Microsens MS430943M Instruction manual

Module presentation
MS430943/4M family is a one slot wide FlexRate (100G/200G) module with the
following characteristics:
Two configurable 100 Gigabit Ethernet / OTU4 client port interfaces
Two operational modes:
o200G Metro Reach (MR) Transponder
o100G Ultra Long Haul (ULH) Transponder
FlexRate 200G Muxponder family is composed of 2 versions:
oDual Fiber (MS430943M)
oSingle Fiber (MS430944M)
QSFP28 modules for client port physical interfacing
Connectors are LC/PC.
The FlexRate client traffic type is 100GbE or OTU4.
MICROSENS
FlexRate Muxponder (MS430943/4M) -
Quick Start Manual

FlexRate Muxponder - Quick Start Manual
STEP 1: plugging & configuration of the module
Insert the FlexRate module
Wait until HW/SW leds on the module are green and stable. (Around 5 min)
Configuration of the module :
1/ In case of new installation: “Restore Default Config”
On Web interface -> Select the module -> Right Click -> Configuration/Start-Up
On CLI -> configure_pm -c ‘slot_number’
SAFETY WARNING: By default, the line Tx and all the client ports are “In Service”.
It means that all Tx are power on.
2/ In case of PM replacement :
On Web interface -> Tic the parameter “Automatic Config Restore” on
MGNT/Configuration menu. Wait for the Cold restart and plug the new module.
On CLI -> set_mgnt_config
Wait for the Cold restart and plug the new module.

FlexRate Muxponder - Quick Start Manual
STEP 2: Module setup
Optical connection
Connect the module on line and client side with optical patchcords.
Line side to the MUX module or Compensation Module
Client side to the respective equipment
WARNING: Line_Tx is emitting by default, so optical power will be received from
the far end module.
In order to prevent Rx damage, use LC/PC attenuator to adjust the input power,
and be as close as possible of the typical value.
Mode configuration
The FlexRate Muxponder is able to work in 200G-MR or in 100G-ULH bitrate
mode. By default, 200G-MR is select. If 100G-ULH mode is required, you need
to modify the setting:
On Web interface -> Select the module -> Right Click -> Configuration/Other
On CLI -> set_config ‘slot_number’ other
After this setting, the module will restart
Wavelength configuration
1/ TX Wavelenght for MS430943M Dual fiber use:
On Web interface -> Select the module -> Right Click -> Configuration/X1-Line1

FlexRate Muxponder - Quick Start Manual
On CLI -> set_config ‘slot_number’ X1-Line1
2/ Tx/Rx Wavelength for MS430944M Single Fiber use:
The MS430944M module has a different wavelength on TX and on Rx line
side to allow the single fiber transmission mode.
On Web interface -> Select the module -> Right Click -> Configuration/X1-Line1
On CLI -> set_config ‘slot_number’ X1-Line1
DCC channel configuration (if necessary)
On Web interface -> Select the module -> Right Click -> /Configuration/Start-
Up/Line
On CLI -> set_config ‘slot_number’ other

FlexRate Muxponder - Quick Start Manual
Label the Client and the Line ports to make easier their identification
On Web interface -> Select the module -> Right Click -> Configuration/Qi-
Client#i (and Configuration/X1-Line1)
On CLI -> set_config ‘slot_number’ Q1-Client1 (for client1) / set_config
‘slot_number’ X1-Line1
For unused client, it is recommended to set the client port(s) “Out Of Service”
to not interfere with the management of the port(s) in service.
Client traffic type
Client physical interfacing is done through standard QSFP28 modules. Client
traffic type can be set in 100 Gigabit Ethernet or in OTU4.
On Web interface -> Select the Client -> Right Click -> /Configuration/Qi-
Client#i
On CLI -> set_config ‘slot_number’ Q1-Client1 (for client1)

FlexRate Muxponder - Quick Start Manual
Configuration of the line output power (MS430944M only)
For MS430944M module, the output power of the line can be modulate in the
range [-25dBm;+3dBm] -> Default value is 0dBm.
For MS430943M output power value, you can refer to the table in STEP 3.
On Web interface -> Select the Line -> Right Click -> Configuration/X1-Line1
On CLI -> set_config ‘slot_number’ Q1-Client1 (for client1) / set_config
‘slot_number’ X1-Line1
STEP 4: End of installation
Leds status
Verify that all the led are green or unlighted (in case of port Out Of service).
Alarms status
Check that no alarm is present on line side and on each client In Service.
On Web interface -> Select the module -> Right Click -> Alarm (for Qi-Client#i
and X1-Line1)
On CLI -> get_alarm ‘slot_number’ S1-Client1 (for client1 and Line)

FlexRate Muxponder - Quick Start Manual
Power Monitoring
Check that input/output power on line side and on each client In Service and
verify it is in the correct range.
Adjust the input power if necessary with LC/PC attenuator, in order to be as
close as possible of the typical value.
(See following table for module characteristics)
On Web interface -> Select the module -> Right Click -> Monitoring/Counters
(for Qi-Client#i and X1-Line1)
On CLI -> get_measurement ‘slot_number’ X1-Line1 (for Line)
Remote Network Monitoring (Rmon) on Ethernet client
Open the Monitoring window to display the counters of the Ethernet traffic on
each port In Service. Check no error is present.
On web interface -> Select the module -> Right Click -> Rmon (for Qi-
Client#i)
On CLI -> get_counters ‘slot_number’ Q1-Client1 (for client1)

FlexRate Muxponder - Quick Start Manual
FEC Correction rate
Verify on Line side the Pre-SD FEC Errors rate.
1/200G Mode
This should be below <1x10-2 to assure a proper transmission without
uncorrected errors
2/100G Mode
This should be below <1x10-3 to assure a proper transmission without
uncorrected errors
On Web interface -> Select the module -> Right Click -> Monitoring/Counter
On CLI -> get_counters ‘slot_number’ X1-Line1
