Miele KM 6207 User manual

Operating instructions
Ceramic hobs
KM 6200 / 6202 / 6203
KM 6204 / 6206 / 6207 / 6208
KM 6212 / 6213 / 6215 / 6216
To avoid the risk of accidents or
damage to the appliance it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 09 140 320
en-GB

2

Description of the appliance.........................................5
Models ...........................................................5
KM 6200 .......................................................5
KM 6202 / KM 6203 ..............................................6
KM 6204 / KM 6206 / KM 6207......................................7
KM 6208 .......................................................8
KM 6212 / KM 6213 / KM 6215 / KM 6216 .............................9
Controls .........................................................10
Cooking zones ....................................................12
Warning and Safety instructions ....................................14
Caring for the environment.........................................26
Before using for the first time.......................................27
Cleaning for the first time............................................27
Before using for the first time.........................................27
How the cooking zones work .......................................28
Operation .......................................................29
Operating principals ...............................................29
Switching on .....................................................30
Settings .........................................................32
Auto heat-up .....................................................33
Outer circle of a vario/extended zone ..................................35
Switching off and residual heat indicators...............................37
Suitable pans ....................................................38
Tips on saving energy ............................................39
Timer ...........................................................40
Minute minder ....................................................41
To switch a cooking zone off automatically ..............................44
To use both timer functions at the same time ............................45
Contents
3

Safety features ...................................................46
Safety lock / System lock ...........................................46
Stop and Go......................................................48
Safety switch-off...................................................49
Overheating/pan protection..........................................51
Cleaning and care ................................................52
Programming ....................................................54
Problem solving guide ............................................57
To test the power level ............................................61
Optional accessories..............................................63
Con|ctivity and Miele|home.......................................67
Signing on the hob.................................................67
Signing off the hob.................................................68
Electrical connection..............................................69
Wiring diagram ...................................................70
After sales service, data plate ......................................71
Contents
4

Models
KM 6200
abd Single cooking zones
cVario cooking zone with ExtraSpeed
eControls
Description of the appliance
5

KM 6202 / KM 6203
aVario cooking zone
bd Single cooking zones
cVario cooking zone with ExtraSpeed
eControls
Description of the appliance
6

KM 6204 / KM 6206 / KM 6207
aVario cooking zone with ExtraSpeed
bd Single cooking zones
cExtended cooking zone
eControls
Description of the appliance
7

KM 6208
aTriple cooking zone with ExtraSpeed
bSingle cooking zone
cSingle cooking zone, can link with
bto make an ExtendedPlus zone
dControls
Description of the appliance
8

KM 6212 / KM 6213 / KM 6215 / KM 6216
aVario cooking zone with ExtraSpeed
bd Single cooking zones
cExtended cooking zone
eControls
Description of the appliance
9

Controls
Description of the appliance
10

Sensors
aFor switching the hob on and off
bNumerical keypad
- For setting the power level
- For setting the time
cSafety lock
dSwitching on the extended cooking area
eFor selecting the cooking zone
fStop and Go
g- For selecting the timer
- For switching between the timer functions
- For selecting the switch-off time (see "Switching off a cooking zone
automatically")
hHour function
Indicator lights
iSafety lock
jExtended cooking area
Cooking zone displays
k0= Cooking zone ready for use
1to 9= Power levels
¦= Residual heat
A= Auto heat-up when the power level range has been extended
lIndicator light for Auto heat-up or extended power setting (see "Programming")
Timer display
mIndicator light for relevant zone, e.g. the rear right cooking zone
n
00 to 99 = Time in minutes
0.^ to 9^ = Time in hours
PS = Programming (see "Programming")
LC = Safety lock / System lock active
oIndicator light for half hours with a minute minder time of more than 99 minutes
Description of the appliance
11

Cooking zones
Cooking
zone
KM 6200 KM 6202 / KM 6203
Cin cm Rating in
watts for 230
V
Cin cm Rating in
watts for 230
V
y18.0 1800 10.0 / 18.0 600 / 1800
w14.5 1200 14.5 1200
x12.0 / 21.0 1200 / 2900 12.0 / 21.0 1200 / 2900
z14.5 1200 14.5 1200
Total: 7100 Total: 7100
Cooking
zone
KM 6204 / KM 6206 / KM 6207
Cin cm Rating in watts for 230 V
y12.0 / 21.0 1200 / 2900
w14.5 1200
x17.0 /
17.0 x 26.5
1500 / 2400
z14.5 1200
Total: 7700
Cooking
zone
KM 6208
Cin cm Rating in watts for 230 V
f14.5 / 21.0 / 27.0 1200 / 2300 / 3400
x18.0 1800
z18.0 1800
z+x18.0 x 41.0 3900
Total: 7300
Description of the appliance
12

Cooking
zone
KM6212 / KM 6213 / KM 6215 / KM 6216
Cin cm Rating in watts for 230 V
y12.0 / 21.0 1200 / 2900
w14.5 1200
x17.0 / 17.0 x 29.0 1500 / 2600
z18.0 1800
Total: 8500
Description of the appliance
13

This appliance complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before installation and
before using it for the first time. They contain important notes on
installation, safety, use and maintenance. Miele cannot be held
liable for damage caused by non-compliance with these Warning
and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Warning and Safety instructions
14

Correct application
~This hob is not designed for commercial use. It is intended for
use in domestic households and similar working and residential
environments.
~The appliance is not intended for outdoor use.
~It is intended for domestic use only to cook food and keep it
warm. Any other use is not supported by the manufacturer and
could be dangerous.
~The appliance can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, if they are supervised whilst using it, or have been
shown how to use it in a safe way and understand the hazards
involved.
Warning and Safety instructions
15

Safety with children
~Children under 8 years of age must be kept away from the
appliance unless they are constantly supervised.
~Children 8 years and older may only use the appliance if they
have been shown how to use it in a safe way and understand the
hazards involved.
~Children must not be allowed to clean the appliance
unsupervised.
~This appliance is not a toy! To prevent the risk of injury, do not
allow children to play with the appliance or its controls.
~The appliance gets hot when in use and remains hot for a while
after being switched off. Keep children well away from the appliance
until it has cooled down and there is no danger of burning.
~Danger of suffocation. Packaging, e.g. cling film, polystyrene and
plastic wrappings, must be kept out of the reach of babies and
children. Whilst playing, children could become entangled in
packaging, or pull it over their head and suffocate.
~Danger of burning.
Do not store anything which might arouse a child's interest in
storage areas above or behind the appliance. Otherwise they could
be tempted into climbing onto the appliance
~Danger of burning or scalding.
Place pots and pans on the cooking zones in such a way that
children cannot pull them down and burn themselves. Special hob
guards, available from good retail outlets, can reduce this risk.
~Activate the system lock to ensure that children cannot switch on
the appliance inadvertently. Activate the safety lock when the hob is
in use to prevent children from altering the settings selected.
Warning and Safety instructions
16

Technical safety
~Installation, maintenance and repairs may only be carried out by
a Miele-authorised person. Installation, maintenance and repairs by
unqualified persons could be dangerous.
~A damaged appliance can be dangerous. Check the appliance
for visible signs of damage. Do not use a damaged appliance.
~The electrical safety of this appliance can only be guaranteed if
correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician.
~To avoid the risk of damage to the appliance, make sure that the
connection data (frequency and voltage) on the data plate
corresponds to the household supply, before connecting the
appliance to the mains supply.
Consult a qualified electrician if in any doubt.
~Do not connect the appliance to the mains electricity supply by a
multi-socket adapter or an extension lead. These are a fire hazard
and do not guarantee the required safety of the appliance.
~For safety reasons, this appliance may only be used after it has
been built in.
~This appliance must not be used in a non-stationary location (e.g.
on a ship).
~Do not open the casing of the appliance.
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
Warning and Safety instructions
17

~While the appliance is under guarantee, repairs should only be
undertaken by a service technician authorised by Miele. Otherwise
the guarantee is invalidated.
~The manufacturer can only guarantee the safety of the appliance
when original Miele replacement parts are used. Faulty components
must only be replaced by genuine Miele original spare parts.
~The hob is not intended for use with an external timer switch or a
remote control system.
~The hob must be connected to the electrical supply by a qualified
electrician. If the connection cable is faulty, it must be replaced with
a special connection cable installed by a qualified electrician. See
"Electrical connection".
~The appliance must be disconnected from the mains electricity
supply during installation, maintenance and repair work.
~If the hob is fitted with a communication module, in addition to
disconnecting the hob, this module must also be disconnected from
the mains electricity during installation and maintenance of the hob
as well as while any repair work is being carried out.
Ensure that power is not supplied to the hob or the communication
module until the hob has been installed or until after any
maintenance or repair work has been carried out.
~Danger of electric shock.
Do not use the hob if it is faulty, or if the ceramic surface is cracked,
chipped or damaged in any way. Switch it off immediately, and
disconnect it from the mains electricity supply.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the guarantee.
Warning and Safety instructions
18

Correct use
~Oil and fat can overheat and catch fire. Do not leave the
appliance unattended when cooking with oil or fat.
If oil or fat does catch fire, do not attempt to put out the flames with
water. Disconnect the appliance from the mains and use a suitable
fire blanket, saucepan lid, damp towel or similar to smother the
flames.
~Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
~Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or
substances in a drawer under the hob. Cutlery inserts must be
heat-resistant.
~Do not heat an empty pan.
~Do not heat up unopened tins of food on the hob, as pressure will
build up in the tin, causing it to explode.
~Do not cover the hob, e.g. with a hob cover, a cloth or protective
foil. The material could catch fire, shatter or melt if the appliance is
switched on by mistake or if residual heat is still present.
~When using an electrical appliance, e.g. a hand-held food
blender, near the appliance, ensure that the cable of the electrical
appliance cannot come into contact with the hot appliance. The
insulation on the cable could become damaged.
~Plastic and aluminium foil containers melt at high temperatures.
Do not use plastic or aluminium foil containers on the hob.
~If the appliance is installed behind a kitchen furniture door, it may
only be used with the furniture door open. Do not close the door
whilst the hob in use or whilst there is any residual heat present.
Warning and Safety instructions
19

~The appliance gets hot when in use and remains hot for a while
after being switched off. There is a danger of burning until the
residual heat indicators go out.
~You could burn yourself on the hot hob. Protect your hands with
heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
~When the appliance is switched on either deliberately or by
mistake, or when there is residual heat present, there is the risk of
any metal items left on the hob heating up, with the danger of
burning.
Depending on the material, other items left on the hob could also
melt or catch fire.
Damp pan lids might adhere to the ceramic surface and be difficult
to dislodge.
Do not use the appliance as a resting place.
Switch the cooking zones off after use.
~Do not allow solid or liquid sugar, or pieces of plastic or
aluminium foil to get onto the cooking zones when they are hot, as
they can damage the ceramic surface when it cools down. If this
should occur, switch off the appliance and scrape off all the sugar,
plastic or aluminium residues from the hob whilst still hot, using a
shielded scraper blade. Wear oven gloves.
Allow the cooking zones to cool down and then clean them with a
suitable ceramic hob cleaning agent.
~Pans which boil dry can cause damage to the ceramic glass. Do
not leave the appliance unattended whilst it is being used.
~Do not use pots or pans on the hob with bases with pronounced
edges or ridges. These could scratch or scour the ceramic glass
surface permanently. Only use pots and pans with smooth bases.
Warning and Safety instructions
20
