Midea HS-131CN User manual

Service Manual_2018-V2.0
1
Service Manual
CHEST FREEZER SERIES
Applicable Models
Model Code
Applicable Models
HS-131CN
UR-BD100-DQ
22032010003261
HS-131CN
UR-BD100-DQ
92032010Z00401
The picture in this service manual is only for reference, and specific appearance
and configuration are subject to the real product.
This manual mainly teaches the method, the specific work skill needs engineer to
accumulate through the daily work.

Service Manual_2018-V2.0
2
WARNING
Important Safety Notice
There are special components used in this equipment which are important for safety. These parts are marked
by in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is
essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacturer.
WARNING
Important Safety Notice
The Maintenance Manual is only for the use of maintenance personnel with certain experience and
background in electrical, electronic and mechanical field.
Any attempt to repair main devices may lead to personal injury and property loss.
Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof.
Midea Refrigerators
Technical Maintenance Manual
Copyright @2017
All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written
approval by the Overseas Sales Corporation of Midea Refrigerators.

Service Manual_2018-V2.0
3
Contents
1. 重要更新说明 SIGNIFICANT UPDATE NOTES(NONE)...............................................................................5
2. 安全警示规范 SAFETY WARNING CODE......................................................................................................6
2.1 作业安全警告 WARNING FOR OPERATION SAFETY..........................................................................................6
2.2 冷媒安全须知 SAFETY INSTRUCTION FOR REFRIGERANT ................................................................................8
3. 运输 TRANSPORT ..........................................................................................................................................9
3.1 搬运 HANDLING............................................................................................................................................9
4. 安装和调试 INSTALLATION AND COMMISSIONING................................................................................. 10
4.1 门体拆装 DOOR DISASSEMBLY AND ASSEMBLY(NONE) ................................................................................ 10
4.2 安装位置 INSTALLATION LOCATION ............................................................................................................. 10
4.3 箱体调平 LEVELING OF THE REFRIGERATOR................................................................................................ 10
4.4 把手安装 INSTALLATION OF HANDLE ........................................................................................................... 10
4.5 门锁安装 INSTALLATION OF DOOR LOCK（NONE）.......................................................................................11
5. 产品配置和尺寸 PRODUCT CONFIGURATION AND DIMENSION ............................................................ 12
5.1 主要部件及名称 MAIN PARTS AND THEIR NAMES......................................................................................... 12
5.2 外观尺寸 EXTERNAL DIMENSION ................................................................................................................ 13
5.3 序列号的位置 LOCATION OF S/N ............................................................................................................... 14
6. 产品规格 PRODUCT SPECIFICATION........................................................................................................ 15
6.1 电气参数 ELECTRICAL PARAMETERS .......................................................................................................... 15
6.2 制冷温度设置范围 COOLING TEMPERATURE SETTING RANGE...................................................................... 15
6.3 电路图 CIRCUIT DIAGRAM .......................................................................................................................... 16
7. 制冷管路系统和冷气循环路线 REFRIGERATING PIPING SYSTEM AND CIRCULATING ROUTE OF
COOLING AIR................................................................................................................................................... 17
7.1 制冷管路系统 REFRIGERATING PIPING SYSTEM........................................................................................... 17
7.2 特殊焊点位置 SPECIAL SOLDERING POSITION(NONE).................................................................................. 17
8. 部件拆装 DISMANTLING OF PARTS .......................................................................................................... 18
8.1 门上部件 PARTS ON THE DOOR .................................................................................................................. 18
8.2 箱内部件 PARTS INSIDE THE REFRIGERATOR............................................................................................... 19
8.3 灯系统 LIGHT SYSTEM ............................................................................................................................... 20
8.4 压缩机仓 COMPRESSOR CASE................................................................................................................... 20
8.5 温控盒组件 TEMPERATURE-CONTROL BOXASSEMBLY.................................................................................. 24
9. 功能和操作 FUNCTION AND OPERATION ................................................................................................. 27
9.1操作面板 OPERATION PANEL...................................................................................................................... 27
9.2 温度控制 TEMPERATURE CONTROL............................................................................................................. 27
9.3 高温报警 HIGH TEMPERATURE AN ALARM(NONE) ........................................................................................ 28
9.4 除霜功能 DEFROSTING FUNCTION............................................................................................................... 28

Service Manual_2018-V2.0
4
10. 压缩机 COMPRESSOR.............................................................................................................................. 29
10.1 压缩机的开停控制规则 COMPRESSOR ON AND OFF CONTROL SPECIFICATIONS.......................................... 29
11. 故障排除方法 TROUBLESHOOTING METHOD........................................................................................ 30
11.1 不制冷 NOT COOLING............................................................................................................................... 30
11.2 压缩机不工作 NO WORKING OF COMPRESSOR.......................................................................................... 31
11.3 温控器故障-过冷 THERMOSTAT MALFUNCTION-UNDERCOOLING................................................................. 31
11.4 灯不亮 LIGHT IS NOT ON........................................................................................................................... 32
11.5 噪音 NOISE ............................................................................................................................................. 32
13. 维修零部件图示和明细 FIGURES AND DETAILS OF REPAIR PARTS .................................................... 33

Service Manual_2018-V2.0
5
1. Significant update notes(None)

Service Manual_2018-V2.0
6
2. Safety Warning Code
2.1 Warning for operation safety
Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your freezer.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your freezer.
WARNING
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this appliance near water.
6) Clean only with a damp cloth.
7) Do not block any ventilation openings.
8) Install in accordance with the manufacturer’s instructions.
9) Do not install near any heat sources, such as radiators, heat registers, stoves, or
other apparatus that produce heat.
10) Do not defeat the safety purpose of the polarized or grounding-type plug.A
polarized plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
11) Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the appliance.
12) Do not attempt to modify or extend the power cord of this appliance.
13) Unplug this appliance during lightning storms or when it will not be used for long
periods of time.
14) Make sure that the available AC power matches the voltage requirements of this
appliance.

Service Manual_2018-V2.0
7
CONNECTING ELECTRICITY
Electrical Shock Hazard.
Plug into a grounded 3-prong outlet.
Do not remove the ground prong.
Do not use an adapter.
Failure to follow these instructions can
result in death, fire, or electrical shock.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in electric shock, fire, or
death.
1) WARNING–Keep ventilation openings, in both the freezer and the built-in structure,
clear of obstruction.
2) WARNING–Do not touch the interior of the freezer with wet hands. This could result
in frost bite.
3) WARNING–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4) WARNING–Do not damage the refrigerant circuit.
5) WARNING–Do not damage the refrigerant tubing when handling, moving, or using
the freezer.
6) WARNING–DANGER–Never allow children to play with, operate, or crawl inside the
freezer. Risk of child entrapment. Before you throw away your old freezer:
6-1) Take off the doors
6-2) Leave the shelves in place so that children may not easily climb inside
7) Unplug the freezer before carrying out user maintenance on it.
8) This freezer can be used by children age eight years and older and persons with
reduced physical or mental capabilities or lack of experience and knowledge if they are
given supervision or instruction concerning the use of the freezer in a safe way and
understand the hazards involved. Children should not play with the freezer. Cleaning and
maintenance should not be performed by children without supervision.
9) If a component part is damaged, it must be replaced by the manufacturer, its service
agent, or similar qualified persons in order to avoid a hazard.
10) Please dispose of the freezer according to local regulations as the freezer contains
flammable gas and refrigerant.
11) Follow local regulations regarding disposal of the freezer due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which under the
guidelines of federal law must be removed before disposal. It is the consumer's responsibility
to comply with federal and local regulations when disposing of this product.
12) This freezer is intended to be used in household and similar environments.

Service Manual_2018-V2.0
8
13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this
freezer.
14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If
the power cord is too short, have a qualified electrician install an outlet near the freezer. Use
of an extension cord can negatively affect the freezer’s performance.
Grounding requirement
This freezer must be grounded. This freezer is equipped with a cord having a grounding
wire with a grounding plug. The plug must be inserted into an outlet that is properly installed
and grounded.
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or service person if the grounding instructions are not completely
understood, or if doubt exists as to whether the freezer is properly grounded.
2.2 Safety instruction for refrigerant
Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from freezer. Failure to do so
can result in fire, explosion, or death.
Safety instruction for refrigerant
DANGER–Risk of Fire or Explosion. Flammable Refrigerant Used. To Be Repaired Only By
Trained Service Personnel. Do Not Use Mechanical Devices. Do Not Puncture Refrigerant
Tubing. CAUTION–Risk of Fire or Explosion. Flammable Refrigerant Used. Consult Repair
Manual/Owner’s Guide BeforeAttempting To Service This Product. All Safety Precautions
Must be Followed. CAUTION–Risk of Fire or Explosion. Dispose of Properly InAccordance
With Federal Or Local Regulations. Flammable Refrigerant Used. CAUTION–Risk of Fire or
Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling Instructions Carefully.
Flammable Refrigerant Used.

Service Manual_2018-V2.0
9
3. Transport
3.1 Handling
Handling
1)Protect the refrigerator in moving it,Same as shown as lef
t photo, please move it by handcart with cushion
2)Remove all packing materials and bottom cushion, the m
ove into house for placement
3)After moving it to appropriate location, wait for 2 hours bef
ore power on.

Service Manual_2018-V2.0
10
4. Installation and commissioning
4.1Door Disassembly and Assembly(None)
The refrigerator door needs to be dismantled if it cannot enter the room in the whole.
4.2 Installation location
Installation location
Location that is easy for ventilation shall be chosen to
facilitate heat dissipation, enhance its performance and
reduce the energy consumption.
4.3 Leveling of the refrigerator
Leveling of the refrigerator
If the refrigerator cannot be placed steadily, adjust the
footing to level it.
4.4 Installation of handle
Installation of handle

Service Manual_2018-V2.0
11
1- Handle
2- M5*14 screw(two)
3- Screw hole cover (two)
1) The handle is inserted below the display control board
of door, aligning with the screw hole.
2) Fixing the handle by using the screw.
3) Assemble the screw hole cover onto the screw hole.
1.Fix the lock loop to its mounting hole near the frame in
the front side plate of the box with a M4x20 or M4x8
screw. Pay attention to the direction of the lock loop with
its countersunk side facing outwards.
2.Hold the handle with the left hand, and aim its
mounting hole at the mounting hole of the door. Insert the
key into the keyhole with the right hand, and then turn the
key clockwise to drive the rotation of the lock hook.
Meanwhile, adjust the position of the handle from side to
side in a proper manner to ensure the lock hook can
hook the lock loop in locked state. Afterwards, fix the
handle to the door with four M5X16 screws.
3.Install the handle cover
4.5 Installation of door lock（None）
Installation of door lock
Installation of door lock
With the door handle together

Service Manual_2018-V2.0
12
5. Product configuration and dimension
5.1 Main parts and their names
(The picture is only for reference, and specific appearance and configuration are subject to the real
product)
Freezer chamber
Refrigerator chamber
❶Door shell
❷The door end cover
❸Door gasket
❹Door liner
❺Cabinet assembly
❻Drain-pipe cover
❼Levelling feet
❽Compressor mounting panel
❾Temperature-control panel
❿Hinge
⓫Lamp cover
⓬Door handle

Service Manual_2018-V2.0
13
5.2 External dimension
Description
Code
HS-131CNSize (mm)
Height to Top of Case
A
842
Width
B
546
Depth/Hinge
C
495
Depth
D
475
Height (Door open)
E
1265
(The picture is only for reference)

Service Manual_2018-V2.0
14
5.3 Location of S/N
Some products also have S/N on the lower part of the right side of the Cabinet.

Service Manual_2018-V2.0
15
6. Product specification
6.1 Electrical parameters
Applicable Models
HS-131CN
Product Name
UR-BD100-DQ
Product Code
22032010003261
Item
Specification
Specification
Refrigerant
R600a
Compressor
FZ35C1M
Starter(PTC)
QPS-4R7
Overload protector(OLP)
DRB18T61A1
Integrate PTC+OLP
None
Variable frequency driver board
None
Capacitor
None
Winding resistance of compressor
wiring terminal
Rmc：12.74-14.66Ω
Rsc：12.09-13.91Ω
Rms=Rmc+Rsc
Winding resistance picture
The input power of compressor
Lights inside the refrigerator
Door lamp
None
Indicator lamp
None
Switch of the refrigerator door
■Mechanical switch
□Magnetism control switch
6.2 Cooling temperature setting range
Compartment
The highest (oC)
Lowest (oC)
Freezing
-12
-26
Refrigerating
10
1

Service Manual_2018-V2.0
16
6.3 Circuit diagram

Service Manual_2018-V2.0
17
7.Refrigerating piping system and circulating route of cooling air
7.1 Refrigerating piping system
❶Compressor→❷Right condenser→❸Left Condenser→❹Dry filter→❺Capillary tube→❻Evaporator
7.2 Special soldering position(None)

Service Manual_2018-V2.0
18
8. Dismantling of parts
8.1 Parts on the door
Door seal
1)Pull the door seal from the corner
2)Take efforts until door seal totally detaches from door
inner liner groove, remove the door seal
3)Fixing the four corners and pressing smoothly.
The hinge cover
The hinge cover teardown
1) Strongly apart a proper angle with your hands along
the side wall of the lower hinge cover when the
refrigerator door is open to separate the hinge cover
boss from the hinge hole and outwardly remove the lower
hinge cover. ❶❷Note: ❶represents the upper hinge
cover, and ❷represents the lower hinge cover.
2) Remove the upper hinge cover in the same way. Then
both the lower and upper hinge covers are all removed.
❷
❶

Service Manual_2018-V2.0
19
The hinge cover install
1) Apart a proper angle with your hands along the side
wall of the lower hinge cover when the refrigerator door is
closed, align to the side wall of hinge and push forward
until the hinge cover boss is fully and correctly inserted
into the hinge holes;
2) Hold the side of hinge cover with your hands, align the
opening to the side wall of hinge and push downward
until the hinge cover boss is fully and correctly inserted
into the hinge holes. Then the upper and lower hinge
covers are all installed in place.
Door lamp line
1) Remove the two screws; 2) Press the clip with your
hand to disconnect the block terminal and separate the
wiring harness ❶❷Note: ❶represents the door lamp
line; ❷represents the wiring harness connecting the
refrigerator.
8.2Parts inside the refrigerator
Basket
Open the door and upwardly lift the basket Note: There
are plastic baskets and wire baskets, and the basket we
offer you is subject to the real product you received.
Inside water pipe cover
Counterclockwise to remove the pipe cover
❷
❶

Service Manual_2018-V2.0
20
8.3 Light system
Door lamp
Door lamp disassembly
1) Open the refrigerator door to dismantle the lamp
cover; Note: There are two kinds of door lamps, namely,
incandescent lamp and LED lamp, and what is shown in
the picture is the incandescent lamp.
2) Screw off the screws to remove the incandescent lamp
holder or LED lamp panel; Note: The incandescent lamp
is shown in the left picture, and the LED lamp is shown in
the right picture, which is mounted on the mounting
panel.
3) Screw the lamp off the holder (or remove the LED
lamp panel).
Pilot light
Pilot light
POWER+RUN+ALARM
8.4 Compressor case
shutter
Pull down the screw, open the shutter.
Compressor and the cooling system pipe
