Miele T 4662 C User manual

Operating instructions
for condenser tumble dryer
T 4662 C
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed and used for the first time.
G
M.-Nr. 06 465 800

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of your
appliance with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person. The plug must be
rendered useless and the cable cut off
directly behind it to prevent misuse.
See the "Warning and Safety" section of
this booklet for further details.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
– Load according to the optimum
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
–Make sure the room in which the
dryer is located is well ventilated.
–Make sure the fluff filters are clean
before using the dryer.
–Check the condenser unit from time
to time and clean it when necessary.
Caring for the environment
2

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Disposal of the packing material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Disposal of your old appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Energy saving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating the tumble dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Care symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Tips on drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Extra options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Low temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Short. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Anti-crease. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Changing a programme while it is running . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To cancel a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
To interrupt a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 23
Electronic programme locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Contents
3

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Emptying the condensed water container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning the fluff filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cleaning them whilst dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Cleaning them with water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cleaning the tumble dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Cleaning the condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Removing the condenser unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Checking the condenser unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cleaning the condenser unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Replacing the condenser unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Fault messages in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Other problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Changing the lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
After Sales service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Future updates (PC). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Appliance guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Installation site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Transporting the machine to its installation site . . . . . . . . . . . . . . . . . . . . . . . . 39
Building under a continous worktop / in a row of kitchen units . . . . . . . . . . . . 39
Replacing the lid. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Levelling the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Room in which the dryer is located . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Washer - dryer stack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Before moving the machine again (e.g. when moving house). . . . . . . . . . . . . 40
External condensed water outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting up the drain hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Connection to a sink drain outlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
If you no longer wish to use an external condensed water outlet . . . . . . . . . . 42
Contents
4

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Settings menu J. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Language J. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Time of day . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Drying levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Extending the cooling down time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Airways indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Display brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Keypad tones. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Contents
5

To avoid the risk of accidents and
damage to the machine please read
these instructions carefully before
using it for the first time. They
contain important information on its
safety, installation, use and
maintenance.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner of the
machine.
Correct use
The tumble dryer is only intended
for drying fabrics which have been
washed in a water solution, marked on
the manufacturer's care label as being
suitable for tumble drying.
"Dry cleaning kits" for freshening up
garments in a tumble dryer are
increasingly available on the market. If
using, do so at your own risk, and
follow the instructions provided on the
packaging.
Any other applications may be
dangerous. The manufacturer is not
liable for damage resulting from
improper use or operation.
Technical safety
Before setting up the machine,
check it for any externally visible
damage.
Do not install or use a damaged
machine.
Before connecting the machine,
ensure that the connection data on
the data plate (voltage and connected
load) match the mains electricity
supply. If in any doubt, consult a
qualified electrician.
The electrical safety of this
machine can only be guaranteed
when continuity is complete between it
and an effective earthing system which
complies with local and national
regulations. It is most important that this
basic safety requirement is present and
regularly tested, and where there is any
doubt the household wiring system
should be inspected by a qualified
electrician. The manufacturer cannot be
held liable for the consequences of an
inadequate earthing system (e.g.
electric shock).
Do not connect the appliance to
the mains electricity supply by an
extension lead. Extension leads do not
guarantee the required safety of the
appliance (e.g. danger of overheating).
Warning and Safety instructions
6

The machine is built in accordance
with current safety requirements.
Unauthorised repairs could result in
unforeseen dangers for the user, for
which the manufacturer cannot accept
liability. Repairs should only be
undertaken by a Miele approved
technician.
Ensure current is not supplied to the
machine until after maintenance or
repair work has been carried out.
Faulty components must only be
replaced by genuine Miele original
spare parts. Only when these parts are
fitted can the safety standards of the
machine be guaranteed.
If the connection cable is faulty it
must only be replaced by a Miele
approved service technician to protect
the user from danger.
In countries where there are areas
which may be subject to infestation
by cockroaches or other vermin, pay
particular attention to keeping the
machine and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the machine guarantee.
Warning and Safety instructions
7

In the event of a fault or for
cleaning purposes, the machine is
only completely isolated from the
electiricty supply when:
–it is switched off at the wall socket
and the plug is withdrawn, or
–it is switched off at the mains, or
–the mains fuse is withdrawn.
Operation
This equipment may only be used
in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
The dryer must not be used without
the fluff filters in place or if the fluff
filters are damaged in any way.
The fluff filters must be thoroughly
dried after cleaning. If they are still
damp or wet when replaced there is a
risk of faults occurring when the
machine is used.
The dryer must not be used without
the condenser unit in place.
Do not install the machine in a
room where there is a risk of frost
occurring. At temperatures around
freezing point the machine may not be
able to operate properly.
There is a risk of damage if the
condensed water is allowed to freeze in
the pump, hoses and / or condensed
water container.
The ambient room temperature should
be between +2°C and +35°C.
If the water is drained externally
through the drain hose instead of
being collected in the condensed water
container, make sure the drain hose is
securely attached if you hang it in a
sink or basin to avoid the hose slipping
and the water causing damage.
Condensed water is not drinking
water. It can cause health
problems in both people and animals.
Always keep the area around the
machine free of dust and fluff. Dust
drawn into the machine can, over time,
cause blockages in the condenser unit.
Warning and Safety instructions
8

To prevent the risk of fire the
following textiles must not be
dried in this machine:
–fabrics which contain a large
proportion of rubber, foam rubber or
rubber like materials.
–items which contain padding or
fillings (e.g. pillows, jackets).
–items which have been treated with
inflammable cleaning agents.
–items which have been splashed with
hair lacquer, hair spray, nail varnish
remover or similar substances.
– items which have been soiled with
oils or residues containing grease
(kitchen oils, cosmetics etc.).
– items soiled with wax or other
chemicals (e.g. mops and floor
cloths).
– items which have not been
thoroughly cleaned and which are
still soiled with grease or oil, e.g.
workwear. Such clothing may require
a heavy duty detergent to get them
clean. If necessary consult the
detergent manufacturer for advice.
Do not let anyone sit or lean on the
door, as this can cause the
machine to tip up.
Always close the door after use.
This way you will avoid the danger
of:
–children climbing onto or into the
dryer or hiding things in it.
–pets or other small animals climbing
into it.
Safety with children
This machine is not a toy. To avoid
the risk of injury keep children
away from the machine at all times and
supervise them whilst you are using it.
Do not allow children to play on or near
it or to play with its controls. Supervise
its use by the elderly or infirm.
Using accessories
Accessory parts may only be fitted
when expressly approved by Miele.
If non-Miele parts are used with this
machine, guarantee, performance and
product liability claims may be
invalidated.
Disposal of your old machine
Before discarding an old machine,
switch it off at the wall socket and
unplug it. Render the plug useless and
cut off the cable directly behind the
machine. This should be done by a
competent person.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
9

Control panel
aDisplay
See the following pages for more
information.
bStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
c–, OK and + buttons
See the following page for more
information.
dmbutton
For selecting delay start and
displaying the time of day.
ePC / Optical interface
This is used by service technicians
to run diagnostic checks on your
machine and can also be used to
update programming data in the
future.
fExtras buttons with indicator lights
Various Extras (options) can be
added to the drying programmes.
gProgramme selector
For selecting a programme. The
programme selector can be turned
clockwise or anti-clockwise.
hI-On/0-Off button
For switching the dryer on and off.
iDoor button
Pressing this button will open the
door, even if the machine is switched
off at the mains.
Operating the tumble dryer
10

Display
The following are shown in the display:
–Programme Selection menu
–Programme duration and the
programme start and end time
–Fault and error messages
When a programme is selected, the
display is used to select:
–Different drying levels
–Delay start
The
Settings Jmenu is also operated
via the display.
- / + buttons
For altering the values shown in the
display:
-decreases the value or moves the
highlighting upwards
+increases the value or moves the
highlighting downwards
OK button
For confirming the value selected and
choosing the next option.
mbutton
For selecting delay start.
You can also press this button during a
drying programme to check the
estimated programme end time or the
current time of day.
Estimated time remaining
When a programme is selected the
estimated drying time will appear in the
display. Please be aware that it is only
an estimate!
The following factors all affect the
estimated time remaining: Residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the machine and adjust
the estimated time remaining for a more
accurate reading. Because of this the
time displayed can alter during the
course of a programme.
In the same way, the
Woollens hand
care
and Smoothing programmes can
finish earlier than expected if a certain
temperature is reached. This can
happen with particularly fine fabrics or
if items were partly dry beforehand.
Operating the tumble dryer
11

Before using for the first time
When the tumble dryer is switched on
for the first time, the welcome screen
will appear.
The welcome screen will not appear
again after you have entered the time of
day, and run an initial programme
lasting longer than one hour.
The display for setting the time of day
will appear.
To set the time of day
10 :00
Set time of day
^Set the hour with the -and +buttons
and confirm your setting by pressing
the
OK button.
^Now set the minutes and confirm
your selection.
Entry menu
The entry menu showing the current
time of day will appear after the
machine has been switched on, until
you select an option.
After a few seconds an additional line
will appear in the display.
Settings J:
10:00
Select programme
Settings F...
See "Settings menu" at the end of this
booklet for more information.
You can now load the laundry into the
dryer and select a programme as
described in "How to dry correctly".
Operating the tumble dryer
12

Care symbols
Before drying check the drying symbol
on the care label. If there are no
symbols, dry at your own risk!
q. . . . . . . . . Dry at normal temperature
r. . . . . . . . . . Dry at a low temperature
s. . . . . . . . . . . . . . . Do not tumble dry
Tips on drying
–Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– Do not put soaking wet items into the
tumble dryer. Spin them thoroughly
after washing using the appropriate
spin speed.
–For delicates and fabrics with the
following care label rselect
Low
temperature
.
–Use the
Automatic programme for
drying mixed loads of cottons and
minimum iron fabrics.
–Open jackets so that they can dry
evenly.
–Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. They can, however,
be partially dried using the
Woollens
hand care
programme.
–Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough. They can
be partially dried using the
Smoothing programme.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not over-dry these
textiles. When purchasing these
garments it is advisable to take their
shrinkage properties into account.
– For garments made from very fine
weave fabrics, such as shirts or
blouses, only use the
Shirts or
Delicates programme to avoid
creasing. If in doubt, reduce the load
or use the
Smoothing or Silks
handcare
programme.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the machine.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
Notes on laundry care
13

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
machine.
ASort the laundry
To ensure an even drying result
separate out the washed laundry and
sort it according to: . .
. . . the drying level required
. . . the type of fibre or weave
. . size
. . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
–Fasten hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
I-On/0-Off button in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
CLoad the tumble dryer
^Press the
Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door make sure
the fluff filter is correctly positioned.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
14

DSelect a programme
^Turn the selector to the programme
you require.
The display will vary according to which
programme has been selected. First
only the programme name will appear:
Cottons
The display will then change.
Please note that the programme
duration shown in the display, will vary
according to the programme selected
(see "Estimated time remaining").
Cottons, Minimum iron, Automatic,
Shirts, Denim
You can select various drying levels for
these programmes.
Normal
Duration: 1:29 h
^Use the
+or - button to alter the
drying level on
Automatic, Shirts and
Denim.
Woollens Hand care, Smoothing
You cannot select a drying level or a
duration for this programme.
Further programmes
When you select this setting the further
programmes will appear in the display.
EDelicates
Silks handcare
Warm air H
^Use the +or -button to highlight the
programme you want. The arrow H
in the display indicates that there are
further options.
^Confirm your selection by pressing
the
OK button.
Delicates
Normal
Duration 0:30 h
^You can use the +or –button to alter
the drying level for the
Outerwear,
Delicates and Sportswear
programmes.
Warm air
2:00 h
Duration: 2:00 h
^You can use the +or –to increase or
decrease the duration from 15 min.
up to 2 h for the
Warm air or Cool air
timed drying programmes.
You cannot alter the drying level or
duration for the other programmes.
How to dry correctly
15

Selecting Extra options
^Select the Extra option you want.
Indicator light on = Extra option is
selected
To select delay start
^See "Delay start".
EStart the programme
The indicator light for the
Start/Stop
button will flash when a programme is
being selected. The flashing indicates
that a programme can be started.
^Press the
Start/Stop button.
The indicator light for the
Start/Stop will
then change from flashing to being on
constantly.
Programme start will appear in the
display, followed by
Drying and the
programme duration.
With sensor drying programmes, e.g.
Machine iron , Hand iron , etc. the drying
level reached will be shown in the
display later on.
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence:
Cool down
will appear in the display. The
programme will not finish until the
cooling down phase has been
completed.
There is no cooling down phase at the
end of the following programmes:
Woollens hand care, Smoothing.
At the end of a programme
Anti-crease (if selected) and Finish will
appear in the display to indicate that
the programme has finished. The
buzzer will sound (if selected).
FRemove the laundry
^Press the
Door button to open the
drum door.
^Remove the laundry.
Make sure that the drum is empty. If
items are left in the dryer, they could
be damaged by overdrying when
the dryer is next used.
If the appliance is switched on and the
door is opened, the drum lighting will
come on. It will go out a few minutes
later to save energy.
^Switch the dryer off by pressing the
l-On/0-Off -button.
^Clean the fluff filters.
^Close the door.
^Empty the condensed water
container (unless the dryer is
connected for external drainage).
How to dry correctly
16

^Each press of the top button selects
the Extra option - indicator light on
(and deselects the previous option)
or no option is selected.
– It is not possible to select the
Short
and Low temperature options at the
same time.
– Not all the extra options are suitable
for use with every programme.
Low temperature
For drying delicates and fabrics with
the rsymbol on the care label at a
lower temperature.
–For all delicate or minimum iron
fabrics with the rsymbol on the
care label (e.g. acrylic garments).
–The programme duration is longer.
–On some programmes
Low
temperature
is a standard part of the
programme and so cannot be
deselected.
Short
For drying fabrics which can
withstand higher temperatures and
have qon the care label. Do not use
on minimum iron or delicate fabrics.
–The programme duration is shorter.
Anti-crease
Helps prevent creasing, if laundry is
not normally removed immediately
after the end of a programme.
– The drum will turn at intervals for up
to an hour.
Buzzer
A buzzer sounds (at intervals for a
maximum of 1 hr) to let you know the
programme has finished.
– You can change the volume of the
buzzer. See "Settings J".
–The buzzer will always sound when
there is a fault, even if it has been
switched off.
Extra options
17

With delay start you can choose when
you want the programme to end,
allowing you to make use of night-time
economy electricity rates for example.
The start of a programme can be
delayed by up to 24 hours.
To select delay start
^Select the programme you want and
then press the mbutton.
10:00
Begin: 10:00
Finish: 11:45
The display will show the current time of
day at the top, the time the programme
will start in the middle and the time the
programme will finish at the bottom.
10:00
Begin: 10:45
Finish: 12:30
^Use the +button to select the time
you want the programme to end at.
The delay start time is selected in
30-minute steps. The first press on the
button will adjust the programme end
time to the next full or half hour. The
start time of the programme is also
adjusted accordingly.
Use the -button to shorten the end time
if you have chosen too long a time.
^Confirm your selection by pressing
the
OK button.
To begin delay start
^Press the
Start/Stop button.
Normal
Begin in: 0:45 h
The delay start time will now count
down in minutes until the start of the
programme.
The drum will turn briefly every hour to
help prevent creasing.
Changing the programme sequence
While the delay start time is counting
down, you can still . . .
. . . change the
Extra options or drying
levels.
. . . press the
Door button and add or
remove laundry. After closing the door,
press the
Start/Stop button again.
To alter delay start
^Press the mbutton.
^Use the -or +button to alter the time
you want the programme to end at.
^Confirm your selection by pressing
the
OK button.
To delete delay start
^Press the mbutton.
^Press and hold the -pressed in, until
the time the programme is due to
start at is the same as the current
time of day.
^Confirm your selection by pressing
the
OK button.
The programme will now start immedi-
ately.
Delay start
18

Cottons Max. load: 6 kg*
Normal+, Normal**
Fabric type Single and multi-layered cotton fabrics such as towelling,
jerseywear, underwear, flannelette bed linen.
Extra
options
Low temperature (select this option for delicate fabrics with the r
symbol on the care label), Short, Anti-crease, Buzzer
Hand iron r**, Machine iron
Fabric type Cottons or linen fabrics, e.g. table linen, bedlinen, starched
laundry.
Note –To prevent laundry from drying out it should be rolled up until
you are ready for ironing.
Extra
options
Low temperature (select this option for delicate fabrics with the r
symbol on the care label), Short, Anti-crease, Buzzer
Minimum iron Max. load: 3 kg*
Normal+, Normal**, Hand iron r
Fabric type Minimum iron items made of cotton, synthetic or blended fabrics,
e.g. shirts, blouses, skirts and table cloths.
Note –In the Minimum iron
Hand iron programme, items are dried with
very little creasing, depending on fabric type and amount of
laundry.
Extra
options
Low temperature (select this option for delicate fabrics with the r
symbol on the care label), Short, Anti-crease, Buzzer
Automatic Max. load: 3 kg*
Normal+, Normal, Hand iron r
Fabric type Mixed load of cotton and minimum iron fabrics.
Extra
options
Anti-crease, Buzzer
* Weight of dry laundry
** Note for test institutes:
Use this programme without any Extra options when testing according to
EN 61121 Standard.
Programme chart
19

Shirts Max. load: 2 kg*
Normal+, Normal, Hand iron r
Fabric type Shirts and blouses
Extra options Anti-crease, Buzzer, Low temperature. (Low temperature cannot
be deselected).
Denim Max. load: 3 kg*
Normal, Hand iron r
Fabric type Denim fabrics, e.g. jeans, jackets, skirts, shirts.
Extra options Anti-crease, Buzzer, Low temperature. (Low temperature cannot
be deselected).
Woollens hand care Max. load: 2 kg*
Fabric type Woollen fabrics
Notes –To refresh and fluff up woollen garments quickly. Woollen
fabrics are not dried completely by this programme.
–Remove garments as soon as the programme has finished and
leave to finish drying at room temperature.
Extra options Buzzer, Low temperature. (Low temperature cannot be
deselected).
Smoothing Max. load: 3 kg*
Fabric type –Cottons and linen fabrics.
–Minimum iron items made of mixed fibres, cottons or synthetics,
e.g. trousers, jackets, shirts.
Notes –Smooths out creasing caused during the spin cycle in the
washing machine.
–Fabrics are not completely dried in this programme. Remove
garments as soon as the programme has finished and leave to
finish drying at room temperature.
Extra options Anti-crease, Buzzer, Low temperature. (Low temperature cannot
be deselected).
* Weight of dry laundry
Programme chart
20
