Microlene DAVEY MTC-HF1M User manual

MTC-HF1M (Chrome nish)
and MTCM-HF1M (Matt nish)
3 Way Mixer Tap and Under
Bench Filtration Systems
HF1M
High Flow Under
Bench Filtration Kit
HF1M-R
Replacement
Cartridge
3 Way Mixer Tap
Under Bench Filtration Systems
Installation and
Operating Instructions
Please pass these instructions on to the operator of this equipment.
Warning: Microlene under bench system installation must be in compliance with
all local legislative requirements, and installed by a licensed plumber.
Tested in compliance with
for use in contact with safe drinking water

2
Congratulations on purchasing this three way mixer tap and/or under bench
ltration system. By purchasing a Microlene Filtration System you are receiving not
only a high quality product but also peace of mind. Protecting your water supply with
a ltration system gives you reassurance that your family will have access to better
tasting ltered drinking water through your designated outlet protecting them from
taste, odour and contamination from unwanted nes in your water supply. Simple
maintenance of your continuous ltration system will ensure good tasting water
from your home’s connected outlet, Microlene makes it that easy.
These instructions are also available in soft copy via email from Microlene Customer Service or on line at the
Davey website: daveywater.com
TABLE OF CONTENTS
Specications ...............................................................................................................................4
Safety Considerations .................................................................................................................4
Water Quality Parameters .........................................................................................................4
Kit Components ...........................................................................................................................5
Installation ...................................................................................................................................8
3 Way Mixer Tap and Under Bench Filtration Systems .......................................... 14
High Flow Under Bench Filtration System ................................................................ 14
Replacing the Filtration Cartridge ......................................................................................... 15
System Troubleshooting ......................................................................................................... 16
Warranty ..................................................................................................................................... 19

3
Water Quality Parameters
The Microlene HF1M-R purication cartridge used in MTC-HF1M, MTCM-HF1M and
HF1M is designed to purify and lter household drinking water only.
The HF1M-R cartridge can be used on both mains water (sanitised) as well as rains
water. For use with Rain water the water coming into the house supply must have rst
been pretreated with 20 micron Poly Pleated Sediment cartridge then a 1 micron Poly
Spun and nally UV treatment in order to remove large sediment, cysts (e.g. Giardia
or cryptosporidium), viruses, bacteria and algae.
System Components
MTC-HF1M (Chrome Finish Tap) and MTCM-HF1M (Chrome Matt Finish Tap) systems
come in two cartons each:
Carton one contains the 3 way mixer tap and ttings.
Carton two labeled “HF1M” contains the lter cartridge system and braided hoses and
brass connections. This carton is also sold separately as HF1M.
Note: When installing MTC-HF1M, MTCM-HF1M and HF1M some parts included in the
carton may not be required.
Safety Considerations
1. The appliance is intended to be
permanently connected to the
water mains and not connected by
a hose-set.
2. Maximum operating pressure
for the system is 680kPa (98psi) -
subject to regulatory limits.
3. Minimum operating pressure is
200kPa (29psi).
4. Water temperature range is 0 to
38°C. Do not operate with water
below or above this range.
5. Do not use this system for any
purpose other than what it was
intended for. Misuse of this system
could potentially cause harm to the
user or others.
6. We recommend that a licensed
plumber or certied technician
install the system. In many areas
this is a legislated requirement.
Specications
• Max pressure rating: 200 - 680kPa
• Water temperature: 0 - 38oC
• Micron rating: 1 micron
• Flow rate: 9.5 lpm
• Cartridge capacity: 65,000 lpm
• Cartridge replacement: 6 monthly
• Replacement cartridge: HF1M-R
Mounting
• Vertical: 500mm (h) x 215mm (w)
• Horizontal: 215mm (h) x 500mm (w)
• Required hole for tap: 33mm
(on MTC-HF1M or MTCM-HF1M)

4
Carton One:
Component
#
Description Quantity Picture
1Mixer tap
(chrome or
matt nish as
applicable)
with three 1/2”
exible hoses
1
2Connector (1/2”
male thread x
G1/4” tube)
1
3Tap base ring -
Stainless steel
1
4Washers (small
& large)
2
5Plastic gasket 1
6Horseshoe
sealing gasket
1

5
7Retainer screw
- long thread
2
8Retainer screw
- brass nut
2
9Pressure
limiting valve
1
10 Connector to
tube (lter x
G1/4” tube)
2
11 Smart Tee
(T piece,
isolating valve
and back
ow valve)
1
12 Flexible plastic
1/4’ tubing
(Total 2 metres)
1

6
Carton Two (or HF1M when sold separately):
Component # Description Quantity Picture
13 1/2” Non
return valve
1
14 1/2” braided
hose 450mm
long
3
15 1/2” MXF Brass
adaptor
1
16 Filter assembly
including
mounting
bracket /
connection head,
cartridge and
mounting screws
1
17 1/2” Brass nipple 2
18 Instruction
and Operating
Instructions
1
19 Thread tape (1m) 1

7
Installation
MTC-HF1M and MTCM-HF1M
3 Way Mixer Tap (carton one) with High Flow Under Bench Cartridge (carton two).
General tap layout
Mixer water handle
1. Raise the lever handle to turn on the water. Push down to stop.
2. Turn the handle lever to the left to increase hot water ow, turn to the right for
cooler water.
Puried water handle
Turn the puried water handle clockwise to open puried water, the more you turn,
the large ow rate. To close or reduce the ow rate, turn opposite way.
25
On
Off
90¡
Hot wate old water
Left Right
90¡
On
Off
Purified
water
handle
33
MaX35
Purified
water
handle
A
erator
Mixer
handl
e
Purified
water
Cold
water
Hot
water
Purified
water
outlet

8
Mixer tap
(item 1)
Tap Base Ring (Item 3)
Washer (item 4)
Plastic gasket
(item 5)
Retainer screw nut
Retainer screw
Horseshoe sealing
gasket (item 6)
Cold
Filtered
Fitted to
(item 1)
Hot

9
Mixer
Tap
Cold
Filter
Cartridge
(Item 16)
Hot
Smart Tee
(item 11)
Pressure
Limiting
Valve
(item 9)
Flexible plastic
1/4’ tubing
(item 12)
Connector to tube
(lter x G1/4” tube) (Item 10)
Connector (1/2”
male thread x
G1/4” tube) (Item 2)

10
1
2
16
12
11
3 & 4
10
NOTE:
Where the lter assembly is required to be mounted further than directly below the
sink additional lengths of item 14 (1/2” braided hose 450mm long) joined using item
17 ( 1/2” brass nipple) can be attached to the braided ltered water line and then to
the mixer tap.
Installation Procedures:
NOTE: All male pipe threads must have adequate thread tape axed for correct
sealing.
1. Ensure all parts and tools required are ready for use.
2. Turn o water supply and relieve pressure in old tap xtures if applicable.
3. The hoses come preconnected to the tap. Check they are all hand tight -
only use hand tightening to screw the exible hoses. Do not over tighten.
Don’t use any tools.
4. Unscrew the Retainer Screw Nuts (item 8) from the Retainer Screws (item 7 ).
5. Insert the Retainer Screws (item 7) into the bottom of the tap – beside the hose
entries – leaving screwdriver slot exposed.
9
12
12
