Miele TCJ 690 WP User manual

Operating instructions
Heat pump tumble dryer
It is essential to read these operating instructions before installing and
using the appliance. This prevents both personal injury and damage to
the appliance.
en-AU, NZ M.-Nr. 11 015 660

Contents
2
Caring for the environment ................................................................................. 6
Warning and Safety instructions ......................................................................... 7
Operating the tumble dryer ................................................................................ 18
Control panel......................................................................................................... 18
Operating the sensor controls............................................................................... 19
Display................................................................................................................... 20
Examples on how to operate the appliance.......................................................... 20
Before using for the first time ............................................................................ 21
Downtime after installation.................................................................................... 21
Removing the protective foil and stickers ............................................................ 21
Miele@home .......................................................................................................... 21
Energy saving tips ............................................................................................... 24
Energy saving tips ................................................................................................. 24
EcoFeedback......................................................................................................... 25
1. Notes on correct laundry care ....................................................................... 26
Points to note regarding washed laundry.............................................................. 26
Preparing the laundry before drying...................................................................... 26
Drying .................................................................................................................... 27
Care label symbols ........................................................................................... 27
Selecting the correct drying level..................................................................... 27
2. Loading the tumble dryer ............................................................................... 28
Loading the laundry............................................................................................... 28
3. Selecting a programme .................................................................................. 29
4. Selecting programme settings....................................................................... 31
Programme settings .............................................................................................. 31
Selecting a drying level with a drying programme ...........................................31
Selecting timed drying programmes and other programmes .......................... 31
Selecting Extras..................................................................................................... 32
 Delay start/SmartStart ..................................................................................... 32
5. Starting the programme ................................................................................. 34
6. End of programme - unloading the drum...................................................... 35
At the end of the programme ................................................................................ 35
Removing the laundry ........................................................................................... 35

Contents
3
Programme chart ................................................................................................ 36
Programmes on the control panel ......................................................................... 36
Further programmes.............................................................................................. 40
Extras.................................................................................................................... 43
Gentle tumble........................................................................................................ 43
Freshen up............................................................................................................. 43
Anti-crease ............................................................................................................ 43
Buzzer.................................................................................................................... 43
Drying programme overview - Extras.................................................................... 44
Changing the programme sequence................................................................. 45
Condensed water container ............................................................................... 47
Emptying the condensed water container ............................................................ 47
Preparing the condensed water container for Steam care.................................... 48
Fragrance flacon.................................................................................................. 49
FragranceDos – 2 positions for inserting a fragrance flacon ................................. 49
Using a fragrance flacon ....................................................................................... 49
Removing the protective seal from the fragrance flacon.................................. 49
Inserting the fragrance flacon...........................................................................50
Opening the fragrance flacon................................................................................ 51
Closing the fragrance flacon ................................................................................. 51
Removing/replacing the fragrance flacon ............................................................. 52
Cleaning and care ............................................................................................... 53
Fluff filters.............................................................................................................. 53
Removing the fragrance flacon ........................................................................53
Removing visible fluff ....................................................................................... 53
Cleaning the fluff filters and air flow openings thoroughly ............................... 54
Cleaning the fluff filters with water ................................................................... 55
Cleaning the plinth filter......................................................................................... 56
Removing the plinth filter .................................................................................56
Cleaning the plinth filter.................................................................................... 57
Cleaning the plinth filter panel.......................................................................... 57
Checking the heat exchanger unit.................................................................... 58
Inserting the plinth filter.................................................................................... 58
Cleaning the dryer ................................................................................................. 59

Contents
4
Problem solving guide ........................................................................................ 60
The display indicates the following messages or faults........................................ 60
Unsatisfactory drying results................................................................................. 62
The drying process takes a long time. .................................................................. 63
General problems with the tumble dryer ............................................................... 64
Cleaning the fluff filter in the condensed water container..................................... 66
Replacing the blocked spray jet for the Steam care programme.......................... 67
Service.................................................................................................................. 68
Contact in case of fault ......................................................................................... 68
Optional accessories............................................................................................. 68
Warranty ................................................................................................................ 68
Installation and connection ................................................................................ 69
Front view .............................................................................................................. 69
Rear view............................................................................................................... 70
Transporting the tumble dryer ............................................................................... 71
Transporting the tumble dryer to its installation site ........................................71
Installation ............................................................................................................. 72
Levelling the dryer ............................................................................................ 72
Downtime after installation............................................................................... 72
Ventilation ......................................................................................................... 72
Before moving the tumble dryer again (e.g. when moving house)................... 73
Additional installation requirements ...................................................................... 73
Externally draining condensed water .................................................................... 74
Installation conditions requiring a non-return valve ......................................... 74
Arranging the drain hose ..................................................................................75
Examples: Draining condensed water.............................................................. 75
Electrical connection ............................................................................................. 78
Technical data...................................................................................................... 79
Consumption data............................................................................................... 80

Contents
5
Settings ................................................................................................................ 81
Calling up settings................................................................................................. 81
Language ........................................................................................................... 82
Drying levels .......................................................................................................... 82
Cooling down temperature.................................................................................... 82
Welcome tone ....................................................................................................... 82
Keypad tone .......................................................................................................... 83
Buzzer volume....................................................................................................... 83
Airways indicator ................................................................................................... 83
Conductivity .......................................................................................................... 84
Consumption......................................................................................................... 84
Code...................................................................................................................... 85
Brightness ............................................................................................................. 85
Display.............................................................................................................. 85
Buttons active .................................................................................................. 85
Buttons inactive................................................................................................ 85
Display switch-off status ....................................................................................... 86
Memory ................................................................................................................. 86
Anti-crease ............................................................................................................ 86
Programme info..................................................................................................... 87
Miele@home .......................................................................................................... 87
Remote control...................................................................................................... 88
SmartGrid .............................................................................................................. 88
RemoteUpdate ...................................................................................................... 89
Running a RemoteUpdate................................................................................ 89

Caring for the environment
6
Disposal of the packing
material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.

Warning and Safety instructions
7
 It is essential to read these instructions.
This tumble dryer complies with current local and national safety
requirements. Inappropriate use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and damage to the tumble dryer,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, installation,
use and maintenance.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Correct application
 This tumble dryer is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
 This tumble dryer is not suitable for outdoor use.
 It must only be used to dry items which have been washed in a
water solution and which are marked on the manufacturer's care
label as being suitable for tumble drying. If using dry cleaning kits,
do so at your own risk, and follow the instructions provided on the
packaging.
Any other applications may be dangerous. Miele cannot be held
liable for damage resulting from incorrect or improper use or
operation.

Warning and Safety instructions
8
 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it by a person responsible
for their safety.
Safety with children
 Young children must not be allowed to use this appliance.
 Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
 Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
 Please supervise children in the vicinity of the tumble dryer and do
not let them play with it.

Warning and Safety instructions
9
Technical safety
 Before setting up the tumble dryer, check it for any externally
visible damage.
Do not install or use a damaged tumble dryer.
 Before connecting the tumble dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) matches
the mains electricity supply. If in any doubt, consult a qualified
electrician.
 The electrical safety of this tumble dryer can only be guaranteed
when correctly earthed. It is essential that this standard safety
requirement is met. If in any doubt, please have the household wiring
system tested by a qualified electrician. Miele cannot be held liable
for the consequences of an inadequate earthing system (e.g. electric
shock).
 Reliable and safe operation of this tumble dryer can only be
assured if it has been connected to the mains electricity supply.
 Do not connect the tumble dryer to the mains electricity supply by
an extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
 If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
 Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the warranty.
 Faulty components must only be replaced by genuine Miele spare
parts. Miele can only guarantee the safety of the appliance when
Miele replacement parts are used.

Warning and Safety instructions
10
 In the event of a fault or for cleaning purposes, the tumble dryer is
only completely isolated from the electricity supply when:
– it is switched off at the wall socket and the plug is withdrawn, or
– it is switched off at the mains circuit breaker.
 This tumble dryer must not be installed and operated in mobile
installations (e.g. on a ship).
 Do not make any alterations to the tumble dryer, unless authorised
to do so by Miele.
 Heat pump technology and refrigerant:
The heat pump in this tumble dryer uses a refrigerant which is
condensed by the compressor and led in a closed circuit through the
heat exchanger unit where heat exchange with the circulating drying
air takes place.
– The humming noises caused by the heat pump are normal and do
not impair the efficient functioning of the dryer.
– The refrigerant is not flammable or explosive.
– In general it is not necessary to leave the dryer standing for any
length of time before it is connected to the mains provided it has
been transported and installed correctly.

Warning and Safety instructions
11
 Please observe the instructions in “Installation and connection”
and “Technical data”.
 The accessibility of the plug must be always ensured in order to
separate the tumble dryer from the mains.
 Do not block the gap between the bottom of the tumble dryer and
the floor with plinth facings, deep pile carpet etc. This would hinder a
sufficient flow of air to the tumble dryer.
 Make sure the dryer door can be opened without hindrance after
installation.

Warning and Safety instructions
12
Correct use
Warning: Risk of fire / Flammable materials.
To avoid the possible danger of fire, please read these warnings
carefully.
A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
 The maximum load for this tumble dryer is 9.0 kg (dry weight). See
the “Programme chart” for the maximum recommended loads for
individual programmes.
 To prevent the risk of fire, do not connect the tumble dryer via a
controllable socket (e.g. a timer or a peak-load switch-off device).
If the drying programme is interrupted before the end of the cooling
down phase, this could cause the laundry to self-ignite.

Warning and Safety instructions
13
 To prevent the risk of fire, the following textiles must not be dried
in this tumble dryer:
– Items which have not been washed.
– Items which have been cleaned using chemicals (e.g. professional
dry-cleaning agents).
– Items, such as workwear, which have not been thoroughly
cleaned and which are still soiled with grease, oil or other
desposits (such as cosmetics, lotions etc). If items have not been
thoroughly cleaned, there is a danger that these might ignite when
heated, even after they have been removed from the dryer at the
end of the programme.
– Items that have been soiled with substances such as cooking oil,
acetone, petrol, kerosene, spot removers, turpentine, waxes, wax
removers and other chemicals (e.g. mops and floor cloths).
– Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
– Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– Damaged fabrics which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting in the dryer.
When washing such heavily soiled items ensure that you use
sufficient detergent and select a high temperature. If in doubt,
wash the items several times.

Warning and Safety instructions
14
 Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
 Remove all items from pockets (e.g. lighters, matches).
 Warning: Ensure that you always wait until the end of the
programme before removing the laundry. If the drying programme is
stopped prematurely, remove the laundry immediately and hang it up
or spread it out to cool it down.
 Fabric softener and similar products must be used according to
the instructions on the manufacturer's packaging.
 In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry self-
igniting). The programme is not finished until the cooling down phase
has been completed.
As soon as the programme has finished, remove all laundry from the
drum.
 Do not let anyone sit or lean on the door, as this can cause the
tumble dryer to tip up.
 Always close the door after use. This way you will avoid the
danger of:
– children climbing onto or into the dryer or hiding things in it.
– pets or other small animals climbing into it.

Warning and Safety instructions
15
 The tumble dryer must not be used without or
– with damaged fluff filters.
– with a damaged plinth filter.
This would cause an excessive build-up of fluff which in turn would
cause a fault.
 The fluff filters must be cleaned after every drying cycle.
Fluff must not be allowed to accumulate around the tumble dryer.
 The fluff filters and the plinth filter must be thoroughly dried after
cleaning. Do no replace them if they are damp or wet. Damp or wet
filters could cause operational faults.
 Do not install the tumble dryer in a room where there is a risk of
frost occurring. At temperatures around freezing point the tumble
dryer may not be able to operate properly. There is a risk of damage
if the condensed water is allowed to freeze in the pump and hoses.
 If the water is drained externally through the drain hose instead of
being collected in the condensed water container, make sure the
drain hose is securely attached if you hang it in a sink or basin to
avoid the hose slipping and the water causing damage.
 Condensed water is not drinking water.
It can cause health problems in both people and animals.
 Always keep the area around the tumble dryer free of dust and
fluff.
Dust drawn into the tumble dryer can cause blockages in the heat
exchanger over time.
 The tumble dryer must not be hosed down.

Warning and Safety instructions
16
Using a fragrance flacon (optional accessory)
 Only use genuine Miele original fragrance flacons.
 The fragrance flacon must be stored in its packaging so please
make sure you retain this.
 Caution. The fragrance can run out of the flacon. Make sure that
you always keep the flacon, or the fluff filter with the flacon inserted
in it, in a horizontal position when carrying and do not tip it or place
it down on any surface.
 Use an absorbent cloth immediately to wipe up any fragrance
which has run out of the flacon onto the floor, the dryer or any dryer
components (e.g. the fluff filter).
 If fragrance which has run out of a flacon should come in contact
with the skin - wash the skin thoroughly with soap and water; come
in contact with the eyes - rinse the eyes with clean water for at least
15minutes; be swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.
 If fragrance which has run out of a flacon comes in contact with
clothing, change the clothing immediately. Wash the clothing or any
cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.
 There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a flacon with fragrance.
– Never use a faulty fragrance flacon.
 Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
 Please also observe the information supplied with the fragrance
flacon.

Warning and Safety instructions
17
Accessories
 Only use genuine Miele spare parts and accessories with this
appliance. If spare parts or accessories from other manufacturers
are used, this will invalidate the warranty, and Miele cannot accept
liability.
 A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the Miele
washing machine and Miele tumble dryer.
Miele cannot be held liable for damage caused by non-
compliance with these Warning and Safety instructions.

Operating the tumble dryer
18
Control panel
aControl panel
The control panel consists of a
display and various sensor controls.
The individual sensors are explained
in the following.
bDisplay
The following values are shown in
the display and/or selected from it:
1. The programme names, the drying
level and the duration of the
selected programme.
2. The individual values of the
selection lists for settings.
cSensor controls 
Values shown in the display can be
changed with the  sensors. The
 sensor increases the value or
moves the selection list up; the 
sensor decreases the value or
moves the selection list down.
dOK sensor
Confirm selected values with the OK
sensor.
ePerfect Dry  indicator
With programmes with a selectable
drying level, the Perfect Dry system
calculates the residual moisture
present in the laundry to ensure a
precise drying result.
The Perfect Dry indicator . . .
. . . flashes after the programme has
started and goes out when the
programme duration appears in the
display.
. . . lights up when the selected
drying level is reached near the end
of the programme.
. . . remains dark with the following
programmes: Woollens handcare,
Silks handcare, Cool air, Warm air,
Basket programme.

Operating the tumble dryer
19
fOptical interface
For service technicians.
gSensor controls for Extras
You can select extra options to
augment the drying programmes.
When a drying programme is
selected, the sensor controls for the
possible Extras light up dimly.
h Sensor
You can use the  sensor to call up
an energy consumption forecast for
the selected drying programme.
See “Washing environmentally and
economically - EcoFeedback” for
more information.
i Sensor controls
The  sensor starts the Delay start
function. With Delay start you can
delay the start of a programme. The
start of the programme can be
delayed from 15minutes up to a
maximum of 24 hours. This allows
you to make use of night-time
economy electricity rates, for
example.
Further information can be found in
chapter 4 - Selecting programme
settings.
jStart/Stop sensor
Touching the Start/Stop sensor
starts the selected programme or
cancels a programme that has
already started. The sensor flashes
slowly as soon as it is possible for a
programme to be started and then
lights up constantly after the
programme has started.
kProgramme selector
For selecting programmes and for
switching off the appliance. The
dryer is switched on by selecting a
programme, and switched off by
turning the programme selector to
the  position.
Operating the sensor controls
The sensor controls react to fingertip
contact. Selection is possible as long
as the respective sensor is illuminated.
If a sensor is brightly lit, this means:
currently selected
If a sensor is dimly lit, this means:
selection possible

Operating the tumble dryer
20
Display
The standard display shows the
following for a drying programme:
OK


Normal 0:55
– The selected drying level and the
expected programme duration.
– After the programme has started, the
drying level reached and the
remaining programme duration.
The standard display shows only the
programme duration for a time-
controlled programme:
OK

2:00
Examples on how to operate
the appliance
Scrolling through a list
The  scroll bar in the display indicates
that a list of choices is available.
OK


Language 
Touching the  sensor scrolls down the
list to the next option and touching the
 sensor scrolls up the list to the next
option. The OK sensor is used to
activate the option shown in the display.
Identifying the selected option
OK



On
An activated option in a list will have a
tick  next to it.
Setting numerical values
OK


:00
00
Start in h
The numerical value is highlighted in
white. Touching the  sensor
decreases the value. Touching the 
sensor increases the value. The OK
sensor is used to activate the value
shown in the display.
Exiting a submenu
Select Back  to exit the submenu.
