Safety instructions for installation
Risk of damage from incorrect installation.
Incorrect installation can cause damage to the steam oven.
The steam oven must only be installed by a qualified person.
 The connection data (frequency and voltage) on the steam oven’s
data plate must correspond with those of the electricity supply in
order to ensure that no damage can occur to the steam oven.
Compare this data before connecting the appliance. If in any doubt,
consult a qualified electrician.
 Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (fire hazard). Do not use them to
connect the steam oven to the power supply.
 The socket and on-off switch should be easily accessible after the
steam oven has been installed.
 The steam oven must be positioned so that you can see the
contents of a cooking container placed on the top shelf level.
Otherwise there is a risk of injuries or spillages of hot food.

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Building-in dimensions
All dimensions are given in mm.
Installation in a tall unit
The furniture housing unit must not have a back panel fitted behind the
building-in niche.

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Installation in a base unit
The furniture housing unit must not have a back panel fitted behind the
building-in niche.
If the steam oven is to be installed in a base unit underneath an electric or
induction cooktop, please also observe the installation instructions for the
cooktop as well as the building-in height required for the cooktop.

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Side view
AGlass front: 22mm
Metal front: 23.3mm

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Connection and ventilation
aFront view
bMains connection cable, L = 2000 mm
cVentilation cut-out, min. 180cm2
dNo connections permitted in this area

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Installing the steam oven
Connect the mains connection cable
to the appliance.
Risk of damage from incorrect
transportation.
Lifting the steam oven by the door
handle could cause damage to the
door.
Use the handle cut-outs on the side
of the casing to lift the appliance.
The steam generator may
malfunction if the steam oven is not
on a level surface.
The maximum deviation from the
horizontal that can be tolerated is 2°.
Push the steam oven into the housing
unit and align it.
When doing so, make sure that the
mains connection cable does not get
trapped or damaged.
Open the door.
Secure the steam oven to the side
walls of the unit using the wood
screws supplied (3.5x25mm).
Connect the appliance to the mains
electricity supply.
Check the appliance for correct
function in accordance with the
operating instructions.

11232260-01
Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
Electrical connection
We recommend that you connect the
steam oven to the electricity supply
using a suitable switched electrical
socket. This simplifies servicing. The
socket must be easily accessible after
the steam oven has been installed.
Risk of damage from incorrect
connection.
Danger of injury! Miele cannot be
held liable for unauthorised
installation, maintenance and repair
work as this can be dangerous to
users.
Miele cannot be held liable for
damage or injury (e.g. electric shock)
caused by the lack of or inadequacy
of an on-site earthing system.
If the plug is removed from the
connection cable or if the cable is
supplied without a plug, the steam
oven must be connected to the
electrical supply by a suitably
qualified and competent electrician.
If the socket is no longer accessible,
or if a hard-wired connection is
planned, an additional means of
disconnection must be provided for
all poles. Suitable means of
disconnection include switches with
an all-pole contact gap of at least
3mm. These include miniature circuit
breakers, fuses and relays. The
connection data is given on the data
plate. Please ensure this information
matches the household mains
electricity supply.
After installation, ensure that all
electrical components are shielded
and cannot be accessed by users.
Total power output
See data plate.
Connection data
The connection data is given on the
data plate. Please ensure this
information matches the household
mains supply.
Residual current device
For extra safety, it is advisable to
protect the steam oven with a suitable
residual current device (RCD) with a trip
range of 30mA.
Replacing the mains connection
cable
If replacing the mains connection cable,
it must be replaced with a cable type
H05VV-F, available from Miele.
Disconnecting from the mains
Risk of electric shock!
There is a risk of electric shock if the
appliance is connected to the mains
electricity supply during repair or
service work.
After disconnection, ensure the
appliance cannot be switched back
on by mistake.
