Midea MRT18B2ASL User manual

Refrigerator
TOP MOUNTED FREEZER SERIES
MRT18B2ASL
USER MANUAL
Warning notices: Before using this product, please read this manual carefully and keep it for future reference.
The design and specifications are subject to change without prior notice for product improvement.
Consult with your dealer or manufacturer for details.
The diagram above is just for reference. Please take the appearance of the actual product as the standard.

02
EN
THANK YOU LETTER
Thank you for choosing Midea! Before using your new Midea product, please read
this manual thoroughly to ensure that you know how to operate the features and
functions that your new appliance offers in a safe way.
CONTENTS
THANK YOU LETTER ------------------------------------------- 02
SPECIFICATIONS------------------------------------------------ 03
PRODUCT OVERVIEW----------------------------------------- 04
PRODUCT INSTALLATION----------------------------------- 05
OPERATION INSTRUCTIONS-------------------------------- 12
CLEANING AND MAINTENANCE--------------------------- 15
TROUBLESHOOTING------------------------------------------- 17
WARRANTY ------------------------------------------------------- 19

03
EN
SPECIFICATIONS
Rated Voltage 115V
Rated Frequency 60Hz
Rated Current 1.2A
Defrost Power 180W
Refrigerant, Amount R600a, 1.73oz(49g)
Foaming Agent Cyclopentane

04
EN
PRODUCT OVERVIEW
Names of components
1Shelf 4Fruits and vegetables box
2Freezer temperature control 5Door tray
3Display control panel 6Storage box
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.

05
EN
PRODUCT INSTALLATION
Install Instruction
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
>100mm >100mm
>100mm
>100mm
>100mm
>100mmm
Top View
Required space
for air circulation
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.

06
EN
Space requirement diagram (when the door is open and when the door is closed)
B
AC
D
B
E
135 °
Width Overall
Height Depth
Width
doors open
135o
Depth
doors open
135o
A B C D E
750 1692 785 1270 1289
Notice: All dimensions in mm

07
EN
Door right-left change(Optional)
List of tools to be provided by the user
Allen wrench-Cross screwdriver
Putty knife Thin-blade screwdriver
5/16″socket spanner
Masking tape
1. Unplug your refrigerator and remove all food from the door shelves. Remove all food from
the inner door liner. Fix the door by tape.
2. Remove the hole cover and the right top hinge cover, then unscrew screws
and remove the right top hinge. Keep the screws to reuse.
3. Lift the freezer door up and away from your refrigerator.
4. Unscrew screws of middle hinge, remove the hinge, then lift the refrigerator
door up and away from your refrigerator. Save the screws to reuse.
Hole cap Right top hinge cover
Top Right hinge
Right door self-locking block
Right door open stopper
Middle right hinge

08
EN
5. Unscrew screws of the bottom hinge, then remove the bottom hinge from the
bottom right side of the refrigerator.
6. Unscrew the hinge shaft from the right side of the bottom hinge and move it
to the left side, then secure the bottom hinge to the bottom left side of the
refrigerator, using the screws you removed previously.
7. Remove the sleeves from the top right of doors and hole cap from top left of
doors, and assemble them on the opposite sides.
8. Remove the refrigerator door open bottom stopper and install it other side of
the door. Remove the freezer right door self-locking block and right door open
stopper and save. Them to reuse take out the left freezer self-locking block
and left door open stopper from the accessory bag in the refrigerator and
installed on the left of freezer door.
Hinge shaft
Bottom hinge
Left door self-locking block
Left door open stopper
Top sleeves
Hole cap
Sleeves
Bottom stopper

09
EN
9. Install the refrigerator door vertically onto the bottom hinge. Take out the
middle left hinge from the accessory bag then assemble the middle left hinge
on the left side of the refrigerator.
10.Install the freezer door vertically into the center hinge. Take out the left top
hinge and left top hinge cover from accessory bag, assembly left top hinge,
left top hinge cover and hole cover.
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.
Left top hinge cover
Top left hinge
Hole cap
Middle left hinge

10
EN
Installing the door handle(Optional)
Parts included with the handle kit:
You will need: A Phillips screwdriver and the included Allen wrench.
1. Insert the two Phillips-head screws into the refrigerator door on the side you
prefer, then tighten.
2. Align the door handle with the screws.
3. Insert the two Allen-head screws through the side of the door handle and
tighten with the Allen wrench.
4. Place the screw caps on the screws.
ATTENTION
The picture above is only for reference. The actual conguration will depend on the physical
product or statement by the distributor.
Installing an optional ice maker
The refrigerator comes set up for ice maker installation, This refrigerator is
compatible with Midea IM1900MD ice maker. Please refer to individual ice maker
installation instruction manual.
• WARNING: Connect to potable water supply only.
• Minimum/Maximum inlet water pressure: 138/827 kPa (20/120 psig).
Screws (4) Allen wrenchHandle assembly Allen wrench
caps (4)
Allen wrench
screws (4)
