Miele KF1913 Vi User instructions

Fully Integrated
36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
8mieleusa.com

FOR FLUSH INSTALLATION
KF 1913 Vi / KF 1903 Vi
Page 2 of 7
Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
36"
25" min.*
35 3/4"
83 1/2" - 85 3/8"
10 1/4"
24 5/8"
"2/18-"8/56
4 1/8"
84"
1 1/8"
E
Notes
5 foot - 120 Volt - 15 Amp 3-wire molded plug power
supply connects lower left rear
Standard NEMA 5-15 Duplex Outlet - locate less than
9" above finished floor
1/4" flexible water line - tape to floor
E -
O -
W -
• All Installations must be done in accordance with local codes
• Sides of adjoining cabinets should be filled (flush to frame) to
insure proper fit and finish
Location Codes
UNIT ACCEPTS
TWO (2) CUSTOM
FRONT PANELS
"8/38-"2
O
W
• For Proud Installation - please adjust accordingly
* Depth assumes a 3/4” panel, please adjust according to
custom panel thickness

Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
KF 1913 Vi / KF 1903 Vi
Page 3 of 7
LOWER HINGE LOCATION
Upper Door
29 11/16"
29 1/8 - 29 1/2"
Hinge
Hinge
Lower Drawer
1/2" - 2 3/8"
FRONT VIEW

Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
KF 1913 Vi / KF 1903 Vi
Page 4 of 7
CUSTOM PANEL INSTALLATIONS
Panel "B" Height
Width: 35 3/4" in all cases
Thickness:Minumum 3/4" outside frame
Standard Upper Panel Height: 53 5/16"
Notes: Finish back side of panels to insure
appearance
Panel may extend above unit. This is not
considered in height calculation
Upper Maximum panel weight: 83.8 Pounds
Lower Panel Height: Use the following calculation:
Panel Height = HOM - 53 9/16 - TKH
HOM=Total height of machine. Can be adjusted to
match adjoining cabinets - typically 84"
HOM is adjustable between 83 1/2" - 85 3/8"
TKH=Toe-kick height (2" - 8 3/8")
Lower Maximum panel weight:31 Pounds
Upper Panel
TKH
HOM
Panel Height
These units do not come equipped with a front panel. They are designed to accept a custom door panel supplied by
the
cabinet maker. Miele has a unique panel integration system which allows the panels to align with the surrounding
cabinets
.
Panel
size is determined in the following manner:
Lower Panel
Upper Panel Note
s
If
the adjoining cabinets are taller than the height of machine (HOM) - the upper panel may be extended accordingly.
Find
the difference between height of the adjoining cabinets and the height of machine (HOM) and add to 53 5/16"
Adjoining cabinet
Machine
Extended Panel Example:
Ajoining cabinet height: 87"
Height of machine: 84"
Difference: 3"
Extended panel height:56 5/16"

Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
KF 1913 Vi / KF 1903 Vi
Page 5 of 7
HINGING DETAILS
0-1/8"
Front Panel
1"
1-1/4"
1-1/2"
0-3/4"
0-3/4"
1-1/4" 1-1/2"
1-3/4"
2"
1"
Cabinet Front
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
Front Panel
0-3/4" 1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
rooD°511rooD°09
snoitpossenkcihTsnoitpossenkcih
T
Door
Swing
NOTE: Additional space needed depending on
thickness of front panels and handle used
38 11/16"
7/16"
Door Swing
16 7/8"
MAX
NOTE: Additional space needed depending on
thickness of front panels and handle used

Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
KF 1913 Vi / KF 1903 Vi
Page 6 of 7
HINGING DETAILS
0-1/8"
Front Panel
1"
1-1/4"
1-1/2"
0-3/4"
0-3/4"
1-1/4" 1-1/2"
1-3/4"
2"
1"
Cabinet Front
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
Front Panel
0-3/4" 1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
rooD°511rooD°09
snoitpossenkcihTsnoitpossenkcihT
Door Swing
NOTE: Additional space needed depending on
thickness of front panels and handle used
38 11/16"
7/16"
Door Swing
16 7/8"
MAX
NOTE: Additional space needed depending on
thickness of front panels and handle used
3”(76.2mm)
13/4”(44.5mm)
13/8”(35mm)
11/6” (29.6mm)
1/4”(6.4mm)
17/24” (18mm)
21/24”(52mm)
21/3” (59mm)
25/8” (67mm)

Fully Integrated 36” Bottom Mount
KF 1913 Vi / KF 1903 Vi
KF 1913 Vi / KF 1903 Vi
Page 7 of 7
HINGING DETAILS FOR INSTALLATION
WITH APPLIANCE/OBJECT ON HINGE
SIDE
0-1/8"
Front Panel
1"
1-1/4"
1-1/2"
0-3/4"
0-3/4"
1-1/4" 1-1/2"
1-3/4"
2"
1"
Cabinet Front
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
Front Panel
0-3/4" 1-1/4"
1-1/2"
1-3/4"
1"
Cabinet Front
rooD°511rooD°09
snoitpossenkcihTsnoitpossenkcihT
Door Swing
NOTE: Additional space needed depending on
thickness of front panels and handle used
38 11/16"
7/16"
Door Swing
16 7/8"
MAX
NOTE: Additional space needed depending on
thickness of front panels and handle used
7/16”
(11 mm)
13/16”
(30mm)
17/16”
(36.5mm)
111/16”
(43mm)
115/16”
(49.2mm)
Handle or object that is
NOT flush with Cabinet
Front.
**When installing hing side next to an appliance or object that is within range of the door panel, limit the
door opening angle to 90O. This is done by installing the banking pin as illustrated. Insert the banking
pin through the holes and drive in with a hammer.
