Midland ER310 User manual

Page 2
Model ER310
midlandusa.com
TableofContents -------------------------------------- 2
Features -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -3
Controls and Functions---------------------------------- 4
ER310 Power Sources -----------------------------------6
Usingthe USB Output Port to Charge a Device ----------8
Operating the Radio-------------------------------------8
Using the Weather Radio-------------------------------- 9
ER310 Settings Menu------------------------------------11
LED Flashlight-----------------------------------------12
SOS Morse Code Flashlight Beacon ---------------------12
Ultrasonic Dog Whistle----------------------------------12
Using the Headphone Jack------------------------------12
Limited Warranty------------------------------------- --13
Service - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 15
Other Products-----------------------------------------16
Accessories - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 17
FCC Notice - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18

Page 3
Model ER310
midlandusa.com
Welcome to the World of Midland Electronics
The Midland ER310 is skillfully constructed from the finest
components. Built with emergency situations in mind, the hand
crank digital weather alert radio and flashlight are perfect for
severe weather situations or daily use.
Features
• Charge battery 3 ways: hand crank, USB or solar panel
• 7 NOAA/NWS weather alert channels and 1 hour alert memory
• Rechargeable Lithium-ion battery
• Powerful flashlight uses Cree®* LEDs
• SOS Morse code flashlight beacon
• Ultrasonic dog whistle
• Charge external electronic devices
• AM/FM radio
• AA battery power option
• Digital clock
• Headphone jack
• Rotatable telescopic antenna
• Large, bright, backlit LCD
*Cree® is a registered trademark of Cree, Inc. or one of its subsidiaries.

Page 4
Model ER310
midlandusa.com
Controls and Functions
Flashlight/
SOS/Dog
Whistle
Button
LCD
Display
Solar
Panel Antenna
Speaker
Tuning
Adjust
Buttons
Volume
Adjust
Buttons
Weather
Alert/Menu
Button
Power/
Band
Button
LED
Flashlight
Ultrasonic
Dog
Whistle
Charge/
Weather
Memory
Indicator

Page 5
Model ER310
midlandusa.com
Dynamo
Crank
Headphone
Jack
USB Input
Port
USB Output
Port
AA/Li-ion
Power Switch
Controls and Functions Continued...

Page 6
Model ER310
midlandusa.com
Powering Your ER310
USB Charge Cable: Before the ER310 is used, the internal
rechargeable battery pack should be charged with the USB charge
cable until the battery indicator icon indicates a full charge. To
charge the ER310 with the USB cable, switch the power source
switch to the “Li” position. Then, insert the USB charge cable into
a USB power source and plug the micro USB connector into
the port labeled “USB In” on the side of the radio. The CHARGE
indicator light will be lit when the USB charge cable is plugged
in. The battery icon on the LCD will flash as the battery charges.
When the Li-ion battery has reached full charge, the battery icon
will stop flashing and will have 3 bars. It will take approximately
5.5 hours to recharge a completely depleted battery pack using the
USB charge cable.
Rechargeable Battery:The included rechargeable battery
is located in the battery compartment and is charged by turning
the hand crank, exposing the solar panel to sunlight, or by using
the USB cable to attach to a USB power source. The battery is
specified as 3.7 VDC, 2600 mAh, lithium ion (Li-ion).
Warning:
• Only use Midland’s Li-ion battery pack.
• Do not attempt to charge alkaline batteries or any battery packs
other than the ones indicated in this manual. This could cause
leakage and damage to the radio.

Page 7
Model ER310
midlandusa.com
ER310 Power Sources Continued...
Dynamo Power: Turning the hand crank charges the built-in
Li-ion battery pack. To charge the radio using the hand crank,
make sure the power source switch is in the “Li” position and start
turning the crank. The CHARGE indicator light will be lit while
the unit is being cranked. Speed of cranking and length of time
cranked will determine the charge of the Li-ion battery. The battery
icon on the LCD will flash as the battery charges. When the Li-ion
battery has reached full charge, the battery icon will stop flashing
and will have 3 bars. One minute of cranking gives up to 9 minutes
of radio use time.
Solar Panel Charge: Make sure the power source switch is
in the “Li” position. Then, place the ER310 where the solar panel
is exposed to direct sunlight. One hour of solar charging in optimal
sunlight conditions gives up to 45 minutes of radio use time. The
battery icon on the LCD will flash as the battery charges. When
the Li-ion battery has reached full charge, the battery icon will stop
flashing and will have 3 bars. The CHARGE indicator light will be
lit while the unit is charging.
AA Battery Operation: The ER310 is designed to operate
on six AA batteries (not included). To power the ER310 on its
AA batteries, flip the power source switch to the “AA” position.
Warning: For long-term storage, it is recommended that the
AA batteries be removed to prevent leakage and damage to
the ER310.

Page 8
Model ER310
midlandusa.com
Operating the Radio
Turning the ER310 On/Off & Selecting a Band
• To turn the radio on, press the BAND button. To cycle through
AM, FM, or Weather radio bands press the band button again.
• To turn the radio OFF, press and hold the BAND button for
2 seconds.
Adjusting the Volume
• To adjust the volume, press the UP/DOWN VOLUME control
buttons to adjust the audio.
Tuning the Radio
• Press the BAND button to cycle through AM, FM, and Weather
radio bands.
• Once you are on the desired radio band, you can tune to the
desired station with the TUNE up or down buttons. For best FM
and Weather reception, fully extend the telescopic antenna and
rotate until reception is clear.
Charging External Devices
Cell phones and USB-powered devices can be charged using the
USB charge cable for that device. Connect the charge cable to the
USB Outlet port on the side of the ER310 labeled “USB Out”. If the
radio is on it will automatically turn off and go into charge mode.
Once charging is complete; disconnect the device and charging
cable from the ER310. This will allow you to operate the other
features in your ER310.

Page 9
Model ER310
midlandusa.com
Using the Weather Radio
About NOAA/NWS
The National Oceanic Atmospheric Administration and the National
Weather Service operates a system of weather and hazard alert
broadcasts covering most of the United States. Typical broadcasts
are within reception distance of 25-50 miles of the weather
station. Fully extend the telescopic antenna and rotate until
reception is clear. The ER310 can receive broadcasts up to 50
miles from the weather station depending on your location and
conditions of weather, terrain, etc. If reception is not good, try a
different location to find a spot of improved reception. If indoors,
placement near a window usually improves reception. If a weather
broadcast cannot be heard on any of the 7 channels, contact your
local NOAA/NWS office and verify the closest station is on air.
Their web site is http://www.nws.noaa.gov/nwr/.
Selecting a Weather Channel
The ER310 has 7 NOAA/NWS weather channels to choose from.
• Press the BAND button to select the weather band.
• Then use the TUNE buttons to select the strongest weather
channel in your area.
Ch. # Frequency
1 162.400 MHz
2162.425 MHz
3162.450 MHz
4162.475 MHz
5162.500 MHz
6162.525 MHz
7 162.550 MHz

Page 10
Model ER310
midlandusa.com
Using the Weather Radio Continued...
Weather Alert Function
• To enable the NOAA Weather Alert function, press the WX
ALERT button.
• When enabled, the “WX” icon on the LCD screen will flash.
• When a weather alert is received, the ER310 will sound an
audible siren and the flashlight will flash on and off along with the
LCD backlight for 1 minute.
• Within the first minute of an alert being received, press any
button on the ER310 to stop the siren and flashlight.
The radio will switch to your selected weather channel.
Weather Alert Memory Function
• After the first minute of receiving a weather alert, if no
button is pressed, the ER310 will go into weather alert
memory mode.
• The WEATHER MEMORY INDICATOR will flash every 5
seconds indicating an alert has been received within the last
hour.
• When the WX ALERT button is pressed, the radio will
switch to your selected weather channel and clear the weather
alert memory.
• Any other button pressed will have normal function and
will clear the weather alert memory.
