Midea MLE27N5AWWC Manual

Dryer
version A
USER MANUAL &
INSTALLATION
INSTRUCTIONS
Warning:
Before using this product,
please read this manual carefully
and keep it for future reference.
The design and specifications
are subject to change without
prior notice for product
improvement. Consult with your
dealer or manufacturer for
details.
Power supply: 240V
Frequency: 60 Hz
MODEL NUMBER
MLE27N5AWWC
www.midea.com/ca
en

Dear user
THANK YOU and CONGRATULATIONS on your purchase of
this high-quality Midea product. Your Midea dryer is designed
for reliable, trouble-free performance. Please take a moment to
register your new dryer.
Register your new dryer at
www.midea.com/ca/support/Product-registration
For future reference, record your product model and serial
numbers located on the inside frame of the dryer.
Model Number________________________________________
Serial Number_________________________________________
SAFETY AND PRECAUTIONS.......................................................... 4
INSTALLATION REQUIREMENTS....................................................
INSTALLATION INSTRUCTIONS
8
........................................................
Important to installer...............................................................................8
Basic requirements ................................................................................. 8
Location requirements .......................................................................... 8
Drain system ............................................................................................10
12
14
14
Control panel ........................................................................................... 21
Removing from the package ............................................................
Parts identification ................................................................................
Electrical requirements
Grounding .................................................................................................
Replacement parts and accessories
Tools required ......................................................................................... 16
15
15
Installation steps.....................................................................................
Filter clean ...............................................................................................
17
DRYER USE ......................................................................................
Drying a load of laundry...................................................................... 23
27
Special laundry tips ..............................................................................29
.........................................................................
................................................
15
21

DRYER CARE ................................................................................... 30
Care and maintenance ........................................................................ 30
3
BEFORE YOU CALL FOR SERVICE .............................................. 31
Error codes .............................................................................................. 33
WARRANTY.....................................................................................34
PRODUCT REGISTRATION............................................................ 36
READ AND KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE
This manual c ontains important information on the installation, use,
and care of your appliance. Please read this manual carefully before
installation and operation of this machine to prevent injury and property
damage.
Warnings and Important Safety Instructions in this manual DO NOT
cover all possible conditions and situations that may occur. It is your
responsibility to use common sense, caution and care when installing,
maintaining and operating your washer.
CAUTION
RISK OF FIRE!
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

4
SAFETY AND PRECAUTIONS
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY
IMPORTANT
To prevent injury to the user or other people and property damage, the
instructions shown here must be followed. Incorrect operation due to
ignoring of instructions may cause harm or damage, including death.
The level of risk is shown by the following indications.
CAUTION
WARNING
This indicates that hazards or unsafe practices may cause
minor personal injury or property damage.
This indicates that hazards or unsafe practices may cause
serious personal injury or death.
To reduce the risk of fire, explosion, electric shock or personal
injury when using your washing machine, these basic safety
precautions SHOULD be followed.
For your safety the information in this manual must be followed to
minimize the risk of fire or explosion, or to prevent property damage,
personal injury or death.
WARNING
•
•
Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the following:
WARNING
•
•
•
•
Read all instructions before using the appliance.
Use this appliance only for its intended purpose as described in this
Owner’s Manual.
Before use, the dryer must be properly installed as described in this
manual.
ALWAYS follow the fabric care instructions supplied by the garment
manufacturer.
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

5
•
•
•
•
•
•
•
•
Do not dry articles that have been previously cleaned in, washed in,
soaked in, or spotted with gasoline, dry-cleaning solvents, other
flammable or explosive substances as they give off vapors that could
ignite or explode.
Do not use the dryer to dry clothes which have traces of any
flammable substance, such as vegetable oil, cooking oil, machine oil,
flammable chemicals, thinner, etc., or anything containing wax or
chemicals, such as mops and cleaning clothes. Flammable substances
may cause the fabric to catch fire by itself.
Do not store or use gasoline or other flammable vapors and liquids
near this or any other appliance.
Do not allow children to play on or in the appliance. Close supervision
of children is necessary when the appliance is used near children.
Before the appliance is removed from service or discarded, remove
the lid of the washing or door of the drying compartment.
Do not reach into the appliance if the drum is moving.
Do not install or store this appliance where it will be exposed to the
weather or freezing temperatures.
Do not tamper with the controls.
Do not repair or replace any part of the appliance or attempt any
servicing unless it is specifically recommended in the user-maintenance
instructions or in published user-repair instructions that you understand
and have the skills to carry out.
Keep the area underneath and around your appliances free of
combustible materials (lint, paper, rags, etc.), gasoline, chemicals and
other flammable vapors and liquids.
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical reaction
that could cause a load to catch fire. To reduce the risk of fire due to
contaminated loads, the final part of a tumble dryer cycle occurs
without heat (cool down period). Avoid stopping a tumble dryer
before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
Turn off the water faucets and unplug the washer if the machine is to
be left for an extended period of time, such as during vacations.
Packaging material can be dangerous for children. There is a risk of
suffocation! Keep all packaging from children.
Always check the inside of the dryer for foreign objects before
loading laundry. Keep the door closed when not in use.
Do not use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or product.
Clean the lint screen before or after each load.
Keep the area around the exhaust opening and surrounding areas free
from lint, dust, and dirt.
The interior of the dryer and exhaust duct should be cleaned
periodically by qualified service personnel.
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical reaction
that could cause a load to catch fire.
•
•
•
•
•
•
•
•
•
•
•
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

To reduce the risk of fire or explosion
WARNING
6
•
•
•
Do not dry items that have been previously cleaned, washed, soaked,
or spotted with gasoline, dry cleaning solvents, or other flammable or
explosive substances. They emit vapors that could ignite or explode.
Any material that has been in contact with a cleaning solvent or
flammable liquids or solids should not be placed in the dryer until all
traces of these flammable liquids or solids and their fumes have been
removed.
There are many highly flammable items used in homes, such as
acetone, denatured alcohol, gasoline, kerosene, some liquid household
cleaners, some spot removers, turpentine, waxes, and wax removers.
Do not dry items containing foam rubber (may be labeled latex foam)
or similarly textured rubber-like materials on a heat setting. Heated
foam rubber materials can under certain circumstances, produce fire
by spontaneous combustion.
This appliance must be grounded. See “Electric requirements” and
“Grounding” in the “INSTALLATION REQUIREMENTS” section.
This appliance must be properly grounded. Never plug the power
cord into a receptacle that is not grounded adequately and in
accordance with local and national codes. Refer to installation
instructions for grounding this appliance.
Ensure pockets are free from small irregularly shaped hard objects
and foreign material, i.e. coins, knives, pins, etc. These objects could
damage your dryer.
Do not use heat to dry articles containing foam rubber or similarly
textured rubber-like materials.
•
•
•
•
CAUTION
Do not sit on top of the dryer.
Because of continuing product improvements, Midea America
reserves the right of change specifications without notice. For
complete details, see the Installation Instructions packed with your
product before selecting cabinetry, making cutouts, or beginning
installation.
Do not dry clothing with large buckles, buttons, or other heavy metal
or solid things.
Install and use in accordance with the manufacturer’s instructions.
Do not place items in your dryer that have been spotted or soaked
with vegetable oil or cooking oil. Even after being washed, these items
may contain significant amounts of these oils.
•
•
•
•
SAVE THESE INSTRUCTIONS
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

WARNING
•
•
Residual oil on clothing can ignite spontaneously. The potential for
spontaneous combustion increases when items containing vegetable
oil or cooking oil are exposed to heat. Heat source such as your dryer
can warm these items, allowing an oxidation reaction in the oil to
occur.
Oxidation creates heat. If this heat cannot escape, the items can
become hot enough to catch fire. Piling, stacking, or storing these
kinds of items may prevent heat from escaping and can create a fire
hazard.
Take care that children’s fingers are not caught in door when closing
it. This may result in injury.
•
7
Risk of Fire
• Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer’s instructions
and local codes.
To reduce the risk of severe injury or death, follow all installation
instructions. Save these instructions.
•
•
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

8
Please read the following instructions carefully before installing the dryer.
These instructions should be kept for future reference.
INSTALLATION REQUIREMENTS
IMPORTANT TO INSTALLER
Make sure you have everything necessary for the proper installation.
BASIC REQUIREMENTS
LOCATION REQUIREMENTS
CAUTION
The dryer is not suitable for installation in a mobile home.
Remove the door from all discarded appliances to avoid the danger of
a child being trapped and suffocating, after unplugging Power Cord.
•
•
A GROUNDED ELECTRICAL OUTLET is required. Refer to the “Electrical
requirements” section.
A POWER CORD (except for Canada).
•
•
The dryer should be located where there is enough space at the front
for loading the dryer, and enough space behind for the exhaust system.
Make sure the room in which the dryer is located has enough fresh air.
The dryer must be located where there are no air-flow obstructions.
The dryer must not be installed or stored in an area where it will be
exposed to water and/or weather. The dryer area must be kept clear of
combustible materials, gasoline, and other flammable vapors and
liquids. A dryer produces combustible lint. The area around the dryer
should be kept lint-free.
•
•
•
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

9
Alcove or closet or wall insert/recessed installations
WARNING
No other fuel-burning appliance should be installed in the same closet as
the dryer.
Minimum clearances between the dryer and adjacent walls or other
surfaces :
Sides
Top
1 in. (25.4 mm)
2 in. (50.8 mm)
Rear
Closet front
2 in. (50.8 mm)
2 in. (50.8 mm)
1 in. (25.4 mm)
23.4 in. (595 mm) 2 in. (50.8 mm) 2 in. (50.8 mm)
25.7 in. (653 mm)
2 in. (50.8 mm)
A
AA
B B
CE
DF
A
B
C
D
E
F
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

10
Undercounter installation
1 in. (25.4 mm)
≥35.5 in. (≥901 mm)
1 in. (25.4 mm)
23.4 in. (595 mm) 42.2 in. (1072 mm)
33.5 in. (850 mm)
A
CB D
E
F
A
B
C
D
E
F
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

11
The front of the closet must have two unobstructed air openings for a
combined minimum total area of 72 sq.in. (465 sq.cm) with a minimum
clearance of 3 in. (76mm) at the top and bottom. A slatted door with
equivalent space clearance is acceptable.
Installation with stacked washing machine and dryer
NOTE:
2 in. (50.8 mm)
2 in. (50.8 mm)
3 in. (76 mm) 3 in. (76 mm)
3 in. (76 mm)
48 in.2(3100 mm2)
24 in.2(1550 mm2)1 in. (25.4 mm)
23.4 in. (595 mm)
25.7 in. (653 mm)
A
B
C
D
E
F
G H I J K
C
D
G
H
K
A
B
E
F
I
J
/
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

•
•
•
•
12
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and install them as
per the instruction below.
Take the hose out of the holder.
water tightness, there is tension between the hose and the inflow and
therefore an increased force is required for disassembly.)
Insert the drain hose and the external drainage hose into the connector.
Put the hose on the washing basin or floor drain. To assure the smooth
drainage, ensure the pipe is not folded.
The wiring diagram is located on the back board of the unit.
DRAIN SYSTEM
ELECTRIC REQUIREMENTS
Installation
WARNING
• The improper connection of the equipment grounding conductor can
result in the risk of electric shock. Check with a qualified electrician or
serviceman if you are in doubt as to whether your dryer is properly
grounded. Do not modify the plug provided with your dryer - if it
doesn’t fit the outlet, have a proper outlet installed by a qualified
electrician.
Condensing drain hose
Connector
Max.78cm
x
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

13
Electrical connections
Electric models - U.S. only
To prevent unnecessary risk of fire, electrical shock, or personal
injury, all wiring and grounding must be done in accordance with
local codes, or in the absence of local codes, with the National
Electrical Code, ANSI/NFPA No. 70 - Latest Revision (for the U.S.) or
the Canadian Electrical Code CSA C22.1 - Latest Revisions and local
codes and ordinances. It is your responsibility to provide adequate
electrical services for your dryer.
All gas installations must be done in accordance with the National
Fuel Code ANSI/Z2231 - Latest Revision (for the U.S.) or CAN/CGA -
B149 Installation Codes - Latest Revision (for Canada) and local
codes and ordinances.
•
•
If a power cord is used, the cord should be plugged into a 30-ampere
receptacle.
The power cord is NOT provided with U.S. electric model dryers.
•
•
The dryers require a 120/240 volt, 60Hz AC approved electrical service.
The electric service requirements can be found on the data label located
on the back.
A 30-amperefuse or circuit breaker on both sides of the line is required.
An individual branch (or separate) circuit serving only your dryer is
recommended. DO NOT USE AN EXTENSION CORD.
WARNING
•
•
RISK OF ELECTRIC SHOCK:
When local codes allow, the electrical supply of the dryer may be
connected by means of a new power supply cord kit, marked for use
with a dryer, that is UL listed and rated at a minimum of 120/240 volts,
30-ampere with three No. 10 copper wire conductors terminated with
closed loop terminals, open-end spade lugs with turned up ends, or with
tinned leads.
Do not reuse a power supply cord from an old dryer. The power cord
electric supply wiring must be retained at the dryer cabinet with a
suitable UL-listed strain relief.
Grounding through the neutral conductor is prohibited for (1) new
branchcircuit installations, (2) mobile homes, (3) recreational vehicles,
and (4) areas where local codes prohibit grounding through the
neutral conductor. (Use a 4-prong plug for 4 wire receptacles, NEMA
type 14-30R.)
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

14
GROUNDING
REPLACEMENT PARTS AND ACCESSORIES
Electric models - Canada only
Install the clothes dry according to manufacture’s instructions and local
codes.
For products sold in the U.S., your dryer has an optional cord with an
equipmentgrounding conductor and a grounding plug, which is sold
separately. For products sold in Canada, your dryer is equipped with a
cord having an equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and
ordinances.
Do not modify the plug provided with the appliance: if it will not fit the
outlet, have a proper outlet installed by a qualified electrician.
If a power cord is not used and the electric dryer is to be permanently
wired, This appliance must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding conductor must
be run with the circuit conductors and connected to the equipment-
grounding terminal or lead on the appliance.
•
•
•
•
A 120/240 volt, 60Hz AC approved electrical service fused through a
30-ampere fuse or circuit breaker on both sides of the line is required.
All Canadian models are shipped with the power cord attached. The
power cord should be plugged into a 30-ampere receptacle.
A power cord is NOT provided with U.S. electric model dryers.
•
•
NOTE:
WARNING
•
•
Improper connection of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualified electrician or
service representative or personnel, if you are in doubt as to whether
the appliance is properly grounded.
Certain internal parts are intentionally not grounded and may present
a risk of electric shock only during servicing.
Service personnel - do not contact the following parts while the
appliance is energized: Main Motor, Cooling Fan.
If your dryer requires replacement parts or accessories, contact the dealer
where you purchased your dryer or email to
[email protected].
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

INSTALLATION INSTRUCTION
REMOVING FROM THE PACKAGE
PARTS IDENTIFICATION
15
Unpack your dryer and inspect it for shipping damage. Make sure you
have received all the items shown below.
To prevent personal injury or strain, wear protective gloves
whenever lifting or carrying the unit.
•
•
WARNING
•
•
Packaging materials can be dangerous to children.
Keep all packaging material (plastic bags, polystyrene, etc.) well out
of children’s reach.
Handle Drawer
Side Plate
Control Panel
Door
Filter
Fan Cover
Maintenance Cover
Adjustable leg (Two legs)
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting

TOOLS REQUIRED
16
Wiring Box
Drain Hose
Pliers
Flat screwdriver Level
Cutting knife
Adjustable wrench
that opens to 1”
(25 mm)
Phillips screwdriver
Tape measure
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation

INSTALLATION STEPS
17
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
For the proper installation, we recommend that you hire a qualified
installer.
Then choose a 3-wire power supply cord with ring
terminals and UL listed strain relief. The 3-wire power
supply cord, at least 4.92 ft. (1.5 m) long, must have 3
10-gauge solid copper wires and match a 3-wire
receptacle of NEMA Type 10-30R, rated 120/240V,
min 10A.
3-Wire system connections
3-wire system instructions:
A. Terminal block screw
B. External ground connector
C. 3/4" (1.9cm) UL-listed strain relief
D. Neutral wire (white or center wire)
3-Wire
receptacle
(10-30R)
STEP 1 Choose the proper location
STEP 2 Connect the electrical wiring
Three wire outlet
Move your dryer to an appropriate location for the installation.
Consider installing the dryer and washer side-by-side, to allow access
to the gas, electrical, and exhaust connections. Place two of the carton
cushion-tops on the floor. Tip your dryer on its side so it lies across
both cushion-tops.
Set your dryer back in an upright position.
•
•
Connect the neutral wire (white or center wire) of the power cord to
the external ground conductor screw.
Remove the two side terminal block screw and connect the other
wires to the outer terminal screws. Be sure to cross the screw through
the terminal ring and tighten the screw.
Tighten the strain relief screws.
Insert the tab of the terminal block cover into your dryer's rear panel
slot. Secure the cover with a screw.
•
•
•
•
AVERTISSEMENT
Ring-type terminals are recommended. If using strip terminals, make
sure they are tightened.
B
C
D
A

18
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation
4-wire system instructions:
A. Terminal block screw
B. External ground connector
C. 3/4" (1.9cm) UL-listed strain relief
D. Green or bare copper wire of the power cord
E. Neutral wire (white or center wire)
4-Wire system connections
Connect the ground wire (green or unwrapped) of the power cord to
the external ground conductor screw.
Remove the center terminal block screw and Connect the neutral
wire (white or center wire) of the power cord to the center terminal
screw of the terminal block. Be sure to cross the screw through the
terminal ring and tighten the screw.
Remove the two side terminal block screw and connect the other
wires to the outer terminal screws. Be sure to cross the screw through
the terminal ring and tighten the screw.
Tighten the strain relief screws.
Insert the tab of the terminal block cover into your dryer's rear panel
slot. Secure the cover with a screw.
•
•
•
•
•
AVERTISSEMENT
Ring-type terminals are recommended. If using strip terminals, make
sure they are tightened.
AVERTISSEMENT
U.S. Models:
Risk Of Electric Shock - All U.S. models are produced for a 3-WIRE
SYSTEM CONNECTION.
Then choose a 4-wire power supply cord with ring
terminals and UL listed strain relief. The 4-wire power
supply cord, at least 4.92 ft. (1.5 m) long, must have 4
10-gauge solid copper wires and match a 4-wire
receptacle of NEMA Type 14-30 R, rated 120/240V,
min 10A. The ground wire (ground conductor) may
be either green or bare.The neutral conductor must
be identified by a white color.
4-Wire
receptacle
(14-30R)
Four wire outlet
C
B
A
D
E

19
Safety and
Precautions
Installation
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
STEP 3 Level the dryer
Adjust the leveling feet only as much as necessary to level the dryer.
Extending the leveling feet more than necessary can cause the dryer
to vibrate.
•
The dryer frame is grounded to the neutral conductor at the terminal
block. A 4-WIRE SYSTEM CONNECTION is required for new or
remodeled construction,mobile homes, or if local codes do not permit
grounding through neutral conductor.
If the 4-wire system is used, the dryer frame cannot be grounded to the
neutral conductor at the terminal block. Refer to the “Electric
requirements” section on page 14 for 3-WIRE or 4-WIRE SYSTEM
CONNECTIONS.
Remove the terminal block cover plate.
Insert the power cord with a UL-listed strain relief through the hose
provided in the cabinet near the terminal block.
A strain relief must be used.
Do not loosen the nuts already installed on the terminal block. Be sure
they are tight.
Use a 3/8" (1cm) deep well socket.
To ensure that the dryer provides the optimal drying performance, it must
be leveled. To minimize vibration, noise, and unwanted movement, the
floor must be a perfectly level, solid surface.
•
Level
loosen lock
Adjustable leg

20
Requirements
Installation
Instructions Dryer Use Dryer Care
Troubleshooting
Safety and
Precautions
Installation
STEP 4 Power on
STEP 5 Final check
Make sure the dryer is plugged into an electrical outlet and is
properly grounded.
The dryer is leveled and is sitting firmly on the floor.
Start your dryer to confirm that it runs, heats, and shuts off.
•
•
•
Make sure all electrical connections are complete. Plug in your dryer.
