Electrolux T5290 User manual

Installationmanual
Tumbledryer
T5290
TypeN2...
4389054-00/EN
Installationmanualinoriginallanguage2011.09.12

Contents
Contents
1SafetyPrecautions.............................................................................................................5
2Technicaldata....................................................................................................................7
2.1Drawing......................................................................................................................7
2.2Technicaldata.............................................................................................................8
2.3Connections................................................................................................................8
3Setup..................................................................................................................................9
3.1Unpacking...................................................................................................................9
3.2Siting...........................................................................................................................10
3.3Mechanicalinstallation...............................................................................................10
4Marineinstallation..............................................................................................................11
5Reversingthedoor.............................................................................................................12
6Evacuationsystem.............................................................................................................15
6.1Airprinciple.................................................................................................................15
6.2Freshair.....................................................................................................................16
6.3Exhaustduct...............................................................................................................17
6.4Sharedexhaustduct...................................................................................................18
6.5Exhaustdimensioning................................................................................................19
7Steamconnection..............................................................................................................20
7.1Connectingthesteam.................................................................................................20
7.2Steamcalorier...........................................................................................................21
8Gasconnection..................................................................................................................23
8.1Fastenthelabel..........................................................................................................23
8.2General.......................................................................................................................23
8.3Gasinstallation...........................................................................................................24
8.4Tableofpressureandadjustment..............................................................................25
8.5Testrun.......................................................................................................................26
8.6Convertinginstructions...............................................................................................27
8.7Datalabel...................................................................................................................29
9Electricalconnection..........................................................................................................30
9.1Electricalinstallation...................................................................................................30
9.2Single-phaseconnection............................................................................................31
9.3Three-phaseconnection.............................................................................................32
9.4Electricalconnections.................................................................................................33
9.5FunctionsforI/O-cards...............................................................................................34
9.5.1Centralpayment(22J)........................................................................................34
9.5.2Centralpayment(22J)........................................................................................35
9.5.3Externalcoinmeter/Centralpayment(22K)........................................................36
9.5.4Pricereduction(22K)..........................................................................................37
9.5Option.........................................................................................................................38
9.5.1Externalconnection100mA...............................................................................38
10Functioncheck.................................................................................................................39
Themanufacturerreservestherighttomakechangestodesignandcomponentspecications.

SafetyPrecautions5
1SafetyPrecautions
Themachineisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor
mentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor
instructionconcerninguseoftheappliancebyapersonresponsiblefortheirsafety.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththemachine.
Themachineisnottobeusedifindustrialchemicalshavebeenusedforcleaning.
Donotdryunwasheditemsinthemachine.
Itemsthathavebeensoiledwithsubstancessuchascookingoil,acetone,alcohol,petrol,kerosene,spot
removers,turpentine,waxesandwaxremoversshouldbewashedinhotwaterwithanextraamount
ofdetergentbeforebeingdriedinthemachine.
Itemssuchasfoamrubber(latexfoam),showercaps,waterprooftextiles,rubberbackedarticlesand
clothesorpillowsttedwithfoamrubberpadsshouldnotbedriedinthemachine.
Fabricsoftenersorsimilarproductsshouldbeusedasspeciedbythefabricsoftenerinstructions.
Thenalpartofadryingcycleoccurswithoutheat(cooldowncycle)toensurethattheitemsareleftata
temperaturethatensuresthattheitemswillnotbedamaged.
Removeallobjectsfrompocketssuchaslightersandmatches.
WARNING.Neverstopthemachinebeforetheendofthedryingcycleunlessallitemsarequicklyremoved
andspreadoutsothattheheatisdissipated.
Adequateventilationhastobeprovidedtoavoidthebackowofgasesintotheroomforappliances
burningotherfuels,includingopenres.
Exhaustairmustnotbedischargedintoauewhichisusedforexhaustingfumesfromappliancesburning
gasorotherfuels.
Themachinemustnotbeinstalledbehindalockabledoor,aslidingdoororadoorwithahingeonthe
oppositesidetothatofthemachine.
Ifthemachinehasalinttrapthishastobecleanedfrequently.
Thelintmustnotbeaccumulatedaroundthemachine.
Gasheatedtumbledryer:
Themachineisnottobeinstalledinroomscontainingcleaningmachineswithperchloroethylene,
TRICHLOROETHYLENEorCHLOROFLUOROCONTAININGHYDROCARBONSascleaningagents.
Ifyoucansmellgas:
•Donotswitchonanyequipment
•Donotuseelectricalswitches
•Donotusetelephonesinthebuilding
•Evacuatetheroom,buildingorarea
•Contactthepersonresponsibleforthemachine
AllexternalequipmentwhichisconnectedtothemachinemustbeCE/EMC-approvedandconnectedusing
anapprovedshieldedcable.

6SafetyPrecautions
Inordertopreventdamagetotheelectronics(andotherparts)thatmayoccurastheresultofcondensation,
themachineshouldbeplacedinroomtemperaturefor24hoursbeforebeingusedforthersttime.

Technicaldata7
2Technicaldata
2.1Drawing
AB(a)
B(b)
KL
H
N
M
C
DE
J
G
I
F
1
2
7
6
3
5
7
6
3
4
5
1Operatingpanel
2Dooropening,⌀580mm
3Electricalconnection
4Gasconnection
5Exhaustconnection
6Steam:in
7Steam:out
AB(a)B(b)CDEFG
mm7101155133516757257801401310
HIJKLMN
mm70155138055355685605

8Technicaldata
2.2Technicaldata
Weight,netkg220
Drumvolumelitres290
Drumdiametermm680
Drumdepthmm770
Drumspeedrpm50
G-factor,max.0.94
Capacity,llingfactor1:18(Max.load)kg16.1
Capacity,llingfactor1:22(Recommended.load)kg13.2
Heating:ElectricitykW18
kW13.5
Heating:GaskW21
Heating:SteamkW25
Airconsumption,Electricheating,13.5kWm3/h380
Airconsumption,Electricheating,18.0kWm3/h450
Airconsumption,Gasheatingm3/h550
Airconsumption,Steamheatingm3/h640
AirbornesoundleveldB(A)70
Pressuredrop,Electricheating,13.5kWMax.Pa400
Pressuredrop,Electricheating,18.0kWMax.Pa350
Pressuredrop,GasheatingMax.Pa350
Pressuredrop,SteamheatingMax.Pa350
2.3Connections
Airoutlet⌀mm200
Steamoutlet1”ISO7/1–Rp1/2
Condensateoutlet-ISO7/1–Rp1/2
Gasconnection1/2”ISO7/1–R1/2

Setup9
3Setup
3.1Unpacking
Note!
Twopersonsarerecommendedfortheunpacking.
Themachineisdeliveredcompletewithsupportingfeet.
Themachineisdeliveredboltedontothetransportpalletandpackedinacrateorbox.
Removepackingfromthemachine.
Removetheboltsbetweenthemachineandpallet.Therearetwoboltsinthefrontofthemachine
andtwointhebackofthemachine.Removethelowerfrontpanelandremovethetwoboltsin
thefrontofthemachine.Removethelowerbackpanelandremovethetwoboltsinthebackof
themachine.Remountthepanelswhendone.
g.7189A
①
Removethemachinefromthepallet.
Note!
Whenremovingthemachine,handleitwithcare.Thedrumhasnotransportsecurities.
Placethemachineonitsnalposition.

10Setup
3.2Siting
Themachineshouldbepositionedsothatthereisplentyofroomforworking,bothfortheuser
andservicepersonnel.
Thegureshowsminimumdistancetoawalland/orothermachines.
Min.150 mm / 5 7/8 inch
Min. 20 mm /
13/16 inch
Max. 50 mm /
1 15/16 inch
500 mm /
20 inch
10 mm /
3/8 inch
10 mm /
3/8 inch
g.7187
②
3.3Mechanicalinstallation
Levelthemachinewiththefeetofthemachine.Themaximumheightadjustmentofthefeet
is15mm.
g.7188
③

Marineinstallation11
4Marineinstallation
Toensuresteadinessofthemachineitisimportanttofastenthemachinetothefoundation.
Fastenthefourttings(suppliedwiththemarinemachinemodel)tothefoundationusingfourxM10
setscrews.Ifthefourttingsisnotsupplied,orderkitNr.487193544.
Fastenthemachinetothettings.
Note!
Marineinstallationisnotapplicableforgasheatedmachines.
15.3 mm / 9/16 inch
43.3 mm / 1 11/16 inch
1065 mm / 41 15/16 inch
1005.6 mm / 39 5/8 inch
73 mm / 2 7/8 inch
677.1 mm / 26 5/8 inch
617.6 mm / 24 5/16 inch
45 mm / 1 3/4 inch
M10
④

12Reversingthedoor
5Reversingthedoor
Disconnectthepowertothemachine.
Demountthehingesandremovethedoor.Removetheupperhingerst.
g.7166
⑤
Removethescrewsonthefrontpanelandcarefullyloosenthepanel.Disconnectthedoorswitch
cableandremovethepanel.
g.7179A
⑥

Reversingthedoor13
Movethedoorswitchcabletotheoppositesite.
Note!
TheplasticplugMUSTbeplacedintheholewherethedoorswitchcablewasbefore.
g.7170
⑦
Loosenthenutsandmovethetwobracketstotheoppositeside.
g.7171
⑧

14Reversingthedoor
Movethedoorswitchonthefrontpanel.
1
2
3
4
g.7172
⑨
Movethefourmetalclipsfromtherightsidetotheleftside.
g.7174
⑩
Connectthedoorswitchcableandremountthefrontpanel.
Fastenthehingesandmountthedoorontheoppositesidethanbefore.
Connectthepowertothemachine.
Testrunthemachine.

Evacuationsystem15
6Evacuationsystem
6.1Airprinciple
Thefancreateslowpressureinthemachine,drawingairintothedrumviatheheatingunit.
Theheatedairpassesthroughthegarmentsandthedrumholes.
Theairthenowsouththroughalintlterpositionedbelowthedrum.Thentheairisevacuated
throughthefanandexhaustsystem.
Dimensionforairevacuation(A)is200mm.
A
g.W00264
⑪
Note!
Itisveryimportantthatthemachinegetsenoughfreshairinordertogetthebestdrying
result.
⑫

16Evacuationsystem
6.2Freshair
Formaximumefciencyandtheshortestpossibledryingtime,itisimportanttoensurethatfreshair
isabletoentertheroomfromtheoutsideinthesamevolumeasthatblownoutoftheroom
Toavoiddraughtintheroomitisimportanttoplacetheairinletbehindthemachine.
Theareaoftheairinletopeningmustbevetimesthesizeoftheexhaustpipearea.The
areaoftheinletopeningistheareathroughwhichtheaircanowwithoutresistancefromthe
grating/slattedcover.
5 x A
A
g.7183
⑬
Note!
Gratings/slattedcoversoftenblockhalfofthetotalfreshairventarea.Remembertotake
thisintoaccount.

Evacuationsystem17
6.3Exhaustduct
•Onlyrigidorexiblemetalductshouldbeusedforexhausting.
•Plasticductingisnottobeused.
•Recommendedmaterialforexhaustisgalvanisedsteel.
•Theductisnottobeassembledwithscrewsofotherfasteningmeansthatextendintothe
ductandcatchlint.
•Theexhaustairshouldnotbeventedintoawall,aceiling,oraconcealedspaceofbuilding.
•Theexhaustductmustleadclearofthebuildingascondensationmaycausefrostdamage
tothebuilding.
•Theexhaustductmustleadtotheoutdoors.
•Theexhaustductmustbeplacedinsuchawaythatitisprotectedontheoutside.
•Theexhaustductmustbesmoothontheinside(lowairresistance).
•Theexhaustductmusthavegentlebends.
•Theexhaustductmustnotbeasharedductbetweenmachinesandappliancesusinggasor
otherfuelsastheirenergysource.
⑭

18Evacuationsystem
6.4Sharedexhaustduct
Itisrecommendedthateachmachineisconnectedtoaseparateexhaustduct.
Whenseveralmachinesshallusethesameexhaustducttheexhaustductmustincreaseafter
eachmachine.
⑮
Numberofmachines12345678910
Exhaustduct⌀mm200280315355400450475500535560
Minimumareaoffresh-airintake
m2
0.150.300.450.600.750.901.051.201.351.50
Theexhaustductdiametermustnotbereduced.

Evacuationsystem19
6.5Exhaustdimensioning
Itisimportantthatthemachinehascorrectairvolumecomparedtoeachmachinespower.
Iftheairvolumeissmallerorbiggerthiswillresultinalongerdryingperiod.
Themachineisdesignedtoworkwith25moutletpipeandtwo90degreebends.Eachbendis
equalto2.5m.Ifmorethantwobendsisneededthelengthshouldmaximumbeshortenedwith
2.5mperbend.
Iftheoutletpipeislongerortheventilationisnotproperlydesignedwerecommendtocleanthe
outletpipesperiodically.
Theexhaustpipesshallbeshortinorderforthemachinetoworkinthebestway.
Allcoverplatesmustbemountedinorderforthemachinetoworkinthebestway.

20Steamconnection
7Steamconnection
7.1Connectingthesteam
Note!
Thesteampipemustbecutoffandmustnotbeunderpressure.
•Thebranchpipe’smustbelocatedatthetopofthemainsteampipetopreventcondensationin
thesteam.
•Thebranchpipemusthaveadescendinggradientandmustendataheightabovetheinlet
connectingbranch(5).FormeasurementsM,NandO,pleaserefertothedimensiondrawing.
•Mountaplugvalve(a)andadirtcollector(c)inthebrachpipe.
5
6
a
b
N
M
b
a
c
L
g.7194
⑯
Condensatereturn
Itisimportantthatthebrachpipeforcondensedwateronreturntothemaincondensatepipehasa
descendinggradientandislowerthantheoutletconnectingbranch(6).
•Mountadirtcollector(b)inthereturnpipe.
•Mountamechanicalwaterdischargerbehindthedirtcollector(c).
•Mountaplugvalve(a).
•Mountpressurehosesbetweenthebranchpipesandthemachine.Notethathosesarenot
supplied.
Pipeinsulation
Allpipesmustbeinsulatedinordertoreduceriskofburning.Insulationalsoreduceslossofheat
tothesurroundings.
