Micron T2252 User manual

Laser Distance Meter
User Manual

Contents
1.Use of the instrument…………………………… 1
2. Start-up………………………………………….5
3. Menu Functions…………………………………6
4. Operation………………………………………..7
5. Measuring……………………………………….8
6. Functions………………………………………..9
7. Appendix………………………………………..10
8. Technical Data…………………………………..11
9. Measuring Conditions…………………………..12
10.Accessories……………………………………..13

1
Congratulations on the purchase of this product. Carefully read
the safety instructions and the user manual before using this product. The
person responsible for the instrument must ensure that all users understand
these directions and adhere to them.
Safety Instructions
Symbols Used
The following symbols are used to distinguish precautions by the degree of
injury or damage that may result if the precaution is ignored.
Warning
Caution: Important paragraphs, which must be adhered to them.
1. Use of the instrument
a) Press to switch on the device. The laser beam emits from the
front of the meter.
b) Press again to measure the distance. The results will show on
the screen.

2
Cautions:
-Do not look straight at the laser beam
-Do not use the device in flammable and explosive environments
-Remove the batteries to avoid leakage if the device is not to be used for a
long period of time
Care
Wipe off dirt with a damp, soft cloth or a clean cloth moistened with alcohol.
Be careful with the optical components (such as optical lens): wipe with a
clean soft cloth or cotton swab moistened with distilled water (same as
cleaning glass or camera lens). Do not use aggressive cleaning agents or
solutions.
Permitted use
Measuring distances, areas and volumes
Prohibited use
-Using the instrument without instruction
-Using outside the stated limits
-Deactivation of safety systems and removal of explanatory and hazard
labels.
-Opening of the equipment by using tools (screw drivers. etc.), as far as not
specifically permitted for certain cases.

3
-Carrying out modification or conversion of the product
-Use of accessories from other manufacturers without the approval of our
company.
Limits of use
See section “Technical Data”
Responsibilities of the person in charge of the instrument
Warning:
The person responsible for the instrument must ensure that the
equipment is used correctly and is responsible for training and safety of the
equipment when in use. The person in charge of the instrument has the
following duties:
-To understand the safety instructions of the product and the instructions in
the user manual.
-To be familiar with local safety regulations relating to accident prevention
-To inform local dealer immediately if the equipment becomes unsafe.
Hazards in use
Caution：
Watch out for incorrect distance measurements. If the instrument is
defected or if it has been dropped or has been misused or modified.
Precautions:
-Carry out periodic test measurements, particularly after the instrument has

4
been subject to abnormal use, and before, during and after important
measurement.
-Make sure the optics are kept clean and undamaged
Caution:
If the instrument is used for positioning moving objects (e.g.
cranes, building equipment, platforms, etc.) unforeseen events may cause
invalid measurements
Warning:
Flat batteries must not be disposed of with household waste.
The product must not be disposed of with household waste.
Take them to the collection points provided in accordance with national or
local regulations.
Electromagnetic compatibility (EMC)
The term” electromagnetic compatibility” means the capability of the product
to function smoothly in an environment where electromagnetic radiation
and electrostatic discharges are present, and without causing
electromagnetic interference to other equipment.
Warning:
The product conformstothemoststringent requirementsoftherelevantstandardsand
regulations.Yet,thepossibilityofitcausinginterferenceinotherdevicescannotbetotally
excluded.
Caution:
Never attempt to repair the product yourself. In case of damage, contact

5
the local dealership.
Laser classification
Integrated distance meter
This product produces a visible laser beam, which emits from the front of the
instrument.
It is a class 2 laser product in accordance with:
IEC60825-1:2007 “Radiation safety of laser products” laser class 2 products:
Do not stare into the laser beam or direct it towards other people.
Warning:
Looking directly into the beam with optical aids (e.g. binoculars telescopes)
can be hazardous.
Precautions:
Do not look directly into the beam with optical aids.
C aution：
Looking into the laser beam may be hazardous to the eyes.
Precautions:
Do not look into the laser beam. Make sure the laser is aimed above or below
eye level.
2. Start-up
2-1 inserting/replacing batteries

6
1). Remove battery compartment lid and attach hand strap
2). Insert batteries
3). Close the battery compartment
Replace the batteries when the symbol flashes permanently in
the display.
Remove the batteries when the meter is not going to be used for a
long period of time to avoid the danger of corrosion
Only use alkaline or rechargeable batteries
3. Menu Functions
3-1. Changing unit of measurement
Press to turn the meter on and press and hold for a while to
change the unit of distance measurement. The following units are available:
m (meter), ft (feet), in (inch), ftin (feet-inch 1/16) or ruler
3-2 Turn on the laser
To turn the laser on, press button.
Aim the laser at a target and press button again. Display shows
measurement result.

7
Press button to clear the measurement and turn the laser off.
3-3 Screen Change
Press together to change the direction of the screen display
4. Operation
4-1 Switching the meter on/off
Press to turn the instrument and laser on. The display shows the
battery symbol until is pressed again.
Press and hold button to turn the instrument off
The instrument switches off automatically after three minutes of no activity.
4-2. Clear Button
Press button to cancel the last action. While making area or volume
measurements, each single measurement can be deleted and re-measured in
succession.
4-3 Reference Setting

8
The default reference setting is from the rear of the instrument. Press
the display will show you . Press button, will measure the
reference edge fixed to the front. The display will show you .
Press the button, the rear reference is set again.
Press the two arrowed button on the base of the meter to pull out the belt
buckle and turn it the other way round to extend the length of the device, you
can measure from the corner. Press this button , a measurement will be
extended along as the reference edge, the display will show you .
5. Measuring
5-1 Single Distance Measurement

9
Press to activate the laser. Press again to trigger the distance
measurement. The result is displayed immediately.
5-2. Continuous Measurement
Press and hold down button for 2 seconds to make continuous
measurements. Press again to stop continuous measurement.
6. Functions
6-1 Area
Press once to enter into area mode.
Press the button to take the first length measurement (e.g. length).
Press again to take the second length measurement（e.g. width）. The
result is displayed in the summary line.
6-2 Volume
Press button twice to enter into volume mode.
Press button to take the first measurement (e.g.length).

10
Press button to take the second measurement (e.g.width)
Press button to take the third measurement (e.g.height)
The volume result appears in the summary line.
7. Appendix
7-1 Message Codes
Icon
Cause
Solution
Calculation error. Signal
is too weak or too
strong, or measurement
time is too long.
Reoperation, change to a better
surface or use a target plate
Ambient light is too
strong
Change the light for measuring
Temperature is too high
(+40°C) or too low
(0°C)
Cool down or warm up the
instrument. This instrument
works best at temperatures
between 0°C to +40°C

11
Hardware error
Switch on/off the instrument
several times. If the symbol still
appears, then your instrument
may be defective. Please call
ATP Instrumentation Ltd for
assistance.
8. Technical Data
Measuring Range
0.05~30m
Measuring Accuracy
±2mm
Display Accuracy
1mm
Laser Classification
Class 2
Pollution Degree
2
Laser Type
620~690nm,<1mw 0.16x0.6 mrad,0.25s
Area, Volume Measuring
yes
Continuous Measuring
yes
Show Beep
yes
Protection against splashes and
dust
IP54
Temperature range for operation
0~40°C
Temperature range for storage
-20~70°C

12
Battery Life
5000 Measurements
Battery Selection
LR3(AAA)2x1.5v
Laser Switch-off Automatically
After 30 seconds
Instrument Switch-off
Automatically
After 3 minutes
Dimensions
118*37*25mm
Weight
70g
Max Operating Altitude:2000m: Max Relative Humidity :0~95%
Remarks：Measurement could reach 10 m in good conditions ( good measurement
surface, room temperature ).Under adverse measuring conditions, such as the light is
too strong, the measured surface reflective weakly or the temperature difference is
too large, or the deviation over distance above 10m will increase on ±0.2
mm/m.
9. Measuring Conditions
9-1 Measuring Range
The range of this meter is limited to 30m, at night or dusk and if the target is
in shadow, the measuring range without target plate is increased. Use a target
plate to increase the measurement range during daylight or if the target has
poor reflection properties.
9-2 Target Surfaces
Measuring errors can occur when measuring toward colorless liquids (e.g.

13
water) or dust free glass, Styrofoam or semipermeable surfaces. Aiming at
high gloss surfaces may deflect the laser beam and lead to measurement
errors. For non-reflective and dark surfaces the measuring time may increase.
-if the equipment is used in a manner not specified by the manufacture, the
warranty will be invalid
Care
Do not immerse the instrument in water. Wipe off dirt with a damp, soft cloth.
Do not use aggressive cleaning agents or solutions. Handle the instrument as
you would a telescope or camera.
Warranty
This instrument comes with a one-year warranty. If it is not used correctly via
this manual, the warranty will be invalid
10.Accessories
1) User’s manual
2) 1.5V AA×2 battery

14
