en Operating Instructions Vacuum Cleaner
fr Instructions d'utilisation Aspirateur
es Manual de Uso y Manejo Aspiradora
SDAE0, SDBE0, SDCE0
M.-Nr. 10 090 380
HS14

2
Only Miele FilterBags, filters and accessories with
the "Original Miele" logo can be used with this
vacuum. Only then can the suction power of the
vacuum cleaner reach its optimum potential creating
the best possible cleaning results.
USE OF NON-MIELE COMPONENTS MAY VOID
THE WARRANTY.
,The use of FilterBags made of paper or a similar
material, or FilterBags with a cardboard retaining
plate can lead to serious damage to the vacuum
cleaner and may void the warranty, just as with the
use of FilterBags without the "Original Miele" logo.
The "Original Miele" Logo will appear on the
packaging or directly on the FilterBag.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters can be purchased
from an authorized Miele vacuum dealer or by visiting the
Miele store at www.mieleusa.com.

IMPORTANT SAFETY INSTRUCTIONS
Guide to the vacuum cleaner
Before using the vacuum cleaner
Using the included accessories
Operation
Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Turning the vacuum on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
While vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Rotary dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Adjusting the suction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the air inlet valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Parking, transport and storage
Maintenance and care
Purchasing new filter bags and filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Which filter bags and filters are the right ones? . . . . . . . . . . . . . . . . . . . . . . . . . . 14
When to change the filter bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Replacing the filter bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
When to change the dust compartment filter (motor protection). . . . . . . . . . . . . . 15
Replacing the dust compartment filter (motor protection). . . . . . . . . . . . . . . . . . . 15
Replacing the exhaust filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Replacing the "AirClean" filter ........................................16
Replacing the "Active AirClean 50" filter and the "HEPA AirClean 50" filter. . . . . . 16
Exchanging exhaust filters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
When to change the thread catcher pads of the standard floor brush . . . . . . . . 17
Replacing the thread catchers .......................................17
Cleaning and care
Frequently asked questions
After sales service
Optional accessories
Caring for the environment
LIMITED WARRANTY - VACUUM CLEANERS USA ..................21
3
en - Contents

When using an electrical appliance, basic precautions should always be followed,
including the following:
READ ALL INSTRUCTIONS BEFORE
USING THIS APPLIANCE
Keep these operating instructions in a safe place and pass them on to any
future user.
WARNING-
To reduce the risk of fire, electric
shock or injury:
Before using
~Check the voltage rating of the
vacuum cleaner before connecting the
power cord to an electrical outlet. Your
power source should correspond with
the voltage rating plate located on the
underside of the vacuum. Use only
household AC outlets. Never use DC
power sources. If you are not sure of
your home’s voltage supply, consult a
qualified electrician. Connecting the
vacuum cleaner to a higher voltage
than indicated in these instructions may
result in damage to the vacuum cleaner
or injury.
~To reduce the risk of electric shock,
this appliance has a polarized plug
(one blade is wider than the other.) This
plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does
not fit, contact a qualified electrician to
install the proper outlet. Do not alter the
plug in any way.
~A damaged vacuum cleaner can be
dangerous. Check the packaging,
vacuum cleaner and accessories for
any signs of damage. Do not use a
damaged appliance.
~Do not use with a damaged cord or
plug. If the appliance is not working as
it should, has been dropped, damaged,
left outdoors or submerged in water,
bring it to a service center.
~The electrical outlet must be fitted
with a 15 A fuse.
en - IMPORTANT SAFETY INSTRUCTIONS
4

Use
~Do not use on people or animals.
~Do not use outdoors or on wet
surfaces. Only dry surfaces should be
vacuumed.
~Use only as described in this
manual. Use only Miele recommended
accessories.
~Do not alter or modify the vacuum
cleaner.
~This appliance is intended for
household use only.
~Do not allow the vacuum cleaner to
be used as a toy. Close attention is
necessary when used near children.
~Never use the vacuum cleaner
without the filter bag or filters in place.
Otherwise it could be damaged.
~If a filter bag is not inserted, the dust
compartment lid will not close. Do not
force it shut.
~Do not leave the vacuum plugged
in. Unplug it from the outlet when not in
use and before servicing.
~On the underside of the vacuum
handpiece is a metal insert designed to
absorb static electricity. Please make
certain that your hand remains around
this metal insert when vacuuming.
~Persons which lack physical,
sensory or mental abilities or
experience with the machine should not
use it without supervision or instruction
by a responsible person.
~Unwind the cord completely to aid
the vacuum cleaner in dissipating heat.
~This vacuum should not be used to
entrap or retain any hazardous
materials.
~Do not use the vacuum cleaner to
pick up liquids or damp dirt. This could
impair the electrical safety of the
vacuum cleaner. Wait for freshly
shampooed carpets to dry.
~Do not vacuum anything that is
burning or smoking such as cigarettes,
matches or hot ashes. The vacuum
cleaner could catch fire.
~Do not vacuum toner dust. Toner,
such as that used in printers and
photocopiers can conduct electricity.
~Do not use to pick up any flammable
or combustible liquids, such as
gasoline, or use in areas where they
may be present. The vacuum cleaner
could explode.
~Do not vacuum up items which are
heavy, hard or have sharp edges. They
could cause a blockage and damage
the appliance.
~Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around sharp
edges or corners. Do not run the
appliance over the cord. Keep the cord
away from heated surfaces.
~Do not unplug by pulling on the
cord. To unplug, grasp the plug, not the
cord.
~Do not handle the plug or vacuum
with wet hands.
en - IMPORTANT SAFETY INSTRUCTIONS
5

~Keep the power cord, hair, loose
clothing, fingers and all parts of the
body away from openings and moving
parts.
~Do not place anything into the
openings of the vacuum cleaner. Do
not use if any openings are blocked;
keep them free of dust, lint, hair, or
anything that may reduce air flow.
~This appliance is equipped with a
power cord reel. Hold plug when
rewinding onto cord reel. Do not allow
plug to whip when rewinding.
~Turn off all controls before
unplugging.
~Use extra care when cleaning on
stairs.
~Floor attachments, accessories and
wands must not be used at head level
to avoid injury to eyes and ears.
~Monitor the filter bag change
indicator and inspect all filters regularly.
For best performance, the filter bag
and filters should be replaced when
necessary. A full bag or blocked filter
will reduce the vacuum cleaner’s
suction power. A temperature limiter
automatically switches the vacuum
cleaner off if it gets too hot, see
"Frequently asked questions".
Using accessories
~The hose and the telescopic wand
contain electrical wires. Do not use the
vacuum cleaner if these parts are
damaged, cut or punctured. Avoid
picking up sharp objects. Danger of
electric shock!
~Unplug the vacuum when changing
accessories, especially the Hose,
Telescopic wand, Turbobrush and
Powerbrush.
~To avoid the risk of injury when
vacuuming with a Miele Power or
Turbobrush do not touch the rotating
roller brush. Danger of injury.
~The socket on the vacuum cleaner
(depending on model) must only be
used for the Miele Powerbrush
specified for use with this appliance.
~Danger of injury. The Miele
Powerbrush is a motor driven
accessory for use only with Miele
vacuum cleaners. The vacuum cleaner
must not be used with another
manufacturer’s powerbrush.
~Do not use the vacuum cleaner
without an accessory attached. The rim
could be damaged and injuries could
result from sharp edges.
~Miele filter bags are disposable and
intended to be used only once. Do not
attempt to reuse. An over stuffed filter
bag will reduce the efficiency of the
vacuum cleaner.
~Only use genuine Miele filter bags
with the Miele quality signet and
original Miele filters and accessories.
Only then will the manufacturer
guarantee its safety.
en - IMPORTANT SAFETY INSTRUCTIONS
6

Cleaning, maintenance and
repairs
~Turn the vacuum cleaner off after
each use and before every cleaning /
maintenance. Pull the plug from the
outlet.
~Never submerge the vacuum
cleaner in water. Clean only with a dry
cloth or slightly damp cloth when
disconnected from the mains supply. If
moisture gets into the appliance there
is a risk of electric shock.
~The electro-suction hose and the
telescopic wand contain electrical
wires. The plug connectors must not
come in contact with water. These
items may only be cleaned with a dry
cloth, no moisture can touch them.
Danger of electric shock.
~Repairs must only be performed by
an authorized service agent in
accordance with national and local
safety regulations. Unauthorized repairs
could cause injury or machine damage.
~If the power cord is damaged it
should be replaced along with a new
cable reel by Miele Technical Service.
Disposing of an old appliance
~Before discarding an old vacuum
cleaner, please cut off the power cord
and render the plug useless. Ensure
the appliance presents no danger to
children while being stored for
disposal.
SAVE THESE
INSTRUCTIONS
en - IMPORTANT SAFETY INSTRUCTIONS
7

en - Guide to the vacuum cleaner
8

The illustrations show the vacuum cleaner and all available options.
aHand piece XXL *
bAir inlet valve *
cLock release button
dThree piece telescopic wand *
eTelescopic wand release button *
fDust compartment lid release
gFloor brush *
hCarrying handle
iSocket for Powerbrush *
jFilter bag
kDust compartment filter (pre-motor filter)
lExhaust filter *
mPower cord
nCord rewind switch
oSuction power selector
pPark-System
qOn/Off sfoot switch
rAirflow indicator
sHose connector *
tSuction hose *
uAccessory clip
The features marked *may vary or not be available on your model.
Some models are supplied with a Miele Powerbrush or Turbobrush as standard
(not illustrated). Separate operating and maintenance instructions are supplied
with these brushes.
en - Guide to the vacuum cleaner
9

The illustrations referred to in the text
are shown on the fold-out pages at the
end of these operating instructions.
Before using the vacuum
cleaner
Attaching the suction hose (see fig. 1)
^Insert the elbow into the suction
socket until it clicks. Use the inlet
guides to direct insertion.
Removing the suction hose (see fig. 2)
^Press the release buttons at the sides
of the elbow and lift the hose from the
socket.
Connecting the handle to the suction
hose (see fig. 3)
^Insert the suction hose into the
handle until it clicks into position.
Connecting the handpiece and
telescopic wand (see fig 4)
^Insert the handpiece into the
telescopic wand. Use inlet guides to
direct insertion.
^To release the handpiece from the
telescopic wand press the locking
button (see arrow) and pull the
handpiece away from the telescopic
wand with a slight twist.
Adjusting the telescopic wand
(see fig. 5)
The telescopic wand consists of two
sections which are height-adjustable.
^Press the adjustment button to
release the tubes and adjust to the
desired height.
Attaching the standard floor brush
(see fig 6)
(depending on model)
^Insert the wand into the floor brush
and twist until it locks with a click.
To release the floor brush from the
telescopic wand, press the locking
button (see arrow) and pull the wand
out of the floor brush.
Floor brush settings (see fig. 7,8+9)
Observe the cleaning instructions of
the floor manufacturer.
To clean carpets and area rugs:
^Press the foot switch %.
To clean hard flooring:
^Press the foot switch ).
Floors with very deep joints and
cracks should be vacuumed using
the floor brush with the bristles out.
AirTeQ Combination Floor Tool
(see fig. 9)
This floor tool has been specially
developed to achieve excellent
cleaning results using low energy. It
has particularly low power consumption
and high suction capability.
Warning: If the suction power of the
AirTeQ Combination Floor Tool
seems too high, reduce the suction
until the tool is easier to move
across the floor (see "Correct use -
adjusting the suction power").
en
10

Activating the exhaust filter change
indicator
Depending on the model, one of the
following standard exhaust filters is
installed (see fig. 10).
aAirClean Filter
bActive AirClean 50 Filter (black)
cHEPA AirClean 50 Filter (white)
If your vacuum cleaner is equipped
with a type bor cexhaust filter, you will
need to activate the exhaust filter
change indicator.
^Open the dust compartment lid and
raise until it clicks into place (see fig.
11).
^Remove the marker strip (see fig. 12).
^Press the exhaust filter change
indicator ~(see fig. 13).
^After about 10-15 seconds, a small
red marker will appear in the left-hand
side of the display (see fig. 14).
^Close the dust compartment lid until
it clicks into place. Take care not to
catch the Filter bag in the lid.
How the exhaust filter change
indicator works
The exhaust filter change indicator
displays the useful life of the exhaust
filter. The indicator will turn fully red
after approx. 50 hours of operation,
which is equivalent to one year of
average use (see fig. 15).
Using the included
accessories (see fig. 16)
The following accessories are included:
aDust brush with natural bristles
For cleaning moldings, decorative or
carved items, etc.
The head of the dusting brush can
be swivelled to attain the best
cleaning position.
For dusting particularly delicate
objects.
bUpholstery tool
For cleaning upholstery, mattresses,
cushions, curtains, covers, etc.
cCrevice nozzle
For cleaning in folds, crevices and
corners.
dAccessory clip for the included
accessories (see fig. 17)
Position the accessories as indicated
with the symbols on the accessory
holder.
^Insert the accessory holder either on
the hand piece at the handle or on
the hose connector of the vacuum
cleaner.
Standard floor brush (see fig. 18)
(depending on model)
^For safety, when vacuuming stairs it
is best to start at the bottom and
move upwards.
Some models are supplied with a Miele
Powerbrush or Turbobrush as standard.
Separate operating and maintenance
instructions are supplied with these
brushes.
en
11

Operation
Power cord
,Unwind the cord completely to
aid the vacuum in dissipating heat.
Do not pull or carry by the cord, use
the cord as a handle, close a door on
the cord, or pull the cord around
sharp edges or corners. Do not run
the appliance over the cord. Keep
the cord away from heated surfaces.
Do not unplug by pulling the cord.
To unplug grasp the plug, not the
cord.
This appliance is equipped with a
power cord reel. Hold the plug when
rewinding onto cord reel. Do not
allow plug to whip when rewinding.
Unwinding (see fig. 19)
^Hold the plug and pull out the power
cord.
,To reduce the risk of electric
shock, the vacuum has a polarized
plug (one blade is wider than the
other). This plug will fit in a polarized
outlet only one way. If the plug does
not fit fully in the outlet, contact a
qualified electrician. Do not alter the
plug in any way.
Danger of overheating and damage.
Rewinding (see fig. 20)
^Unplug the vacuum from the outlet.
^Press the rewind switch - the power
cord will rewind automatically. Hold
the plug so that it does not whip
around when rewinding.
Turning the vacuum on and off
(see fig. 21)
^Press the On/Off sbutton.
While vacuuming (see fig. 22 + 23)
^The vacuum cleaner can also stand
on its end for vacuuming stairs,
drapes etc.
,To prevent static electricity your
hand must touch the metal inlay on
the underside of the vacuum hand
piece. Be certain to continuously
touch this inlay when vacuuming
fine dust, flour or sawdust as these
materials are more likely to create a
static discharge. To further prevent
static discharge, pull the vacuum
along by the hose with one hand
while continuing to hold the hand
piece in the other hand.
Rotary dial (see fig. 24)
^Turn the rotary dial to the desired
suction power setting.
Adjusting the suction
You can adjust the suction power to suit
the type of flooring. By reducing the
suction power the floor brush can be
pushed easier.
en
12

The symbols on the controls indicate the
type of use the settings are suitable for:
#curtains, lightweight fabrics
$upholstery, cushions
%thick pile carpets, rugs and
runners
*energy saving, daily vacuuming
with low noise level
(low pile carpets
)hard flooring and intensive
cleaning of carpets
When using the AirTeQ Combination
Floor Tool, if the suction seems too
high, reduce the suction until the
tool is easier to move across the
floor.
Opening the air inlet valve (see fig. 25)
(depending on model)
The air inlet valve can be opened to
quickly reduce the suction power of the
tool being used, e.g. when moving from
a carpet to an area rug.
^Open the air inlet valve far enough to
reduce the suction power.
Opening the air inlet valve reduces the
power to the tool being used.
Parking, transport and storage
Park-System (see fig. 26)
The Park system allows you to
conveniently park the wand and floor
brush on the vacuum cleaner during
brief pauses.
^Insert the lower clip on the floor brush
into the slot on the end of the vacuum
cleaner from above.
When vacuuming on a sloping
surface, e.g. on a ramp, push all
telescopic tubing parts completely
together.
Park-System for storage (see fig. 27)
(depending on model)
,Turn the vacuum cleaner off
after use. Unplug the power plug
from the electrical outlet.
^Stand the vacuum cleaner upright.
It is helpful to completely insert the
tubes into the telescopic wand.
^Insert the suction unit with the
parking slot from above into either
side of the Park-System.
This makes the vacuum cleaner easier
to carry and store.
Maintenance and care
,Turn off and unplug the vacuum
cleaner before performing any
maintenance work.
The Miele filter system consists of the
following three components.
–Filter bag
–Exhaust filter
–Dust compartment filter
Each of these components must be
changed periodically to maintain the
vacuum cleaner’s efficiency.
13
en

Only use Miele filter bags, filters and
accessories with the "Original Miele"
logo. Only then can the suction
power of the vacuum cleaner reach
its optimum potential creating the
best possible cleaning results.
,The use of filter bags made of
paper or a similar material, or filter
bags with a cardboard retaining
plate can lead to serious damage to
the vacuum cleaner and possibly
voiding the warranty, just as with the
use of filter bags without the
"Original Miele" logo.
Purchasing new filter bags and filters
Original Miele filter bags and filters can
be purchased from an authorized Miele
vacuum dealer or by visiting the Miele
store at www.mieleusa.com.
Which filter bags and filters are the
right ones?
This vacuum cleaner uses Original
Miele filter bags Type F/J/M and
Original Miele filters. The "Original
Miele" Logo will appear on the
packaging or directly on the filter bag.
An "AirClean" exhaust filter and a dust
compartment filter are supplied with
every box of Miele filter bags.
If you would like to purchase additional
Miele filters separately, contact your
vacuum dealer or Miele, please quote
the model number of your Miele
vacuum cleaner to ensure correct parts
are ordered. These parts are also
available to order from the online Miele
store.
The exhaust filter supplied with the
vacuum cleaner can be exchanged
with another type of Original Miele filter
(see "Exchanging exhaust filters").
When to change the filter bag
(see fig. 28)
Change the filter bag when the colored
marker in the airflow indicator fills the
display.
Miele filter bags are disposable and
made to be used only once. Do not
attempt to reuse.
Checking the airflow indicator
^Attach the standard floor brush
(depending on model) to the vacuum
cleaner. Perform this test with the
standard floor brush only, since other
attachments can affect the function of
the airflow indicator.
^Turn the vacuum cleaner on and
select the highest power setting.
^Lift the floor brush slightly off the
floor. If the marker completely fills the
indicator window, the filter bag needs
to be changed.
en
14

How the airflow indicator works
The airflow indicator is designed to
show when the bag is full of common
household dust and measures the
amount of air flow through the filter bag.
Normal household dust is a mixture of
dust, hair, carpet fluff, threads, sand,
etc.
However, if fine dust, such as drill dust,
sand, plaster or flour is vacuumed, the
pores of the filter bag may become
blocked. The marker will indicate that
the bag is "full" even when it is not. The
filter bag should be changed as the
suction power is greatly reduced.
If the bag is bulging with pet fur, hair,
carpet fluff, etc. the indicator may not
register "full". This is because the air
flow of the filter bag may still be high
enough not to activate the marker to
show maximum. The filter bag should
still be changed.
Replacing the filter bag (see fig. 29 +
30)
^Open the dust compartment lid and
raise until it clicks into place
(see fig. 11).
The filter bag has a closing flap which
closes automatically when the dust
compartment lid is raised to prevent
any dust from escaping.
^Grasp the finger grip and pull the
filter bag out of the holder.
^Insert the new filter bag as far as it
will go into the filter bag holder. Do
not unfold the filter bag when taking it
out of the box.
^Unfold the filter bag in the dust
compartment.
^Close the dust compartment lid until
it clicks into place. Take care not to
catch the filter bag in the lid.
,A empty-operation-barrier will
block the dust compartment lid from
closing if no filter bag is inserted.
Do Not Use Force!
When to change the dust
compartment filter (motor protection)
Replace the dust compartment filter
every time you start a new box of filter
bags. A dust compartment filter is
supplied with each box of Miele filter
bags.
Replacing the dust compartment
filter (motor protection) (see fig. 31)
^Open the dust compartment lid.
^Remove the filter bag.
^Open the filter frame, remove the old
filter and replace with a new one.
^Close the filter frame.
^Replace the filter bag.
^Close the dust compartment lid firmly
until it clicks into place, making sure
the filter bag does not get caught.
en
15

Replacing the exhaust filter
Depending on model, the vacuum
cleaner will be equipped with one of the
following exhaust filters (see fig. 10):
aAirClean Filter
An "AirClean" filter is supplied with
every box of Miele filter bags. It should
be replaced each time a new box of
bags is started.
bActive AirClean 50 Filter (black)
cHEPA AirClean 50 Filter (white)
If the display of the exhaust filter
change indicator has turned fully red
(see fig. 15).
The indicator light will come on after
approx. 50 hours of operation, which is
equivalent to one year of average use.
The vacuum cleaner can still be used
however, the filter performance and
suction power will be reduced.
Replacing the "AirClean" filter (see
fig. 32 + 33)
Do not use more than one filter at a
time.
^Open the dust compartment lid.
^Squeeze the release for the filter
frame and open until it clicks.
^Grasp one of the two clean corners
(see arrow) to remove the used
AirClean exhaust filter.
^Insert the new filter.
If you wish to replace the AirClean
filter with an Active AirClean 50 filter
or HEPA AirClean 50 filter see
"Maintenance and care -
Exchanging exhaust filters".
^Close the dust compartment lid firmly
until it clicks into place.
Replacing the "Active AirClean 50"
filter and the "HEPA AirClean 50"
filter (see fig. 34 + 35)
Do not use more than one filter at a
time.
^Open the dust compartment lid.
^Remove the exhaust filter.
^Insert the new filter.
^Press the exhaust filter change
indicator ~(see fig. 13).
^After about 10-15 seconds, a small
red marker will appear in the left-hand
side of the display (see fig. 14).
If you wish to replace the Active
AirClean 50 filter or the HEPA
AirClean 50 filter with an AirClean
filter see "Maintenance and care -
Exchanging exhaust filters".
^Close the dust compartment lid firmly
until it clicks into place.
en
16

Exchanging exhaust filters
1. If you wish to replace the aAirClean
filter with the bActive AirClean 50 filter
or the cHEPA AirClean 50 filter, you
must remove the filter frame before
inserting the new filter (see fig. 35).
The exhaust filter change indicator
must also be activated (see fig. 13).
2. If you use an AirClean filter ayou
must insert it into a filter frame (see fig.
33), see "Optional accessories".
Do not use more than one filter at a
time.
The Active AirClean 50 filter can be
used instead of the HEPA AirClean 50
filter and vice versa without any
changes.
When to change the thread catcher
pads of the standard floor brush
(depending on model)
The thread catcher pads on the bottom
of the standard floor brush (depending
on model) should be checked
occasionally. Replace the pads if they
appear worn.
Replacing the thread catchers (see
fig. 36 + 37)
^Use a screwdriver or similar object to
remove the thread catchers from the
slots.
^Insert the new thread catchers.
New thread catcher pads can be
purchased from any authorized Miele
vacuum dealer or Miele.
Cleaning the floor roller of the floor
brush AllTeQ (see fig. 38)
aUnlock the roller pin with a coin.
bPush the pin out and remove it.
cRemove the roller.
^Remove any threads and hair from
the roller.
^Replace roller in the reverse order.
Cleaning and care
,Turn off the vacuum and unplug
it from the outlet before performing
any maintenance work.
Vacuum cleaner and accessories
The vacuum cleaner and other plastic
accessories can be cleaned with a
damp cloth or a cleaner suitable for
plastics.
,Do not use abrasive, glass or all
purpose cleaners, or oil-based
conditioning agents! They will
damage the surface.
Dust compartment
The dust compartment can, if
necessary, be cleaned using a dry
cloth, dusting brush or a second
vacuum to remove any dust.
Monitor the airflow indicator and
inspect all filters regularly. Clean or
replace them when necessary
according to these Operating
Instructions.
en
17

,Do not submerge the vacuum in
water. If moisture gets into the
appliance there is the risk of an
electric shock.
Frequently asked questions
,Turn off and unplug the vacuum
cleaner before performing any
maintenance work.
What if the vacuum turns off
automatically?
The vacuum has overheated. The
temperature limiter automatically turns
the vacuum off.
This can occur if, for instance, large
articles block the suction tube or when
the filter bag is full or contains particles
of fine dust. A heavily soiled exhaust or
dust compartment filter can also be the
cause of overheating. Turn the vacuum
off sand pull the plug from the outlet.
Check for any blockages and allow the
vacuum to cool for 30 minutes.
After sales service
In the event of a fault which you cannot
fix yourself please contact the Miele
Service Department at the phone
number listed on the back of this
booklet.
^Please quote the model type of your
appliance.
This can be found on the data plate on
the bottom of the vacuum.
Optional accessories
Observe the cleaning instructions of
the floor manufacturer.
Many of these accessories as well as
other products can be purchased from
the Miele Store at www.Mieleusa.com.
Some models come standard with one
or more of the following accessories.
Powerbrushes
To connect a Powerbrush you also
need :
– Electro telescopic wand SET 220
– Electro suction hose SES 117.
Powerbrush SEB 217-3 (EB02)
The Powerbrush is particularly suitable
for cleaning and restoring crushed
carpet pile of wall to wall carpeting and
floor coverings subject to hard wear,
especially in high traffic areas.
Powerbrush SEB 228 (EB03)
This Powerbrush is similar to the
SEB 217-3 with the addition of a height
adjustable brush, allowing it to also be
used on smooth floor surfaces.
Powerbrush SEB 236 (EB01)
This Powerbrush is similar to the
SEB 228 except it also includes a
headlight and multifunction indicator.
en
18

Turbo / Floor brushes
Turbobrush Turbo Comfort - 3
Intended for cleaning short to medium
pile carpeting.
Hand Turbobrush Turbo Mini
Intended for vacuuming upholstery,
mattresses, car seats, carpeted stairs
and other areas inaccessible with the
standard Turbobrush.
Floor brush Hard floor - 3
To vacuum sturdy hard floors, e.g. tiles
and stone floors.
Floor brush Parquet - 3
Special brush with natural bristles
intended for cleaning parquet and
laminate floors, especially those
susceptible to scratching.
Floor brush Parquet Twister with
swiveling head
For cleaning all hard flooring, e.g.
parquet and tiles. Especially suitable
for vacuuming niches and tight spaces.
Floor brush Parquet Twister XL with
swiveling head
For cleaning large areas of hard
flooring, e.g. parquet and tiles.
Other accessories
MicroSet
For cleaning small objects and difficult
to reach areas (such as PC keyboards,
stereo equipment, carved furniture and
ornaments, models, etc).
CarCare accessory case
For cleaning car interiors.
Cat&Dog accessory case
For cleaning the homes of pet owners.
HomeCare accessory case
For cleaning your home.
Universal brush
For dusting bookshelves, mantles,
molding, ceiling fans, sculptures, etc.
Dust brush with natural bristles
For dusting particularly delicate objects.
Radiator brush
For cleaning radiators, vents, refrigerator
coils, air conditioners, decorative vases,
etc.
Mattress tool
For cleaning deep crevices, mattresses
and upholstery.
Crevice nozzle 12" (300 mm)
For cleaning in folds, crevices, corners,
etc.
en
19

Crevice nozzle 22" (560 mm)
For cleaning hard to reach areas.
Upholstery tool 7 ½" (190 mm)
For cleaning upholstered furniture,
mattresses and pillows.
Comfort handle with light (SGC 20)
To illuminate the work area.
Filters
Active AirClean 50 filter SF-AA 50
This charcoal filter absorbs odors from
the dust collected in the filter bag.
HEPA AirClean 50 filter SF-HA 50
This filter are particularly suitable for
allergy sufferers and those concerned
with a high level of hygiene.
Filter frame
The filter frame is needed if you would
like to exchange an AirClean filter with
an Active AirClean 50 or HEPA AirClean
50 filter.
Caring for the environment
Disposal of the packing material
The cardboard box and packaging
protect the vacuum cleaner during
shipping. These materials are
recyclable. Please recycle.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of an old machine
Old vacuum cleaners may contain
materials that can be recycled.
Please contact your local recycling aut-
hority about the possibility of
recycling these materials.
en
20
