Midea TMF Series User manual

Service Manual_2017-V1
1
Service Manual TMF SERIES
(The picture in this service manual is only for reference, and specific appearance and configuration are
subject to the real product)
Applicable Models
Model Code
UL-BCD595WE-SQ
22031020003381
UL-BCD595WE-SQ
22031020001681
UL-BCD595WE-SQ
92031020Z00029
UL-BCD595WE-SQ
92031020Z00041
UL-BCD595WE-SQ
92031020Z00042
Prepared by
R&D:Liu lu
Reviewed by
QA:huang juan
SVC:Zhang Kun
Approved by
R&D:Geng xiuhua
SVC:Guang Taoshuai

Service Manual_2017-V1
2
WARNING
Important Safety Notice
There are special components used in this equipment which are important for safety. These parts are marked
by in the Schematic Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is
essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacturer.
WARNING
Important Safety Notice
The Maintenance Manual is only for the use of maintenance personnel with certain experience and
background in electrical, electronic and mechanical field.
Any attempt to repair main devices may lead to personal injury and property loss.
Manufacturers or distributors are not responsible for the content of the Manual and interpretation thereof.
Midea Refrigerators
Technical Maintenance Manual
Copyright @2017
All rights reserved. Replication of all or part of the Manual in any forms shall not be allowed without written
approval by the Overseas Sales Corporation of Midea Refrigerators.

Service Manual_2017-V1
3
Contents
1. SAFETY WARNING CODE................................................................................................................................... 5
1.1WARNING FOR OPERATION SAFETY ........................................................................................................................... 5
1.2 SAFETY INSTRUCTION FOR REFRIGERANT................................................................................................................. 7
2. DESCRIPTION FOR PRODUCT FEATURES..................................................................................................... 8
3. INSTALLATION AND COMMISSIONING............................................................................................................ 9
3.1 HANDLING................................................................................................................................................................... 9
3.2 DOOR DISASSEMBLY AND ASSEMBLY ........................................................................................................................ 9
3.3 INSTALLATION LOCATION ............................................................................................................................................ 9
3.4 LEVELING OF THE REFRIGERATOR........................................................................................................................... 10
3.5 DOOR REVERSAL...................................................................................................................................................... 10
3.6 INSTALLATION OF HANDLE........................................................................................................................................ 13
3.7 INSTALLATION OF DOOR LOCK.................................................................................................................................. 13
3.8ADJUSTMENT TO LEVEL THE DOOR .......................................................................................................................... 13
3.9ADJUSTMENT TO SHELVES ....................................................................................................................................... 13
4. TERMS...................................................................................................................................................................14
4.1 DEFINITION OF MODEL(NONE)................................................................................................................................. 14
4.2 LOCATION OF NAMEPLATE(NONE)............................................................................................................................ 14
5. PRODUCT SPECIFICATION...............................................................................................................................15
5.1 TYPE SPECIFICATION(NONE)................................................................................................................................... 15
5.2 ELECTRICAL PARAMETERS....................................................................................................................................... 15
5.3 INSIDE TEMPERATURE.............................................................................................................................................. 16
5.4 DEFROSTING PARTS................................................................................................................................................. 16
5.5 CIRCUIT DIAGRAM .................................................................................................................................................... 16
6. INTERNAL VIEW AND DIMENSION ..................................................................................................................17
6.1 MAIN PARTS AND THEIR NAMES................................................................................................................................ 17
6.2 EXTERNAL DIMENSION ............................................................................................................................................. 18
7.REFRIGERATING PIPING SYSTEM AND CIRCULATING ROUTE OF COOLING AIR.................................19
7.1 REFRIGERATING PIPING SYSTEM ............................................................................................................................. 19
7.2 CIRCULATING ROUTE OF COOLING AIR..................................................................................................................... 20
8. DISMANTLING OF PARTS..................................................................................................................................21
8.1 PARTS ON THE DOOR................................................................................................................................................ 21
8.2 PARTS INSIDE THE REFRIGERATOR .......................................................................................................................... 21
8.3 LIGHT SYSTEM.......................................................................................................................................................... 22
8.4AIR DUCTAND FAN MOTOR........................................................................................................................................ 22
8.5EVAPORATOR AND TEMPERATURE SENSING SYSTEM .............................................................................................. 23
8.6 COMPRESSOR CASE ................................................................................................................................................ 25

Service Manual_2017-V1
4
8.7 DISPLAY CONTROL BOARD ....................................................................................................................................... 30
8.8 MAIN CONTROL BOARD ............................................................................................................................................ 30
8.9 BAR COUNTER.......................................................................................................................................................... 31
8.10WATER DISPENSER................................................................................................................................................ 31
8.11ICE MAKER............................................................................................................................................................... 31
9. FUNCTION AND OPERATION............................................................................................................................32
9.1 OPERATION PANEL ................................................................................................................................................... 32
9.2 DISPLAY.................................................................................................................................................................... 32
9.3 SETTING OF THE GEAR............................................................................................................................................. 32
9.4 CONTROL OF STANDBY FUNCTION ........................................................................................................................... 33
9.5 CONTROL OF ICE MAKER (NONE)............................................................................................................................. 33
9.6 FAULT CODE AND SOLUTIONS................................................................................................................................... 33
9.7 DEFROSTING FUNCTION........................................................................................................................................... 33
9.8 TEST MODE............................................................................................................................................................... 33
10. CIRCUIT DESCRIPTION ...................................................................................................................................35
10.1 POWER SUPPLY..................................................................................................................................................... 35
10.2 DOOR TRIP TEST CIRCUIT(NONE).......................................................................................................................... 35
10.3 TEMPERATURE TEST CIRCUIT ................................................................................................................................ 35
10.4 FAN MOTOR CIRCUIT OF THE FREEZING CHAMBER................................................................................................ 36
10.5 REFRIGERATOR FAN MOTOR CIRCUIT (NONE)....................................................................................................... 36
10.6 CONDENSER FAN MOTOR CIRCUIT(NONE)............................................................................................................. 36
10.7 DAMPER MOTOR CIRCUIT(NONE).......................................................................................................................... 36
10.8 SENSOR RESISTANCE(R/T) ................................................................................................................................... 36
11. TROUBLESHOOTING METHOD......................................................................................................................38
11.1 NO COOLING(AIR COOLING-ELECTRONIC)............................................................................................................ 38
11.2 NO WORKING OF COMPRESSOR............................................................................................................................. 39
11.3 INSIDE FROSTING,NO DEFROSTING....................................................................................................................... 39
11.4 INSIDE FROSTING,NO DEFROSTING-MAINTENANCE GUIDELINES.......................................................................... 40
11.5 LIGHT IS NOT ON..................................................................................................................................................... 41
11.6AIR DUCT NOT OPERATED(ELECTRONICALLY)(NONE)........................................................................................... 41
11.7 FAN FAILURE........................................................................................................................................................... 41
11.8 DEFECTIVE DEFROST CIRCUIT ............................................................................................................................... 42
11.9 NOISE ..................................................................................................................................................................... 42
12. FIGURES AND DETAILS OF REPAIR PARTS(DOCUMENTS ARE PROVIDED SEPARATELY) .............43
12.1 FIGURES(NONE)..................................................................................................................................................... 43
12.2 LIST OF PARTS AND COMPONENTS(NONE)............................................................................................................. 43
13. APPENDIX...........................................................................................................................................................44
13.1 REFRIGERATOR MAINTENANCE TOOLINGAND EQUIPMENTAND MATERIAL............................................................ 44

Service Manual_2017-V1
5
1. Safety Warning Code
1.1 Warning for operation safety
Important Safety Instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present
within your freezer.
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying your freezer.
WARNING
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this appliance near water.
6) Clean only with a damp cloth.
7) Do not block any ventilation openings.
8) Install in accordance with the manufacturer’s instructions.
9) Do not install near any heat sources, such as radiators, heat registers, stoves, or
other apparatus that produce heat.
10) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
11) Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles, and the point where they exit from the appliance.
12) Do not attempt to modify or extend the power cord of this appliance.
13) Unplug this appliance during lightning storms or when it will not be used for long
periods of time.
14) Make sure that the available AC power matches the voltage requirements of this
appliance.

Service Manual_2017-V1
6
CONNECTING ELECTRICITY
Electrical Shock Hazard.
Plug into a grounded 3-prong outlet.
Do not remove the ground prong.
Do not use an adapter.
Failure to follow these instructions can
result in death, fire, or electrical shock.
WARNING
Electric Shock Hazard
Failure to follow these instructions can result in electric shock, fire, or
death.
1) WARNING–Keep ventilation openings, in both the freezer and the built-in structure,
clear of obstruction.
2) WARNING–Do not touch the interior of the freezer with wet hands. This could result
in frost bite.
3) WARNING–Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
4) WARNING–Do not damage the refrigerant circuit.
5) WARNING–Do not damage the refrigerant tubing when handling, moving, or using
the freezer.
6) WARNING–DANGER–Never allow children to play with, operate, or crawl inside the
freezer. Risk of child entrapment. Before you throw away your old freezer:
6-1) Take off the doors
6-2) Leave the shelves in place so that children may not easily climb inside
7) Unplug the freezer before carrying out user maintenance on it.
8) This freezer can be used by children age eight years and older and persons with
reduced physical or mental capabilities or lack of experience and knowledge if they are
given supervision or instruction concerning the use of the freezer in a safe way and
understand the hazards involved. Children should not play with the freezer. Cleaning and
maintenance should not be performed by children without supervision.
9) If a component part is damaged, it must be replaced by the manufacturer, its service
agent, or similar qualified persons in order to avoid a hazard.
10) Please dispose of the freezer according to local regulations as the freezer contains
flammable gas and refrigerant.
11) Follow local regulations regarding disposal of the freezer due to flammable
refrigerant and gas. All refrigeration products contain refrigerants, which under the
guidelines of federal law must be removed before disposal. It is the consumer's
responsibility to comply with federal and local regulations when disposing of this product.
12) This freezer is intended to be used in household and similar environments.

Service Manual_2017-V1
7
13) Do not store or use gasoline or any flammable liquids inside or in the vicinity of this
freezer.
14) Do not use extension cords or ungrounded (two-prong) adapters with this freezer. If
the power cord is too short, have a qualified electrician install an outlet near the freezer. Use
of an extension cord can negatively affect the freezer’s performance.
Grounding requirement
This freezer must be grounded. This freezer is equipped with a cord having a grounding
wire with a grounding plug. The plug must be inserted into an outlet that is properly installed
and grounded.
Improper use of the grounding plug can result in a risk of electric shock. Consult a
qualified electrician or service person if the grounding instructions are not completely
understood, or if doubt exists as to whether the freezer is properly grounded.
1.2 Safety instruction for refrigerant
Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from freezer. Failure to do so
can result in fire, explosion, or death.
Safety instruction for refrigerant
DANGER–Risk of Fire or Explosion. Flammable Refrigerant Used. To Be Repaired Only By
Trained Service Personnel. Do Not Use Mechanical Devices. Do Not Puncture Refrigerant
Tubing. CAUTION–Risk of Fire or Explosion. Flammable Refrigerant Used. Consult Repair
Manual/Owner’s Guide Before Attempting To Service This Product. All Safety Precautions
Must be Followed. CAUTION–Risk of Fire or Explosion. Dispose of Properly InAccordance
With Federal Or Local Regulations. Flammable Refrigerant Used. CAUTION–Risk of Fire or
Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling Instructions Carefully.
Flammable Refrigerant Used.

Service Manual_2017-V1
8
2. Description for product features
This product is provided with following features:
1) Full air-cooling and frost-free design
2) Electronic temperature control system with more accurate temperature control.
3) The crisper for fruits and vegetables can be adjusted in humidity.
4) Space is reserved for ice maker and customers can purchase the matching ice maker to install

Service Manual_2017-V1
9
3. Installation and commissioning
3.1 Handling
Handling
1)Protect the refrigerator in moving it,Same as shown as
left photo, please move it by handcart with cushion
2)Remove all packing materials and bottom cushion, the
n move into house for placement
3)After moving it to appropriate location, wait for 2 hours
before power on.
3.2 Door Disassembly and Assembly
The refrigerator door needs to be dismantled if it cannot enter the room in the whole.
Disassembly of Freezer door
Disassembly of Freezer door
None
Disassembly of refrigerator door
Disassembly of refrigerator door
None
3.3 Installation location
Installation location
Location that is easy for ventilation shall be chosen to
facilitate heat dissipation, enhance its performance and
reduce the energy consumption.

Service Manual_2017-V1
10
3.4 Leveling of the refrigerator
Leveling of the refrigerator
If the refrigerator cannot be placed steadily, adjust the
footing to level it.
3.5 Door reversal
Door reversal
1.Unplug your refrigerator and remove all food from the
door shelves. Remove all food from the inner door liner.
Tape the door shut with masking tape. Remove the left
cover plate and the right top hinge cover, then unscrew
screws and remove the right top hinge. Keep the
screws to reuse.
2.Lift the freezer door up and away from your
refrigerator.Unscrew screws holding the center hinge,
remove the hinge, then lift the refrigerator door up and
away from your refrigerator. Save the screws to reuse.

Service Manual_2017-V1
11
3. Unscrew screws holding the bottom hinge, then
remove the bottom hinge
4.Unscrew the hinge pin from the right side of the bottom
hinge and move it to the left side,then secure the bottom
hinge to the bottom left side of the refrigerator, using the
screws you removed previously.
5. Remove the hole cap from the top left of the
refrigerator door and insert it in the other side.
6.Remove the door block from the bottom right side of the
freezer and refrigerator door and attach it to the other side.

Service Manual_2017-V1
12
7.Remove the two hole caps from the left side, where the
center hinge will go,and insert them into the other
side.Attach the refrigerator door on the bottom hinge,
then attach the center left hinge to the left side of the
refrigerator.the top hinge and replace the hinge cover.
8.Put the freezer door onto the center left hinge, then
attach the top left hinge to the top of refrigerator. Cover
the hinge with the top left hinge cover and cover the
screw
holes on the right side of the top with the cover plate you
previously removed.
9.Remove the screw caps on the door handles, then
remove the fourAllen-screws securing
the handles to the left side of the doors with the Allen
wrench. Remove the handles.
10.Remove the four Phillips-head screws from the left
side of the door.Screw the four Phillips-head screws into
the holes on the right side of the door.Attach the handles
to the right sides of doors with the Allen-head screws you
just removed. Tighten with the Allen wrench and replace
the screw caps.

Service Manual_2017-V1
13
3.6 Installation of handle
Installation of handle
Installation of handle
Take out the two crisscross-screw; and install them into the
door holes; turn the screws till to the bottom;Aim at screws to
install the handle;The screws in the hole at the side of the
handle and turn the screws till them very tight;Screw cap
should be put on the screw.
3.7 Installation of door lock
Installation of door lock
Installation of door lock
None
3.8 Adjustment to level the door
Adjustment to level the door
Adjustment to level the door
None
3.9 Adjustment to shelves
Adjustment to shelves
Adjustment to shelves
None

Service Manual_2017-V1
14
4. Terms
4.1 Definition of model(None)
4.2 Location of nameplate(None)

Service Manual_2017-V1
15
5. Product specification
5.1 Type specification(None)
5.2 Electrical parameters
Product Name
UR-BCD280WE-SQ
UR-BCD326WE-SQ
None
None
Product Code
22031020003381
22031020001681
92031020Z00041
92031020Z00029
92031020Z00042
None
None
Item
Specification
Specification
Specification
Specification
Compressor
Compressor
EE45H1C
EE50H1C
None
None
Starter(PTC)
QPE2-A4R7MD3
QPE2-A4R7MD3
None
None
Overload
protector(OLP)
DRB34T61A1
DRB31T61A1
None
None
Winding resistance of
compressor wiring
terminal
Rmc:4.18±7%Ω
Rsc:4.58±7%Ω
Rms=Rmc+Rsc
Rmc:3.88±7%Ω
Rsc:4.51±7%Ω
Rms=Rmc+Rsc
None
None
Winding resistance
None
None
Variable frequency
driver board
None
None
None
None
Motor
Fan motor of the
freezing chamber
DC12V/4W
DC12V/4W
None
None
Ventilation door of the
refrigerating chamber
None
None
None
None
Condensation fan
None
None
None
None
separation the ice
motor
None
None
None
None
ice output motor
None
None
None
None
Open door motor
None
None
None
None
Lights inside the refrigerator
Lights inside the
freezing chamber
None
None
None
None
Lights inside the
refrigerating chamber
115V/＜3.5W
115V/＜3.5W
None
None
Switch of the
Sector
Sector
None
None

Service Manual_2017-V1
16
refrigerator door
5.3 Inside temperature
Temperature tolerance ≤ 2 oC
Compartment
The highest (oC)
Lowest (oC)
Freezing
-14
-24
Refrigerating
9
1
Variable temperature
/
/
5.4 Defrosting parts
Item
Initial defrosting period
Normal defrosting period
Defrosting period
Temperature is lower than 0oC
6~24 hours
Defrosting sensor
B3839
B3839
Defrosting temperature
controller
None
None
Thermal fuse
Can’t be restored 77℃
Can’t be restored 77℃
Defrosting heater in freezing
chamber
115V/200W
115V/200W
5.5 Circuit diagram
BCD595WE(22031020003381_22031020001681_92031020Z00041_92031020Z00029_92031020Z000
42)

Service Manual_2017-V1
17
6. Internal view and dimension
6.1 Main parts and their names
Freezer chamber
Refrigerator chamber
❶Air duct components in freezing chamber
❷Steel wire shelf
❽Bottle frame in freezing chamber
❸Air duct components in refrigerating chamber
❹Glass shelf
❺Cover plate of crisper
❻Crisper for fruit and vegetable
❼Regulating foot
❾Storage box
❿Small bottle frame in refrigerating chamber

Service Manual_2017-V1
18
6.2 External dimension
Description
Code
Size (mm)
Height to Top of Case
A
1687
None
None
Width
B
837
None
None
Depth w/o Handles
C
837
None
None
Depth (90 deg. with Door Open)
D
734
None
None
Width (door open 90 deg. w/ handle)
E
None
None
None

Service Manual_2017-V1
19
7.Refrigerating piping system and circulating route of cooling air
7.1 Refrigerating piping system
BCD595WE(22031020003381_22031020001681_92031020Z00041_92031020Z00029_92031020Z000
42)
❶Compressor→❷Right condenser→❸Anti-condensation tube→❹Left Condenser→❺Dry
filter→❻Capillary tube→❼Evaporator→❽Suction tube→❶Compressor

Service Manual_2017-V1
20
7.2 Circulating route of cooling air
