Microtek NDT-2000 Operation instructions

I49-005438 A
Assemble the Multi-Channel Film Feeder (MFF) with the Digitizer
Before using the Multi-channel Film Feeder (MFF) with your digitizer, you need to mount it onto the digitizer. Follow the
instructions and graphs belows to assemble the MFF correctly.
Securing the Back Support
After the Base Tray has been installed on the digitizer, please
follow the steps below to lock two Back Supports at the back
of the Base Tray.
To lock the rst Back Support:
1. Look for the side with a soft pad of the Back Support and
put it facing down towards the top of the digitizer.
2. Lean the other side with a groove of the Back Support on
the back of the Base Tray, making sure the bottom of the
groove on the Back Support match with the bottom of the
groove on the Base Tray.
Accessories in the Box
Check for the major components listed here.
Installing the Base Tray
1) Look for two sets of the Feed Tray Holes at both ends of
the front-top of the digitizer.
2) Insert and push down both sides of the Base Tray into its
compartment holes, making sure the Base Tray snaps into
place.
Base Tray
Quick-lock Nuts
Multi-channel Film Tray
Back Supports
Film-rolling
Rack
Screw & Washer Sets
Feed Tray Holes
Base Tray
3. Insert one set of Screw & Washer through the bottom
groove of the Back Support; then, screw one Quick-lock
Nut on the set clockwise. Follow the step here to lock
the top Quick-lock Nut on the Base Tray and the Back
Support.
4. Follow the step 1 to 3 to secrue another Back Support on
the back of the Base Tray.
Screw &
Washer
Quick-lock Nut
Match up the bottom
groove of the Back
Support with the
bottom groove of the
Base Tray.
MFF Mask Kit

NOTE: For how to use the Multi-channel Film Feeder (MFF) with the digitizer and software in details, refer to the user's
manual on the CD/DVD in your digitizer package.
Hanging the Multi-channel Film Tray
over the Base Tray
1. Hold up both sides of the Multi-channel Film Tray carefully,
locate the hooks at the back of the Multi-channel Film
Tray and then use them to hang the Multi-channel Film
Tray over the top of the Base Tray gently.
2. Pleas take note that when hooking up the Multi-channel
Film Tray over the Base Tray, make sure that the hooks
at the back of the Multi-channel Film Tray have been
attached to the pads located at the top of the Base Tray.
Pads at the top
of the Base Tray
Hooks at the back
of the Multi-channel
Film Tray
Installing the Film-rolling Rack
1. Hold up both sides of the Film-rolling Rack carefully and
locate two slots at the bottom sides of the Film-rolling
Rack.
2. Locate two shafts at both sides of the Multi-channel Film
Tray; then, snap the slots at the bottom of the Film-rolling
Rack into the shafts of the Multi-channel Film Tray.
3. When done, fasten Quick-lock Nuts clockwise to each
shaft to secure the Film-rolling Rack at the top of the
Multi-channel Film Tray.
Shafts at both sides of
the Multi-channel Film
Tray
Slots at the bottom
sides of the Film-
rolling Rack
Fasten the Quick-lock
Nut to each shaft of
the Multi-channel Film
Tray.
