Microlife BP W100 User manual

IB BP W100 EN-RU 3919
Прибор для измерения артериального
давления и частоты пульса
BP W100
Microlife AG
Espenstrasse 139
9443 Widnau / Switzerland
www.microlife.com
EN 1
RU  12
Уполномоченный представитель производителя
«Микролайф» в России
ООО «МИП-Тест», 123001 Москва, Ермолаевский пер., д.22-26, стр.1 Телефоны
бесплатной горячей линии:
Часы работы: пн.-пт. 09:00 - 17:00 (время московское)
для Москвы: [phone]
для регионов: 8 800 550 10 52
Производитель
Microlife AG, Швейцария
Адрес: Espenstrasse 139, 9443 Widnau, Switzerland
Web-сайт: www.microlife.com
Место производства:
ONBO Electonic (Shenzhen) Co., Ltd., Китай
Адрес: No. 497, Ta Laneg Nan Road, Ta Laneg Street,
Baoan District, Shenzhen, China
Сделано в Китае

Microlife BP W100
1
Microlife BP W100
1
4
2
3
6 5
I
AT
7
8
9
AO
AK
AN
AL AM
II
BP W100Guarantee Card
Name of Purchaser /
Ф.И.О. покупателя
Serial Number /
Серийный номер
Date of Purchase /
Дата покупки
Specialist Dealer /
Специализированный дилер

1BP W100 EN
Display
Intended use:
This oscillometric blood pressure monitor is intended for measuring
non-invasive blood pressure in people aged 12 years or older.
Dear Customer,
Your new Microlife blood pressure monitor is a reliable medical device
for taking measurements on the wrist. It is simple to use, accurate and
comes highly recommended for blood pressure monitoring in your
home. This device was developed in collaboration with physicians and
clinical tests prove its measurement accuracy to be very high.*
If you have any questions, problems or want to order spare parts
please contact your local Microlife-Customer Service. Your dealer or
pharmacy will be able to give you the address of the Microlife dealer
in your country. Alternatively, visit the internet at www.microlife.com
where you will find a wealth of invaluable information on our products.
Stay healthy – Microlife AG!
* This device is clinically tested according to the British and Irish
Hypertension Society (BIHS) protocol. Highest possible grading for
Systolic (A) and Diastolic (A) measurement accuracy.
Microlife BP W100 EN
1ON/OFF button
2Display
3Battery Compartment
4Cuff
5M-button (memory)
6Time Button
7Systolic Value
8Diastolic Value
9Pulse Rate
AT Date/Time
AK Alarm Time
AL Stored Value
AM Heart Arrhythmia Indicator
AN Pulse
AO Battery Display

2
Table of Contents
1. Explanation of symbols
2. Important Facts about Blood Pressure and Self-Measure-
ment
• How do I evaluate my blood pressure?
3. Using the Device for the First Time
• Activating the fitted batteries
• Setting the date and time
4. Taking a Blood Pressure Measurement
5. Appearance of the Heart Arrhythmia Indicator for early
Detection
6. Data Memory
• Viewing the stored values
• Memory full
• Clearing all values
• How not to store a reading
7. Setting the Alarm Function
8. Battery Indicator and Battery change
• Low battery
• Flat battery – replacement
• Using rechargeable batteries
9. Error Messages
10. Safety, Care, Accuracy Test and Disposal
• Safety and protection
•Devicecare
• Cleaning the cuff
• Accuracy test
•Disposal
11. Guarantee
12. Technical Specifications
1. Explanation of Symbols
Batteries and electronic devices must be disposed of in
accordance with the locally applicable regulations, not with
domestic waste.
Read the instructions carefully before using this device.
Type BF applied part
Keep dry
Conformity mark

3BP W100 EN
2. Important Facts about Blood Pressure and Self-
Measurement
 Blood pressure is the pressure of the blood flowing in the arteries
generated by the pumping of the heart. Two values, the
systolic
(upper) value and the
diastolic (lower) value, are always measured.
The device indicates the pulse rate (the number of times the heart
beats in a minute).
Permanently high blood pressure values can damage your
health and must be treated by your doctor!
Always discuss your values with your doctor and tell him/her if you
have noticed anything unusual or feel unsure. Never rely on
single blood pressure readings.
 A number of factors can affect the accuracy of measurements
taken on the wrist.
In some cases, the result may differ from the
measurement taken on the upper arm. We therefore advise you to
compare these values with those produced by the upper arm
measurement and discuss them with your doctor.
Enter your readings in the enclosed blood pressure diary. This
will give your doctor a quick overview.
 There are many causes of excessively high blood pressure
values
. Your doctor will explain them in more detail and offer treat-
ment where appropriate. Besides medication, relaxation techniques,
weight loss and exercise can also lower your blood pressure.
Type approval of measuring device
Serial number
Catalogue number
Manufacturer
Class II equipment
Operating
Operating temperature restriction
10 - 40 °C
Storage
Storage temperature restriction
-20 - +55 °C
CE Marking of Conformity
S N
N

4
Under no circumstances should you alter the dosages of
drugs or initiate a treatment without consulting your doctor.
 Depending on physical exertion and condition, blood pressure is
subject to wide fluctuations as the day progresses.
You should
therefore take your measurements in the same quiet conditions
and when you feel relaxed!
Take at least two measurements per
day, one in the morning and one in the evening.
It is quite normal for two measurements taken in quick succession
to produce significantly different results.
Deviations between measurements taken by your doctor or in the
pharmacy and those taken at home are quite normal, as these
situations are completely different.
Several measurements provide a much clearer picture than just
one single measurement.
Leave a small break of at least 15 seconds between two
measurements.
If you are pregnant, you should monitor your blood pressure
regularly as it can change drastically during this time.
If you suffer from an irregular heartbeat (arrhythmia, see
«Section 5.»), measurements taken with this device should only
be evaluated after consultation with your doctor.
The pulse display is not suitable for checking the frequency
of heart pacemakers!
How do I evaluate my blood pressure?
The higher value is the one that determines the evaluation. Example:
a readout value between 150/85 or 120/98 mmHg indicates «blood
pressure too high».
Table for classifying blood pressure values in adults in accordance
with the World Health Organisation (WHO) in 2003. Data in mmHg.
Range Systolic Diastolic
Recommenda-
tion
1. blood pressure
normal
< 120 < 80 Self-check
2. blood pressure
normal
120 - 129 80 - 84 Self-check
3. blood pressure
slightly high
130 - 139 85 - 89 Consult your
doctor
4. blood pressure too
high
140 - 159 90 - 99 Seek medical
advice
5. blood pressure far
too high
160 - 179 100 - 109 Seek medical
advice
6. blood pressure
dangerously high
≥180 ≥110 Urgently seek
medical advice!

5BP W100 EN
3. Using the Device for the First Time
Activating the fitted batteries
Pull out the protective strip from the battery compartment 3.
Setting the date and time
1. After the new batteries are fitted, the year number flashes in the
display. You can set the year by pressing the M-button 5. To
confirm and then set the month, press the time button 6.
2. Press the M-button to set the month. Press the time button to
confirm and then set the day.
3. Follow the instructions above to set the day, hour and minutes.
4. Once you have set the minutes and pressed the time button, the
date and time are set and the time is displayed.
5. If you want to change the date and time, press and hold the time
button down for approx. 3 seconds until the year number starts to
flash. Now you can enter the new values as described above.
4. Taking a Blood Pressure Measurement
Checklist for taking a reliable measurement
1. Avoid activity, eating or smoking immediately before the measurement.
2. Sit down on a back-supported chair and relax for 5 minutes. Keep
the feet flat on the floor and do not cross your legs.
3. Always measure in a sitting position and on the same wrist. Use
the wrist which usually shows higher blood pressure values.
4. Remove any items of clothing and your watch, for example, so
that your wrist is free.
5. Always ensure that the cuff is positioned correctly, as shown in the
pictures illustrated on the short instruction card.
6. Fit the cuff comfortably but not too tight. The cuff will cover a wrist
circumference of 13.5 to 21.5 cm (5.25 - 8.5 inches).
7. Support your arm in a relaxed position and ensure that the device
is at the same height as your heart.
8. Press the ON/OFF button 1to start the measurement.
9. The cuff will now pump up automatically. Relax, do not move and
do not tense your arm muscles until the measurement result is
displayed. Breathe normally and do not talk.
10.When the correct pressure is reached, the pumping stops and the
pressure falls gradually. If the required pressure was not reached,
the device will automatically pump some more air into the cuff.
11.During the measurement, the heart symbol AN flashes in the
display and a beep sounds every time a heartbeat is detected.
12.The result, comprising the systolic 7 and the diastolic 8 blood
pressure and the pulse rate
9 is displayed and a long beep is heard.
Note also the explanations on further display symbols in this booklet.
13.Remove and switch off the monitor and enter the result in the
enclosed blood pressure pass. (The monitor does switch off auto-
matically after approx. 1 min.).

6
You can stop the measurement at any time by pressing the
ON/OFF button (e.g. if you feel uneasy or an unpleasant pres-
sure sensation).
5. Appearance of the Heart Arrhythmia Indicator for
early Detection
This symbol AM indicates that certain pulse irregularities were detected
during the measurement. In this case, the result may deviate from your
normal blood pressure – repeat the measurement. In most cases, this is
no cause for concern. However, if the symbol appears on a regular basis
(e.g. several times a week with measurements taken daily) we advise you
to tell your doctor. Please show your doctor the following explanation:
6. Data Memory
At the end of each measurement, this device automatically stores the
result, including date and time.
Viewing the stored values
Press the M-button 5 briefly, when the device is switched off. The
display first shows «
M » AL and then a value, e.g. « M 17 ». This means
that there are 17 values in the memory. The device then switches to the
last stored result.
Pressing the M-button again displays the previous value. Pressing the
M-button repeatedly enables you to move from one stored value to
another.
Memory full
When the memory has stored 200 results, the memory is full.
From this point onwards, a new measured value is stored by
overwriting the oldest value.
Clearing all values
If you are sure that you want to permanently remove all stored
values, hold down the M-button (the device must have been switched
off beforehand) until «CL» appears and then release the button. To
permanently clear the memory, press the M-button while «CL» is
flashing. Individual values cannot be cleared.
Information for the doctor on frequent appearance of the
Arrhythmia indicator
This device is an oscillometric blood pressure monitor that also
analyses pulse frequency during measurement. The device is clin-
ically tested.
The arrhythmia symbol is displayed after the measurement, if pulse
irregularities occur during measurement. If the symbol appears
more frequently (e.g. several times per week on measurements
performed daily) we recommend the patient to seek medical
advice.
This device does not replace a cardiac examination, but serves to
detect pulse irregularities at an early stage.

7BP W100 EN
How not to store a reading
As soon as the reading is displayed press and hold the ON/OFF
button 1until «M» AL is flashing. Confirm to delete the reading by
pressing the M-button 5.
7. Setting the Alarm Function
This device allows you to set 2 alarm times at which an alarm signal
will then be triggered. This can be a useful aid, for instance as a
reminder to take medication.
1. To set an alarm time, press the time button 6(the device must
have been switched off beforehand) and immediately afterwards
the M-button 5and hold both down until the bell symbol AK
appears in the bottom left of the display. Then release both
buttons. The flashing «1» in the display indicates that the first
alarm time can now be set.
2. Press the time button to set the hours – the hour display flashes
and pressing the M-button allows you to set the alarm hour. To
confirm, press the time button.
3. The minute display will now flash. The minutes can be set using
the M-button. To confirm, press the time button again.
4. The bell symbol will now flash. Use the M-button to select whether
the alarm time is to be active (bell) or inactive (crossed-out bell).
To confirm, press the time button.
 To set a second alarm time, proceed as above but if the « 1 » flashes,
press the M-button to select «
2 » and confirm with the time button.
 An active alarm time is indicated by the bell symbol in the display.
 The alarm will sound at the set time every day.
 To switch-off the alarm when it is sounding, press the ON/OFF
button 1.
 To permanently switch off the alarm, proceed as above and select the
crossed-out bell symbol. This will then disappear from the display.
 The alarm times must be re-entered each time the batteries are
replaced.
8. Battery Indicator and Battery change
Low battery
When the batteries are approximately ¾ empty the battery symbol AO
will flash as soon as the device is switched on (partly filled battery
displayed). Although the device will continue to measure reliably, you
should obtain replacement batteries.
Flat battery – replacement
When the batteries are flat, the battery symbol AO will flash as soon
as the device is switched on (flat battery displayed). You cannot take
any further measurements and must replace the batteries.
1. Open the battery compartment 3by pulling off the cap.

8
2. Replace the batteries – ensure correct polarity as shown by the
symbols in the compartment.
3. To set date and time, follow the procedure described in «Section 3.».

The memory retains all values although date and time (and
possibly also set alarm times) must be reset – the year number
therefore flashes automatically after the batteries are replaced.
Use 2 new, long-life 1.5 V, size AAA alkaline batteries.
Do not use batteries beyond their date of expiry.
Remove batteries if the device is not going to be used for a
prolonged period.
Using rechargeable batteries
You can also operate this device using rechargeable batteries.
Only use «NiMH» type reusable batteries.
Batteries must be removed and recharged when the flat
battery symbol appears. They should not remain inside the
device as they may become damaged (total discharge as a
result of low use of the device, even when switched off).
Always remove the rechargeable batteries if you do not intend
to use the device for a week or more.
Batteries cannot be charged in the blood pressure monitor.
Recharge batteries in an external charger and observe the
information regarding charging, care and durability.
9. Error Messages
If an error occurs during the measurement, the measurement is inter-
rupted and an error message, e.g. «ERR 3», is displayed.
Error Description Potential cause and remedy
« ERR 1 »Signaltoo
weak
The pulse signals on the cuff are too weak.
Re-position the cuff and repeat the
measurement.*
«
ERR 2 » Error signal During the measurement, error signals were
detected by the cuff, caused for instance by
movement or muscle tension. Repeat the
measurement, keeping your arm still.
«
ERR 3 » No pressure
in the cuff
An adequate pressure cannot be generated
in the cuff. A leak may have occurred. Check
that the cuff is correctly connected and is not
too loose. Replace the batteries if neces-
sary. Repeat the measurement.
«
ERR 5 » Abnormal
result
The measuring signals are inaccurate and
no result can therefore be displayed. Read
through the checklist for performing reliable
measurements and then repeat the
measurement.*
