Unimplemented: Read as ‘0’
bit 4 VOSCAL: Internal Offset Measurement Enable bit
1= Converter is configured to sample its own internal offset error
0= Converter is configured for normal operation
bit 3 Unimplemented: Read as ‘0’
bit 2 SDREFN: SD A/D Negative Voltage Reference Configuration bit
1= SVREF- pin
0= SVSS
bit 1 SDREFP: SD A/D Positive Voltage Reference Configuration bit
1= SVREF+ pin
0= SVDD
bit 0 PWRLVL: Analog Amplifier Bandwidth Select bit
1= 2x bandwidth (higher power consumption compared to normal bandwidth)
0= Normal bandwidth

PIC24F Family Reference Manual
DS30687A-page 66-6 © 2013 Microchip Technology Inc.
Register 66-2: SDxCON2: SD A/Dx Control Register 2
R/W-0 R/W-0 R/W-0 R/W-0 U-0 U-0 R/W-0 R/W-0
CHOP1 CHOP0 SDINT1 SDINT0 ——SDWM1SDWM0
bit 15 bit 8
U-0 U-0 U-0 R/W-0 R/W-0 U-0 U-0 HS/C-0
— — — RNDRES1 RNDRES0 —— SDRDY
bit 7 bit 0
Legend: HS = Hardware Settable bit C = Clearable bit
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-14 CHOP<1:0>: Amplifier Chopping Enable bits
11 = Chopping is enabled
10 = Reserved
01 = Reserved
00 = Chopping is disabled
bit 13-12 SDINT<1:0>: SD A/D Interrupt Event Generation Select bits
11 = Interrupt on every data output
10 = Interrupt on every fifth data output
01 = Interrupt when the new result is less than the old result
00 = Interrupt when the new result is greater than the old result
bit 11-10 Unimplemented: Read as ‘0’
bit 9-8 SDWM<1:0>: SD A/D Output Result Register Write Mode bits
11 = Reserved; do not use
10 = SDxRESH/SDxRESL are never updated (used for > or < threshold compare)
01 = SDxRESH/SDxRESL are updated on every interrupt
00 = SDxRESH/SDxRESL are updated on every interrupt after SDRDY is cleared to ‘0’ by the software
bit 7-5 Unimplemented: Read as ‘0’
bit 4-3 RNDRES<1:0>: Round Data Control bits
11 = Round result to 8 bits
10 = Round result to 16 bits
01 = Round result to 24 bits
00 = No Rounding (32 bits)
bit 2-1 Unimplemented: Read as ‘0’
bit 0 SDRDY: SD A/D Filter Data Ready bit (set by hardware)
1= SINC filter delay is satisfied (clear this bit in software)
0= SINC filter delay is not satisfied

© 2013 Microchip Technology Inc. DS30687A-page 66-7
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Register 66-3: SDxCON3: SD A/Dx Control Register 3
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
SDDIV2(1)SDDIV1(1)SDDIV0(1)SDOSR2 SDOSR1 SDOSR0 SDCS1 SDCS0
bit 15 bit 8
U-0 U-0 U-0 U-0 U-0 R/W-0 R/W-0 R/W-0
— — — — — SDCH2(3)SDCH1(3)SDCH0(3)
bit 7 bit 0
Legend:
R = Readable bit W = Writable bit U = Unimplemented bit, read as ‘0’
-n = Value at POR ‘1’ = Bit is set ‘0’ = Bit is cleared x = Bit is unknown
bit 15-13 SDDIV<2:0>: SD A/D Input Clock Divider/Postscaler Ratio bits(1)
111 = Reserved
110 = 64
101 = 32
100 = 16
011 = 8
010 = 4
001 = 2
000 = 1 (No divider, clock selected by SDCS<1:0> is provided directly to A/D)
bit 12-10 SDOSR<2:0>: SD A/D Oversampling Ratio (OSR) Selection bits
111 = Reserved
110 = 16 (fastest conversion results, low quality)
101 = 32
100 = 64
011 = 128
010 = 256
001 = 512
000 = 1024 (slowest conversion results, best quality)
bit 9-8 SDCS<1:0>: SD A/D Clock Source Select bits
11 = Reserved
10 = Primary Oscillator (OSCI/CLKI)
01 = FRC (8 MHz)(2)
00 = System clock (FOSC/2)
bit 7-3 Unimplemented: Read as ‘0’
bit 2-0 SDCH<2:0>: SD A/D Analog Channel Input Select bits(3)
Note 1: To avoid overclocking or underclocking the module, set SDDIV<2:0> to obtain an A/D clock frequency
(input frequency selected by SDCS<1:0> is divided by the SDDIVx postscaler) at or between 1 MHz and
4 MHz.
2: The 8 MHz FRC output is used directly, prior to the FRCDIV<2:0> postscaler.
3: Refer to the specific device data sheet for more information on the actual number and type of channels
available.

PIC24F Family Reference Manual
DS30687A-page 66-8 © 2013 Microchip Technology Inc.
66.3 SD A/D MODULE CONFIGURATION
All of theregisters described in the previous sectionmust be configured for the module operation.
The various configuration and control functions of the module are distributed throughout the
module’s three control registers. Control functions can be sorted into four groups: input, timing,
conversion and output. Table 66-1 shows the location of the control or status bits by register.
The following steps should be followed for performing an SD A/D conversion.
1. Configure the SD A/D module:
a) Select the power level
b) Select thevoltage reference source tomatch the expected range on theanaloginputs
c) Set the dither value
d) Set the gain
e) Select the output resolution
f) Select the Data Overwrite mode
g) Select the Chopping Clock mode
h) Select the input channel
i) Select the SD A/D module clock source
j) Select the desired output data rate
k) Select the sampling frequency
2. Configure the SD A/D interrupt (if required):
a) Select the Interrupt mode
b) Clear the SDAxIF bit
c) Select the SD A/D interrupt priority
3. Turn on the SD A/D module.
The options for each configuration step aredescribed in the subsequent sections. Example 66-1
shows the possible initialization sequence.
Table 66-1: SD A/D Module Functions by Registers and Bits
SD A/D
Function Register(s) Specific Bits
Input SDxCON1 PWRLVL, SDREFP, SDREFN, VOSCAL, DITHER<1:0>,
SDGAIN<2:0>
SDxCON2 CHOP<1:0>
SDxCON3 SDCH<2:0>
Timing SDxCON3 SDCS<1:0>, SDDIV<2:0>
Conversion SDxCON1 SDON, SDSIDL
SDxCON2 SDINT<1:0>
Output SDxCON2 RNDRES<1:0>, SDWM<1:0>
SDxCON3 SDOSR<2:0>

© 2013 Microchip Technology Inc. DS30687A-page 66-9
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Example 66-1: Channel Measurement
66.3.1 Selecting the Voltage Reference Source
The voltage references for SD A/D conversions are selected using the SDREFN and SDREFP
control bits (SDxCON1<2:1>). The upper voltage reference (VREF+) can be SVDD or the voltage
applied on the SVREF+ pin. The lower voltage reference (VREF-) can be SVSS or the voltage
applied on the SVREF- pin.
signed short int count;
signed short int result;
// Configure the SD A/D module
SD1CON1bits.PWRLVL = 0; // Low power, normal bandwidth
SD1CON1bits.SDREFP = 0; // Positive Voltage Reference is SVDD
SD1CON1bits.SDREFN = 0; // Negative Voltage Reference is SVSS
SD1CON1bits.VOSCAL = 0; // Internal Offset Measurement is disabled
SD1CON1bits.DITHER = 1; // Low Dither
SD1CON1bits.SDGAIN = 0; // Gain is 1:1
SD1CON2bits.RNDRES = 2; // Round result to 16-bit
SD1CON2bits.SDWM = 1; // SDxRESH/SDxRESL updated on every Interrupt
SD1CON2bits.CHOP = 3; // Chopping should be enabled
SD1CON3bits.SDCH = 0; // Channel 0 (see the specific device data sheet)
SD1CON3bits.SDCS = 1; // Clock Source is a 8 MHz FRC
SD1CON3bits.SDOSR = 0; // Oversampling Ratio (OSR) is 1024 (best quality)
SD1CON3bits.SDDIV = 1; // Input Clock Divider is 2 (SD ADC clock is 4MHz)
// Configure SD A/D interrupt
SD1CON2bits.SDINT = 3; // Interrupt on every data output
IFS6bits.SDA1IF = 0; // Clear interrupt flag
// Turn on the SD A/D module
SD1CON1bits.SDON = 1;
// Wait for a minimum of five interrupts to be generated. Need to throw at least
// the first four away when using interrupt every period option, since the
// low pass SINC filter needs to be flushed with new data when we change
// ADC channel or initialize the ADC.
for(count=0; count<8; count++)
{
//Clear interrupt flag.
IFS6bits.SDA1IF = 0;
//Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Channel #0 conversion result.
result = SD1RESH;

PIC24F Family Reference Manual
DS30687A-page 66-10 © 2013 Microchip Technology Inc.
66.3.2 Gain Control
The Programmable Gain Amplifier (PGA) block can be used to amplify very low signals, but the
differential input range of the SD A/Dmodule should not be exceeded to avoid a saturated output
result code. The PGA is controlled by the SDGAIN<2:0> bits in the SDxCON1 register.
Table 66-2 shows the PGA configuration settings.
66.3.2.1 SELECTION OF ANALOG AMPLIFIER BANDWIDTH
Setting the PWRLVL bit in the SDxCON1 register improves the bandwidth and response time of
the input amplifier, but at the cost of consuming more power. Smaller response time decreases
the settling error in amplifier stages, and thereby, improves harmonic distortions. The PWRLVL
bit can be cleared to save power.
66.3.3 Selecting the SD A/D Module Clock Source
The clock source to the SD A/D Converter (SDCLK) can be one of the following three possible
clocks:
• Primary Oscillator
•FRC(8MHz)
• System Clock (FCY)
The selection can be done using the SDCS<1:0> bits in the SDxCON3 register. The A/D
Converter source clock is divided inside of the module, as shown in Figure 66-2.
Figure 66-2: SD A/D Module Clocking Details
Table 66-2: PGA Configuration Setting
SDGAIN<2:0> Gain
(V/V) Gain (dB) Differential VIN Range (V)
000 1 0 ± |Reference|
001 2 6 ± (|Reference| /2)
010 4 12 ± (|Reference| /4)
011 8 18 ± (|Reference| /8)
100 16 24 ± (|Reference| /16)
101 32 30 ± (|Reference| /32)
SINC3
Low-Pass
Filter
SDOSR<2:0>
SDDIV<2:0>
Primary
Oscillator
FRC
FCY
SDCS<1:0>
1/4
SDxRESH
SDxRESHL
Sampling
Circuit
Modulator

- 
Prescaler
SDCLK
OSR Select

© 2013 Microchip Technology Inc. DS30687A-page 66-11
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
66.3.3.1 SELECTING THE SD A/D CONVERTER SAMPLING FREQUENCY AND
OUTPUT DATA RATE
The selected source clock (see SDCLK in Figure 66-2) is divided by the selected ratio deter-
mined by the SDDIV<2:0> bits in the SDxCON3 register. The resulting clock must be in the range
of 1 MHz to 4 MHz.
The module clock is further divided by the selected ratio determined by the SDOSR<2:0> bits in
the SDxCON3 register. The result is the rate at which the SD A/D outputs new data. To determine
the SDOSR<2:0> setting for the required output data rate, see Table 66-3.
Table 66-3: Data Rate Settings
Data Rate
(ksps) A/D Clock Frequency (MHz) SDOSR<2:0>
62.500 4 110
31.2500 4101
2110
15.6250 4100 2101
1110
7.8125 4011 2100
1101
3.90625 4010 2011
1100
1.953125 4001 2010
1011
0.9765625 4000 2001
1010
0.4883 2000
1001
0.2441 1 000

PIC24F Family Reference Manual
DS30687A-page 66-12 © 2013 Microchip Technology Inc.
66.3.4 Selection of Dither
Dithering helps in suppressing the Idle tones present in the SD A/D module. Dithering is the pro-
cess of intentionally adding a small error to the SD A/D feedback loop in order to “decorrelate”
the outputs and “break” the Idle tones’ behavior. The dithering process scrambles the Idle tones
into baseband whitenoise andensures that dynamic parameters (SNR, SINAD, THD, SFDR) are
less signal dependent.
The baseband white noise can then be filtered and averaged through the internally provided
hardware Oversampling Ratio (OSR) to achieve better result quality. It is therefore, generally
recommended to enable dithering in most applications. However, the optimum dithering setting
for a given application depends on the OSR selected and the relative voltage of the applied A/D
reference to the SVDD voltage.
The higher OSR settings(e.g., 128 to 1024) are better at averaging the baseband white noise intro-
duced by dithering. At the higher OSR settings, enabling dithering improves overall performance
and is recommended. At lower OSR settings (e.g., 16 to 64), the averaging is not as effective and
the extra noise injected by dithering can potentially decrease the SNR, even though it may help to
suppress Idle tones. At the very low OSR settings, this results in a performance trade-off, and in
some cases (at very low OSR), it may be preferable to disable dithering. The dithering can be
enabled by the DITHER<1:0> bits in the SDxCON1 register.
66.3.5 Chop Clock Select Mode
Chopping Select bits (CHOP<1:0> bits in the SDxCON2 register) are mainly used to remove the
1/f noise from the signal band in the modulator. To obtain 16-bit resolution, chopping should
always be enabled.
66.3.6 SINC3Filter and Rounding of Result
The SD A/D module includes a decimation filter that is a third-order SINC (or notch) filter. This
filter processes the multibit stream into 8, 16, 24 or 32-bit words (depending on the
RNDRES<1:0> bits in the SDxCON2 register). The settling time of the filter is threedata rate peri-
ods. It is recommended to discard unsettled data. This can be done by polling the SDRDY bit in
the SDxCON2 register. The output of the SINC filter is padded with Least Significant zeros for
any resolution less than 32 bits.
66.3.7 Data Write Modes
The Write mode bits, SDWM<1:0> (SDxCON2) determine when the Result register is updated.
There are three options in Write mode:
• Result register is never updated (useful for the Threshold Compare feature)
• Result register is updated on every interrupt
• Result register is updated on every interrupt, after the SDRDY bit (SDxCON2<0>) is
cleared to ‘0’ in software
66.3.7.1 RESULT DATA READY
The conversion result value is valid only when the SDRDY bit (SDxCON2<0>) reads as ‘1’ and
the A/D module interrupt is generated. The SDRDY bit can only be cleared by software or on a
device Reset. If the user sets the SDWM<1:0> bits (SDxCON2<9:8>) to ‘00’, then the SD A/D
Converter does not update the Result register with the result until the SDRDY bit is cleared in
software.
If SDWM<1:0> = 01, then the SD A/D Converter updates the Result register, regardless of the
SDRDY bit.

© 2013 Microchip Technology Inc. DS30687A-page 66-13
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
66.3.7.2 SD A/D RESULT REGISTER
The SD A/D Converter result is stored in the SDxRESH:SDxRESL registers as a 32-bit
2’s complement signed number. When rounding is enabled (RNDRES<1:0> bits in the
SDxCON2 register), the Least Significant bits (LSbs) which are rounded off will read as ‘0’. Addi-
tionally, when operating the A/D at OSR values lessthan 1024, notenough data will be internally
generated by the hardware to fill all 32 bits of the SDxRESH/SDxRESL register pair. Therefore,
especially when operating at OSR values less than 1024, some of the LSbs will be fully mean-
ingless and may read back as static values. The Most Significant bits (MSbs) of the 32-bit result
will remain meaningful, but will be restricted by the result quality for a given OSR setting.
66.3.8 Input Channel Selection
The input analog channel can be selected using the SDCH<2:0> bits in the SDxCON3 register. The
SD A/D Converter comprises both single-ended and differential channels. The number of
single-ended and differential channels available is device-specific. For more information, refer to
the specific device data sheet. Each differential channel has inverting (CHn-) and non-inverting
inputs (CHn+). If any channel is not used, both CHn- and CHn+ should be connected to SVSS.
Single-ended channels are available as the positive input to the SD A/D Converter. The negative
input for these channels will always be SVSS. This performs a single-ended conversion on the
selected channel. When performing single-ended conversions, the A/D module still produces two’s
complement signed numbers. It is therefore possible for slightly negative number results to occur
due to offset error. The application firmware should check for negative results, and treat all negative
numbers as ‘0’, if true unsigned single-ended behavior is desired. The module also facilitates a
dedicated differential channel used for gain error measurements. For more information on gain
error measurements, see Section 66.6 “Gain Error Calibration”.
66.3.9 Channel Switching
When the channel is switched, five data rate clocks are required to flush the previous contents
from the SINC3filter (low-pass filter). During this time, the results generated may not be valid.
The results can have residual voltage information from the previous selected channel due to the
low-pass filtering effect of the SINC filter. Therefore, it is recommended to select an interrupt on
every fifth data output by setting the SDINT<1:0> bits to ‘10’, and upon first interrupt, the required
interrupt can be selected.
66.3.10 Enabling the Module
The SD A/D is enabled by setting the SDON bit (SDxCON1<15>) to ‘1’. After SDON is set to ‘1’,
the module requires a power-up analog settling time of about 10 µs, during which time, the A/D
Converter may not generate accurate results. The application firmware should therefore throw
away the initial results associated with the analog settling time and the time it takes to flush the
low-pass SINC filter with new data. When SDON is set to ‘0’, the module is disabled; the digital
and analog portions of the module are turned off for maximum current savings.
The module should be configured to the required settings and the SDRDY bit (SDxCON2<0>)
should be cleared before turning on the SD A/D.
Note: When the module is enabled (SDON = 1), the firmware may change the channel
selection (SDCH<2:0> or VOSCAL bit settings). If other A/D module settings must
be changed, the module should be disabled first (SDON = 0).

PIC24F Family Reference Manual
DS30687A-page 66-14 © 2013 Microchip Technology Inc.
66.4 INTERRUPT MODES
There are four Interrupt modes:
• Interrupt on Every Data Ready mode
• Interrupt on every Fifth Data Ready mode
• Interrupt on Threshold Current Value Lesser than the Previous Value mode
• Interrupt on Threshold Current Value Greater than the Previous Value mode
The four modes are controlled by the SDINT<1:0> bits in the SDxCON2 register.
66.4.1 Interrupt on Every Data Ready
This mode is useful after the first data is read. Note that the frequency of the data rate clock must
be less than FCY/2 to avoid missing the samples.
66.4.2 Interrupt on Every Fifth Data Ready
This mode is useful immediately after the module is enabled, when the input channel is switched
or when the device wakes up from Sleep. The module takes five data rate clocks for flushing old
values from the SINC3filter.
66.4.3 Interrupt on Threshold Compare
The SDINT<1:0> bits allow the user to have interrupts, only if the data coming out of the filter is
greater than, or less than, the value currently in the Result register. If the user wishes to retain
the threshold value, the SDWM<1:0> bits must be set to ‘10’. If SDWM<1:0> are set to ‘01’ or
‘00’, the threshold compare function turns into a “find the lowest/highest sampled value” type of
operation.
66.5 OFFSET CALIBRATION
The SD A/D module includes a feature for measuring internal offset error. Application firmware
can enable this feature by fully configuring the A/D module and setting the VOSCAL bit in the
SDxCON1 register.
When the VOSCAL bitis set, the A/D module ignores the currently selected SDCH<2:0> channel
select bits, and instead, performs conversions on an internal channel that generates
SDxRESH/SDxRESL results which represent the offset error of the A/D Converter. After the
SINC filter delay has been satisfied, the application firmware should save the result value (which
will be formatted as a signed two’s complement value, the same as normal A/D module results).
After the offset error measurement resultdata has beensaved, the application firmware canclear
the VOSCAL bit to switch the A/D module back into Normal Channel Measurement mode.
The application firmware can then correct for offset error in subsequent analog channel
measurements by subtracting the offset error value from all future results. Equation 66-1 shows
the method for correcting offset error.
Equation 66-1: Correcting Offset Error
Example 66-2 shows a example C code for the offset calibration.
Offset Corrected Result = (New SDxRES Result) – (VOSCAL Result)

© 2013 Microchip Technology Inc. DS30687A-page 66-15
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
66.6 GAIN ERROR CALIBRATION
The SD A/D module has a dedicated channel for gain error measurements. Selecting this
channel allows the module to internally sample the reference voltages as an input to the A/D
Converter. In theory, if the A/D module has no offset or gain error, this always generates an
SDxRESH result of 32767 (maximum full-scale value). In practice, it is normal for a real world
Sigma-Delta A/D to have a significant, but highly correctable, gain error. In this design, the A/D
Converter has a gain error, which will cause the A/D Converter to generate a result that is some-
what less than the theoretical 32767 full-scale result value. Gain error varies depending on the
SDGAIN<2:0> bits (SDxCON1<10:8>) selection, and some part, to part variations. Equation 66-2
shows the method for calculating a floating-point “gain error correction factor”, which can be
multiplied against subsequent result values to compensate for gain error.
Equation 66-2: Gain Error Correction Factor
Example 66-2 shows the process to perform a channel measurement, which uses offset correction
and gain error correction to compute a fully calibrated result value.
66.6.1 Considerations for Gain Error
The following needs to be considered for gain error correction:
1. Gain error of the A/D Converter can be measured by intentionally inputting a well-known
analog voltage and comparing the output resultcode with the theoretically expected result
code.
2. If the VREF+/VREF- reference sources are measured (with a gain setting of 1), the result
code should theoretically be full scale (e.g., 32767).
3. Due to the internal gain error of the A/D design, the actual value will be less than full scale.
4. A floating-point gain error correction factor can be computed using the raw A/D Converter
result (e.g., when measuring the references) and the expected result, as shown in
Example 66-2.
5. Once the gain error correction factor is known, it can be saved in the firmware. While
carrying out A/D Converter measurements on other channels/input voltage sources, the
gain error correction factor can be multiplied by the raw result (after offset correction
through VOSCAL) to compensate for the A/D Converter gain error.
Legend:
GECF = Floating-point gain error correction factor
ADRESEXPECTED = The expected A/D result (with no offset or gain error) based on the
applied input voltage. When the A/D is configured to measure the references in 1x Gain
mode, the expected result is 32767.
ADRESRAW = The raw, uncorrected 16-bit signed result read from the SDxRESH register.
ADRESVOSCAL = The 16-bit value representing the offset error measured with the A/D
“VOSCAL” feature.
GECF ADRESEXPECTED
ADRESRAW ADRESVOSCAL –
---------------------------------------------------------------------------=

PIC24F Family Reference Manual
DS30687A-page 66-16 © 2013 Microchip Technology Inc.
Example 66-2: Channel Conversion with Offset and Gain Correction
unsigned char count;
signed short int offset;
signed long int maxValue;
const double expectedMaxValue = 32767; // 0x7FFF
double gain;
signed long int channelValue;
double calibratedResult;
// ADC initialization.
SD1CON1bits.PWRLVL = 0; // Low power, normal bandwidth
SD1CON1bits.SDREFP = 0; // Positive Voltage Reference is SVDD
SD1CON1bits.SDREFN = 0; // Negative Voltage Reference is SVSS
SD1CON1bits.VOSCAL = 1; // Internal Offset Measurement Enable
SD1CON1bits.DITHER = 1; // Low Dither
SD1CON1bits.SDGAIN = 0; // Gain is 1:1
SD1CON2bits.RNDRES = 2; // Round result to 16-bit
SD1CON2bits.SDWM = 1; // SDxRESH/SDxRESL updated on every Interrupt
SD1CON2bits.SDINT = 3; // Interrupt on every data output
SD1CON2bits.CHOP = 3; // Chopping should be enabled
SD1CON3bits.SDCH = 0; // Channel 0 (see the specific device data sheet)
SD1CON3bits.SDCS = 1; // Clock Source is a 8 MHz FRC
SD1CON3bits.SDOSR = 0; // Oversampling Ratio (OSR) is 1024 (best quality)
SD1CON3bits.SDDIV = 1; // Input Clock Divider is 2 (SD ADC clock is 4MHz)
// Enable ADC.
SD1CON1bits.SDON = 1;
// Wait for a minimum of five interrupts to be generated. Need to throw at least
// the first four away when using interrupt every period option, since the
// low pass SINC filter needs to be flushed with new data when we change
// ADC channel or initialize the ADC.
for(count=0; count<8; count++)
{
//Clear interrupt flag.
IFS6bits.SDA1IF = 0;
//Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Save the initial VOSCAL offset value from the ADC.
// This value will be used to correct the offset error for all
// subsequent ADC measurements.
offset = SD1RESH;
// Configure ADC for normal operation.
SD1CON1bits.VOSCAL = 0;
// Measures the reference selected by SDREFP/SDREFN
// (see the specific device data sheet).
SD1CON3bits.SDCH = 3;

© 2013 Microchip Technology Inc. DS30687A-page 66-17
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Example 66-2: Channel Conversion with Offset and Gain Correction (Continued)
// Wait for a minimum of five interrupts to be generated.
for(count=0; count<8; count++)
{
//Clear interrupt flag.
IFS6bits.SDA1IF = 0;
//Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Save the maximum value to calculate the gain.
maxValue = (signed short int) SD1RESH;
// Calculate gain.
gain = expectedMaxValue/((double)(maxValue-offset));
// Select channel #0 for the measurement.
// (see the specific device data sheet).
SD1CON3bits.SDCH = 0;
// Adjust loop end value for desired settling time (value must be >= 5).
for(count=0; count<8; count++)
{
// Clear interrupt flag.
IFS6bits.SDA1IF = 0;
// Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Not corrected channel #0 result.
channelValue = (signed short int) SD1RESH;
// Correct offset.
channelValue -= offset;
// Correct gain.
calibratedResult = gain*channelValue;

PIC24F Family Reference Manual
DS30687A-page 66-18 © 2013 Microchip Technology Inc.
66.6.2 Gain Error Correction Using Integer Math
Floating-point math is easy and convenient to use, but is often undesirable during actual
execution because it generally consumes a large amount of CPU execution time and code space
to perform. Fortunately, it is possible to correct for A/D gain error using pure integer-based math.
In mathematical theory, if an expression is multiplied by a constant and then divided by the same
constant, the expression stays the same (Equation 66-3).
Equation 66-3: Math Example
In this example, multiplying and dividing by a constant number (218 or 262144) does not change
the value of the expression. Using this approach, it is possible to convert floating-point numbers
into integers with minimal truncation error (Equation 66-4).
Equation 66-4: Converting Floating Point Number into Integer Example
The final expression (323623/262144) is very easy and quick to evaluate by the microcontroller
during run time, as it isequivalent to taking a 32-bitinteger and arithmetically shifting it to the right
by 18 bit positions (equivalent to dividing by 262144). This mathematical principle can therefore
be used to perform traditional floating-point math operations, using integer math with very little
error, provided that the constant number being multiplied and divided by is a very large number
(ex: 218 or larger). Example 66-3 shows how this principle can be used to correct for the
Sigma-Delta A/D gain error quickly during application run time.
Example 66-3: Channel Conversion with Offset and Gain Correction Using Integer Math
1.2345 1.2345 218 218 =
1.23456 1.23456 262144 262144323623 262144=
// This is fixed point location
#define FIXED_POINT_POS 15
unsigned char count;
signed long int offset;
signed long int maxValue;
signed long int expectedMaxValue;
signed long int gain;
signed long int channelValue;
signed short int calibratedResult;
// ADC initialization.
SD1CON1bits.PWRLVL = 0; // Low power, normal bandwidth
SD1CON1bits.SDREFP = 0; // Positive Voltage Reference is SVDD
SD1CON1bits.SDREFN = 0; // Negative Voltage Reference is SVSS
SD1CON1bits.VOSCAL = 1; // Internal Offset Measurement Enable
SD1CON1bits.DITHER = 1; // Low Dither
SD1CON1bits.SDGAIN = 0; // Gain is 1:1
SD1CON2bits.RNDRES = 2; // Round result to 16-bit
SD1CON2bits.SDWM = 1; // SDxRESH/SDxRESL updated on every Interrupt
SD1CON2bits.SDINT = 3; // Interrupt on every data output
SD1CON2bits.CHOP = 3; // Chopping should be enabled
SD1CON3bits.SDCH = 0; // Channel 0 (see the specific device data sheet)
SD1CON3bits.SDCS = 1; // Clock Source is a 8 MHz FRC
SD1CON3bits.SDOSR = 0; // Oversampling Ratio (OSR) is 1024 (best quality)
SD1CON3bits.SDDIV = 1; // Input Clock Divider is 2 (SD ADC clock is 4MHz)

© 2013 Microchip Technology Inc. DS30687A-page 66-19
Section 66. 16-Bit Sigma-Delta A/D Converter
16-Bit Sigma-Delta
A/D Converter
66
Example 66-3: Channel Conversion with Offset and Gain Correction Using Integer Math (Continued)
// Enable ADC
SD1CON1bits.SDON = 1;
// Wait for a minimum of five interrupts to be generated. Need to throw at least
// the first four away when using interrupt every period option, since the
// low pass SINC filter needs to be flushed with new data when we change
// ADC channel or initialize the ADC.
for(count=0; count<8; count++)
{
//Clear interrupt flag.
IFS6bits.SDA1IF = 0;
//Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Save the initial VOSCAL offset value from the ADC.
// This value will be used to correct the offset error for all
// subsequent ADC measurements.
offset = (signed short int)SD1RESH;
// Configure ADC for normal operation.
SD1CON1bits.VOSCAL = 0;
// Measures the reference selected by SDREFP/SDREFN
// (see the specific device data sheet).
SD1CON3bits.SDCH = 3;
// Wait for a minimum of five interrupts to be generated.
for(count=0; count<8; count++)
{
//Clear interrupt flag.
IFS6bits.SDA1IF = 0;
//Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Save the maximum value to calculate the gain.
maxValue = (signed short int)SD1RESH;
// Correct offset.
maxValue -= offset;
// Calculate gain.
expectedMaxValue = ((signed long int)32767)<<FIXED_POINT_POS;
gain = expectedMaxValue/maxValue;
// Select channel #0 for the measurement.
// (see the specific device data sheet).
SD1CON3bits.SDCH = 0;

PIC24F Family Reference Manual
DS30687A-page 66-20 © 2013 Microchip Technology Inc.
Example 66-3: Channel Conversion with Offset and Gain Correction Using Integer Math (Continued)
// Adjust loop end value for desired settling time (value must be >= 5).
for(count=0; count<8; count++)
{
// Clear interrupt flag.
IFS6bits.SDA1IF = 0;
// Wait for the result ready.
while(IFS6bits.SDA1IF == 0);
}
// Not corrected channel #0 result.
channelValue = (signed short int)SD1RESH;
// Correct offset.
channelValue -= offset;
// Correct gain.
channelValue = gain*channelValue;
// 16-bit signed result
calibratedResult = channelValue>>FIXED_POINT_POS;
