Middle Atlantic MPR-A Series User manual

I-00632 Rev D
MPR-A SERIES
SERIES PROTECTION MODULES
Instruction Sheet
Thank you for purchasing the MPR-A Series Protection Module. Please read these instructions
thoroughly before installing this product.
- Non-sacrificial surge technology protects equipment without compromising system ground
- No MOVs or other degrading parts
- Thermal circuit breaker overload protection
- Advanced EMI/RFI filtering
RLM-15A-SP SHOWN
Control Status
Activation
Momentary Maintained ON
OFF
AUTO
SERIES PROTECTED AND CONTROLLED
15 AMP MODULE
120V - 12A - 60Hz
RLM-15A-SP
Conforms to UL Standard
1449
Certified to CSA Standard
C22.2 No. 8
OUTPUT
Normally Closed Normally Open
RESET
U.S. Patent No. 8,947,844

Page 2
DANGER HAZARDOUS VOLTAGE/DANGER HAUTE
TENSION
The lightning flash with the arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
L'éclair avec le symbole de flèche dans un triangle
équilatéral est destiné à alerter l'utilisateur de la présence
d'une tension dangereuse non isolée dans l'enceinte du
produit qui peut être d'une ampleur suffisante pour constituer
un risque de choc électrique pour les personnes.
CAUTION/ATTENTION
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
Le point d'exclamation dans un triangle équilatéral est
destiné à alerter l'utilisateur de la présence d'importants
instructions d’opération et de maintenance (entretien) dans la
documentation accompagnant l'appareil.
READ AND SAVE THESE INSTRUCTIONS!
CONSERVER CES INSTRUCTIONS!
• To reduce risk of shock , disconnect the device from the power source before
servicing any connected equipment
Pour réduire les risques d'électrocution, débranchez l'appareil de la source
d'alimentation avant l'entretien de tout équipement connecté
• Do not overload this device. Ensure the total load to this device does not
exceed that which is listed in the specifications section of this manual
Ne pas surcharger cette appareil. S'assurer que la charge totale à cet
appareil ne dépasse pas celle qui est répertoriée dans la section des
spécifictions de ce manuel
• To be used indoors in a dry location only
Pour être utilisé en intérieur dans un endroit sec seulement
• Do not operate with a damaged cord or plug
Ne pas faire fonctionner avec un cordon ou une prise endommagée
• Clean only with dry cloth
Nettoyer avec un chiffon sec seulement
The product meets the requirements of the following standards:
• UL Standard 1449
• CSA-C22.2 No. 8
FCC CLASS A
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. Modifications not expressly approved by the manufacturer could void the user's authority to operated the
equipment under FCC rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
REGULATORY COMPLIANCE
IMPORTANT SAFETY INSTRUCTIONS

Page 3
THE RECEPTACLES RECEIVE POWER VIA THE CONTROL CIRCUITS UNDER THE FOLLOWING CONDITIONS:
A) The AUTO-OFF-ON switch is in the ON position.
B) The AUTO-OFF-ON switch is in the AUTO position with the NORMALLY OPEN/CLOSED control selector switch in the
NORMALLY OPEN position and there is a contact closure on the remote control terminal block.
C) The AUTO-OFF-ON switch is in the AUTO position with the NORMALLY OPEN/CLOSED control selector switch in the
NORMALLY CLOSED position and there is no contact closure on the remote control terminal block.
CONTACT CLOSURE OPERATION
The customer provided contact closure connected to remote control terminal block, can be either momentary or maintained.
The MOMENTARY/MAINTAINED selector switch must be in the proper position. The terminal block control closure is
ignored when the AUTO-OFF-ON switch is in the ON or OFF position.
MOMENTARY OPERATION
A contact closure is required for the control PCB to process the control signal. Each subsequent closure will alternately turn off
and on the power to the controlled receptacles.
MAINTAINED OPERATION
With the NORMALLY OPEN/CLOSED switch in the NORMALLY OPEN position, a maintained contact closure will energize the
receptacles. When this maintained contact is removed, the receptacles will become de-energized. With the NORMALLY
OPEN/CLOSED switch in the NORMALLY CLOSED position, a maintained contact closure will de-energize the receptacles.
When this maintained contact is removed, the receptacles will become energized.
CONTROLLED OUTLET TERMINAL BLOCK
The Controlled Outlet Terminal Block provides status of outlets via a dry contact. The CLOSED position indicates the
receptacles are energized, while the OPEN position indicates that the receptacles are de-energized.
FUNCTIONALITY

Control Status
Activation
Momentary Maintained ON
OFF
AUTO
SERIES PROTECTED AND CONTROLLED
15 AMP MODULE
120V - 12A - 60Hz
RLM-15A-SP
Conforms to UL Standard
1449
Certified to CSA Standard
C22.2 No. 8
OUTPUT
Normally Closed Normally Open
RESET
Page 4
RLM-15A-SP SHOWN
CONNECTIONS, CONTROLS AND INDICATORS (RLM SERIES)
123
4
5
967
8
1
2
3
4
5
6
7
8
9
DUPLEX RECEPTACLE: All Modules contain one duplex receptacle.
15A Models - (NEMA 5-15R)
20A Models - (NEMA 5-20R)
‘MOMENTARY’ or ‘MAINTAINED’ control selection switch.
CONTROL STATUS LED: Green LED indicates receptacles are ON.
CONTROL SWITCH: ‘AUTO-OFF-ON’ (Factory Position OFF).
CONTROL STATUS LED: Yellow LED indicates control switch is on AUTO.
SURGE STATUS: Provides remote notification of surge status (customer provided closure).
REMOTE CONTROL TERMINAL BLOCK: This terminal block will activate the receptacle with a
dry contact closure (customer provided closure). The control power is provided by the modules’
internal 12V DC power supply.
‘NORMALLY OPEN’ or ‘NORMALLY CLOSED’ control selection switch.
CIRCUIT BREAKER: Press to reset if the circuit breaker trips.

Page 5
M-15A-SP SHOWN
CONNECTIONS, CONTROLS AND INDICATORS (M SERIES)
1
2
DUPLEX RECEPTACLE: All Modules contain one duplex receptacle.
15A Models - (NEMA 5-15R)
20A Models - (NEMA 5-20R)
CIRCUIT BREAKER: Press to reset if the circuit breaker trips.
SERIES PROTECTED
15 AMP MODULE
120V - 12A - 60Hz
M-15A-SP
RESET
Conforms to UL Standard
1449
Certified to CSA Standard
C22.2 No. 8
2
1

Page 6
1) Insert the flange on the module into the raceway. (FIGURE A)
2) Place the module into raceway. (FIGURE B)
3) Screw the module to the raceway (FIGURE C).
USE A HAND-HELD SCREWDRIVER AND DO NOT OVERTIGHTEN
FIGURE C
FIGURE A
FIGURE B
INSTALLATION OF MODULE TO RACEWAY

Page 7
INSTALLATION OF MODULE TO RACEWAY
Please note that there is a separate input and output for this module. The bottom of the circuit
board is shown below denotes the input/output.

Page 8
WARRANTY
Middle Atlantic Products (the "Company") warrants the Series Protection Module to be free from defects in material or workmanship under normal use and conditions for a period of three (3) years from the
date of shipment by the company.
The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and exclusive remedy, under this warranty shall be limited, at the Company's option, to either (a) return of and
refund of the price paid for, or (b) repair or replacement at the Company's factory of the products purchased, or any part or parts thereof, which the Company has determined to be defective after inspection
thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by parties other than the Company, or any modification or alteration of the products. In addition, this warranty
does not cover damage due to improper handling, assembly, installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE
OF THE PRODUCTS PURCHASED, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER (OR ANY OTHER
PARTY) HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS PAID TO THE COMPANY.
Corporate Headquarters Middle Atlantic Canada Factory Distribution
Corporate Voice 973-839-1011 - Fax 973-839-1976 Voice 613-836-2501 - Fax 613-836-2690 USA: NJ - CA - IL Canada: ON - BC
International Voice +1 973-839-8821 - Fax +1 973-839-4982 middleatlantic.ca - [email protected]
WARRANTY
