Miele T 80 Series Manual

TECHNICAL INFORMATION
T 80xx Dryers (US Models)
© 2019 Miele USA

Technical Information
2
T 80xx
Table of Contents
AWarning and Safety Instructions ............................................................6
1General Information................................................................................... 6
2Fire Danger due to Excessive Lint............................................................. 6
3Restoring the Ground Connection after Dismantling the Front and Side
Panels........................................................................................................ 7
BModification History.................................................................................8
CTechnical Data..........................................................................................9
DLayout of Electrical Components .........................................................10
1Optical Interface ...................................................................................... 10
2T 8002, T 8003, T 8005 ........................................................................... 11
3T 8012 C, T 8013 C ................................................................................. 12
4T 8019 CI................................................................................................. 13
5T 8023 C.................................................................................................. 14
010Casing, Front Panel ...............................................................................15
4Service..................................................................................................... 15
4.1Lid Removal................................................................................. 15
4.2Toekick Removal ......................................................................... 16
4.3Removing the Front Panel ........................................................... 16
4.4Side Panel Removal .................................................................... 16
4.5Metal Support Bracket Removal .................................................. 16
020Door, Lock ..............................................................................................18
2Function................................................................................................... 18
2.1Door Lock (A2)............................................................................. 18
4Service..................................................................................................... 18
4.1Door Assembly Removal ............................................................. 18
4.2Door Disassembly........................................................................ 18
4.3Removing the Door Lock ............................................................. 19
030Drum, Rear Bearing, Residual-Moisture Sensor, Heater Bank........... 21
1Technical Data......................................................................................... 22
2Function................................................................................................... 23
2.1Residual Moisture Measurement ................................................. 23
2.2Drying-Air NTC (1R30) ................................................................ 23
2.3Heater Bank NTC (2R30) ............................................................ 23
2.4Interior Drum Light (H3/6) ............................................................ 24
3Fault Repair ............................................................................................. 24
3.1Temperature Limiter (Thermostat) F2 Has Tripped ..................... 24
4Service..................................................................................................... 25
4.1Heater Bank Removal.................................................................. 25
4.2Heater Bank NTC Removal ......................................................... 27
4.3Temperature Limiter Removal ..................................................... 27
4.4Rear Bearing Removal ................................................................ 27

Technical Information
3
T 80xx
4.5Residual Moisture Sensor Removal ............................................ 29
4.6Lightbulb Replacement ................................................................ 29
040Drive, Fan................................................................................................30
1Technical Data......................................................................................... 30
2Function................................................................................................... 32
2.1Preferred Orientation/Counter Orientation................................... 32
4Service..................................................................................................... 32
4.1Drum Rib Removal ...................................................................... 32
4.2Contact Strip Removal................................................................. 32
4.3Fan Impeller Replacement........................................................... 32
4.4Motor/Drive Replacement ............................................................ 34
050 Fill Ring, Air Shield, Front Bearing....................................................... 36
4 Service..................................................................................................... 37
4.1Fill-Ring NTC Removal ................................................................ 37
4.2Air Shield Removal ...................................................................... 37
4.3Air Shield Installation ................................................................... 38
4.4Extractor Module Replacement ................................................... 38
060Condensate Box..................................................................................... 39
2Function................................................................................................... 40
2.1Heat Exchanger ........................................................................... 40
4Service..................................................................................................... 40
4.1 Condensate Box Removal ........................................................... 40
070Condensate Pump.................................................................................. 41
1Technical Data......................................................................................... 42
4Service..................................................................................................... 42
4.1Rear Service Panel Removal....................................................... 42
4.2 Condensate Pump Removal........................................................ 42
090Fascia Panel, Electronic ........................................................................ 44
1 Technical Data......................................................................................... 45
2 Function................................................................................................... 45
2.1Programming Functions............................................................... 45
2.2Service Functions ........................................................................ 46
2.3Overriding the Time Control......................................................... 47
2.4No-Load Recognition ................................................................... 47
2.5Residual-Moisture Sensing.......................................................... 47
2.6Heater (R1, R2) Safety Function ................................................. 48
2.7Insufficient-Air Detection.............................................................. 48
2.8Dryer Function after a Power Interruption.................................... 48
3 Fault Repair ............................................................................................. 48
3.1“Child Lock” LED Flashes ............................................................ 48
3.2“End/Anti-Crease” LED Lights Up................................................ 49
3.3“Container” LED Lights Up........................................................... 49
3.4“Filter/Vent” LED Lights Up.......................................................... 50
3.5All LEDs Flash/Demo Mode Active.............................................. 50
3.6F0 - No Fault................................................................................ 51

Technical Information
4
T 80xx
3.7F1 - Short Circuit in Heater Bank NTC (2R30) ............................ 51
3.8 F2 - Open Circuit in Heater Bank NTC (2R30) ............................ 51
3.9 F3 - Short Circuit in Fill-Ring NTC (1R30) ................................... 52
3.10 F4 - Open Circuit in Fill-Ring NTC (1R30) ................................... 52
3.11 F41 - Electronic Fault (Faulty EEPROM/Faulty Data).................. 53
3.12 F43 - Wrong Model Detected....................................................... 53
3.13 F50 - Drive Stalls and Heater Is On for 3 Seconds...................... 53
3.14F55 - Overriding Time Limit Exceeded, Approximately 180
Minutes ........................................................................................ 54
3.15F66 - Air Leakage ........................................................................ 55
3.16Laundry is Overdried/F55 (Overriding Time Limit Exceeded)...... 55
3.17Appliance Not Functioning/Wrong Version Detected................... 55
4 Service..................................................................................................... 56
4.1Programming Mode Summary..................................................... 56
4.2Activating/Deactivating the Demonstration Mode ........................ 57
4.3Service Mode Summary .............................................................. 58
4.4Removing the Fascia Panel......................................................... 61
4.5Control/Power Electronic Removal .............................................. 61
4.6Electronics Support Bracket (Plastic) Removal ........................... 62
100Electrical Components .......................................................................... 64
4 Service..................................................................................................... 64
4.1Heater Relay (1K1/1, 2K1/1) Removal ........................................ 64
4.2RemoteVision Module Removal .................................................. 64
110Technical Service Bulletins................................................................... 65
1 Dryer Venting Information........................................................................ 65
2 Laundry Detergent Notice: Purex Complete 3-in1 Laundry Sheets......... 67
3 Dryer Duct Length ................................................................................... 67
45.5-Kilo Dryer Electrical Requirements.................................................... 70
List of Figures
Figure D-1: Optical Interface for MDU............................................................................. 10
Figure D-2: T 8002/T 8003/T 8005 Component Layout .................................................. 11
Figure D-3: T 8012 C/T 8013 C Component Layout .......................................................12
Figure D-4: T 8019 CI Component Layout ...................................................................... 13
Figure D-5: T 8023 C Component Layout ....................................................................... 14
Figure 010-1: Lid Removal.............................................................................................. 15
Figure 010-2: Metal Support Bracket .............................................................................. 17
Figure 020-1: Door Panel Retainers ...............................................................................19
Figure 020-2: Door Cap Screws...................................................................................... 19
Figure 020-3: Door Lock Removal .................................................................................. 20
Figure 030-1: Heater Bank Removal............................................................................... 26
Figure 030-2: Similar illustration. Some models have only one temperature limiter. ...... 27
Figure 030-3: Bearing Housing Attachment .................................................................... 28
Figure 030-4: Rear Bearing............................................................................................. 28
Figure 030-5: Residual Moisture Sensor......................................................................... 29
Figure 040-1: Drive/Fan - T 8002, T 8003, T 8005 .........................................................30

Technical Information
5
T 80xx
Figure 040-2: Drive/Fan - T 8012 C, T 8013 C, T 8023 C............................................... 31
Figure 040-3: Drive/Fan - T 8019 CI ............................................................................... 31
Figure 040-4: Drum Rib................................................................................................... 32
Figure 040-5: Fan Impeller Removal............................................................................... 33
Figure 040-6: Motor and Drive Belt ................................................................................. 35
Figure 050-1: Air Shield .................................................................................................. 37
Figure 050-2: Condensate Box Seal ...............................................................................38
Figure 060-1: Condensate Box ....................................................................................... 40
Figure 070-1: Rear Service Panel................................................................................... 42
Figure 070-2: Condensate Pump ....................................................................................43
Figure 090-1: Removing the Fascia Panel...................................................................... 61
Figure 090-2: Control/Power Electronic Screws ............................................................. 62
Figure 090-3: Pushbutton Switch Assembly ...................................................................62
Figure 090-4: Plastic Support Bracket ............................................................................63
List of Tables
Table C-1: Technical Data, Novotronic IV (Single-Board Electronic)................................ 9
Table 030-1: Technical Data ........................................................................................... 22
Table 030-2: Heater Bank and Drying-Air NTC Resistance Values................................23
Table 040-1: Fan and Drive Data.................................................................................... 30
Table 070-1: Technical Data ........................................................................................... 42
Table 090-1: Technical Data ........................................................................................... 45
Table 090-2: Residual Moisture Level Adjustment - Normal Wash................................. 45
Table 090-3: Residual Moisture Level Adjustment - Wrinkle-Free.................................. 45
Table 090-4: Programming Mode Summary ................................................................... 57
Table 090-5: Service Mode Summary............................................................................. 60

Technical Information
6
T 80xx
A Warning and Safety Instructions
1 General Information
Danger!
Danger of high voltages when working on small components.
In a single-board control, as in this appliance's electronic (EPWL 3xx),
there is no structural galvanic potential disconnection to the power supply.
Therefore, be careful when working on small components, as they may
be carrying voltage if the dryer is not disconnected completely from its
power supply.
Components with sharp edges may stick out. Wear protective gloves and
goggles and use edge shields to prevent cuts by sharp-edged components.
Note:
All repairs should be performed by a trained technician in strict
accordance with national, state and local codes. Any repairs or
maintenance performed by unqualified personnel could be dangerous.
When servicing, modifying, testing or maintaining appliances, all
applicable laws, regulations and accident prevention guidelines must be
observed.
After work has been completed, a visual as well as an operational check
should always be performed.
After work has been completed, do a touch current measurement on
machines with a ground connection on all accessible conductive parts
that are not grounded.
Before starting any service work, disconnect the dryer from its power
source. Even with the appliance switched off, voltage may exist on some
components.
2 Fire Danger due to Excessive Lint
Danger!
The dryer must not be operated if there are leaks in the air shield, such as
those caused by a defective seal.
If the dryer is operated regardless of these leaks, this will result in heavy
lint in the appliance interior. Moisture can make this excessive lint soggy,
which will lead to electrical short circuits and possibly fire.
Indications of excessive lint: a poorly maintained dryer, long running time
(fixed maximum time has been exceeded), water under the fascia panel.
Remedy:

Technical Information
7
T 80xx
- Remove all lint from the dryer.
- Find and repair leaks.
3 Restoring the Ground Connection after Dismantling the
Front and Side Panels
The ground connection for laundry-care appliances is established via
screws: raised-head screws with teeth or serrated washers underneath
connect the ground lead to the interference-suppression filter, the front
panel, the side panels and the housing frame. These screws are different
from the rest of the appliance screws in their diameter, type of thread, and
type and material of the washer.
The ground connection is made only if the ground screws are screwed
into their correct positions during reassembly.
When dismantling the front and side panels, mark the positions of the
ground screws. During reassembly, screw the ground screws into these
same positions.
To check the proper screw positions, measure the resistance of the
ground connection loop.

Technical Information
8
T 80xx
B Modification History
When Who What
2/1/2019 Jessica Naples Conversion for Website
11/20/2013 Martina Aßman Version 4
11/10/2008 Liane Westerhelweg Version 3
5/14/2008 Liane Westerhelweg Version 2
10/4/2007 Liane Westerhelweg Initial compilation

Technical Information
9
T 80xx
C Technical Data
Casing Design Generation 2000
Frame design
Condenser or vented dryer
Control panel Program LEDs, on/off button
Dimensions Height with/without lid 33.5”/32.3” (850mm/820mm)
Width 23.4” (595mm)
Depth 22.8” (580mm)
Power cord length 6.5' (2m)
Hose length 5' (1.5m)
Control
technology Single-board electronic Novotronic IV Midi pushbuttons
Condenser dryer: EPWL 314
Vented dryer: EPWL 315
T 8019CI: EPWL 316-DI
Update capable via optical PC
interface
Drying
technology Heater bank 2-filament heater bank, 2.6kW
Temperature limiter Temperature limiter (SOD) 347°F
(175°C) on heater bank
NTC NTCs on heater bank and at fill ring
Residual-moisture sensing Conductivity process
Insufficient-air detection Via heater bank NTC (2R30) and fill-
ring NTC (1R30)
Drum speed 48 - 57 rpm
Table C-1: Technical Data, Novotronic IV (Single-Board Electronic)

Technical Information
10
T 80xx
D Layout of Electrical Components
1 Optical Interface
Figure D-1: Optical Interface for MDU

Technical Information
11
T 80xx
2 T 8002, T 8003, T 8005
Figure D-2: T 8002/T 8003/T 8005 Component Layout
1(2K1/1) Heater relay 2 9(2N1) RemoteVision interface
2(Z/1) Interference suppression capacitor 10 (M5) Motor
3(1K1/1) Heater relay 1 11 (C5) Motor capacitor
4(1N1) Electronic (EPWL) 12 (1R30) Drying-air NTC
5(S2) Power (on/off) switch 13 (R1, R2) Heater bank
6(S4) Door pushbutton (mechanical via Bowden
cable) 14 (2R30) Heater bank NTC
7(H3/6) Drum light 15 (F2) Fuse
8(A2) Door lock 16 (B3/1) Residual-moisture sensor assembly

Technical Information
12
T 80xx
3 T 8012 C, T 8013 C
Figure D-3: T 8012 C/T 8013 C Component Layout
1(2K1/1) Heater relay 2 10 (M5) Motor
2(Z/1) Interference suppression capacitor 11 (C5) Motor capacitor
3(1K1/1) Heater relay 1 12 (1R30) Drying-air NTC
4(1N1) Electronic (EPWL) 13 (B8/7) Condensate float switch
5(S2) Power (on/off) switch 14 (M13) Condensate pump
6(S4) Door pushbutton (mechanical via Bowden
cable) 15 (R1, R2) Heater bank
7(H3/6) Drum light 16 (2R30) Heater bank NTC
8(A2) Door lock 17 (F2) Fuse
9(2N1) RemoteVision interface 18 (B3/1) Residual-moisture sensor assembly

Technical Information
13
T 80xx
4 T 8019 CI
Figure D-4: T 8019 CI Component Layout
1(2K1/1) Heater relay 2 10 (M5) Motor
2(Z/1) Interference suppression capacitor 11 (C5) Motor capacitor
3(1K1/1) Heater relay 1 12 (1R30) Drying-air NTC
4(1N1) Electronic (EPWL) 13 (B8/7) Condensate float switch
5(S2) Power (on/off) switch 14 (M13) Condensate pump
6(S4) Door pushbutton (mechanical via Bowden
cable) 15 (R1, R2) Heater bank
7(H3/6) Drum light 16 (2R30) Heater bank NTC
8(A2) Door lock 17 (F2) Fuse
9(2N1) RemoteVision interface 18 (B3/1) Residual-moisture sensor assembly

Technical Information
14
T 80xx
5 T 8023 C
Figure D-5: T 8023 C Component Layout
1(2K1/1) Heater relay 2 11 (C5) Motor capacitor
2(Z/1) Interference suppression capacitor 12 (1R30) Drying-air NTC
3(1K1/1) Heater relay 1 13 (B8/7) Condensate float switch
4(1N1) Electronic (EPWL) 14 (M13) Condensate pump
5(S2) Power (on/off) switch 15 (R1, R2) Heater bank
6(S4) Door pushbutton (mechanical via Bowden
cable) 16 (2R30) Heater bank NTC
7(H3/6) Drum light 17 (1F2) Fuse
8(A2) Door lock 18 (2F2) Fuse
9(2N1) RemoteVision interface 19 (B3/1) Residual-moisture sensor assembly
10 (M5) Motor

Technical Information
15
T 80xx
010 Casing, Front Panel
4 Service
4.1 Lid Removal
1. Disconnect the machine from the power supply.
2. Remove the screw caps from the lid, if applicable, using a lid opener. See
Figure 010-1.
Note:
The lid contains locking clips which hold it onto the casing frame.
3. Loosen the T20 screws a maximum of 5 turns. Do not unscrew the
screws completely.
4. Press in on the screws.
5. Lift the lid at the front and slide it back to release it from its retainers.
Take the lid off.
Figure 010-1: Lid Removal

Technical Information
16
T 80xx
4.2 Toekick Removal
1. Disconnect the appliance from the power supply.
2. Remove the screw caps using a flathead screwdriver. See Figure 010-1.
3. Remove the two T20 screws securing the toekick.
4. Take off the toekick.
4.3 Removing the Front Panel
1. Disconnect the appliance from the power supply.
2. Remove the toekick. See Section 010-4.2.
3. Open the door.
4. Remove the five T20 screws around the fill ring and the two T20 screws
securing the door lock. See Figure 010-1.
5. Close the door.
6. Holding the front panel securely, remove the two T20 screws securing the
bottom outer corners of the front panel. See Figure 010-1.
7. Remove the front panel from the machine.
4.4 Side Panel Removal
1. Disconnect the machine from the power supply.
2. Remove the lid; refer to Section 010-4.1.
3. Remove the toekick; see Section 010-4.2.
4. Remove the front panel; refer to Section 010-4.3.
5. Remove the side panel retaining screws (up to nine T20s per panel). See
Figure 010-1.
6. Take the side panel(s) off.
4.5 Metal Support Bracket Removal
1. Disconnect the appliance from the power supply.
2. Remove the lid; refer to Section 010-4.1.
3. Take out the condenser box.
4. Remove the fascia panel; see Section 090-4.4.
5. Remove the electronic; see Section 090-4.5.
6. Remove the electronics support bracket (plastic); see Section 090-4.6.
7. Remove the four T20 screws securing the corners of the metal support
bracket (Figure 010-2).
8. Release the metal support bracket from the appliance chassis.

Technical Information
17
T 80xx
Figure 010-2: Metal Support Bracket

Technical Information
18
T 80xx
020 Door, Lock
2 Function
2.1 Door Lock (A2)
The door lock is released by a Bowden cable.
The door lock has a reset switch (A2): open door = open switch contact.
Even if there is an open circuit in the line to the switch contact, the electronic
registers an open door. It then stops a drying cycle in progress.
4 Service
4.1 Door Assembly Removal
1. Disconnect the appliance from the power supply.
2. Remove the front panel; see Section 010-4.3.
3. Open the door and remove the T20 screw securing each door hinge to
the back of the front panel.
4. Separate the door from the front panel.
4.2 Door Disassembly
1. Disconnect the appliance from the power supply.
2. Remove the door assembly; see Section 020-4.1.
3. Lay the door, face down, on a mat or blanket.
4. Remove the T20 screw securing the locking plate to the door and take off
the locking plate.
5. Remove the T20 screws securing the hinges to the door (one each) and
take off the hinges.
6. Using a Phillips screwdriver, twist open the six retainers (one-quarter turn
counterclockwise) securing the inner door panel to the outer door panel
(see Figure 020-1). Separate the inner door panel from the outer door
panel.

Technical Information
19
T 80xx
Figure 020-1: Door Panel Retainers
7. Remove the insulation from the inner door panel.
8. Remove the five T20 screws securing the door cap to the inner door
panel (Figure 020-2, Item 3). Take off the door cap (Figure 020-2, Item 1)
and remove the seal (Figure 020-2, Item 2).
Figure 020-2: Door Cap Screws
4.3 Removing the Door Lock
1. Disconnect the appliance from the power supply.
2. Remove the front panel; see Section 010-4.3.

Technical Information
20
T 80xx
3. Release the lock assembly from its retainer on the air shield (Figure 020-
3, Item 1).
4. Disconnect the Molex plug and unsnap the Bowden cable (Figure 020-3,
Item 2) from the lock assembly.
Figure 020-3: Door Lock Removal
