Miele H 4700 B User manual

Operating and installation instructions
Oven
H 4700 B, H 4710 B
H 4800 B, H 4810 B
To avoid the risk of accidents or
damage to the appliance, it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 07 856 420
en - AU, NZ

2

Warning and Safety instructions .....................................6
Caring for the environment.........................................11
Description of the appliance........................................12
H 4700 B, H 4710 B, H 4800 B, H 4810 B ...............................12
Features ........................................................13
Oven controls.....................................................13
Safety features ....................................................13
Cooling fan ....................................................13
Vented oven door ...............................................13
Energy-saving features .............................................13
Rapid heat-up function ...........................................13
PerfectClean treated surfaces ........................................13
Catalytic enamelled surfaces ........................................13
Accessories ......................................................14
Baking tray, universal tray and rack with anti-tip safety notches ...........14
FlexiClip telescopic runners .......................................15
Fitting the FlexiClip telescopic runners ................................15
Remove FlexiClip telescopic runners ................................16
Oven controls....................................................17
Function selector ..................................................17
Temperature selector ..............................................17
Temperature indicator light ....................................17
Functions .......................................................18
Before using for the first time.......................................20
To set the time of day for the first time..................................20
Cleaning and heating up for the first time ...............................20
Clock timer ......................................................22
Sensors .........................................................22
Operation ........................................................22
Time displays ..................................................23
Changing the time of day ...........................................23
To change the audible tone..........................................24
Using the minute minder lfunction ...................................24
To set the minute minder .........................................25
To change the time set for the minute minder .........................25
To cancel the time set for the minute minder ..........................25
Contents
3

Operation .......................................................26
Using the oven....................................................26
Pre-heating ......................................................26
Switching on and off automatically ....................................27
Entering a cooking duration .......................................27
To enter the duration and finish time ................................28
At the end of the duration ........................................29
To check and change the duration..................................29
To delete the duration............................................29
Baking tips ......................................................30
Bakeware ........................................................30
Baking paper ..................................................30
Universal tray ..................................................30
Retangular tins .................................................30
Notes about the charts .............................................31
Temperature, baking duration .....................................31
Shelf level .....................................................31
Frozen food ......................................................31
Baking chart .....................................................32
Fan Plus U......................................................32
Conventional V..................................................33
Intensive Bake O.................................................34
Roasting tips ....................................................35
Useful tips .......................................................36
Roasting chart ...................................................37
Notes on low temperature cooking ..................................38
Procedure for low temperature cooking ................................38
Cooking times/Core temperatures.....................................39
Grilling tips ......................................................40
Preparing food for grilling ...........................................42
Grilling ..........................................................42
Useful tips .......................................................42
Fan Grilling guide (Fan Grill \)......................................43
Grilling guide (Grill Y/ Economy Grill Z).............................44
Defrost .........................................................45
Bottling .........................................................46
Contents
4

Cooking ready meals..............................................47
Cleaning and care ................................................48
Appliance front ...................................................48
Accessories ......................................................49
Baking tray, universal tray, anti-splash insert ..........................49
Rack, runners ..................................................49
FlexiClip telescopic runners .......................................49
Lubricating the FlexiClip telescopic runners ..........................50
Oven interior .....................................................51
Seal and inside of the oven door ...................................51
PerfectClean .....................................................52
Catalytic enamel surfaces ...........................................54
To remove the oven door............................................55
To dismantle the oven door .......................................56
To refit the door ...................................................58
To remove the FlexiClip telescopic runners .............................59
To remove the shelf runners .........................................59
To remove the back panel ...........................................60
To lower the top heat/grill element.....................................60
Problem solving guide ............................................61
After sales service and warranty ....................................63
Optional accessories..............................................64
Electrical connection..............................................66
Building-in diagrams ..............................................67
Appliance dimensions and unit cut-out .................................67
Front dimensions ..................................................68
Installing the oven ................................................69
Contents
5

This appliance conforms to current
safety requirements. Inappropriate
use can, however, lead to personal
injury and damage to property.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time.
They contain important notes on
installation, safety, use and
maintenance.
Keep these instructions in a safe
place and ensure that new users are
familiar with the content. Pass them
on to any future owner.
Correct application
~This oven is designed for domestic
use and for use in similar environments
by guests in hotel or motel rooms, bed
& breakfasts and other typical living
quarters. This does not include
common/shared facilities or commercial
facilities within hotels, motels or bed &
breakfasts.
~This oven is designed to bake,
roast, grill, cook, defrost, dry fruit etc.
Any other usage is at the owner's risk.
Miele cannot be held liable for damage
resulting from incorrect or improper use
or operation.
~This oven is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they are supervised
whilst using it or have been given
instruction concerning its use by a
person responsible for their safety.
Safety with children
~This appliance is not a toy! To
prevent the risk of injury or damage, do
not let children play with the appliance
or its controls.
~Older children may only use the
oven when its operation has been
clearly explained to them and they are
able to use it safely, recognising the
dangers of misuse.
~Great care should be taken to
ensure that children do not touch the
appliance when it is being used.
Children's skin is far more sensitive to
high temperatures than that of adults.
External parts of the oven such as the
door glass, control panel and the vent
become quite hot.
~Warning
To avoid burns, young children should
be kept away.
Warning and Safety instructions
6

Technical safety
~Installation, maintenance and
repairs may only be carried out by a
suitably qualified and competent
person in strict accordance with current
national and local safety regulations.
Repairs and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable for
unauthorised work.
~Before installation, check the
appliance for visible signs of damage.
Do not install and use a damaged
appliance. A damaged appliance could
be dangerous.
~The electrical safety of this
appliance can only be guaranteed
when continuity is complete between it
and an effective earthing system. It is
most important that this basic safety
requirement is present and tested
regularly and, where there is any doubt,
the household wiring system should be
inspected by a qualified electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
~Before connecting the appliance,
make sure that the connection data on
the data plate (voltage and connected
load) match the mains electricity
supply.
This data must correspond in order to
avoid the risk of damage to the
appliance. Consult a competent person
if in doubt.
~Do not connect the appliance to the
mains electricity supply by a multi-
socket unit or an extension lead. These
do not guarantee the required safety of
the appliance (e.g. danger of
overheating).
~For safety reasons, this appliance
may only be used when it has been
built in.
~Never open the housing of the
appliance.
Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user and can
cause operational faults.
~While the appliance is under
guarantee, repairs should only be
undertaken by a service technician
authorised by the manufacturer.
Otherwise the warranty will be
invalidated.
Warning and Safety instructions
7

~During installation, maintenance and
repair work, the appliance must be
disconnected from the mains electricity
supply. It is only completely isolated
from the electricity supply when:
–the mains fuse is disconnected,
–the screw-out fuse is removed (in
countries where this is applicable),
–it is switched off at the isolator.
Ensure that current is not supplied to
the appliance until after maintenance or
repair work has been carried out.
~Faulty components must only be
replaced by genuine Miele original
spare parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
~If the supply cord is damaged, it
must be replaced by a Miele approved
service technician to avoid a hazard.
~This appliance may only be used in
mobile installations such as ships,
caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
~In areas which may be subject to
infestation by cockroaches or other
vermin, pay particular attention to
keeping the appliance and its
surroundings in a clean condition at all
times. Any damage which may be
caused by cockroaches or other vermin
will not be covered by the warranty.
Correct use
Caution. Danger of burning.
High temperatures are produced by
the oven and the appliance
becomes hot. Care should be taken
to avoid touching heating elements
inside the oven.
~Use oven gloves when placing food
in the oven, turning or removing it and
when adjusting oven shelves etc. in a
hot oven. Be very careful that you do
not burn yourself on the top heating /
grill element.
~Never leave the appliance
unattended when cooking with oil or
fats, as these are a fire hazard if
allowed to overheat.
~Do not exceed the recommended
grilling times when using the "Grill Y",
"Economy Grill Z" and "Fan Grill \"
functions. Excessively long grilling
times can lead to food drying out and
burning, or could even cause it to catch
fire.
~Do not use the "Grill Y", "Economy
Grill Z" or "Fan Grill \" to finish
baking part-cooked rolls or bread or to
dry flowers or herbs. Fire hazard.
Use "Fan Plus U" or "Conventional V"
instead.
Warning and Safety instructions
8

~If using alcohol in your recipes, high
temperatures can cause the alcohol to
vaporise and even to ignite on the hot
heating elements.
Alcohol should be burnt off before the
dish is placed in the oven to avoid this
danger.
~Cover any food which is left in the
oven to be kept hot. Any moisture in the
food could lead to corrosion damage in
the oven. This also prevents the food
from drying out.
~If you wish to complete a cooking
process using the residual heat in the
oven, leave the function selector at the
position set and turn the temperature
selector to the lowest setting. Do not
switch the appliance off until the food
has been removed. Increased moisture
in the oven could cause condensation
to form which could lead to
– corrosion in the oven compartment.
– damage to the control panel, worktop
and surrounding kitchen furniture.
~Do not line the floor of the oven with
aluminium foil when using
"Conventional V"/"Bottom Heat X"/
"Intensive Bake O"/"Rapid Heat-up S".
This would cause a build-up of heat
which could cause damage to the floor of
the oven.
For this reason, do not place a dish, tin or
baking tray directly on the oven floor.
If using a tray made by a different
manufacturer, make sure that there is a
gap of at least 6 cm between the
bottom of the tray and the floor of the
oven.
~Never add cold water to food on a
hot universal tray or baking tray or
directly onto food in a hot oven. The
steam created could cause serious
burns or scalding and the sudden
change in temperature can damage the
enamel.
~Always ensure that food is suitably
cooked or reheated.
Some foods may contain micro-
organisms which are only destroyed by
thorough cooking at temperatures over
70 °C for a minimum of 10 minutes.
Therefore when cooking or reheating
foods, e.g. poultry, it is particularly
important that food is fully cooked
through. If in doubt, select a longer
cooking or reheating time.
It is important that the heat is allowed to
spread evenly throughout the food
being cooked. This can be achieved by
stirring and/or turning the food during
cooking.
~If using plastic containers for
cooking, they must be declared by the
manufacturer as being suitable for use
in an oven. Other types of plastic
containers melt at high temperatures,
and could damage the oven.
Warning and Safety instructions
9

~Do not heat up unopened tins or jars
of food in the oven. Pressure can build
up and they may explode, resulting in
injury or damage.
~Do not push pots and pans around
on the oven floor, as this could damage
the surface.
~Do not lean or sit on an open oven
door, or place heavy items on it. Make
sure that nothing gets trapped between
the door and the oven compartment.
This could damage the oven.
The oven door can support a maximum
load of 15 kg.
~Do not use the appliance to heat up
the room. Due to the high temperatures
radiated, objects near the appliance
could catch fire.
Accessories
~Only use genuine Miele spare parts
and accessories with this appliance. If
spare parts or accessories from other
manufacturers are used, this will
invalidate the warranty, and Miele
cannot accept liability.
The manufacturer cannot be held
liable for damage caused by non-
compliance with these Warning and
Safety instructions.
Warning and Safety instructions
10

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
or machine
Electrical and electronic appliances /
machines often contain materials
which, if handled or disposed of
incorrectly, could be potentially
hazardous to human health and to the
environment. They are, however,
essential for the correct functioning of
your appliance or machine. Therefore,
please do not dispose of your old
machine or appliance with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person.
The plug must be rendered useless
and the cable cut off directly behind the
appliance or the machine to prevent
misuse.
Caring for the environment
11

H 4700 B, H 4710 B, H 4800 B, H 4810 B
aFunction selector *, retractable when it is at "0"
bClock timer with sensors ?, OK, ;*
cTemperature selector *, retractable when it is at "0"
dTemperature indicator light 
eTop heat/grill element
fCatalytic coated back panel with air inlet for the fan
gRunners with five shelf levels
hDoor
* not available in H 4700 B and H 4800 B
Description of the appliance
12

Oven controls
In addition to operating the various
cooking programmes to bake, roast
and grill, the controls also offer the
following:
–a time of day display,
–a minute minder,
–a timer to automatically switch
cooking programmes on and off,
–settings that can be customised.
Safety features
Cooling fan
A cooling fan will come on
automatically when a cooking
programme is started. The cooling fan
mixes hot air from the oven cavity with
cool room air before venting it out into
the kitchen through vents located
between the appliance door and the
control panel.
The cooling fan will continue to run for a
while after the oven has been switched
off to prevent any humidity building up
in the oven, on the control panel or in
the oven housing unit.
When the temperature in the oven has
fallen sufficiently, the cooling fan will
switch off automatically.
Vented oven door
The oven door is an open system and
the door panes have a heat-reflecting
coating.
During operation, cool air is passed
through the oven door to keep the outer
pane cool.
If necessary, the oven door can be
dismantled for cleaning.
See "Cleaning and care" for more
information.
Energy-saving features
Rapid heat-up function
To minimise the time it takes to heat up
the oven interior, you can utilise the
Rapid heat-up function.
However, pre-heating the oven is only
required for select applications. Please
refer to cooking instructions or separate
User instructions (if available).
PerfectClean treated surfaces
The following surfaces have been
treated with PerfectClean enamel:
– Oven interior
– Universal tray
– Baking tray (if available)
– Anti-splash insert (if available)
PerfectClean enamelled surfaces have
very good anti-stick properties and are
much easier to keep clean than
conventional enamel, if cleaned
regularly.
See "Cleaning and care" for more
information.
Catalytic enamelled surfaces
The back panel is coated with dark
grey catalytic enamel. Soiling from oil
and fat is burnt off this surface when
very high temperatures are used in the
oven.
See "Cleaning and care" for more
information.
Features
13

Accessories
Depending on the model, your
appliance is delivered with some of
the following accessories.
These and other accessories are also
available to order from Miele, your
Chartered Agent or via the internet on
www.miele-shop.com (depending on
country).
Baking tray, universal tray and rack
with anti-tip safety notches
(depending on model)
Baking tray
Universal tray
Rack
The baking tray, universal tray and rack
are inserted into the oven between the
two rails of a shelf runner.
The short sides of the tray and rack
have a groove in the middle. The non-
tip safety notch prevents the trays and
rack from slipping out of a shelf when
they only need to be partially pulled
out.
The trays and rack can then only be
taken out of the oven by raising them
upwards and then pulling them out.
Always insert the rack in the shelf with
the groove on the sides facing
downwards.
If you are using a tray with the rack on
top, insert the tray between the rails of
a shelf runner and the rack will sit on
top of it.
Anti-splash insert
(depending on model)
The anti-splash insert should be placed
in the universal tray when grilling or
roasting.
The juices from the food being cooked
collect under the anti-splash tray. This
prevents them from spitting and making
the oven dirty. The juices can then be
used for making gravy and sauces.
Features
14

FlexiClip telescopic runners
(depending on model)
The FlexiClip telescopic runners can be
clipped into any of the existing shelf
runners and pulled out of the oven to
their fullest extent.
Push the telescopic runners right in
before placing a tray or rack on
them.
To prevent the risk of a rack or tray
sliding off the runners, make sure that
they are sitting securely on their
runners in between the stoppers at
either end of each runner.
The maximum load for the runners is
15 kg.
Fitting the FlexiClip telescopic runners
,Danger of burning
The oven interior needs to have
cooled down before you start
handling anything inside it.
The telescopic runners are fitted in
between the two rails that make up a
shelf level.
The telescopic runner with the Miele
logo is fitted on the right.
When fitting the telescopic runners,
do not extend them.
^Fit the telescopic runner in between
the two rails at the front (1) and then
push it into the oven compartment (2).
^Then secure the telescopic runner to
the bottom of the two rails as
illustrated (3).
If the telescopic runners are difficult
to pull out after fitting, you may need
to pull firmly on them once to release
them.
Features
15

Remove FlexiClip telescopic runners
,Danger of burning
The oven interior needs to have
cooled down before you start
handling anything inside it.
To remove a FlexiClip runner so that
you can clip it into another shelf runner,
for example,
^lift it at the front and then pull it out
along the rail of the oven shelf runner.
^Clip it to the required shelf level, see
"Features - Fitting the FlexiClip
telescopic runners".
Features
16

Function selector
The left-hand control is used to select
the function.
It can be turned clockwise or anti-
clockwise.
The function selector can only be
retracted when it is at "0".
SRapid Heat-up
UFan Plus
\Fan Grill
OIntensive Bake
PDefrost
VConventional
XBottom Heat
YGrill
ZEconomy Grill
TLighting:
The oven lighting can be
switched on separately, e.g. for
cleaning.
Temperature selector
The right-hand control is used to select
the temperature.
It can be turned clockwise as far as it
will go and back again.
The temperature selector can only be
retracted when it is at "0".
Temperature indicator light 
The temperature indicator light is
located next to the temperature
selector.
The indicator light is always on when
the heating is on.
When the set temperature is reached,
–the oven heating switches off.
–the temperature indicator light goes
out.
However, if the temperature falls below
the set temperature, the oven heating
and the temperature indicator light will
switch on again.
Oven controls
17

Your oven has a range of oven functions for preparing a wide variety of recipes.
The oven has the following functions:
aTop heat/grill element (underneath the roof of the oven)
bBottom heat element (underneath the oven floor)
cRing heating element (behind the air inlet for the fan)
dFan (behind the air inlet for the fan)
Depending on the function, these components will be combined differently, see
information in [ ].
Functions Notes
VConventional
[a+b]
–For baking and cooking traditional recipes, e.g. fruit cake,
casseroles.
– Also ideal for soufflés.
– If using an older recipe or cookbook, set the oven
temperature for Conventional 10 °C lower than that
recommended.
The cooking duration does not need to be changed.
XBottom Heat
[b]
– Use this setting towards the end of baking to reheat or
brown the base of a cake, quiche or pizza.
YGrill
[a]
– The grill is ready for use when it glows red.
– For grilling larger quantities of thin cuts (e.g. steaks).
–For browning larger dishes.
ZEconomy
Grill
[a]
–The inner element of the grill is ready for use when it glows
red.
–For grilling small quantities of thin cuts (e.g. steaks)
–For browning smaller dishes.
Functions
18

Functions Notes
SRapid Heat-
up
[a+c+d]
–For pre-heating the oven compartment.
The oven function required must then be selected.
UFan Plus
[c+d]
–For baking and roasting.
–You can bake and roast on different levels at the same
time.
–Lower temperatures can be used than with "Conventional
V" as the Fan Plus system distributes the heated air
around the food.
\Fan Grill
[a+d]
–The heating elements and fan are switched on alternately.
– For grilling larger items, e.g. rolled meat, poultry.
– The hot air from the grill is distributed over the food by the
fan. This enables a lower temperature to be selected than
when using "Grill Y"/"Economy Grill Z".
OIntensive
Bake
[b+c+d]
– For cooking dishes which require a moist topping and a
crisp base such as pizza and quiche lorraine.
– Intensive Bake is not suitable for baking thin biscuits etc.
or for roasting as the juices will become too dark.
PDefrost
[d]
– For the gentle defrosting of frozen food.
Functions
19

Before the oven can be used, you
will need to
– release the controls by pressing
them in if they are pushed in
when the oven is delivered.
– set the time of day on ovens
with a clock timer.
To set the time of day for the
first time
The clock timer has a 24-hour clock.
000
ß
After connecting the appliance, ßlights
up and 000starts flashing.
^Touch the OK sensor.
000lights up in the display and ß
flashes.
^While ßis flashing in the display,
enter the time of day with the ?or ;
sensor.
^Touch the OK sensor.
The time of day is now registered and ß
lights up.
The time of day operates in minute
units.
Cleaning and heating up for
the first time
Before use, please remove
– any stickers from the floor of the
oven.
– any protective foil from the
oven front.
See "Cleaning and care" for more
information.
Before using the oven for the first time,
–take all accessories out of the oven
and wash them.
– then heat the oven up once with
nothing in it. New ovens can give off
a slight smell on first use. Doing this
will dissipate the smells before you
use it to cook food.
^Wipe out the interior with a damp
cloth to remove any dust or bits of
packaging that may have
accumulated in the oven
compartment during storage and
unpacking.
^Press in the function selector and the
temperature selector to release them.
^Use the function selector to select
Fan Plus U.
^Use the temperature selector to set
the highest temperature (250 °C).
Before using for the first time
20
