Miele T 7944 C User manual

Operating instructions
for condenser tumble dryer
T 7944 C
To avoid the risk of accidents
or damage to the appliance
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 09 874 800
en-GB

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and should be recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose it with
your household waste.
Please dispose of it at your local
community waste recycling centre or
contact your dealer for advice. Ensure
that it presents no danger to children
while being stored for disposal.
Energy saving tips
To avoid unnecessarily long drying
times and high consumption of energy:
–Make sure that your laundry is
thoroughly spun before drying.
The higher the spin, the greater the
savings that can be made in energy
and time during drying.
–Load according to the optimum
amount of laundry recommended for
the programme being used (see
Programme chart).
Underloading is uneconomical.
Overloading gives a poorer quality of
drying and may cause unnecessary
creasing.
– Make sure the room in which the
dryer is located is well ventilated.
– Make sure the fluff filters are clean
before using the dryer.
– Check the condenser unit from time
to time and clean it when necessary.
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the tumble dryer.........................................15
Control panel .....................................................15
Notes on laundry care .............................................17
Garment care label symbols .........................................17
Tips on drying ....................................................17
How to dry correctly ..............................................18
Brief instructions ..................................................18
Extra options / Delay start..........................................21
Extra options .....................................................21
Low temperature................................................21
Buzzer........................................................21
Delay start .......................................................21
Programme chart .................................................22
Changing the programme sequence .................................25
Once a programme has started ......................................25
- changing the programme........................................25
- cancelling the programme and then selecting a different programme .....25
- cancelling the programme and then removing the laundry ..............25
Altering Delay start ................................................25
Adding or removing laundry after a programme has started ................25
Time remaining ...................................................25
Electronic system lock ............................................26
Contents
3

Cleaning and care ................................................27
Emptying the condensed water container...............................27
Cleaning the fluff filters .............................................28
Cleaning them whilst dry .........................................28
Cleaning them with water .........................................29
Cleaning the tumble dryer ...........................................30
Cleaning the condenser unit .........................................31
Removing the condenser unit......................................31
Checking the condenser unit ......................................32
Cleaning the condenser unit.......................................32
Replacing the condenser unit......................................33
Problem solving guide ............................................34
Check and fault messages ..........................................34
An unsatisfactory drying result .......................................37
Other problems ...................................................38
Changing the lamp ................................................40
After Sales service................................................41
Repairs..........................................................41
Future updates (PC) ...............................................41
Appliance guarantee ...............................................41
Optional accessories ...............................................41
Installation and connection ........................................42
Front view........................................................42
Rear view ........................................................43
Installation site ....................................................43
Transporting the machine to its installation site ........................43
Washer-dryer stack..............................................43
Levelling the machine............................................44
Room ventilation ................................................44
Before moving the tumble dryer again (e.g. when moving house) .........44
External condensed water outlet ......................................45
Arranging the drain hose .........................................45
External drainage via a sink or gully ................................46
Installation conditions requiring a non-return valve .....................46
Contents
4

Electrical connection .............................................48
Electrical connection U.K. ...........................................48
Consumption data ................................................49
Technical data ...................................................50
Programmable functions...........................................51
Altering the residual moisture level in the Cottons programme...............51
Altering the residual moisture level in the Minimum iron programme ..........52
Anti-crease ......................................................53
Altering the volume of the buzzer .....................................54
Altering the standard drying level in the Automatic plus programme ..........55
Extending the cooling down time .....................................56
Standby .........................................................57
Memory function ..................................................59
Clean out airways indicator ..........................................60
Keypad tone .....................................................61
Adjusting the dryer's electronics for very soft water .......................62
Extending the range of the drying levels ................................63
Contents
5

~It is essential to read these instructions.
This tumble dryer complies with current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
~This tumble dryer is intended for use in domestic households and
similar working and residential environments.
~The tumble dryer is not intended for outdoor use.
~It must only be used as a domestic appliance to dry items which
have been washed in a water solution and which are marked on the
manufacturer's care label as being suitable for tumble drying. If
using dry cleaning kits, do so at your own risk, and follow the
instructions provided on the packaging.
Any other usage is not supported by the manufacturer and could be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.
Warning and Safety instructions
6

~The tumble dryer can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are are supervised whilst using it or have been
shown how to use it in a safe way and recognise and understand the
consequences of incorrect operation.
Safety with children
~Children under 8 years of age must be kept away from the tumble
dryer unless they are constantly supervised.
~Children 8 years and older may only use the tumble dryer
unsupervised if they have been shown how to do so in a safe way
and and recognise and understand the consequences of incorrect
operation.
~Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
~Please supervise children in the vicinity of the tumble dryer and
do not let them play with it.
Warning and Safety instructions
7

Technical safety
~Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
~Before connecting the tumble dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) match
the mains electricity supply. If in any doubt, consult a qualified
electrician.
~The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the electrical
installation tested by a qualified electrician. Miele cannot be held
liable for the consequences of an inadequate earthing system (e.g.
electric shock).
~Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads are a fire hazard and do not
guarantee the required safety of the tumble dryer.
~If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the guarantee. Ensure
current is not supplied to the tumble dryer until after maintenance or
repair work has been carried out.
Warning and Safety instructions
8

~Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can the safety
standards of the tumble dryer be guaranteed.
~The tumble dryer must be isolated from the electricity supply in
the event of a fault and during cleaning and maintenance.
~The tumble dryer must not be used in a non-stationary location
(e.g. on a ship).
~Do not make any alterations to the tumble dryer, unless
authorised to do so by Miele.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the tumble dryer
and its surroundings in a clean condition at all times. Any damage
which may be caused by cockroaches or other vermin will not be
covered by the guarantee.
Warning and Safety instructions
9

~Please observe the instructions in "Installation and connection"
and "Technical data".
~The socket must be easily accessible after installation in order to
disconnect the tumble dryer from the electricity supply.
~Do not block the gap between the base of the tumble dryer and
the floor with plinth facings, deep pile carpet etc. as this would
hinder a sufficient intake of air.
~Make sure the tumble dryer door can be opened without
hindrance after installation.
Correct use
~The maximum load of dry laundry for this tumble dryer is 7 kg.
See the Programme chart for the maximum recommended loads in
individual programmes.
~Fire hazard.
The tumble dryer must not be connected to a controllable socket
(e.g. a timer switch or a peak load shut-off device).
If the drying programme were to be interrupted before the end of the
cooling down phase, the laundry could self-ignite.
Warning and Safety instructions
10

~To prevent the risk of fire, the following textiles must not be dried
in this appliance:
–items which have not been washed.
–items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
deposits (such as cosmetics, lotions etc).
If items have not been thoroughly cleaned there is a danger that
these might self-ignite when heated, even after they have been
removed from the tumble dryer at the end of the programme.
–items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzine, petrol, kerosene, stain remover,
turpentine, wax, wax remover or other chemicals.
– items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items, ensure that you use
additional detergent and select a high temperature. If in doubt,
wash the items several times.
~Remove all items such as lighters and matches from pockets.
~Warning: Do not switch the tumble dryer off before the drying
programme has finished. If this is done, the laundry must be hung
up or spread out to cool it down.
~Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
Warning and Safety instructions
11

~To prevent the risk of fire, the following must not be tumble dried:
–items which have been cleaned using chemicals (e.g.
professional dry-cleaning agents).
–fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
–damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of
igniting in the tumble dryer.
~In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items remain at a temperature which
will not damage them and so that they are not too hot to handle
when you remove them (this also avoids the danger of the laundry
self-igniting). The programme is not finished until the cooling down
phase has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
~Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
~Always close the doors after use. This way you will avoid the
danger of:
–children climbing into the tumble dryer or hiding things in it.
–pets or other small animals climbing into it.
Warning and Safety instructions
12

~The tumble dryer must not be used without the fluff filters in place
or if the fluff filters are damaged in any way.
~The fluff filters must be cleaned regularly.
~The tumble dryer must not be used without the condenser unit in
place.
~The fluff filters must be thoroughly dried after cleaning. Damp or
wet filters could cause operational faults.
~Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and in the
drain hose.
The ambient room temperature should be between +2°C and
+35°C.
~If the water is drained externally instead of being collected in the
condensed water container, make sure the drain hose is securely
attached if you hang it in a sink or basin to avoid the hose slipping
and the water causing damage.
~Condensed water is not drinking water.
It can cause health problems in both people and animals.
~Always keep the area around the tumble dryer free of dust and
fluff. Dust and dirt drawn into the tumble dryer can cause blockages
in the condenser unit over time.
~The tumble dryer must not be hosed down.
Warning and Safety instructions
13

Accessories
~Only use genuine Miele original spare parts and accessories with
this tumble dryer.
If non-Miele parts are used, guarantee, performance and product
liability claims may be invalidated.
~A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the
Miele tumble dryer and Miele washing machine.
~If installing the tumble dryer on a Miele plinth, (available as an
optional accessory), please make sure you order the correct one for
this tumble dryer.
,Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
14

Control panel
aPerfect Dry indicator
For all drying level programmes. See
next page.
bDisplay
See next page.
cDelay start button
This button is used for:
- Delaying the start of a programme
- Selecting the duration of the timed
drying Warm air and Cool air
programmes
dBuzzer button
An audible tone sounds at the end of
the programme.
eCheck lights
See "Problem solving guide" / "After
sales service".
fStart/Stop button
For starting or cancelling a
programme.
The button flashes while a
programme is being selected and
then lights up constantly when the
programme has started.
gLow temperature button
Delicate fabrics are dried at a lower
temperature.
hDrying level button
with indicator lights to show the
drying level selected.
iProgramme selector
with indicator lights to show the
programme selected.
jDoor button
Pressing this button will open the
door even when the dryer is
switched off at the mains.
kOn/Off button jk
For switching the dryer on and off.
Operating the tumble dryer
15

The display shows:
–Programme duration
–Programme stage
Drying
Cooling down
Finish
–Check and fault messages
The following are also selected via
the display:
–Duration of the Warm air and Cool air
programmes
– Delay start
You can select a programme and set
it to start at a later time.
The programme will start
automatically once the delay start
time has a elapsed.
– Programmable functions
Default settings can be altered to
adapt the dryer to different
requirements. See "Programmable
functions" at the end of this booklet
for more details.
Perfect Dry indicator
The Perfect Dry system measures the
residual content in the laundry in the
sensor drying programmes to ensure
perfect drying results.
After a programme has started, the
electronics will estimate the duration of
the programme (time remaining). The
Perfect Dry indicator will flash while this
is happening.
After a short while, the programme
duration will appear in the display and
the indicator will go out.
The Perfect Dry indicator will light up
again when the selected drying level is
reached and remain on until the
programme is finished.
The Perfect Dry indicator does not light
up during time controlled programmes:
Woollens handcare, Cool air, Warm air,
Gentle smoothing.
Programme duration /
Estimated time remaining
The estimated duration (time remaining)
will appear in the display.
The following factors all affect the
estimated time remaining: residual
moisture content after spinning; type of
fabric; size of load; room temperature;
fluctuations in power supply.
The electronics continually assess
conditions in the dryer and adjust the
estimated time remaining for a more
accurate reading. Because of this, the
time displayed can alter during the
course of a programme.
Programmes can also finish earlier than
expected, if, for example, particularly
fine fabrics are being dried, the load is
very small or items were partially dry
beforehand.
Operating the tumble dryer
16

Garment care label symbols
Drying
qNormal/higher temperature
rReduced temperature:
Select Low temperature
(for delicate textiles)
sDo not tumble dry
Ironing
IVery hot
HHot
GWarm
JDo not iron
Tips on drying
– Always observe the maximum
recommended loads given in the
"Programme chart". Never overload
the drum.
Overloading can cause
unnecessary wear and tear to the
laundry, give a disappointing drying
result and cause more creasing.
–Do not put soaking wet items into the
tumble dryer. Spin fabrics for at least
30 seconds before drying.
–Open jackets so that they can dry
evenly.
–Use the Automatic plus programme
for drying mixed loads of cotton and
minimum iron fabrics.
–Woollens and wool blends tend to
become matted and shrink if dried in
a tumble dryer. They can, however,
be "fluffed up" using the Woollens
handcare programme.
–Down-filled garments have linings
which have a tendency to shrink,
depending on the quality of the item.
They can be partially dried using the
Gentle smoothing programme.
–Pure linen should only be machine
dried if specified as suitable by the
manufacturer on the care label, as
the surface of the fabric may
otherwise become rough.
–Loopknit garments (e.g. T-shirts and
underwear) tend to shrink depending
on their quality. Do not over-dry
these textiles. When purchasing
these garments it is advisable to take
their shrinkage properties into
account.
– Minimum iron fabrics tend to crease
more, the larger the load. This is also
the case for garments made from
very fine weave fabrics, such as
shirts or blouses.
If in doubt, divide the garments into
smaller loads.
–Starched laundry can be dried in the
tumble dryer. To achieve the usual
finish, double the amount of starch
should be used.
–New dark coloured garments should
be washed and dried separately
from light coloured garments to avoid
the danger of colours running and
discolouring other garments or even
plastic components in the dryer.
Dark coloured fibres can also settle
on light coloured garments and vice
versa.
Notes on laundry care
17

Brief instructions
The headings numbered (A,B,C...)
show the operating sequence and can
be used as a brief guide to using your
dryer.
ASort the laundry
To ensure an even drying result sort
laundry according to:
. . . the drying level required
. . . the type of fibre or weave
. . . size
. . . the moisture content after spinning.
,Make sure that objects e.g.
detergent dispensing balls have
been removed from the laundry.
They could melt, and cause
damage to the dryer or the laundry.
– Check seams and stitching to ensure
that padding and linings are intact.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
–Fasten hooks and eyes etc.
–Tie fabric belts and apron strings.
–Sew in or remove underwiring from
bras.
BTurn on the tumble dryer
^Switch the dryer on by pressing the
On/Off jk button in.
The tumble dryer may be switched on
after loading, saving energy as the light
will not come on.
CLoad the tumble dryer
^Press the Door button to open the
door.
^Load the laundry loosely into the
drum.
Do not overload the drum. See the
"Programme chart" for
recommended loads for each
programme.
Overloading can cause
unnecessary wear and tear to the
laundry and give a disappointing
drying result.
^Before closing the door make sure
the fluff filter is correctly positioned.
Check the laundry is right inside the
drum so that it cannot get trapped
or damaged when the door is shut.
^Shut the door either with a gentle
swing, or lean against it and push it
shut.
How to dry correctly
18

DSelect a programme
^Select the programme you want.
The indicator for the programme
selected will light up.
A drying level or extra option indicator
may also light up and the duration may
also be displayed.
Drying level programmes
–Cottons, Minimum iron, Delicates,
Automatic plus, Denim
^Press the drying level button
repeatedly until the indicator for the
drying level you want lights up (for
almost all programmes).
Any of the four drying levels can be
selected for the Cottons programme. A
more limited range is available when
using other programmes and with some
the drying level is pre-set and cannot
be changed.
Tip:
You can extend the range of the drying
levels for some programmes (see
"Programmable functions").
Woollens handcare, Gentle
smoothing, Cottons t
–This programme cannot be changed.
Selecting the duration of the timed
drying Cool air and Warm air
programmes
The indicator light for the Delay start
button will flash when the Cool air or
Warm air programme is selected.
^Press the Delay start button
repeatedly until the required duration
shows in the display.
Range:
–Cool air: from 20 minutes up to i:00
hour.
–Warm air: from i5 minutes up to 2:00
hour.
ESelect any Extra options / Delay
start
^Low temperature, Buzzer and Delay
start are selected by pressing the
appropriate button (see "Extra
options/Delay start").
Anti-crease (see next page) is
permanently switched on.
N.B.: It is not possible to select Delay
start when using the Warm air or Cool
air programme.
How to dry correctly
19

FStart the programme
The Start/Stop button will flash when a
programme is being selected. The
flashing indicates that a programme
can be started.
^Press the Start/Stop button.
The Start/Stop button will now light up
constantly.
The Perfect Dry indicator will flash or
light up constantly with the sensor
controlled drying programmes. It will
not come on at all with timed drying
programmes (see "Operating the
tumble dryer").
Please note: The duration shown in the
display is an estimate and can vary.
Before the end of a programme
There is a cooling down phase at the
end of the drying sequence (Cooling
down will light up). The programme will
not finish until the cooling down phase
has been completed.
There is no cooling down phase at the
end of the Woollens handcare
programme.
GRemove the laundry when the
programme has finished
0and Finish will appear in the display
to indicate that the programme has
finished. The buzzer (if selected) will
sound at intervals.
The drum will continue to rotate at
intervals for up to two hours to prevent
laundry creasing, if you do not wish to
remove it immediately (anti-crease).
There is no anti-crease phase at the
end of the Woollens handcare
programme.
^Press the Door button.
^Open the door.
^Remove the laundry.
Check that all items have been
removed from the drum. If items are
left in the dryer, they could be
damaged by overdrying when the
dryer is next used.
If the dryer is switched on at the mains
and the door is opened, the drum
lighting will come on. It will go out a few
minutes later to save energy.
^Press the jk button to switch the
dryer off.
^Clean the fluff filters.
^Close the door.
^Empty the condensed water
container (unless the dryer has been
connected for external drainage).
^The condenser unit should be
checked and cleaned on a regular
basis (see "Cleaning and care").
How to dry correctly
20
