Midland G9 User manual

LINK SETTING FOR MIDLAND G9
Fig 1

Fig 2

If you have the radios as configuration Fig 2, make more attention when you cut the jumper, verify
and remove the part in excess of coil’s, otherwise whether the one remain inside the radios, can
bring about a short-circuit. If you want soldering the jumpers again, you make it in the base of pcb
and whether neccesary remove all coil’s.




‐Open the radio and follow below table for link setting:
defaultsettingfor
PMRversiononly
defaultsettingfor
dualbandversion
PMR/LPD
 
J_POWER1ShortopenopenOpenShortShort
J_POWER2ShortShortopenOpenShortopen
J_POWER4ShortShortShortOpenOpenopen
Bymenu
radio
24CHPMR
(500/10mW)
24CHPMR
(500/10mW)+
69CHLPD(10mW)
LPD
10mW
LPD=
5W/500mW
24CHPMR
(5W/500mW)+
69CHLPD
(5W/500mW)
24CHPMR
(5W/500mW)
Whenpress
PTTbutton
500/10mWPMR=500/10mW
LPD=10mW
always
10mW
5W/500mW PMReLPD=
5W/500mW
5W/500mW
Whenpress
BOOST
button
Always500mWPMR=always
500mW
LPD=always
10mW
Always
10mW
Always5WAlways5Wfor
LPDandPMR
Always5W
After editing mode to switch LPD turn on the radio, and then hold down the menu for 5 / 6 seconds
until the display does not appear LPD channels. To return in PMR, repeat the procedure.
