FlexView™
FVS IFP Series Fixed
Instruction Sheet
PRODUCT FEATURES
Thank you for purchasing the FlexView™ FVS IFP series fixed height cart. Please read these
instructions thoroughly before installing this product.
THANK YOU
• Middle Atlantic PD-815SC (8) outlet, 15 amp power strip with surge and circuit breaker
• Simple display mounting with manual adjustment of display height
• Lever Lock™ for easy mounting of codecs and smaller components
• Adjustable cable management included
I-00871 Rev -
GROUNDING INSTRUCTIONS / INSTRUCTIONS DE MISE À LA TERRE
Page 2
Grounding Pin
Grounded
Outlet
Grounded
Outlet Box
Metal
Screw
Adapter
Tab For
Grounding Screw
(A) (B) (C)
This product must be grounded. If it should malfunction or breakdown, grounding provides a
path of least resistance for electric current to reduce the risk of electric shock. This product is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Ce produit doit être mis à la terre. En cas de dysfonctionnement ou de panne, la terre fournit
un chemin de moindre résistance au courant électrique afin de réduire le risque de choc électrique.
Ce produit est équipé d'un cordon muni d'un conducteur de terre et d'une fiche de mise à la terre.
La fiche doit être branchée dans une prise appropriée qui est correctement installé et mis à la terre
conformément à tous les codes et ordinaces locales.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of electric
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the product is
properly grounded. Do not modify the plug provided with the product - if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
DANGER : un mauvais branchement du conducteur de terre de l'équipement peut entraîner un
risque de choc électrique. Consultez un électricien qualifié si vous avez des doutes quant à savoir
si le produit est correctement mise à la terre. Ne pas modifier la fiche fournie avec le produit. Si
elle ne rentre pas dans la prise, installer une prise adéquate par un électricien qualifié.
This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug
illustrated in sketch A. Make sure that the product is connected to an outlet having the same
configuration as the plug. No adapter should be used with this product.
Ce produit est destiné à être utilisé sur un circuit de 120 volts et a une fiche de terre qui ressemble
à la fiche illustrée par le croquis A. Assurez-vous que le produit est connecté à une prise ayant la
même configuration que la fiche. Aucun adaptateur ne doit être utilisé avec ce produit.
IMPORTANT SAFETY INSTRUCTIONS / INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ
WARNING
Can tip over resulting
in risk of injury.
Do not allow children under
16 to move cart.
Move Cart Slowly.
Push, do not pull.
Only adults should
move this unit.
DO NOT REMOVE
Apply moving force
on narrow dimension.
Never apply force at top,
always push near middle.
ATTENTION
Peut basculer et entraîner des
risques de blessures . Ne pas
laisser des enfants de moins de
16 ans utiliser le chariot.
Déplacer le chariot lentement.
Ne pas tirer,
mais pousser.
Cet appareil doit étre
déplacé uniquement
NE PAS ENLEVER
Ne jamais appliquer une
force dans la partie
par des adulties.
Appliquer une force
d’entraînement sur
la partie étroite.
supérieure, toujours
pousser vers le milieu.
Page 3
WARNING/CAUTION! The exclamation point within an
equilateral triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature accompanying the
appliance
AVERTISSEMENT/ATTENTION! Le point d'exclamation
dans un triangle équilatéral est destiné à alerter l'utilisateur
de la présence d'importants instructions d’opération et de
maintenance (entretien) dans la documentation
accompagnant l'appareil.
!
!
WARNING! Failure to read, understand and follow the
following information can result in serious personal injury,
damage to the equipment or voiding of the warranty. It is
the responsibility of the Installer/User to ensure
that this product is loaded according to specifications.
AVERTISSEMENT! Refus de lire, comprendre et suivre
la renseignements suivants peut traduire par de graves
blessures, des dommages à l'équipement ou invalider la
garantie. Il est la responsabilité de l'installateur / utilisateur
de s'assurer que ce produit est chargé conformément aux
spécifications.
AVERTISSEMENT! Les caractéristiques de poids de ce
produit peuvent être trouvées sur le produit. Le
dépassement de ces caractéristiques de poids peut
entraîner des blessures graves ou des dommages
à l'équipement. C'est l'responsabilité de l'installateur /
utilisateur de s'assurer que les composants installé ne
dépassent pas les notes de poids comme un instable
condition peut se produire qui peut causer des blessures
ou dommages.
!
!!
!
CAUTION! To avoid an unstable condition, place heavier
components at the bottom of the cabinet. When more than
one component is placed in the cabinet, begin at the
bottom of the cabinet and place equipment at the lowest
available point, evenly distribute weight (vertically) within
the cabinet.
ATTENTION! Pour éviter une condition instable, placer
des composants plus lourds dans le bas de l'armoire.
Lorsque plus d'un composant sera placé dans l'armoire,
commencez en bas de l'armoire, placent l'équipement sur
le point le plus bas disponible, distribuant uniformément le
poids (verticalement) dans l l'armoire.
!
!
WARNING! The weight ratings of this product can be
found on the product. Exceeding these weight ratings can
result in serious injury or damage to the equipment. It is the
responsibility of the Installer/User to ensure the components
installed do not surpass the weight ratings as an unstable
condition can occur which may cause possible injury or
damage.
IMPORTANT SAFETY INSTRUCTIONS
Page 4
When using an electrical furnishing, basic precautions should always be followed, including the
following:
• For institutional use.
• Read and follow all instructions before using.
• WARNING – Death or serious injury may occur when children climb on audio and/or video equipment furniture.
A remote control or toys placed on the furnishing may encourage a child to climb on the furnishing and as a result the
furnishing may tip over on the child.
• WARNING – Relocating audio and/or video equipment to furniture not specifically designed to support audio and/or
video equipment may result in death or serious injury due to the furnishing collapsing or over turning onto a child.
• DANGER – To reduce the risk of electrical shock:
Always unplug this furnishing from the electrical outlet before cleaning.
• WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
1. Unplug from outlet before putting on or taking off parts.
2. Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled persons.
3. Use this furnishing only for its intended use as described in these instructions. Do not use attachments not
recommended by the manufacturer.
4. Never operate the furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the furnishing to a service center for examination and repair.
5. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
6. Keep the cord away from heated surfaces.
7. Never operate the furnishing with the air openings blocked. Keep the air openings free of lint, hair, and the like.
8. Never drop or insert any object into any opening.
9. Do not use outdoors.
10. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
11. To disconnect, turn all controls to the off position, then remove plug from outlet.
12. For chairs and similar furnishings with movable parts such as foot supports the following statement:
WARNING: Risk of Injury – Keep children away from extended foot support (or other similar parts).
13. WARNING: Risk of Electric Shock – Connect the furnishing to a properly grounded outlet only.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
14. For loading always put heavier items at the bottom and not near the top in order to help prevent the possibility of the
furnishing tipping over.
15. Each surface is intended to support a load shall have a corresponding statement in the use instructions specifying the
maximum intended load for the surface in pounds and (kilograms).
16. WARNING: The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus"
17. The mains plug is used as your disconnect device. This device shall remain readily operable.
18. Clean only with dry cloth.
19. Unplug this apparatus during lightning storms or when unused for long periods of time.
20. Only use attachments/accessories specified by the manufacturer.
21. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
SAVE ALL INSTRUCTIONS
INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ
Page 5
Lorsque vous utilisez des mobiliers électriques, toujours respecter les précautions de base, notamment :
• Usage institutionnel.
• Lire et suivre toutes les instructions avant l'utilisation du matériel.
• AVERTISSEMENT - Des blessures graves ou mortelles peuvent survenir si un enfant grimpe sur le meuble d'un
équipement audio ou vidéo. Une télécommande ou un jouet placé sur le meuble peut encourager un enfant à grimper
dessus et conduire à la chute du meuble sur ce dernier.
• AVERTISSEMENT - Le transfert d'un équipement audio ou vidéo sur un meuble qui n'a pas été spécialement conçu
pour soutenir un équipement audio ou vidéo peut entraîner l'effondrement ou le basculement du meuble sur un enfant
et provoquer des blessures graves ou mortelles.
• DANGER - Pour réduire le risque de choc électrique :
Toujours débrancher le meuble de la prise électrique avant de le nettoyer.
• AVERTISSEMENT - Pour réduire les risques de brûlures, d'incendie, de choc électrique ou de blessures :
1. Débrancher de la prise électrique avant d'installer ou de retirer des pièces.
2. Surveiller étroitement ce meuble s'il est utilisé par ou à proximité d'un enfant, d'une personne invalide ou handicapée.
3. N'utiliser ce meuble que pour l'usage auquel il est destiné, tel que décrit dans la présente fiche d'instructions. Ne pas
utiliser d'accessoires non recommandés par le fabricant.
4. Ne jamais utiliser ce meuble si le cordon ou la prise est endommagé, s'il ne fonctionne pas correctement, s'il est
tombé ou est endommagé, ou s'il est tombé dans l'eau. Renvoyer le meuble à un centre de service après-vente pour
qu'il soit examiné et réparé.
5. Le cordon d'alimentation doit être placé de manière à éviter qu'il soit piétiné ou pincé, notamment au niveau des
prises, des réceptacles et à la sortie de l'appareil.
6. Garder le cordon d'alimentation loin des surfaces chauffées.
7. Ne jamais utiliser le meuble si des ouvertures d'air sont obstruées. Veiller à ce que les ouvertures ne soient jamais
obstruées par de la peluche, des cheveux ou tout autre élément.
8. Ne jamais faire tomber ou introduire un objet dans une ouverture.
9. Ne pas utiliser en extérieur.
10. Ne pas utiliser dans des lieux où des produits aérosols sont utilisés ou à proximité d'une source d'oxygène.
11. Pour débrancher, placer tous les boutons en position off, puis retirer la fiche de la prise électrique.
12. Les chaises et meubles similaires dotés de pièces mobiles comme les repose-pieds doivent être accompagnés de la
déclaration suivante :
AVERTISSEMENT : Risque de blessure - Ne pas laisser les enfants s'approcher d'un repose-pied tiré (ou toute autre
pièce similaire).
13. AVERTISSEMENT : Risque de choc électrique - Brancher le meuble uniquement à une prise correctement mise
à la terre. Ne pas détériorer le dispositif de sécurité de la fiche polarisée ou de la fiche de terre. Une fiche polarisée
possède deux broches, dont l'une plus large que l'autre. Une fiche de type terre possède deux broches et une
troisième de mise à la terre. La broche large ou la troisième fiche sont fournies pour des raisons de sécurité. Si la
fiche fournie n'entre pas dans votre prise de courant, veuillez faire appel à un électricien pour remplacer la prise
obsolète.
14. Les objets les plus lourds doivent toujours être placés dans la partie inférieure du meuble, et non pas dans la partie
supérieure, afin d'éviter tout risque de basculement du meuble.
15. Chaque surface est destinée à soutenir une charge spécifique et sera accompagnée d'une déclaration dans la fiche
d'instructions spécifiant la charge maximale prévue pour cette surface en livres et en (kilogrammes).
16. AVERTISSEMENT : L' appareil ne doit pas être exposé à des éclaboussures et aucun objet rempli de liquide,
comme des vases , ne doit être placé sur l'appareil "
17. La fiche secteur est utilisée comme sectionneur de courant. Ce dispositif doit rester en état de marche.
18. Nettoyer uniquement avec un chiffon sec.
19. Débrancher cet appareil pendant les orages ou s'il n'est pas utilisé pendant de longues périodes.
20. Utiliser uniquement les pièces/accessoires indiqués par le fabricant.
21. Confier toutes les réparations à un personnel qualifié. Une réparation s'impose lorsque l'appareil a été endommagé
d'une manière quelconque, par exemple en cas d'endommagement du cordon d'alimentation ou de sa fiche, de
renversement de liquide ou de chute d'objets à l'intérieur, d'exposition à la pluie ou à l'humidité, de dysfonctionnement
ou de chute de l'appareil.
CONSERVER CES INSTRUCTIONS
Page 6
WEIGHT RATINGS
ITEM
Display
Display (Including Camera Mount and Soundbar Mount)
Internal
Total Rated Load
DETAILS
300 lbs. (136.1 kg) Maximum
320 lbs. (145.2kg)
Maximum
50 lbs. (23 kg) Maximum
370 lbs. (168 kg) Maximum
WARNING - This cart is intended for use only with the products and maximum
weights indicated. Use with other products or products heavier than the
maximum weights indicated may result in instability causing possible injury.
Total equipment weight must not exceed 370 lbs (168 kg).
DISPLAY MAXIMUM: 300 LBS (136.1KG)
CAMERA MAXIMUM: 20LBS (9.1KG)
SOUNDBAR MAXIMUM: 20LBS (9.1KG)
AVERTISSEMENT - Ce chariot a été spécifiquement conçu pour les produits et
le poids maximal indiqués. En cas d'utilisation avec d'autres produits ou des
produits plus lourds que le poids maximal indiqué, le chariot peut devenir
instable et causer des blessures. Le poids total de l'équipement ne doit pas
dépasser 168 kg (370 lbs).
• #2 Phillips Screwdriver
• 3/8 Hex Wrench or Socket
• Protective Eyewear
• (4) directional locking casters are supplied
to allow easy “steering” of unit in locked direction.
Page 7
MOBILITY FEATURES
TOOLS REQUIRED
To prevent FlexView from
moving, lock casters
perpendicular to each
other as shown
NOTE: Push levers to lock, lift levers to unlock.
WARNING: Use tools with caution and follow all necessary safety protocols.
AVERTISSEMENT: Utiliser des outils avec prudence et suivre tous les protocoles de sécurité
nécessaires.
OPTIONAL LEVELING FEET
For xed location installations, Middle Atlantic Products
oers a leveling foot kit FVS-LEVELERS-4 to replace the
supplied casters.
NOTE: Additional hardware is included
that may not be required for your installation.
Page 8
SUPPLIED COMPONENTS AND HARDWARE
Thread Depth Indicator
(Qty 1)
5/16” Flat Washers
(Qty 10)
M5 x 12 (Qty 8)
M6 x 12 (Qty 8)
M4 x 16 (Qty 8)
(Qty 6)
M5 x 16
(Qty 6)
M5 x 20
M6 x 20 (Qty 6)
M8 x 20 (Qty 6)
(Qty 4)
M4 x 25
(Qty 4)
M5 x 25
M8 x 25 (Qty 6)
M8 x 30 (Qty 6)
M8 x 35 (Qty 4)
(Qty 8)
M5 x 50
M8 x 70 (Qty 4)
Universal Washers
(Qty 8)
Level
(Qty 1)
1/4” Large Nylon Spacers
(Qty 6)
1/2” Large Nylon Spacers
(Qty 12)
1” Nylon Spacers
(Qty 6)
1/4” Small Nylon Spacers
(Qty 6)
Nylon Spacers
(Qty 4)
1/2” Small Nylon Spacers
(Qty 6)
5/16”-18 Hex Head
Display Mount Bolts
(1/2” Socket Req’d)
(Qty 4)
Keys (Qty 2)
FLAT PANEL MOUNTING HARDWARE
Plastic Lever Lock™
Locking Rivets (Qty 3)
#6 Washers For Mounting
Small-Screw Components
To Lever Lock™ (Qty 20)
Cable Management Clips (Qty 8)
Pan Head Wood Screws (Qty 8)
(NOT REQUIRED FOR
MOTORIZED UNITS)
Wire Ties (Qty 12)
Display Mounting Brackets (Qty 2)
Pan Head Screws 8-32 (Qty 8)
Page 9
DOOR REMOVAL
1. Pull latch on bottom door panel, tilt and lift off to expose rear component and storage compartment.
(FIGURE A)
2. To reinstall, hook the bottom of door panel tilt up and latch panel in place. For equipment security,
door panel can also be locked.
FIGURE A
DISPLAY ARM ADJUSTMENT
NOTE: Fixed cart is designed to provide 20” of display adjustment in 2” increments.
Lowest postion being 40” from the ground and highest being 60” from the ground.
To adjust display arm to desired height:
1. With back door panel removed, unscrew and remove (6) 1/4-20 bolts (4 short & 2 long), spacers,
hex nuts and display arm. (FIGURE B)
2. Remove 2 pre-installed hole grommets. (FIGURE B)
FIGURE B
Hole Grommets
Page 10
