Miele T 8947 WP User manual

Operating instructions
for heat pump tumble dryer
T 8947 WP
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 09 264 070
en - AU, NZ

Disposal of the packing
material
The packing material protects the dryer
from transport damage. The transport
and protective packing has been
selected from materials which are
environmentally friendly for disposal
and can normally be recycled.
Rather than just throwing these
materials away, please ensure they are
recycled.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Therefore, please do not dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre, or contact your Chartered
Agent for advice.
Ensure that your old appliance presents
no danger to children while being
stored for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
–Load according to the optimum
amount of laundry recommended for
the programme being used.
Underloading is uneconomical.
Overloading gives poorer quality of
drying and may cause unnecessary
creasing.
– Make sure that the room temperature
is not too high. If there are other heat
producing appliances in the room in
which the dryer is located, make sure
the room is well ventilated and switch
the other appliances off, if possible.
– After every cycle, remove the fluff
from the surfaces and the fluff filters
(see "Cleaning and Care").
–Clean the fine filter when the prompt
to do so appears in the display.
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................15
Control panel .....................................................15
Display ..........................................................16
Before using for the first time.......................................18
Notes on laundry care .............................................19
Garment care label symbols .........................................19
Tips on drying ....................................................19
How to dry correctly ..............................................20
Brief instructions ..................................................20
Extra options ....................................................25
Freshen up.......................................................25
Anti-crease.......................................................25
Gentle tumble ....................................................25
Buzzer ..........................................................25
Delay start.......................................................26
Programme chart .................................................27
Changing the programme sequence .................................31
Once a programme has started ......................................31
- changing the programme........................................31
- cancelling the programme and then selecting a different programme .....31
- cancelling the programme and then removing the laundry ..............31
Altering Delay start ................................................31
Adding or removing laundry after a programme has started ................31
Time remaining ...................................................31
Contents
3

Cleaning and care ................................................32
Emptying the condensed water container...............................32
Make sure you clean all the filters at the correct intervals...................33
When to clean the surfaces of the fluff filters ..........................33
When to clean additional fine filters .................................33
Cleaning the surfaces of the fluff filter ..................................34
1. In the door. ..................................................34
2. In the door opening. ...........................................34
Cleaning the fine filters .............................................35
1. Cleaning the fine filter in the door.................................35
2. Cleaning the fine filters in the door opening. ........................37
3. Cleaning the fine filter in front of the heat exchanger unit ..............38
Cleaning the tumble dryer ...........................................39
Problem solving guide ............................................40
What to do if...?..................................................40
Fault messages in the display ........................................40
An unsatisfactory drying result .......................................42
Other problems ...................................................43
Cleaning the cooling fins (Grille at bottom right) ..........................45
Changing the lamp ................................................46
After Sales service................................................47
Future updates (PC) ...............................................47
Optional accessories ...............................................47
Installation and connection ........................................48
Front view........................................................48
Rear view ........................................................49
Transporting the dryer ..............................................49
Installation site ....................................................50
Building under a continuous worktop/in a row of kitchen units ............50
Levelling the machine............................................51
Washer-dryer stack..............................................51
Contents
4

External condensed water outlet ......................................52
Arranging the drain hose .........................................52
External drainage via a sink or gully ................................53
Installation conditions requiring a non-return valve .....................53
Electrical connection ...............................................55
Consumption data ................................................56
Technical data ...................................................57
Settings menu ...................................................58
To open the Settings menu........................................58
To select a setting...............................................58
To close the Settings menu .......................................58
Language F......................................................58
Time ............................................................58
Drying levels .....................................................59
Lock code .......................................................59
Buzzer ..........................................................60
Keypad tone .....................................................60
Contrast .........................................................60
Brightness .......................................................60
Standby Display...................................................61
Memory .........................................................61
Anti-crease.......................................................61
Contents
5

~It is essential to read these instructions.
This tumble dryer conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
~This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
~This tumble dryer must only be used to dry items which have
been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. "Dry
cleaning kits" for freshening up garments in a tumble dryer are
increasingly available on the market. If using, do so at your own risk,
and follow the instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation of the tumble dryer.
Warning and Safety instructions
6

~The tumble dryer is not intended for outdoor use.
~This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it correctly by a person
responsible for their safety.
~This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
Safety with children
~Keep children away from the tumble dryer at all times. It is not a
toy! To avoid the risk of injury do not allow them to play on or near it
or to play with its controls. Supervise children whilst you are using it.
~Older children may only use it if its operation has been clearly
explained to them, and they are able to use it safely, recognising the
dangers of incorrect use.
Warning and Safety instructions
7

Technical safety
~Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
~Before connecting the appliance, make sure that the connection
data on the data plate (voltage and rated load) match the mains
electricity supply. If in doubt, consult a qualified electrician.
~The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is most important that this basic safety requirement is
present and regularly tested, and where there is any doubt, the
household wiring system should be inspected by a qualified
electrician. Miele cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~The heat pump technology in the
tumble dryer uses a refrigerant which is condensed by a
compressor. It is led in a closed circuit through the heat exchanger
unit where heat exchange with the circulating drying air takes place.
It is normal for humming noises caused by the heat pump
technology to be heard during the drying process. This does not
impair the efficient functioning of the dryer.
–The refrigerant is not flammable or explosive.
–In general it is not necessary to leave the dryer standing for any
length of time before it is connected to the mains provided it has
been transported and installed correctly (see "Installation").
~Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
Warning and Safety instructions
8

~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liabilty. Repairs should only be
undertaken by a Miele approved service technician.
~Faulty components must only be replaced by genuine Miele
spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
~If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
~In the event of a fault or for cleaning purposes, the tumble dryer
is only completely isolated from the electricity supply when:
– it is switched off at the wall socket and the plug is withdrawn, or
– it is switched off at the mains, or
– the mains fuse is withdrawn.
~Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the warranty.
Warning and Safety instructions
9

Correct use
,Caution! Risk of fire.
To avoid the possible danger of fire, please
read these warnings carefully.
,A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
~Remove all objects from pockets such as lighters and matches.
~To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned, there is a danger that
these might ignite when heated, even after they have been
removed from the dryer at the end of the programme.
–Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths) should
be washed in hot water with extra detergent before being dried in
the tumble dryer.
–Items which have been splashed with hair lacquer, hair spray, nail
polish remover or similar substances.
Warning and Safety instructions
10

When washing such heavily soiled items, ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.
~Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
~To prevent the risk of fire, the following textiles or products must
not be dried in this tumble dryer:
– Items which have been dry-cleaned (for example with a chemical
treatment).
–Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
–Fabrics which contain padding or fillings (e.g. pillows, jackets). If
these were damaged, the filling could get out with the risk of
igniting in the dryer.
Warning and Safety instructions
11

~In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase is complete.
Ensure that you always wait until the end of the programme before
removing the laundry.
~Warning: Do not switch the tumble dryer off before the end of the
drying programme. If this was done, remove and spread out all
items quickly so that the heat is dissipated.
~Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
~The tumble dryer is not to be used if industrial chemicals have
been used to clean it.
Warning and Safety instructions
12

~The tumble dryer must not be used
–without the fluff filters in place or if the fluff filters are damaged.
–without the fine filter in place or if the fine filters are damaged.
This would cause an excessive build-up of fluff which in turn would
cause a fault!
~After every cycle, remove the fluff from the surfaces and the fluff
filters (see "Cleaning and care").
~Fluff must not be allowed to accumulate around the tumble dryer.
~The fluff filters and the fine filter must be thoroughly dried after
cleaning. Damp or wet filters could cause operational faults.
~Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly.
There is a risk of damage if the condensed water is allowed to
freeze in the pump and in the drain hose.
~If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
~Condensed water is not drinking water. It can cause health
problems in both people and animals.
Warning and Safety instructions
13

~Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the
condenser unit over time.
~Do not lean on the door. This can cause the tumble dryer to tip
over.
~Always close the door after use. This way you will avoid the
danger of
–children climbing onto or into the dryer or hiding things in it.
–pets or other small animals climbing into it.
~The tumble dryer must not be hosed down.
Accessories
~Only use genuine Miele spare parts and accessories with this
tumble dryer. If non-Miele parts are used, warranty, performance
and product liabilty claims may be invalidated.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
14

Control panel
aStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
bDisplay with X,OK and Ybuttons
See the following pages for more
information.
c+button
For selecting Delay start.
dPC / Optical interface
This is used by service technicians
to run diagnostic checks on your
dryer and can also be used to
update programming data in the
future.
ePerfect Dry indicator
For all drying level programmes.
See next page.
fExtra option buttons with indicator
lights
Various Extra options can be added
to the drying programmes.
gProgramme selector
The programme selector can be
turned clockwise or anti-clockwise.
hKOn/Off button
For switching the dryer on and off.
To save energy, the dryer will switch
off automatically 15 minutes after the
end of the programme/Anti-crease
phase or 15 minutes after the dryer is
switched on if it is not operated.
iDoor button
Pressing this button will open the
door even when the dryer is
switched off at the mains.
Operating the tumble dryer
15

Display
The display is operated using the X,
OK and Ybuttons. The text or value
currently selected will appear
highlighted.
– Press the Xbutton
to scroll to the next text or decrease
the value highlighted in the display.
– Press the Ybutton
to scroll to the previous text or
increase the value highlighted in the
display.
–Press the OK button
to confirm the value highlighted in
the display.
Programme selection examples
To select a Further programme
Further programmes
Sportswear ;
Outerwear ,
Press the Xbutton to scroll to the next
programme which will then appear
highlighted or press the Ybutton to
scroll to and highlight the previous
programme.
Press the OK button to confirm the
selection of the highlighted programme.
To increase or decrease a value
Cottons
Extra dry O O O O O O
Duration: 2:21 h
Press the Xbutton to select a lower
drying level and the Ybutton to select
a higher drying level.
Single option selection
Here one of the values is always
selected. A tick (will appear next to
the one currently selected. The other
values are deselected automatically.
Memory
Off (;
On ,
Press the Xand Ybuttons to scroll up
or down the values available.
Press the OK button to confirm your
selection of the value highlighted.
To come out of a sub-menu
Select Back #to come out of a
sub-menu.
Operating the tumble dryer
16

The following are selected via the
display
–the drying level (e.g. Hand iron,
Normal...)
–the duration of the timed drying
programmes: Cool air, Warm air,
Drying basket programme
–Delay start
–cancellation of a programme.
The following are selected via
Further programmes/Settings 4
Further programmes
– Sportswear
– Outerwear
– Standard pillows
– Large pillows
– Drying basket prog.
The Miele drying basket (optional
accessory) must be used with this
programme.
Settings
The Settings menu Jis used to alter the
tumble dryer's electronics to suit
different requirements. See "Settings
menu" at the end of this booklet for
more details.
Perfect Dry indicator
The Perfect Dry system measures the
laundry's residual moisture in
programmes with drying levels and
provides a more precise drying result.
After starting the programme, the
electronics will measure the duration of
the programme (Estimated time
remaining). The Perfect Dry indicator
light will flash during this time.
The programme duration will be shown
after a short time and the indicator light
will go out.
Once the selected drying level has
been reached, the Perfect Dry indicator
light will remain on until the end of the
programme.
The Perfect Dry indicator light always
remains dark during the following time
controlled programmes: Woollens,
Silks, Cool air, Warm air, Gentle
smoothing, Drying basket prog.
Programme duration /
Estimated time remaining
The estimated duration (time remaining)
will appear in the display.
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the appliance and adjust
the estimated time remaining for a more
accurate reading. Because of this, the
time displayed can alter during the
course of a programme.
Programmes can also finish earlier than
expected – if, for example, particularly
fine fabrics are being dried, the load is
very small or items were partially dry
beforehand.
Operating the tumble dryer
17

,Before using the dryer for the
first time, ensure that it is correctly
installed and connected. If the
tumble dryer has not been
transported as described in
"Installation" then it must be left to
stand for at least 1 hour before it is
connected to the electricity supply.
^Press the Kbutton in.
When the tumble dryer is switched on
for the first time, the welcome screen
will appear.
Setting the language for the display
You will be asked to select the
language you require for the display. It
is possible to select another language
at any time via Further programmes/
Settings 4in the Settings sub-menu.
Sprache
deutsch ;
english ,
^Press the Xand Ybuttons to scroll
through the options until the
language that you want is
highlighted. Press the OK button to
confirm your selection.
Setting the time (of day) (if
necessary)
Time
12:00
^Press the Xbutton to decrease or the
Ybutton to increase the hour.
^Confirm the hour selected with the
OK button. Then do the same to set
the minutes.
Completing the "Before using for the
first time" procedure
The entry menu showing the current
time of day will appear after the tumble
dryer has been switched on, until you
select a programme.
12:00
Select programme
^You can now load the laundry into the
dryer and select a programme as
described in "How to dry correctly".
The "Before using for the first time
procedure" is completed when a
programme lasting longer than 1 hour
has been carried out. The welcome
screen will appear again the next time
the dryer is switched on if a programme
shorter than 1 hour is selected but not if
a programme longer than 1 hour is
selected.
Before using for the first time
18

Garment care label symbols
Drying
q/rNormal/low temperature
Drying is carried out at a low
temperature in every
programme, so you do not need
to sort your garments according
to whether they have the qor
rsymbol.
sDo not tumble dry
Tips on drying
– Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause unnecessary
wear and tear to the laundry, give a
disappointing drying result and
cause more creasing.
– Do not put soaking wet items into the
tumble dryer. Spin fabrics for at least
30 seconds before drying.
–Use the Automatic plus programme
for drying mixed loads of cotton and
minimum iron fabrics.
–Open jackets so that they can dry
evenly.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the garment care
label, as the surface of the fabric
may otherwise become rough.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not overdry these
textiles. When purchasing these
garments, it is advisable to take their
shrinkage properties into account.
–Minimum iron fabrics tend to crease
more, the larger the load. This is also
the case for garments made from
very fine weave fabrics, such as
shirts or blouses.
Make sure you select a suitable
programme. If in doubt, divide the
garments into smaller loads and
select the Gentle tumble Extra
option.
– Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
– New dark coloured garments should
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the dryer.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
–Use the Basket programme for
drying / airing items which are not
suitable for drying with mechanical
action. Important: You must use a
Miele drying basket (optional
accessory).
Notes on laundry care
19

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
dryer.
ASort the laundry
To ensure an even drying result,
separate out the washed laundry and
sort it according to:
. . . the drying level required
. . . the type of fibre or weave
. . . size
. . . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause damage
to the dryer or the laundry.
– Remove all objects from pockets
such as lighters and matches.
– Check seams and stitching to ensure
that padding and linings are intact.
–Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
–Fasten zips, hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
sbutton in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
CLoad the tumble dryer
^Press the Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause unnecessary
wear and tear to the laundry and
give a disappointing drying result.
^Before closing the door, make sure
the fluff filter is correctly positioned in
the door.
Check the laundry is right inside the
drum so that it cannot get trapped or
damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
20
