Adey MagnaClean CMX MIDI PRO ASSIST User manual

1
MIDI PRO ASSIST &
MIDI PRO
Sidestream Monitored Filtration
Installation and servicing
MagnaClean CMX®
Commercial®

2
Contents
Checklist 3
Location 4
Key Features 5
Unit Installation 6
Electrical Installation/Earthing 8
Controller Wiring Diagrams 10
Operation 11
Controller Programming Parameters 12
Filtration & Pressure Differential Monitoring 19
Flow & Temperature Measurement 20
Maintenance & Servicing 21
Environment Protection 23
Technical Specification 24
Troubleshooting Guide 26
UK Declaration of Conformity 28
Product Description
Heating & chilled system sidestream and pumped sidestream filtration units with integrated MagnaClean
CMX Midi filter; automated control system with BMS connectivity options providing connected system/
filtration monitoring via constant system flow, pressure differential and temperature sensing.
Application
The MagnaClean CMX Midi Pro & Midi Pro Assist Sidestream filters provide high performance,
sidestream filtration for all heating & chilled systems. Featuring a high performance MagnaClean CMX
Midi filter, the option of an integrated Grundfos UPM3 Flex AS pump for pumped, assisted filtration
and the security of system flow, pressure differential and temperature sensing with full BMS alarm
connectivity, these solutions are designed to actively monitor the system and the active filtration of
any heating or chilled system in a sidestream configuration for 24 hours a day.
Transport/Storage
These units are heavy - care should be taken during lifting & handling. During transportation,
secure the units properly to prevent any damage. If this product is not being installed immediately,
ensure it is stored in a dry, frost & vibration-free location in its original packaging.
The WEEE symbol on this product indicates that the product must not be disposed of with normal
household waste. Instead such marked waste equipment must be disposed of by arranging to return
to a designated collection point for the recycling of waste electrical and electronic equipment.
This MagnaClean CMX Midi filter contains a strong magnet.
Keep away from all electrical devices, bank cards and other magnetic devices.
This MagnaClean CMX Midi filter contains a strong magnet.
Caution should be taken at all times when handling if you have a pacemaker fitted.
This MagnaClean CMX Midi filter is a pressurised device.
Always release pressure before servicing.
The filter unit may be hot in operation.
Handle with care.
THIS PRODUCT COMPLIES WITH ALL CURRENT UK and EU PRODUCT LEGISLATION.

3
Warnings
The electrical installation must be carried out in accordance with the current national electrical
regulations by a qualified person.
This appliance must be earthed via the supply cord.
The pump is not accessible in normal operation mode. The unit must be operated with the
front cover in place.
This appliance must not be used for any other application without the written consent of ADEY
Commercial Limited.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
Children should be supervised to ensure that they do not play with the appliance.
Please read installation details carefully as they are intended to ensure this product provides
long, trouble free service. Failure to install & maintain the units in accordance with the
guidelines in this manual may lead to invalidation of the product warranty.
1. Checklist
IMPORTANT: With the appliance removed from its packaging, check for any damage prior to
installation. If any damage is found, please contact ADEY Customer Services on [phone]
within 24 hours of receipt.
MagnaClean CMX Midi Pro Assist (FL1-03-06632)
Item Description Qty Item Description Qty
ACMX Midi Pro Assist Skid Base 1 GLED Warning Light 1
BMagnaClean CMX Midi Filter 1HPower Switch 1
CGrundfos DPS Diff. Pressure Sensor 1 IAutomatic Air Vent (1") & Valve 1
D28mm Compression Ball Valves 2 JGrundfos VFS Flow & Temp Sensor 1
EGrundfos UPM3 FLEX AS 130 Pump 1 K¼" Male - ½" Female Adaptor 1
FADEY DEK1002 Modbus Controller 1 L50-Micron Filter Cartridges 3
Fig. 1
C
D
A
E
B
G
I
K
F
J
H
L

4
1. Checklist (Cont.)
MagnaClean CMX Midi Pro (FL1-03-06631)
Item Description Qty Item Description Qty
ACMX Midi Pro Skid Base 1 GPower Switch 1
BMagnaClean CMX Midi Filter 1HAutomatic Air Vent (1”) & Valve 1
CGrundfos DPS Diff. Pressure Sensor 1IGrundfos VFS Flow & Temp Sensor 1
D28mm Compression Ball Valves 2 J¼” Male - ½” Female Adaptor 1
EADEY DEK1002 Modbus Controller 1 K50-Micron Filter Cartridges 3
FLED Warning Light 1
Fig. 2
2. Location
Location: These sidestream skid units should be installed on a solid, level floor which is able to support
the filled weight of the unit of c.41-44kg, dependent on the model being installed. Please also ensure
that minimum clearance requirements are followed to allow for servicing of the unit, which can be
found on page 5.
Access and minimum clearance requirements: : For emergencies and maintenance, the sidestream
skid units must be easily accessible and have the minimum clearance around it as laid out in Fig. 3.
on page 5. Additional access to the front of the unit will be required to service the filter/unit and
programme/operate the controller.
C
D
A
B
F
H
J
E
I
G
K

5
2. Location (Cont.)
Access & Minimum Clearance Requirements
Fig. 3
5 6
4
3
1
2
400mm 150mm
150mm
150mm 150mm
Protection: Units should be located in a dry, frost free area.
Ambient temperature: Units should be sited in a location where the ambient temperature does not
drop below +2°C or exceed +40°C.
3. Key Features
1. Robust, mild steel skid frame: High quality, powder-coated skid based filtration unit, providing
single-person installation & re-installation, offering the flexibility and potential to move one or more
units from one location to another across multiple locations.
2. MagnaClean CMX Midi Filter & Grundfos UPM3 Flex AS 130 Pump: The CMX Midi®Pro Assist option
has been designed to provide complete flexibility across a plant room environment, offering high
performance, pumped sidestream filtration when space is a premium and/orwhere it isn’t possible
to install a filter across-a-pump on any heating or chilled system.
3. Grundfos Vortex Flow & Temperature Sensor (VFS): The VFS sensor is a combined flow and
temperature sensor based on the principle of vortex shedding behind a bluff body. The VFS sensor
is fully compatible with wet, aggressive liquids, constantly monitoring system flow through the filter
whilst also accurately measuring system water temperature.
4. Grundfos Differential Pressure Sensor (DPS): The integrated DPS Sensor is attached to the inlet
and outlet flow via capillary tubes and measures the differential pressure between the filter inlet and
outlet, providing alarms to warn about filter servicing requirements and blockages should they occur.
5. ADEY DEK1002 Modbus Controller: The integrated controller supports Modbus BMS & sensor
connectivity and monitoring capability, with programmable warnings & alarms such as high/low flow
and high/low system water temperature; automatic on/off control, service interval alerts, unit/pump
failure alarms and system data logs, covering servicing, operational hours, total water volume/total
water volume through the unit in the last 24 hours & total pump hours.
6. LED Warning Light & Alarm function: The integrated warning light will flash and an alarm will sound
when high/low programmable parameter limits are reached during unit operation.

6
4. Unit Installation
MagnaClean CMX Midi Pro Assist (FL1-03-06632)
The MagnaClean CMX Midi Pro Assist sidestream skid unit should be installed by a competent plumber
or service engineer on a solid, level floor which is able to support the filled weight of the unit of c.44kg.
Please ensure the minimum clearance requirements detailed in Fig.3 on page 5 are followed to allow for
servicing of the unit. No special equipment or tools are required for installation.
This unit can be connected to a heating or chilled system in any location in a sidestream configuration,
via the two 28mm compression ball valves included with the unit.
IMPORTANT: As this unit is driven by an integrated pump, both the unit inlet & outlet connections must
both be connected to EITHER the main system flow OR the system return as indicated below in Fig.4.
The unit outlet connection onto the system flow or return pipe should ideally be installed UPSTREAM
of the unit inlet connection.
IMPORTANT: The inlet and outlet connections into the system flow or return should be a minimum of
386mm apart to prevent back-circulation of system water.
WARNING: The unit inlet & outlet connections must not be connected across the system flow and
system return or across a system pump, as would be the case in a standard, unpumped sidestream
installation configuration. If the unit is installed in this way, it may result in the unit not operating as
intended.
Fig. 4 386mm
501mm
425mm
849mm
1029mm
939mm

7
386mm
501mm 425mm
849mm
1029mm
939mm
4. Unit Installation
MagnaClean CMX Midi Pro (FL1-03-06631)
The MagnaClean CMX Midi Pro sidestream skid unit should be installed by a competent plumber or
service engineer on a solid, level floor which is able to support the filled weight of the unit of c.41kg.
Please ensure the minimum clearance requirements detailed in Fig.3 on page 5 are followed to allow for
servicing of the unit. No special equipment or tools are required for installation.
This unit can be connected to a heating or chilled system in any location in a sidestream configuration,
via the two 28mm compression ball valves included with the unit.
IMPORTANT: The unit inlet and outlet should be connected either across the system flow and return,
(with the filter inlet connected to the system flow and the filter outlet connected to the system return)
or across a system pump, as indicated below in Fig.5. The inlet and outlet connections should be a
minimum of 386mm apart to prevent back-circulation of system water.
Fig. 5

8
4. Unit Installation (Cont.)
IMPORTANT: Whilst the MagnaClean CMX Midi filters attached to these units carry a min/max
temperature rating of -10⁰C to +150⁰C, when installed and used as an integral part of the CMX Midi
Pro & CMX Midi Pro Assist sidestream units as they are, the MagnaClean CMX Midi filter min/max
temperature rating is +2⁰C to +100⁰C only. Operating these units outside of these temperature
parameters will compromise safe working operation and result in permanent damage to sensitive
components, voiding any outstanding product warranty.
5. Electrical Installation/Earthing
Regulations: The electrical installation must be carried out in accordance with the current
national electrical regulations and installed by a qualified person only.
Safety: In the interests of electrical safety a 30 mA residual current device (R.C.D. not supplied) should
be installed in the supply circuit. This may be part of a consumer unit or a separate unit.
Before starting work on the electrical supply ensure power supply is isolated.
DO NOT allow the supply cord to contact hot surfaces. The cord should be safely routed and secured by
cable clips.
Adjacent pipes: Adjacent suction and delivery pipes should be fitted with earthing clamps in
accordance with current regulations.
Earthing: This appliance must be earthed via the supply cord.
Pipework: Copper or metallic pipework must have supplementary earth bonding where the continuity
has been broken by flexible hoses or plastic components.
Additional earthing: Certain installations may require additional earthing arrangements such as
equipotential bonding. Reference should be made to the relevant regulations concerning this subject to
ensure compliance.
Connections: The unit must be connected to a dedicated fused SPUR via a lockable isolator to avoid
unauthorised disconnection.
The electrical connection must be made adjacent to, (not behind) the Pumped Sidestream unit to allow
disconnection of the electrical supply should the pump module or controller need to be removed for
service or maintenance.
WARNING: This appliance must be earthed.
Wiring of connection unit: The wires in the mains lead (supply cord) are coloured in accordance with
the following code:
Green and Yellow: Earth
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your connection unit proceed as follows:
The wire which is coloured green and yellow must be connected to the terminal in the connection unit
which is marked with the letter E: or coloured green or green and yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or
coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L
or coloured red.

9
5. Electrical Installation/Earthing (Cont.)
RS 485 Modbus – BMS Connection: RS 485 is available on this product for BMS connection directly
into the unit controller.
Fuses: A 5 Amp replacement fuse size should be used. The complete unit is fused via the live terminal
block contained within the upper electrical compartment.
Supply cord replacement: The supply cord and internal wiring within the terminal box are routed and
secured to ensure compliance with the electrical standard EN60335-1.
It is essential that prior to any disturbance of this internal wiring, all cable routing and securing details
are carefully noted to ensure re-assembly to the same factory pattern is always maintained.
If the supply cord is to be changed or is damaged, it must be replaced with a special cord assembly
available from ADEY or one of their approved repairers.
On disassembly note the cord retention and routing system. Re-assemble to the same pattern.
For information on controller wiring connection requirements, please consult the appropriate wiring
diagram overleaf on page 10.

10
6. Controller Wiring Diagram
MagnaClean CMX Midi Pro Assist (FL1-03-06632)
Fig. 6
Controller Wiring Diagram
MagnaClean CMX Midi Pro (FL1-03-06631)
Fig. 7

11
7. Operation
Controller Overview: The unit controller is designed to be intuitive to use and allows functions and
alarms to be set by the installer/user. It also allows faults to be monitored and logged to enable easier
system fault diagnosis. The functions are set using the 4 buttons on the front of the controller, as per
below in Fig. 8:
Fig. 8 Fig. 9
The unit can be connected to a BMS system through RS485
- Modbus. The controller has been tested using ModScan
software. Connection is via RS485 protocol connecting the
positive data wire to MODBUS Terminal A and the negative
data wire to MODBUS Terminal B on the controller, (Fig.9).
The controller has three menu choices upon setup and during servicing which allow control over
access to important parameter settings for the product. The three menus are: Engineers Menu: 315;
Customer Data Menu: 815; Data Logging Menu: 111. Details about parameter access levels for each
menu type can be found from page 12 of this booklet.
The controller is fully programmable providing automatic on/off control, service interval alerts, unit and
pump failure alarms and system data logs covering servicing, operational hours & pump activity.
The integrated Grundfos 10-200L VFS Flow Sensor constantly monitors water flow through the
unit and system water temperature and the pressure differential across the inlet and outlet of the
MagnaClean CMX Midi filter via the integrated Grundfos DPS Sensor, providing warning alerts and
alarms at two levels:
Grundfos VFS Flow Sensor
a) A warning alarm, alerting the persons responsible for monitoring the heating or chilled system that l/
min flow through the unit has reached its warning level and that a service visit is advised;
b) An alarm, alerting the persons responsible for monitoring the heating or chilled system that
flow through the unit has reached its alarm level and that a service visit is required. The pump is
deactivated and the controller will not clear until a new service date is entered.
Grundfos DPS Pressure Differential Sensor
a) A warning alarm, alerting the persons responsible for monitoring the heating or chilled system that
the installed cartridge filter is beginning to block and that a service visit is advised;
b) An alarm, alerting the persons responsible for monitoring the heating or chilled system that the
installed cartridge filter is full and needs changing. The pump is deactivated and the controller will
not clear until a new service date is entered.
System temperature is also constantly monitored by the VFS Flow Sensor, providing warning alarms
should the water temperature fall below or above the programmable low/high temperature warning
parameters.
A full list of controller parameters and their factory default values can be found on pages 12-15,
together with applicable warnings and alarms on page 18.

12
8. Controller Programming Parameters
DURING NORMAL OPERATION
1. On initial start-up, the user is required to input the correct Day, Month, Year, Hour & Minutes, using
the up and down buttons to cycle to the correct number and pressing ‘SET’ to pass on to the next
parameter. Once the Minutes value is adjusted, hold the SET button to save all Day. Month, Year,
Hour & Minutes settings.
2. The controller will then scroll, ‘ADEY MagnaClean CMX Monitored Filtration v1.0’ followed by a unit
status message:
a) In normal operation with system monitoring and pump running, the display will scroll, ‘Pump
Running’, ‘Unit Filtering’.
b) In normal operation with system monitoring and pump disabled, the display will scroll, ‘Sensor OK’.
PARAMETER READINGS - QUICK LOOK
1. Press ‘UP’, (Button 1) to display future service date followed by last service date.
2. Press ‘DOWN’, (Button 3) to display date followed by time.
3. Press ‘SET’ & ‘UP’, (Buttons 4 & 1) to display pressure difference across the filter inlet and outlet.
4. Press ‘SET’ & ‘DOWN’, (Buttons 4 & 3) to display current system water temperature.
5. Press ‘SET’ & ‘MUTE’, (Button 4 & 2) for current flow reading through the unit.
PROGRAMMING MODES
1. Press ‘UP’ & ‘DOWN’, (Buttons 1 & 3) for 3 seconds to enter TIME & DATE PROGRAMMING MODE
TIME & DATE PROGRAMMING MODE
a) Press ‘UP’, (Button 1) to increase the value. If held, will cycle through menu options automatically
– release button when desired value is achieved.
b) Press ‘DOWN’, (Button 3) to decrease the value. When held, will cycle through menu options
automatically – release button when desired value is achieved.
c) Press ‘SET’ to confirm and move to the next value.
d) To exit time & date programming mode, press and hold the ‘SET’ button.
2. Press ‘SET’. (Button 4) for 3 seconds to enter PARAMETER PROGRAMMING MODE and enter
the appropriate code: Engineers Menu: 315; Customer Data Menu: 815; Data Logging Menu: 111
NOTE: If pressed during Power On, controller enters ‘Software Download’.
PARAMETER PROGRAMMING MODE
a) To cycle through the controller parameters, HOLD ‘SET’ followed by ‘UP’, (Button 4 & 1) to move
to the next parameter; HOLD ‘SET’ followed by ‘DOWN’, (Button 4 & 3) to move to the previous
parameter.
b) Press ‘UP’, (Button 1) to increase the value. If held, will cycle through menu options automatically
– release button when desired value is achieved.
c) Press ‘DOWN’, (Button 3) to decrease the value. When held, will cycle through menu options
automatically – release button when desired value is achieved.
d) Press ‘SET’, (Button 4) to enter the password value during password request and to save any
Parameter changes.
e) Press ‘MUTE’, (Button 2) to reset the pump hours counter.
f) To exit parameter programming mode, press and hold the ‘SET’ button.

13
PARAMETER PROGRAMMING MODE - ENGINEERS PARAMETER MENU (Code: 315)
#Parameter Description Default Range
-
Service Date Adjust future service date: Day/Month/Year. Press
& hold ‘SET to cycle across values. Will pass onto
next parameter once complete
--
-
Last Service Date Automatically updates when a new service date
has been entered and will be visible next time user
accesses parameters
--
1Cartridge*
Present
Monitors presence of a filter cartridge No Yes/No
2
Magnet Only**
Service Warning
Daily/weekly/monthly warning alarm
Daily
Daily
Weekly
Monthly
3
Magnet Only
Service Warning
Duration
Number of days/weeks/months (unit representation
dependent upon Parameter 2 Alarm choice - Daily,
Weekly or Monthly)
21-12
4
Pressure
Difference
Warning
Warning trigger point based on pressure
differential output (The default value of 0.4 bar
should not be changed)
0.4 0.1 - 2.5 bar
5
Pressure
Difference Alarm
Alarm trigger point based on pressure differential
output (The default value of 0.6 bar should not be
changed)
0.6 0.1 - 2.5 bar
6Flow Monitoring
Enable
Enables/disables flow monitoring & measurement YY/N
7Low Flow Warning Low Flow warning value 10 0 - 200L
8Low Flow Alarm Low Flow alarm value 00 - 200L
9Sensor Minimum
Pressure
Maximum pressure value of sensor (The default
value of 0.0 bar should not be changed) 0.0 bar 0 - 2.5 bar
10 Sensor Maximum
Pressure
Maximum pressure value of sensor (The default
value of 2.5 bar should not be changed) 2.5 bar 0 - 2.5 bar
11 Temperature
Alarm Enable
Enables/disables temperature alarm Yes Yes/No
12 Low Temperature
Alarm
Low temperature alarm value 4°C 0 - 120°C
13 High Temperature
Alarm
High temperature alarm value 90°C 0 - 120°C
14
Pump Required Disables activation of pump relay. If set to NO, Current
Sense (Parameter 13) will auto NO; When set to YES,
Current Sense (Parameter 13) will auto YES
Yes Yes/No
15 Current Sense Monitors current for presence of pump Yes Yes/No
16
Alarm Relay
Contact
Type of Contact for Alarm Output (NO= Relay in
open position; closes on alarm; NC = Relay in closed
position; opens on alarm)
No No/NC
17 ID Number Address for Mod Bus 00 - 99
18 Pump Hours Total Operation Hours for Pump (Auto Update) 0 - 999 1 = 24 hrs
19
Battery Activation Enable or disable the Battery (Maintains date and
time settings if power is lost to the controller - on
first power up battery will automatically activate)
No Yes/No

14
*NOTE: PARAMETER 1:
- If Parameter 1 “Cartridge Present” is set to “YES”, Parameters 2 & 3 are not activated.
- If Parameter 1 “Cartridge Present” is set to “NO”, Parameters 2 & 3 are activated and the timer
will be active from that point.
**NOTE: PARAMETER 2:
- Parameter 2 “Magnet Only Service Warning” setting, (Daily, Weekly or Monthly) will affect the
default value of Parameter 3 “Magnet Only Service Warning Duration”, e.g. with Parameter 2 set
at the default “Daily” setting, the controller will provide a warning alarm every 2 days by default.
If Parameter 2 is changed to “Weekly” the controller will provide a warning alarm every 2 weeks.
Default Parameter 3 values can be manually changed during Parameter Programming Mode
within a range of 1 – 12 days, weeks or months as applicable.
PARAMETER PROGRAMMING MODE - CUSTOMER DATA MENU (Code: 815)
PRESS & HOLD ‘SET’ & ‘UP’ TO PASS TO PARAMETER MENUS
#Parameter Description Default Range
P1
Cartridge Present Monitors presence of a filter cartridge
No Yes/No
P4 ID Number Address for ModBus 00 - 99
P5
Battery Activation Enable or disable the battery, (maintains date &
time settings if power lost to the controller - on
first power up, battery will automatically activate
No Yes/No
DL1
Last Service Date Automatically updates when a new service date
has been entered and will be visible next time the
user accesses parameters
--
DL2 Service Date Automatically updates when a new service date
has been entered
Auto-
Update
DL3 Pump Hours Total pump operation time (Auto-Update) Auto-
Update
DL4 Current water
flow I/min
Flow rate through sensor at that point in time Auto-
Update
DL5 Water Volume in
last 24 hours
Amount of water that has passed through the filter
during the previous 24 hours
Auto-
Update
DL6
Water volume
since last
Pressure
Difference Alarm
activation
Flow rate through sensor at that point in time
Auto-
Update
DL7 Total Water
Volume
Total amount of water that has passed through the
filter since the unit was last powered ON
Auto-
Update

15
PARAMETER PROGRAMMING MODE - DATA LOGGING MENU (Code: 111)
#Parameter Description Default Range
DL1
Last Service Date Automatically updates when a new service date
has been entered and will be visible next time the
user accesses parameters
--
DL2 Service Date Automatically updates when a new service date
has been entered --
DL3 Pump Hours Total pump operation time (Auto-Update) 0 - 999 1 = 24 hrs
DL4 Current water
flow I/min
Flow rate through sensor at that point in time Auto-
Update
DL5 Water Volume in
last 24 hours
Amount of water that has passed through the filter
during the previous 24 hours
Auto-
Update
DL6
Water volume
since last
Pressure
Difference Alarm
activation
Flow rate through sensor at that point in time
Auto-
Update
DL7 Total Water
Volume
Total amount of water that has passed through the
filter since the unit was last powered ON
Auto-
Update

16
ADEY DEK1002 MODBUS PROTOCOL - VARIABLE LIST
DEFAULT SETTINGS
BAUD RATE 9600
WORD LENGTH 8
PARITY NO
STOP BITS 1
X Variable
Address
Denomination Type X Variable
Format
Data Conversion Units Equivalent
Range
Range of
X Variable
Notes
40001 Cartridge Present read/write word 16 bits 4 = No 5 = Yes
6 = FastFast
4->6 4->6
40002 Magnet Only Service Warning read/write word 16 bits 11 = Daily 12 = Weekly
13 = Monthly
11->13 11->13
40003 Magnet Only Service Warning
Duration
read/write word 16 bits Value = X 1->12 1->12
40004 Parameter Pressure Difference
Warning
read/write word 16 bits Value = X/10 Bar 0,1-0,6 1-6
40005 Parameter Pressure Difference read/write word 16 bits Value = X/10 Bar 0,1-6,0 1-60
40006 Parameter Flow Monitoring
Enable
read/write word 16 bits 4 = No 5 = Yes 4-5 4-5
40007 Parameter Low Flow Warning read/write word 16 bits Value = X l/min “0->
Parameter
Low Flow
Alarm”
“0->
Parameter
Low Flow
Alarm”
40008 Parameter Low Flow Alarm read/write word 16 bits Value = X l/min Parameter
Low Flow
Warning ->
200
Parameter
Low Flow
Warning ->
200
40009 Parameter Minimum Pressure read/write word 16 bits Value = X/10 Bar “0 ->
Parameter
Maximum
Pressure”
“0 ->
Parameter
Maximum
Pressure”
40010 Parameter Maximum Pressure read/write word 16 bits Value = X/10 Bar “Parameter
Minimum
Pressure
>-6,0”
“Parameter
Minimum
Pressure
->60”
40011 Parameter Temperature Alarm
Enable
read/write word 16 bits 4 = No 5 = Yes 44685.00 4-5
40012 Parameter Low Temperature
Alarm
read/write word 16 bits Value = X °C “0->
Parameter
High Temp
Alarm”
“0->
Parameter
High Temp
Alarm”
40013 Parameter High Temperature
Alarm
read/write word 16 bits Value = X °C “Parameter
Low Temp
Alarm >120”
“Parameter
Low Temp
Alarm >120”
40014 Parameter Pump Required read/write word 16 bits 4 = No 5 = Yes 4-5 4-5
40015 Parameter Current Sense Active read/write word 16 bits 4 = No 5 = Yes 4-5 4-5
40016 Parameter Alarm Relay Contact
Type
read/write word 16 bits 0 = Norm. Open
1 = Norm. Close
0-1 0-1
40017 Parameter ID Number read/write word 16 bits Value = X 0-99 1-99
40018 Parameter Battery Activated read/write word 16 bits 4 = No 5 = Yes 4-5 4-5
40019 Service Date Day read/write word 16 bits Value = X 1-31 1-31
40020 Service Date Month read/write word 16 bits Value = X 1-12 1-12
40021 Service Date Year read/write word 16 bits Value = X 0-99 0-99
40022 Last Serviced Date Day read word 16 bits Value = X 1-31 1-31
40023 Last Serviced Date Month read word 16 bits Value = X 1-12 1-12
40024 Last Serviced Date Year read word 16 bits Value = X 0-99 0-99
40025 Magnet Only Service Day read word 16 bits Value = X 1-31 1-31
40026 Magnet Only Service Month read word 16 bits Value = X 1-12 1-12
40027 Magnet Only Service Year read word 16 bits Value = X 0-99 0-99

17
X Variable
Address
Denomination Type X Variable
Format
Data Conversion Units Equivalent
Range
Range of
X Variable
Notes
40028 Parameter Pump Hours read/write word 16 bits Value = X Days 0-9999 0-9999 NOTE 2
40029 Current Water Flow read word 16 bits Value = X l/min 0->200 0->200
40030 Water Flowed Last 24 Hours
(thousands)
read/write word 16 bits Value = X Khours 0->999 0->999
40031 Water Flowed Last 24 Hours
(units)
read/write word 16 bits Value = X hours 0->999 0->999
40032 Water Flowed since Last
Pressure Alarm (Billions)
read/write word 16 bits Value = X Bhours 0->999 0->999
40033 Water Flowed since Last
Pressure Alarm (Millions)
read/write word 16 bits Value = X Mhours 0->999 0->999
40034 Water Flowed since Last
Pressure Alarm (Thousands)
read/write word 16 bits Value = X Khours 0->999 0->999
40035 Water Flowed since Last
Pressure Alarm (Units)
read/write word 16 bits Value = X hours 0->999 0->999
40036 Total Water Flowed (Billions) read/write word 16 bits Value = X Bhours 0->999 0->999
40037 Total Water Flowed (Millions) read/write word 16 bits Value = X Mhours 0->999 0->999
40038 Total Water Flowed (Thousands) read/write word 16 bits Value = X Khours 0->999 0->999
40039 Total Water Flowed (Units) read/write word 16 bits Value = X hours 0->999 0->999
40040 Actual Day read/write word 16 bits Value = X day 1->31 1->31
40041 Actual Month read/write word 16 bits Value = X month 1->12 1->12
40042 Actual Year read/write word 16 bits Value = X year 0->99 0->99
40043 Actual Hours read/write word 16 bits Value = X hours 0->23 0->23
40044 Actual Minutes read/write word 16 bits Value = X min 0->59 0->59
40045 Pump Status read word 16 bits 0 = OFF 1 = ON 0-1 0-1
40046 Common Alarm Status read word 16 bits 0 = OFF 1 = ON 0-1 0-1
40047 LED Alarm Status read word 16 bits 0 = OFF 1 = ON 0-1 0-1
40048 Alarm Pump Failure read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40049 Alarm Excessive Differential
Pressure
read word 16 bits 0 = Norm. Open
1 = Norm. Close
0-1 0-1
40050 Low Flow Warning read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40051 Low Flow Alarm read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40052 Alarm Maximum Pump Activity read word 16 bits 0 = Norm. Open
1 = Norm.Close
0-1 0-1
40053 Alarm Low Temperature read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40054 Alarm High Temperature read word 16 bits 0 = Norm. Open
1 = Norm. Close
0-1 0-1
40055 Warning Differential Pressure read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40056 Magnet Only Service Warning read word 16 bits 0 = Not Active
1 = Active
0-1 0-1
40057 Pressure read word 16 bits Value = X/10 Bar Par.3 - Par.4 Par.3 - Par.4
40058 Temperature read word 16 bits Value = X °C 0-120 0-120
40059 Flow read word 16 bits Value = X l/min 0->200 0->200
40060 Save the changes in Flash
Memory
read/write word 16 bits Value = X “Write 111
to save
in Flash
Memory”
“Write 111
to save
in Flash
Memory”
NOTE 1
NOTE 1. All writings via ModBus will affect the values of the variable in volatile memory. To save changes to parameters in permanent
memory, write the value 111 to address 40060
NOTE2. 1 is equivalent to 24 hours

18
Warning Conditions for Trigger Scrolled Message “Auto Reset” “Action on Outputs”
Pump Fail Current Sense
Parameter = Y
Pump Activated
Current level below
125mA
Pump Fail
N
Pump – OFF
Buzzer – ON
LED Light – ON
Common Alarm – ON
Service
Interval
Alarm
Actual date beyond
Service Date (Control
will not clear error
until new service date
entered)
Filter Service
Required
N
Pump – ON
Buzzer – ON
LED Light – ON
Common Alarm – ON
Magnet-Only
Service
Warning*
Magnet-only service
requirement value has
been reached
Magnet-Only
Service Warning
- Hold MUTE for 5
secs to reset
N
Pump – ON
Buzzer – ON
LED Light – ON
Common Alarm – OFF
Pressure
Differential
Warning
Pressure Differential
Warning value has been
reached
Differential
Pressure Warning
- Check Cartridge Y
Pump – ON
Buzzer – ON
LED Light – ON
Common Alarm – OFF
Pressure
Differential
Alarm
Pressure Differential
Alarm value has been
reached (Control will
not clear error until new
service date entered)
Filter Service
Required
N
Pump – OFF
Buzzer – ON
LED Light – ON
Common Alarm – ON
Low Flow
Warning
Low flow warning value
has been reached
Low Flow Warning
Y
Pump - ON
Buzzer - ON
LED Light - ON
Common Alarm - OFF
Low Flow
Alarm
Low flow alarm value
has been reached
Low Flow Alarm
Y
Pump - OFF
Buzzer - ON
LED Light - ON
Common Alarm - ON
Low
Temperature
Alarm
Low temperature alarm
value reached
Low Temperature
Warning Y
Pump – ON
Buzzer – ON
LED Light – ON
Common Alarm – ON
High
Temperature
Alarm
High temperature alarm
value reached
High Temperature
Warning Y
Pump – ON
Buzzer – ON
LED Light – ON
Common Alarm – ON
*NOTE: When the “Magnet-Only Service Warning” alarm is activated, the alarm is a service reminder
only which can be reset by holding down the MUTE button for 5 seconds. When the alarm is reset
via the mute button, the alarm will reinstate the previous Parameter 2 & 3 values, e.g. if Parameter 2
is set to “Weekly” the controller will provide another warning alarm in 2 weeks until/unless default
parameters are manually updated/changed.

19
9. Filtration & Pressure Differential Monitoring
The integrated Grundfos Pressure Differential Sensor, (DPS) and DEK1002 controller
within these sidestream units monitor the pressure drop across the inlet and outlet of the
MagnaClean CMX Midi filter as the cartridge filters fill-up with captured system debris.
The controller has two preset warning and alarm settings based on debris collection rates within
the spun-bonded cartridge filters used with the CMX Midi filter. The first ‘warning’ setting sets off an
audible and visual alarm, warning that the installed cartridges are beginning to fill with debris and that
a service visit will be required soon. The second ‘alarm’ setting creates an audible and visual alarm,
warning that the installed cartridges are saturated with system debris, automatically switching off the
integrated pump. When this alarm function is activated, a service visit is required to clean the internal
magnet and replace the cartridge filters before the unit can be reset and put back into filtration mode.
For accurate pressure differential monitoring warnings and alarms, cartridge filters must be
installed in the filter housing; the DEK1002 controller does however feature programmable magnet-
only service warning alarms for when the sidestream skid unit filters are configured with magnets
only, with no cartridge filters installed. These magnet-only warnings are based on time elapsed rather
than differential pressure measurement across the filter, as there is no distinguishable pressure drop
across the filter without cartridges installed, even when they are full of captured magnetic debris.
These time-based alarms are important as ADEY always recommend that when a CMX
filter is installed onto an existing heating or chilled system, the filter should initially be
configured with magnets only. This is to ensure that cartridge filters aren’t needlessly wasted
& blocked with magnetic system debris. The programmable daily, weekly or monthly alarms
are intended as service reminders which can be easily reset within the controller menu.
After initial set up of the unit, we would recommend a service visit within 24-48 hours to check
magnetic debris capture levels and service as required. Subsequent service intervals will largely
depend on the amount of debris being captured. To ensure the unit is able to fully protect and filter the
system it is installed upon, regular servicing & maintenance of the CMX Midi filter is recommended.
Once magnetic capture rates begin to reduce, 5, 10, 20 or 50-micron cartridge filters should
then be installed to capture non-magnetic debris within the system whilst also assisting in the
capture of any remaining/reoccurring magnetic system debris in conjunction with the internal
magnet array and where required, the CMX Midi External Magnetic Jacket accessory.
However, there is no right or wrong way to configure the CMX Midi filter, which can be
configured with cartridge filters immediately if that is what you believe the system requires.
Please contact ADEY Customer Services on [phone] if you have any queries.

20
10. Flow & Temperature Measurement
The integrated Grundfos VFS Flow Sensor and DEK1002 controller within the MagnaClean
CMX Midi Pro Assist & Midi Pro units constantly monitor and log the temperature of the
system water and the amount of water that passes through them. BSRIA guidance states
that when using sidestream filtration, 100% of the system water volume should have passed
through the sidestream filter within a 24-hour period. The MagnaClean CMX Midi Pro Assist &
MagnaClean CMX Midi Pro units are designed for use on systems up to 93,000 litres in size.
The VFS flow sensor provides and logs real-time data around flow volume through the unit and filter:
a) Total water volume through the unit from the point of time the unit was last powered ON
b) Total water volume within the last 24 hours
c) Total water volume since the last Differential Pressure alarm activation
These facilities help meet the intent of BSRIA Guides BG 29/2021 Pre-Commission Cleaning of
Pipework Systems and BG 50/2021 Water Treatment for Closed Heating & Cooling Systems, for
products providing sidestream filtration and chemical dosing capabilities, as referenced in the
following sections of those guides and when installed in accordance with published guidelines:
- Sidestream filtration BG 29/2021; Section 2.3.8 and BG 50/2021; Section 3.4.2
- Chemical dosing facilities – BG29/2021; Section 2.3.8 and BG50/2021; Section 3.4.3
- Corrosion monitoring technology and services BG 29/2021; Section 2.3.8
The additional features of these products are also consistent with the descriptions in BG 50 including:
- Magnetic filtration BG 50/2021; Section 5.3.2
- Disposable media filters BG 50/2013; Section 5.3.3
- Passive deaeration BG 50/2013; Section 5.4.1
- Chemical water treatment BG 50/2021; Section 5.1
- Real-time monitoring of system parameters BG50/2021; Section 2.10
The VFS Sensor and DEK1002 controller also carefully monitor system water temperature
as it passes through the units. Low/high water temperature settings can be configured
as required, with automatic alarms when the configured low/high limits are reached. The
pump deactivates and the controller will not clear until a new service date is entered.
Both features help provide more pro-active maintenance, combining the security
of sensing technology with live data to warn you of critical system issues such as
pressure, temperature and flow and of course unit maintenance requirements,
ensuring the filter is always cleaning and protecting the system.
The ADEY MagnaClean Monitored Filtration™range actively monitors system flow, pressure
differential and system water temperature, offering configurable BMS alarm connectivity.
These solutions are designed to actively monitor the system water and the active filtration
of any heating or chilled system in a sidestream configuration for 24 hours a day.
