Miele SmartLine CS 7612 User manual

Operating and installation
instructions
SmartLine induction hob
To avoid the risk of accidents or damage to the appliance it is essen-
tial to read these instructions before it is installed and used for the
first time.
en-GB M.-Nr. 10 758 371

Contents
3
Warning and Safety instructions...................................................................... 5
Caring for the environment .............................................................................. 15
Guide to the appliance...................................................................................... 16
Hob...................................................................................................................... 16
Controls and display ........................................................................................... 17
Cooking zones..................................................................................................... 18
How it works ...................................................................................................... 19
Noises.................................................................................................................. 19
Power management ............................................................................................ 20
Pans .................................................................................................................... 21
Before using for the first time .......................................................................... 23
Cleaning the SmartLine element for the first time............................................... 23
Switching on the SmartLine element for the first time ........................................ 23
Operation............................................................................................................ 24
Using the appliance............................................................................................. 24
Switching on the hob .......................................................................................... 25
Setting the power level........................................................................................ 25
Switching off a cooking zone .............................................................................. 25
Residual heat indicator........................................................................................ 26
Power level setting - Extended setting range...................................................... 26
PowerFlex cooking area ...................................................................................... 27
Auto heat-up ....................................................................................................... 28
Booster function.................................................................................................. 29
Keeping warm ..................................................................................................... 30
Setting range...................................................................................................... 31
Tips on saving energy ...................................................................................... 32
Timer................................................................................................................... 33
Minute minder ..................................................................................................... 33
Auto switch off .................................................................................................... 34
Using both timer functions at the same time ...................................................... 35
Additional functions .......................................................................................... 36
Stop&Go............................................................................................................ 36
Recall................................................................................................................... 36
Wipe protection ................................................................................................... 37
Demonstration mode........................................................................................... 37
Displaying the SmartLine element data .............................................................. 37

Contents
4
Safety features................................................................................................... 38
System lock/safety lock ...................................................................................... 38
Safety switch-off ................................................................................................. 39
Overheating protection........................................................................................ 40
Programming ..................................................................................................... 41
Note for test institutes ...................................................................................... 44
Cleaning and care ............................................................................................. 45
Problem solving guide ...................................................................................... 47
Messages in the display...................................................................................... 47
Unexpected behaviour ........................................................................................ 49
Unsatisfactory results.......................................................................................... 50
General problems or technical faults................................................................... 50
Optional accessories ........................................................................................ 52
After sales service............................................................................................. 53
Contact in the event of a fault ............................................................................. 53
Data plate ............................................................................................................ 53
Warranty .............................................................................................................. 53
Installation.......................................................................................................... 54
Safety instructions for installation ....................................................................... 54
Safety distances.................................................................................................. 55
Installation notes – surface-mounted.................................................................. 59
Worktop cutout – surface-mounted .................................................................... 61
Spacer bars – surface-mounted.......................................................................... 64
Installation dimensions–Surface-mounted........................................................ 65
Installation – surface-mounted............................................................................ 66
Installation notes – flush-fit ................................................................................. 68
Worktop cutout – flush-fit.................................................................................... 70
Spacer bars – flush-fit ......................................................................................... 73
Installation dimensions–Flush-fit ....................................................................... 74
Installation – flush-fit ........................................................................................... 75
Electrical connection ........................................................................................... 77
Product data sheets ......................................................................................... 79

Warning and Safety instructions
5
This hob complies with all relevant local and national safety re-
quirements. Inappropriate use can, however, lead to personal in-
jury and material damage.
Read the operating and installation instructions carefully before
using the hob. They contain important information on safety, in-
stallation, use and maintenance. This prevents both personal injury
and damage to the hob.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the hob as well as the safety instructions and
warnings.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.

Warning and Safety instructions
6
Correct application
 This hob is intended for domestic use and use in other similar en-
vironments.
 This hob is not intended for outdoor use.
 It is intended for domestic use only to cook food and keep it
warm. Any other use is not supported by the manufacturer and could
be dangerous.
 This hob is not intended for use by people with reduced physical,
sensory or mental capabilities or lack of experience and knowledge,
unless they have been given supervision and instruction concerning
its use by a person responsible for their safety. They may only use
the hob unsupervised if they have been shown how to use it in a
safe way. They must be able to recognise and understand the
dangers of misuse.

Warning and Safety instructions
7
Safety with children
 Children under 8 years of age must be kept away from the hob
unless they are constantly supervised.
 Children over 8years of age may use the hob without supervision
if its operation has been clearly explained to them and they are able
to use it safely. Children must be able to understand and recognise
the possible dangers caused by incorrect operation.
 Children must not be allowed to clean the hob unsupervised.
 Please supervise children in the vicinity of the hob and do not let
them play with it.
 The hob gets hot when in use and remains hot for a while after be-
ing switched off. Keep children well away from the hob until it has
cooled down and there is no danger of burning.
 Danger of burning! Do not store anything which might arouse a
child's interest in storage areas above or behind the hob. Otherwise
they could be tempted into climbing onto the appliance with the risk
of burning themselves.
 Risk of burning and scalding. Place pots and pans on the cooking
zone in such a way that children cannot pull them down and burn
themselves.
 Danger of suffocation! Whilst playing, children may become en-
tangled in packaging material (such as plastic wrapping) or pull it
over their head with the risk of suffocation. Keep packaging material
away from children.
 Activate the system lock to ensure that children cannot switch on
the hob inadvertently. Use the safety lock when the hob is in use to
prevent children from altering the settings selected.

Warning and Safety instructions
8
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re-
pairs must only be carried out by a Miele authorised technician.
 Damage to the hob can compromise your safety. Check the hob
for visible signs of damage. Do not use the hob if it is damaged.
 Temporary or permanent operation on an autonomous power sup-
ply system or a power supply system that is not synchronised with
the mains power supply (e.g. island networks, back-up systems) is
possible. A prerequisite for operation is that the power supply sys-
tem complies with the specifications of EN50160 or an equivalent
standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
 The electrical safety of this hob can only be guaranteed when cor-
rectly earthed. It is essential that this standard safety requirement is
met. If in any doubt please have the electrical installation tested by a
qualified electrician.
 To avoid the risk of damage to the hob, make sure that the con-
nection data on the data plate (voltage and frequency) match the
mains electricity supply before connecting it to the mains.
Consult a qualified electrician if in doubt.
 Do not connect the hob to the mains electrical supply by a multi-
socket adapter or extension lead. These are a fire hazard and do not
guarantee the required safety of the appliance.
 For safety reasons, this hob may only be used after it has been
built in.

Warning and Safety instructions
9
 This hob must not be used in a non-stationary location (e.g. on a
ship).
 Never open the casing of the hob.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.
 While the hob is under warranty, repairs should only be under-
taken by a Miele authorised service technician. Otherwise the war-
ranty is invalidated.
 Miele can only guarantee the safety of the appliance when genu-
ine original Miele replacement parts are used. Faulty components
must only be replaced by Miele spare parts.
 The hob is not intended for use with an external timer switch or a
remote control system.
 If the plug is removed from the connection cable or if the cable is
supplied without a plug, the appliance must be connected to the
electrical supply by a suitably qualified electrician.
 If the mains connection cable is damaged, it must be replaced
with a special connection cable by an electrician (see “Electrical
connection”).
 The hob must be disconnected from the mains electricity supply
during installation, maintenance and repair work. Ensure that power
is not supplied to the appliance until after it has been installed or un-
til any maintenance or repair work has been carried out.
 Danger of electric shock. Do not use the hob if it is faulty, or if the
ceramic surface is cracked, chipped or damaged in any way. Switch
it off immediately. Disconnect the hob from the mains electricity sup-
ply. Contact Miele Service.

Warning and Safety instructions
10
 If the hob is installed behind a cabinet door, do not close the door
while the hob is in use. Heat and moisture can build up behind the
closed door. This can result in damage to the hob, the housing unit
and the floor. Do not close the door until the residual heat indicators
go out.
 In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by cock-
roaches or other vermin will not be covered by the warranty.

Warning and Safety instructions
11
Correct use
 The hob gets hot when in use and remains hot for a while after be-
ing switched off. There is a danger of burning until the residual heat
indicators go out.
 Oil and fat can overheat and catch fire. Do not leave the hob unat-
tended when cooking with oil and fat. If it does ignite do not attempt
to put the flames out with water.
Disconnect the hob from the mains and use a suitable fire blanket,
saucepan lid, damp towel or similar to smother the flames.
 Do not leave the SmartLine element unattended whilst it is being
used. It should be continually monitored whilst boiling and flash fry-
ing.
 Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
 Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or substances
in a drawer under the hob. Cutlery inserts must be heat-resistant.
 Do not heat an empty pan.
 Do not heat up food in closed containers e.g. tins or sealed jars
on the hob, as pressure can build up in the container, causing it to
explode.
 Do not cover the hob, e.g. with a hob cover, a cloth or protective
foil. The material could catch fire, shatter or melt if the hob is
switched on by mistake or if residual heat is still present.
 When the appliance is switched on either deliberately or by mis-
take, or when there is residual heat present, there is the risk of any
metal items left on the hob heating up, with the danger of burning.
Depending on the material, other items left on the hob could also
melt or catch fire. Damp pan lids might adhere to the ceramic sur-
face and be difficult to dislodge. Do not use the appliance as a rest-
ing place. Switch the cooking zones off after use.

Warning and Safety instructions
12
 You could burn yourself on the hot hob. Protect your hands with
heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to trans-
fer through the material more quickly with the risk of scalding or
burning yourself.
 When using an electrical appliance, e.g. a hand-held food blender,
near the hob, ensure that the cable of the electrical appliance cannot
come into contact with the hot hob. The insulation on the cable
could become damaged.
 Grains of salt, sugar and sand (e.g. from cleaning vegetables) can
cause scratches if they get under pan bases. Make sure that the
ceramic surface is clean before placing pans on it.
 Even a light object can cause damage in certain circumstances.
Do not drop anything on the ceramic surface.
 Placing hot pans on the sensors and indicators could damage the
electronics underneath. Do not place hot pans on the sensors or in-
dicators.
 Do not allow solid or liquid sugar, or pieces of plastic or aluminium
foil to get onto the hob when it is hot, as they can damage the
ceramic surface when it cools down. If this should occur, switch off
the appliance and scrape off all the sugar, plastic or aluminium
residues whilst still hot, using a shielded scraper blade suitable for
use on glass. Wear oven gloves when doing this. Allow the ceramic
surface to cool down and then clean it with a suitable ceramic hob
cleaning agent.
 Pans which boil dry can cause damage to the ceramic glass. Do
not leave the hob unattended whilst it is being used.
 Only use pots and pans with smooth bases. Rough bases will
scratch the ceramic glass.
 Lift pans into position on the hob. Sliding them into place can
cause scuffs and scratches.

Warning and Safety instructions
13
 Because induction heating works so quickly, the base of the pan
could, under certain circumstances, heat up to the temperature at
which oil or fat self-ignites within a very short time. Never leave the
hob unattended during use!
 Heat oil or fat for a maximum of one minute. Never use the
Booster function to heat oil or fat.
 For people fitted with a heart pacemaker: Please note that the
area immediately surrounding the hob is electromagnetically
charged. It is very unlikely to affect a pacemaker. However, if in any
doubt, consult the manufacturer of the pacemaker or your doctor.
 To prevent damage to items which are susceptible to electromag-
netic fields, e.g. credit cards, digital storage devices, pocket calcu-
lators, etc, do not leave them in the immediate vicinity of the hob.
 Metal utensils stored in a drawer under the hob can become hot if
the appliance is used intensively for a long time.
 The hob is fitted with a cooling fan. If a drawer is fitted directly un-
derneath the hob, ensure that there is sufficient space between the
drawer and its contents and the underside of the hob in order to en-
sure sufficient ventilation for the hob.
 If a drawer is fitted directly underneath the hob, do not store any
pointed or small items, paper, serviettes, etc. in the drawer. They
could get in through the ventilation slots or be sucked into the casing
by the fan and damage the fan or impair cooling.
 Never use two pans on a cooking zone, extended zone or Power-
Flex zone at the same time.
 If the cookware only partially covers a cooking or extended zone,
the handle could become very hot.
Always place cookware in the middle of a cooking or extended zone!
 The induction generators could be damaged or even destroyed if
you use an induction adapter plate for cookware. Do not use induc-
tion adapter plates.

Warning and Safety instructions
14
Cleaning and care
 Do not use a steam cleaning appliance to clean this hob.
The steam could reach electrical components and cause a short cir-
cuit.
 If the hob is built in over a pyrolytic oven, the hob should not be
used whilst the pyrolytic process is being carried out, as this could
trigger the overheating protection mechanism on the hob (see relev-
ant section).
 Miele will guarantee to supply functional spare parts for a min-
imum of 10years and up to 15years following the discontinuation of
your CombiSet.

Caring for the environment
15
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible for deleting any personal data that
may be stored on the appliance being
disposed of. Please ensure that your
old appliance poses no risk to children
while being stored prior to disposal.

Guide to the appliance
16
Hob
aPowerFlex cooking zone with TwinBooster
can be combined with PowerFlex cooking zone  to form PowerFlex cooking
area
bPowerFlex cooking zone with TwinBooster
cControls and indicators

Guide to the appliance
17
Controls and display
Sensor controls
aHob On/Off
bStop&Go
To stop/start a cooking process in progress
cWipe protection
To lock the sensor controls
dPowerFlex cooking zones
For manual connection/disconnection of PowerFlex cooking zones
eKeeping warm
To activate/deactivate the Keeping warm function
fNumerical display
– To set the power level
– To set the times
gAuto switch off
Switches the cooking zones off automatically
hMinute minder

Guide to the appliance
18
Displays/indicator lights
iCooking zone allocation auto switch off
Auto switch off for the cooking zone is activated
jResidual heat
kBooster function
Booster function is activated
lTimer display
: to
:
Time
 System lock/safety lock is activated
 Demo mode is activated
Cooking zones
Cooking zone Øin cm1Rating in watts for 230V2
15–23 Normal
TwinBooster, level 1
TwinBooster, level 2
2100
3000
3650
15–23 Normal
TwinBooster, level 1
TwinBooster, level 2
2100
3000
3650
+22–23/
15x23–23x39
Normal
TwinBooster, level 1
TwinBooster, level 2
3150
3400
3650
Total 3650
1Cookware with a base diameter within the given range may be used.
2The power given may vary depending on the size and material of the cookware used.

How it works
19
An induction coil is located under each
induction cooking zone. The coil cre-
ates a magnetic field that reacts directly
with the base of the pan and heats it
up. The cooking zone itself is heated up
indirectly by the heat given off by the
pan.
An induction cooking zone only works
when cookware with a magnetic base is
placed on it (see “Cookware”). Induc-
tion automatically recognises the size of
the cookware.
Risk of burning due to hot items.
When the appliance is switched on
either deliberately or by mistake, or
when there is residual heat present,
there is the risk of metal items placed
on the hob heating up.
Do not use the appliance as a resting
place for anything.
After use, switch the hob off with
the sensor control.
Noises
When using an induction hob, the fol-
lowing noises can occur in the pan, de-
pending on what it is made of and how
it has been constructed.
Buzzing on the higher power settings.
This will decrease or cease altogether
when the power setting is reduced.
If the pan base is made of layers of dif-
ferent materials (e.g. in a sandwiched
base), it might emit a crackling sound.
Whistling might occur if linked zones
(see “Operation - Booster”) are being
used at the same time, and the pans
also have bases made of layers of dif-
ferent materials.
You might hear a clicking sound from
the electronic switches, especially on
lower settings.
A whirring sound, when the cooling fan
comes on. This switches on to protect
the electronics when the hob is being
used intensively. The cooling fan may
continue to run after the appliance has
been switched off.

How it works
20
Power management
The hob has a maximum total permitted
power consumption which cannot be
exceeded for safety reasons.
The two cooking zones on the hob are
interconnected. This allows additional
power to be transferred from one cook-
ing zone to another.
The previously set setting has preced-
ence and the hob will operate with this
level.
If power is transferred from one cooking
zone to the linked cooking zone, the
power for the first cooking zone must
be reduced.
The possible values for the maximum
total permitted power consumption
can be found in “Overview – Cooking
zone data”.
If the new cooking zone requires more
power than the first cooking zone can
provide, this may result in the following
consequences for the first cooking
zone:
- The power level is reduced.
- Auto heat-up will be deactivated.
Cooking continues at the set level. If
the power is not sufficient, the power
level will be reduced again.
- The Booster function is deactivated.
- The cooking zone is switched off.
If the most recently set power level is
reduced or the Booster function is
switched off, the power level for the
linked cooking zone can be increased
again.
