Miele DA 2900 EXT User manual

Operating and installation instructions
Cooker hood
DA 2900
DA 2900 EXT
To avoid the risk of accidents
or damage to this appliance,
it is essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 09 725 030
en-GB

Caring for the environment..........................................3
Warning and Safety instructions .....................................4
Guide to the appliance ............................................10
Description of the functions ........................................12
Miele|home .....................................................13
Con|ctivity ......................................................13
Operation .......................................................14
Remote control....................................................14
To switch the fan on K.............................................14
To select a power level -/+.........................................14
Intensive setting ................................................14
Run-on option 5 ¢15...............................................15
Hob lighting I....................................................15
Power management................................................16
Filter operating hours counter [....................................17
Cleaning and care ................................................19
Housing .........................................................19
Panels and grease filters ............................................20
Resetting the grease filter operating hours counter ....................23
Fitting and replacing the charcoal filters ................................24
Resetting the charcoal filter operating hours counter ...................24
Remote control....................................................25
Installation ......................................................26
Appliance dimensions ..............................................26
Safety distance between hob and cooker hood (S) .....................28
Installation instructions .............................................29
Connection for air extraction .......................................30
Condensate trap ..................................................31
Silencer .........................................................32
Electrical connection .............................................33
Operation with Control module DSM 400 .............................34
Potential free connection .........................................34
Connection to a push button switch .................................34
After Sales Service ...............................................35
Technical data ...................................................36
Declaration of Conformity .........................................36
Contents
2

Disposal of the packing material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for
disposal, and should be recycled.
Recycling packaging reduces the use
of raw materials in the manufacturing
process and also reduces the amount
of waste in landfill sites.
Packaging e.g. cling film, polystyrene
and plastic wrappings must be kept out
of the reach of babies and young
children. Danger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain materials which, if handled
or disposed of incorrectly, could be
potentially hazardous to human health
and to the environment. They are,
however, essential for the correct
functioning of your appliance. Please
do not therefore dispose of it with your
household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Caring for the environment
3

This appliance complies with all
relevant safety requirements.
Improper use can, however, present
a risk of both personal injury and
damage to property.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time.
They contain important information
on its safety, installation, use and
maintenance.
Keep these instructions in a safe
place and ensure that all users are
familiar with the contents. Pass them
on to any future owner of the
appliance.
Correct application
~This appliance is intended for use in
domestic households and in similar
working and residential environments
such as:
–Shops
–Offices and showrooms
and by residents in establishments
such as:
–Hostels and guest houses.
~It must only be used as a domestic
appliance to extract vapours and
remove odours from cooking.
Any other usage is not supported by
the manufacturer and could be
dangerous. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation.
~The cooker hood is not intended for
outdoor use.
~This appliance can only be used by
people with reduced physical, sensory
or mental capabilities, or lack of
experience or knowledge, if they are
supervised whilst using it or have been
shown how to use it in a safe way and
understand the hazards involved.
Safety with children
~The appliance is not a toy! To avoid
the risk of injury, do not allow children
to play with the appliance or the remote
control.
~Children under 8 years of age must
be kept away from the cooker hood
unless they are constantly supervised.
~Children 8 years and older may use
the cooker hood only if they have been
shown how to use it in a safe way and
understand the hazards involved.
~Keep the battery in the remote
control out of the reach of children.
Warning and Safety instructions
4

Technical safety
~Before installation, check the cooker
hood for visible signs of damage. Do
not install and use a damaged
appliance. It could be dangerous.
~Before connecting the appliance to
the mains supply, make sure that the
voltage and frequency details given on
the data plate correspond with the
household electricity supply, otherwise
the appliance could be damaged.
Consult a qualified electrician if in any
doubt.
~The electrical safety of this
appliance can only be guaranteed if it
is correctly earthed. It is most important
that this basic safety requirement is
observed and tested regularly, and
where there is any doubt, the
household wiring system should be
inspected by a qualified electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
~For safety reasons, this appliance
may only be used when it has been
fully installed.
~Only open the housing as described
in the instructions given in the
installation sheet and in the Cleaning
and care section of this booklet. Under
no circumstances should any other
parts of the housing be opened.
Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user, and can
cause operational faults.
~Installation, maintenance and
repairs may only be carried out by a
Miele authorised person in strict
accordance with current national and
local safety regulations.
Repairs and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable for
unauthorised work.
~Faulty components must only be
replaced by genuine Miele original
parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
Warning and Safety instructions
5

~During installation, maintenance and
repair work, the appliance must be
disconnected from the mains electricity
supply.
~Do not connect the appliance to the
mains electricity supply by a
multi-socket adapter or an extension
lead. These do not guarantee the
required safety of the appliance (e.g.
danger of overheating).
~For appliances with an external fan
motor (...EXT models) the connection of
the two units must be made using the
connection cable and the plug
connectors.
These models may only be combined
with a Miele external motor.
~The appliance must not be used in a
non-stationary location (e.g. on a ship).
~In areas which may be subject to
infestation by cockroaches or other
vermin, pay particular attention to
keeping the appliance and its
surroundings in a clean condition at all
times. Any damage which may be
caused by cockroaches or other vermin
will not be covered by the guarantee.
Using at the same time as other
heating appliances that depend on
the air from the room
Warning - danger of toxic fumes
~Great care should be taken when
using the cooker hood at the same time
and in the same room or area of the
house as another heating appliance
which depends on the air in the room.
Such appliances include gas, oil, wood
or coal-fired boilers and heaters,
continuous flow or other water heaters,
gas hobs, cookers or ovens which draw
air in from the room and duct exhaust
gases out through a chimney or
extraction ducting.
When used in extraction mode, with or
without an external motor fitted, the
appliance draws air in from the room in
which it is installed and from
neighbouring rooms.
If there is insufficient air, an
underpressure will occur. The heating
appliance may be starved of oxygen,
impairing combustion.
Harmful gases could be drawn out of
the chimney or extraction ducting back
into the room, with potentially fatal
consequences.
Warning and Safety instructions
6

This also applies to recirculation mode
if the air is being directed out of the
kitchen.
In order to ensure safe operation, and
to prevent gases given off by the
heating appliances from being drawn
back into the room when the cooker
hood and the heater are in operation
simultaneously, an underpressure of
0.04 mbar (4 pa) is the maximum
permissible in the room.
Ventilation can be maintained by air
inlets which must not be blocked, in
windows, doors and outside wall vents,
or by other technical measures, such
as ensuring that the cooker hood can
only be switched on when the heating
appliance is switched off or vice versa.
A ventilation brick alone is not generally
sufficient to ensure safe ventilation.
,The overall ventilation condition
of the dwelling must be taken into
account. If in any doubt, the advice
of a competent builder or, for gas, a
qualified gas fitter (GasSafe
registered in the UK) must be
sought.
If the hood is being operated in
recirculation mode and the air is being
directed back into the kitchen, the
above restrictions do not apply.
Warning and Safety instructions
7

Correct use
~Do not use an open flame beneath
the cooker hood. To avoid the danger
of fire, do not flambé or grill over an
open flame.
When switched on, the cooker hood
could draw flames into the filter. Fat
particles drawn into the cooker hood
present a fire hazard.
~When using the cooker hood over a
gas hob, ensure that any burners in use
are always covered by a pan. Switch
the cooking zone off when a pan is
removed, even for a short time.
Regulate the flame so that it does not
burn up the sides of the pan.
Do not allow the pans to overheat
excessively (e.g. when using a wok).
The cooker hood can become
damaged when exposed to excessive
heat.
~Always switch the cooker hood on
when using the hob, otherwise
condensation may collect in the hood,
which could cause corrosion.
~When cooking with oil or fat, chip
pans and deep fat fryers etc, do not
leave the pans unattended. Never leave
an open grill unattended when grilling.
Overheated oil and fat can ignite and
could set the cooker hood on fire.
~Do not use the cooker hood without
the filters in place. This way you will
avoid the risk of grease and dirt getting
into the appliance and hindering its
smooth operation.
~The filters should be regularly
cleaned or changed as appropriate.
Saturated filters are a fire hazard. See
"Cleaning and care".
~The cooker hood can get very hot
during cooking due to heat rising from
the hob.
Do not touch the housing or the grease
filters until the cooker hood has cooled
down.
~Do not use a steam-cleaner to clean
this appliance. Steam could reach
electrical components and cause a
short circuit.
~Important information on the
handling of the battery in the remote
control:
– Do not short circuit or recharge the
battery, or throw it into a fire. Danger
of explosion.
–Dispose of the used battery in your
recycling bin. Do not dispose of it
with the normal household waste.
Warning and Safety instructions
8

Correct installation
~Refer to the cooker or hob
manufacturer's instructions as to
whether a cooker hood may be
operated above the cooker/hob.
~The minimum safety distances
between the top of the cooker or hob
and the bottom of the cooker hood
given in the "Appliance dimensions"
section of this booklet must be
maintained, unless the hob
manufacturer states that a greater
safety distance is required.
If more than one cooking appliance is
fitted beneath the cooker hood, and
they have different minimum safety
distances to the cooker hood, select
the greater distance.
~Safety regulations prohibit the fitting
of a cooker hood over solid fuel stoves.
~All ducting, pipework and fittings
must be of non-flammable material.
These can be obtained from the Miele
Spare Parts department or from
builders' merchants.
~The appliance must not be
connected to a chimney or vent flue
which is in use. Neither should it be
connected to ducting which ventilates
rooms with fireplaces.
~If exhaust air is to be extracted into
a chimney or ventilation duct no longer
used for other purposes, seek
professional advice.
Accessories
~Only use genuine Miele original
spare parts and accessories with this
appliance. If spare parts or accessories
from other manufacturers are used, this
will invalidate the guarantee, and Miele
cannot accept liability.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
9

Guide to the appliance
10

aEdge extraction panels
DRP 2900 Glass (4 panels) or
DRP 2900 Stainless steel (4 panels)
bHob lighting
cControls
dGrease filter
eIndicator light
The indicator light will light up briefly
when a function is selected using the
remote control.
fHob lighting button
gButtons for selecting
the fan power level
On the remote control, these buttons
can also be used to switch the fan on
and off.
hButton for the run-on option
The fan can be set to switch off
automatically after either 5 or
15 minutes.
iThese buttons have no allocated
function for this cooker hood
jOn/Off button for the fan
kOperating hours button
The grease filter symbol lfor the
operating hours button lights up when
the grease filters need to be cleaned.
The charcoal filter symbol lights up
when the charcoal filters used in
recirculation mode need to be
replaced. For this to happen, the
operating hours counter needs to be
activated before the appliance is used
for the first time (only applies if the
cooker hood has been fitted with
DUU 2900 conversion kit for
recirculation).
This button is used to reset the
appropriate operating hours counter
each time the grease filters are cleaned
or the charcoal filters have been
replaced (see "Cleaning and care").
It can also be used to check and alter
the operating hours counter.
For information about using the
appliance, see "Operation".
Guide to the appliance
11

The cooker hood works with
. . . air extraction:
The cooker hood draws in the cooking
vapours. First, the air is drawn in via the
edge extraction panels. It is then
guided through and cleaned by the
grease filters before being directed
outside.
The cooker hood operates with a
non-return flap.
This flap is closed when the cooker
hood is switched off, so that no
exchange of room air and outside air
can take place.
When the cooker hood is switched on,
the non-return flap opens for the
cooking vapours to be blown directly
outside.
. . . air recirculation:
(DUU 2900 conversion kit for
recirculation required)
The air is drawn in through the edge
extraction panels and then cleaned by
the grease filters. It is then directed into
the recirculation unit where it is also
cleaned by the charcoal filters. The
cleaned air is then recirculated back
into the kitchen.
Before using the cooker hood in
recirculation mode, ensure that the
charcoal filters are in place. See
Cleaning and care.
...anexternal motor:
(EXT models only)
EXT models are designed to be
connected to an external motor located
outside the room.
The external motor is connected to the
cooker hood by means of a control
cable, and is operated by the controls
on the cooker hood.
Description of the functions
12

Con|ctivity
This cooker hood is communication
enabled.
Communication module XKM 2000 DA
a, available as an optional extra,
enables the operation of the cooker
hood to be automatically controlled by
the operating status of a Miele electric
hob with onset controls.
For communication to take place, the
hob must be fitted with the appropriate
communication module b.
The hob transmits information about its
operating status to the cooker hood via
the household power supply
(Powerline) c.
–When the hob is switched on the
cooker hood hob lighting also comes
on and then after a short time the fan
switches on.
–During cooking the cooker hood
automatically sets its power level
according to the number of cooking
zones in operation and their power
levels.
–After switching the hob off the fan
and the hob lighting will switch off
automatically after a period of time.
For detailed information about this
function please read the separate
instruction booklet supplied with the
XKM 2000 DA communication module.
The communication module is fitted to
the cooker hood in the area of the
motor and is connected to the controls
of the cooker hood.
This module must be installed by a
Miele service technician or suitably
qualified electrician.
Miele|home
13

Remote control
The main functions can be selected via
the cooker hood or by remote control.
The indicator light on the remote control
unit will light up briefly when a function
is selected by remote control.
The maximum operating range of the
remote control is approx. 10 m.
However, this may be less depending
on the physical conditions present in
the room (e.g. furniture, walls).
The back of the remote control unit is
magnetic which allows it to be attached
to various metal surfaces.
Interaction with other remote control
systems
In instances where the remote control is
affected by the remote control of a
similar type of cooker hood in the im-
mediate vicinity, the remote control
coding can be altered.
Please contact the Miele Service
Department (see "After Sales Service").
To switch the fan on K
^Press the +button on the remote
control.
or
^Press the On/Off button Kon the
cooker hood.
The fan will switch on at power level 2.
The Ksymbol and 2will light up on the
control panel of the cooker hood.
To select a power level -/+
The power level for the fan can be
selected either on the cooker hood or
by using the remote control.
^Press the –symbol to select a lower
power level or the +symbol to select
a higher power level.
Depending on the intensity of the
cooking vapours, levels 1to 3are
usually sufficient for normal cooking.
Intensive setting
For short periods of cooking food with
intensive vapours and a strong aroma,
e.g. when searing meat, you may wish
to select level IS, the Intensive setting.
Operation
14

Run-on option 5 ¢15
It is advisable to run the fan for a few
minutes after cooking has finished to
neutralise any lingering odours in the
air, whether you are using air extraction
or recirculation mode.
The fan can be set to switch off
automatically after 5 or 15 minutes.
The Run-on option can be selected
either on the cooker hood or by using
the remote control.
^After cooking has finished, press the
Run-on button 5¢15 whilst the fan is
still running
– Press once = The fan will switch off
after 5 minutes (5¢will light up).
– Press twice = The fan will switch off
after 15 minutes (¢15 will light up).
If you press the Run-on button 5¢15
again, the fan remains on (5¢15 will go
out).
To switch the fan off K
^Reduce the power level by pressing
the –button on the remote control
until the fan switches off,
or
^Press the On/Off button Kon the
cooker hood to switch the fan off.
The Ksymbol will go out.
Hob lighting I
The hob lighting can be switched on
and off independently of the fan.
^Press the lighting button Ion the
remote control or on the cooker hood.
The Isymbol lights up when the
lighting is switched on.
Operation
15

Power management
The cooker hood features a power
management system for switching off
the lighting and reducing the fan power
level automatically.
–The lighting will switch off
automatically after 12 hours.
–If the Intensive setting is selected,
the fan will automatically revert to
level 3 after 10 minutes, to level 2
after 2 hours and then after a further
30 minutes to level 1. Finally, after a
further 30 minutes the fan will switch
off.
– If power level 2 or 3 is selected, the
fan will revert to a lower setting after
2 hours and then in 30-minute stages
until it switches off.
– If level 1 is selected, the fan will
switch off after 2 hours.
Power management can be
deactivated. This can only be done via
the control panel on the cooker hood. It
cannot be deactivated using the remote
control.
^Press the Run-on option button
5¢15 for approx. 10 seconds until 1
lights up in the power level display.
^Then press in turn –
–the lighting button I,
–the –button, and
–the lighting button Iagain.
If Power management is activated,
1and IS will light up constantly.
^Press the –button to deactivate
Power management.
1and IS will flash.
Press +if you want to activate it
again.
^Confirm your selection by pressing
the Run-on option button 5¢15.
If you do not confirm within 4 minutes,
the cooker hood will automatically
revert to the original setting.
Operation
16

Filter operating hours
counter [
The number of hours the cooker hood
has been in operation is stored in
memory.
The Grease filter symbol [or the
Charcoal filter symbol will light up to
tell you that the filters need to cleaned
or changed.
See "Cleaning and care" for further
information about cleaning and
changing the filters and resetting the
operating hours counters.
Altering the grease filter operating
hours counter [
You can set the operating hours
counter for the grease filter to suit the
type of cooking you do.
– Select a short time if you roast or fry
a lot.
– If you use very little fat for cooking,
select a longer time.
–If you only cook occasionally, we still
recommend selecting a short time
because grease which has built up
gradually over a long period of time
will harden on the filter and make
cleaning more difficult.
The grease filter operating hours
counter is set at the factory for
30 hours. This can be lengthened or
shortened. You can choose 20, 30, 40
or 50 hours.
^Switch the fan off by pressing the
On/Off button K.
^Press the Run-on option button
5¢15 and the operating hours
button [on the control panel on
the cooker hood at the same time.
The Grease filter symbol [of the
operating hours button and one of the
fan power levels will flash.
Fan power level indicator lights 1to IS
show the time set:
1........................20hours
2........................30hours
3........................40hours
IS .......................50hours
^Press the –symbol to select a shorter
operating time or the +symbol to
select a longer operating time.
^Confirm your selection by pressing
the operating hours button [.
All the indicator lights will go out.
If you do not confirm within 4 minutes,
the cooker hood will automatically
revert to the original setting.
Operation
17

Activating and altering the charcoal
filter operating hours counter 
(recirculation mode with conversion kit
fitted)
The charcoal filter is needed for
recirculation mode.
On delivery, the operating hours counter
for the charcoal filter is deactivated.
For recirculation mode, the operating
hours counter needs to be set to suit
the type of cooking you do.
^Switch the fan off by pressing the
On/Off button K.
^Press the +symbol and the
operating hours button [on the
control panel on the cooker hood at
the same time.
The Charcoal filter symbol of the
operating hours button and one of the
fan power levels will flash.
Fan power level indicator lights 1to IS
show the time set:
1.......................120hours
2.......................180hours
3.......................240hours
IS ....................Deactivated
^Press the –symbol to select a shorter
operating time or the +symbol to
select a longer operating time.
^Confirm your selection by pressing
the operating hours button [.
All the indicator lights will go out.
If you do not confirm within 4 minutes,
the cooker hood will automatically
revert to the original setting.
Checking the filter operating hours
counter
To check the percentage of time set
already used:
^Switch the fan on with the On/Off
button K.
^Press and hold the operating hours
button [on the cooker hood
control panel:
–Once, to read the grease filter
operating hours. The Grease filter
symbol [will light up.
– Twice, to read the charcoal filter
operating hours. The Charcoal filter
symbol will light up.
One or more of the power level
indicators will flash at the same time.
The number of flashing indicator lights
shows the percentage of the operating
time which has already been used up:
1...........................25%
1and 2.....................50%
1to 3.......................75%
1to IS .....................100%
The number of operating hours used
remains in the memory, even when the
cooker hood is switched off or there is a
power cut.
Operation
18

,Before any cleaning or
maintenance work is carried out,
disconnect the cooker hood from
the mains supply.
Housing
General
The surfaces and controls are
susceptible to scratches and
abrasion. Please observe the
following cleaning instructions.
^All external surfaces and controls can
be cleaned using a Miele E-Cloth or
with warm water and a little
washing-up liquid applied with a well
wrung-out soft sponge or cloth.
Do not use too much water when
cleaning the controls. Water could
penetrate into the electronics and
cause damage.
^Wipe the surfaces dry using a soft
cloth.
Avoid:
–cleaning agents containing soda,
acids, chlorides or solvents,
–abrasive cleaning agents, e.g.
powder cleaners or cream cleaners,
and abrasive sponges, as well as pot
scourers or sponges which have
been previously used with abrasive
cleaning agents. These will damage
the surface material.
– sharp metal scrapers,
– oven sprays.
Important for appliances with
stainless steel housing
(This infomation does not apply to the
controls).
Stainless steel surfaces can be cleaned
using Miele's non-abrasive cleaning
agent for stainless steel, following the
instructions on the packaging.
To help prevent re-soiling, Miele
conditioning agent for stainless steel
can also be used. Follow the
instructions on the packaging.
Cleaning and care
19

Important for appliances with glass
surfaces
Glass surfaces can be cleaned using a
proprietary non-abrasive cleaning
agent designed specifically for use on
glass.
Important for appliances with
lacquered housing
(Special order finish)
It is very difficult to clean this type of
surface without causing minor marks to
the surface material. This can become
particularly noticeable with darker
colours and if there is halogen lighting
in the kitchen.
Controls
The controls may suffer
discolouration or damage if soiling is
left on them for too long.
Remove soiling straight away.
Please observe the General notes on
cleaning earlier in this section.
Do not use stainless steel cleaning
agents on the controls.
Panels and grease filters
The edge extraction panels and the
re-usable metal grease filters in the
appliance remove solid particles
(grease, dust, etc.) from the kitchen
vapours, preventing soiling of the
cooker hood.
Clean the panels and grease filters
regularly but always clean them imme-
diately if the Grease filter symbol [of
the operating hours button lights up.
We recommend cleaning them at least
every 3-4 weeks. Otherwise grease
which builds up on the panels and
grease filters over a long period of time
can harden, making cleaning more
difficult.
,An oversaturated filter is a fire
hazard.
Cleaning and care
20
