Miele EGW 3060-10 User manual

Operating and installation instructions
Plate warming drawer
EGW 3060-10
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 07 241 630
en-GB

Guide to the appliance .............................................3
Warning and Safety instructions .....................................4
Caring for the environment..........................................8
Before using for the first time........................................9
Cleaning and heating up for the first time ................................9
Operation .......................................................10
Opening and closing the drawer ......................................10
Controls .........................................................10
Operation ........................................................11
Selecting a temperature ............................................11
Heating up times ..................................................12
Capacity.........................................................13
Cleaning and care ................................................14
Appliance front and interior ..........................................14
Anti-slip mat ......................................................15
Problem solving guide ............................................16
Optional accessories..............................................18
Safety instructions for installation...................................19
Building-in dimensions ...........................................20
Possible combinations..............................................20
Installing the appliance ............................................21
Aligning the front of the plate warmer ................................22
Electrical connection..............................................23
After sales service, data plate ......................................25
Contents
2

aOn/Off switch (lights up)
bTemperature control
cWarming drawer
dAnti-slip mat
eIn-operation indicator
fWarning sticker (Caution: Danger of burning on the heating element)
Guide to the appliance
3

This appliance complies with all
relevant local and national safety
requirements. Inappropriate use can
lead to personal injury and damage
to property.
To avoid the risk of accidents and
damage to the appliance, please
read these instructions carefully
before using it for the first time.
They contain important notes on its
installation, safety, use and
maintenance.
Keep these instructions in a safe
place and ensure that all users are
familiar with the contents. Pass them
on to any future owner of the
appliance.
Correct application
~This appliance is not designed for
commercial use. It is intended for use in
domestic households and in similar
working and residential environments
such as:
–Shops
–Offices and showrooms,
and by residents in establishments
such as:
–Hostels and guest houses.
~The warming drawing is intended for
domestic use only as described in
these operating and installation
instructions. Miele cannot be held liable
for damage resulting from incorrect or
improper use or operation.
~This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities or lack of
experience or knowledge, unless they
are supervised whilst using it, or have
been shown how to use it correctly by a
person responsible for their safety.
Warning and Safety instructions
4

Safety with children
~This appliance is only intended for
use by adults who have read these
instructions. It is not a toy! To avoid the
risk of injury, keep children away from it
at all times, and do not let them play
with it or use the controls. They will not
understand the potential dangers
posed by it. They should be supervised
whenever you are working in the
kitchen.
~Older children may only use the
appliance when its operation has been
clearly explained to them and they are
able to use it safely, recognising the
dangers of misuse.
~The appliance gets hot when in use
and remains hot for quite a while after
being switched off. To safeguard
against burning, keep children well
away from the appliance at all times.
~Packaging, e.g. cling film,
polystyrene and plastic wrappings,
must be kept out of the reach of babies
and young children. Danger of
suffocation. Dispose of or recycle all
packaging safely as soon as possible.
Technical safety
~Before installation, check the
appliance for visible signs of damage.
Do not use a damaged appliance. It
could be dangerous.
~The electrical safety of this
appliance can only be guaranteed
when continuity is complete between it
and an effective earthing system which
complies with current national and local
safety regulations. It is most important
that this basic safety requirement is
present and regularly tested, and
where there is any doubt, the
household wiring system should be
inspected by a qualified electrician.
Miele cannot be held liable for the
consequences of an inadequate
earthing system (e.g. electric shock).
~Before connecting the appliance,
make sure that the connection data on
the data plate (voltage and frequency)
match the mains electricity supply.
This data must correspond in order to
avoid the risk of damage to the
appliance. Consult a qualified
electrician if in any doubt.
~For safety reasons, this appliance
may only be used when it has been
built in.
Warning and Safety instructions
5

~This appliance must be installed
and connected by a suitably qualified
and competent person in strict
accordance with current local and
national safety regulations. The
manufacturer cannot be held liable for
damage caused by incorrect
installation or connection.
~Never open the housing of the
appliance.
Tampering with electrical connections
or components and mechanical parts is
highly dangerous to the user and can
cause operational faults.
~Installation, maintenance and
repairs may only be carried out by a
suitably qualified and competent
person in strict accordance with current
national and local safety regulations.
Repairs and other work by unqualified
persons could be dangerous. Miele
cannot be held liable for unauthorised
work.
~If the connection cable is damaged,
it must be replaced by a suitably
qualified electrician with a special
connection cable of type H 05 V V-F
(pvc insulated), available from the Miele
Spare Parts Department.
~Faulty components must only be
replaced by genuine Miele original
parts. The manufacturer can only
guarantee the safety of the appliance
when Miele replacement parts are
used.
~During installation, maintenance and
repair work, the appliance must be
disconnected from the mains electricity
supply. It is only completely isolated
from the electricity supply when:
–the mains fuse is disconnected, or
–the screw-out fuse is removed (in
countries where this is applicable), or
–it is switched off at the isolator, or it is
switched off at the wall socket and
the plug is withdrawn from the
socket.
~While the appliance is under
guarantee, repairs should only be
undertaken by a service technician
authorised by Miele. Otherwise the
guarantee is invalidated.
~Do not connect the appliance to the
mains electricity supply by a
multi-socket unit or an extension lead.
These do not guarantee the required
safety of the appliance (e.g. danger of
overheating).
~In countries where there are areas
which may be subject to infestation by
cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the guarantee.
Warning and Safety instructions
6

Correct use
~Depending on the temperature
selected and the length of time the
appliance is being used, the inside of
the drawer can get extremely hot
during use, and remain hot for some
time after being switched off.
~For added protection, it is advisable
to use heat-resistant pot holders or
gloves when using the appliance. Do
not let them get damp or wet, as this
causes heat to transfer through the
material more quickly with the risk of
scalding or burning yourself.
~Do not use the appliance to re-heat,
cook or keep food or drinks warm, as
moisture in the food or drinks could
cause corrosion damage to the drawer.
~Do not store any plastic containers
or inflammable objects in the warming
drawer. They could melt or catch fire
when the appliance is switched on,
causing a fire hazard.
~Do not use the appliance to heat up
the room. Due to the high temperatures
radiated, objects near the appliance
could catch fire. The life of the
appliance could also be reduced.
~Never replace the anti-slip mat
supplied with the appliance with paper
kitchen towel or similar.
~Do not overload the drawer. The
maximum load bearing capacity of the
drawer is 15 kg.
~To minimise the risk of burning
yourself on the inside of the drawer,
always pull it out as far as it will go
before removing crockery.
~Do not sit or lean on the opened
drawer. This can damage the
telescopic runners. The drawer has a
maximum load bearing capacity of
15 kg.
~If the appliance is installed behind a
kitchen furniture door, it may only be
used with the furniture door open.
Only close the door if the appliance is
switched off.
Miele cannot be held liable for
damage caused by non-compliance
with these Warning and Safety
instructions.
Warning and Safety instructions
7

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for
disposal, and should be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Please ensure that it presents
no danger to children while being
stored for disposal.
Caring for the environment
8

Please stick the extra data plate for the appliance supplied
with this documentation in the space provided in the "After
sales service" section of this booklet.
Cleaning and heating up for the first time
^Remove any protective foil and sticky labels.
^Remove the anti-slip mat from the drawer, and clean it with
warm water and a little washing-up liquid. Wipe dry using a
soft cloth.
^Wipe the appliance inside and out with a damp cloth only,
and then dry with a soft cloth.
^Replace the anti-slip mat in the drawer.
^Then heat the empty drawer for at least two hours. Set the
temperature control to maximum (see "Selecting a
temperature").
Metal components have a protective coating which may give
off a slight smell when heated up for the first time.
The smell and any vapours will dissipate after a short time,
and do not indicate a faulty connection or appliance.
Ensure that the kitchen is well ventilated.
Before using for the first time
9

Do not use the appliance to re-heat, cook or keep food or
drinks warm. Condensation from the food or drinks could
lead to corrosion in the appliance.
Always use oven gloves to remove heated crockery from
the drawer.
The load bearing capacity of the appliance is 15 kg
maximum.
The base of the drawer is fitted with an anti-slip mat which
stops crockery sliding about when the drawer is opened and
closed.
Opening and closing the drawer
The drawer can be opened and closed by pressing lightly in
the middle of the drawer front.
Controls
The controls consist of a temperature dial and an On/Off
switch. These are only visible when the drawer is open.
When the drawer is closed, you can tell when the appliance is
switched on because the On/Off switch illuminates through a
hole in the front of the drawer.
Operation
10

Operation
^Place the crockery inside the drawer.
^Select the temperature required.
^Switch on the appliance (j).
The switch lights up.
^Close the drawer.
Switch the appliance off (k) before removing the heated
crockery.
Pull the drawer out to its full extent before unloading it.
Selecting a temperature
The temperature dial allows you to select any temperature
between approx. 30 and 50 °C.
The temperature selector must only be turned in a
clockwise direction as far as it will go and then back
again.
Otherwise it will be damaged.
When the temperature is reached, the heating element
switches itself off. When the temperature falls below that
selected, the heating element switches on again
automatically.
The optimum temperature for warming cups is approx. 40 °C.
Drinks poured into warmed cups do not cool down so
quickly, but cups are still not too hot to handle.
Operation
11

Heating up times
Various factors will affect the heating up times:
–The material and thickness of the crockery
–Maximum capacity
–How the crockery is arranged
–The temperature setting.
It is therefore not possible to state precise times.
However, the following information can be used as a guide:
At a temperature setting of approx. 50 °C, it takes approx.
30-40 minutes to heat crockery through to an even
temperature.
As you use the plate warmer, you will get to know which
setting suits your own needs best.
Operation
12

Capacity
The quantity that can be loaded will depend to a great extent
on the type and size of your own crockery.
Example
–25 Cappuccino cups, C88 mm
or
–56 Espresso cups, C60 mm
Place cups and glasses upside down in the drawer so that
they warm through thoroughly.
The maximum load bearing capacity of the appliance is
15 kg.
Operation
13

Always allow the appliance to cool down before cleaning.
Under no circumstances use a steam cleaning appliance
to clean this appliance. The steam could reach the
electrical components and cause a short circuit.
Only use domestic washing-up liquid to clean this
appliance; commercial cleaning products are not suitable,
and may damage the appliance.
Appliance front and interior
Remove any soiling immediately.
If not, it might become impossible to remove and could
cause the outer surfaces to alter or discolour.
Clean the front using a Miele microfibre E-cloth or with a
clean sponge and a solution of hot water and washing-up
liquid. Then dry with a soft cloth.
The outer surfaces of this appliance are all susceptible to
scratching. Scratches on glass surfaces could even cause
a breakage.
Contact with unsuitable cleaning agents can alter or
discolour the outer surfaces.
Cleaning and care
14

To avoid damaging the surface of your appliance, do not
use:
–cleaning agents containing soda, ammonia, acids or
chlorides,
–cleaning agents containing descaling agents,
–abrasive cleaning agents, e.g. powder cleaners and cream
cleaners,
–solvent-based cleaning agents,
–stainless steel cleaning agents,
–dishwasher cleaner,
–oven sprays,
– glass cleaning agents,
– hard, abrasive sponges and brushes, e.g. pot scourers,
– sharp metal scrapers.
Anti-slip mat
The anti-slip mat can be removed for cleaning.
^Clean the anti-slip mat by hand using warm water and a
little washing-up liquid, and then dry with a cloth.
Do not put the anti-slip mat back into the drawer until it is
completely dry.
Do not wash the anti-slip mat in a dishwasher or washing
machine.
Never place the anti-slip mat in the oven to dry.
Cleaning and care
15

,Installation work and repairs to electrical appliances
must only be carried out by a suitably qualified and
competent person in strict accordance with current local
and national safety regulations (BS 7671 in the UK).
Repairs and other work by unqualified persons could be
dangerous. The manufacturer cannot be held liable for
unauthorised work.
What to do if...
. . . the crockery is not warm enough.
Check whether
–the appliance has been switched on.
– the correct temperature setting has been selected.
– the crockery has been allowed to heat up for a sufficiently
long time.
Various factors will affect how long the crockery will take to
heat up, for example:
– The material and thickness of the crockery
– Maximum capacity
–How the crockery is arranged
–The temperature setting.
The times quoted are only guidelines. As you use the plate
warmer you will get to know which setting suits your own
needs best.
Problem solving guide
16

. . . the crockery does not heat up.
Check whether
–the mains fuse has tripped.
If any of the following problems occur, please contact the
Miele Service Department.
. . . The crockery is too hot.
The temperature control is faulty.
. . . the On/Off switch does not light up when the
appliance is switched on.
The indicator light for the switch is defective.
Problem solving guide
17

These can be ordered via the internet at
www.miele-shop.com, or from the Miele Customer Contact
Centre (see back cover for contact details) or from your Miele
dealer.
Anti-slip mat
Anti-slip mat to keep crockery secure
E-Cloth (microfibre cloth)
Removes finger marks and light soiling.
Optional accessories
18

~Before connecting the appliance to the mains supply
make sure that the connection data on the data plate (voltage
and frequency) correspond with the mains electricity supply,
otherwise the appliance could be damaged.
Consult a qualified electrician if in any doubt.
~The socket and on-off switch should be easily accessible
after the appliance has been built in.
~The plate warmer may only be built in in combination with
those appliances quoted by the manufacturer as being
suitable. The manufacturer cannot guarantee trouble-free
operation if the appliance is operated in combination with
appliances other than those quoted by the manufacturer as
being suitable.
~When building in the plate warmer in combination with
another suitable appliance, the plate warmer must be fitted
above a fixed interim shelf in the housing unit. Please ensure
that the housing unit can support the weight of the plate
warming drawer and that of the other appliance.
~As the combination appliance is placed directly on top of
the plate warmer once it is built in, an interim shelf is not
necessary between the two appliances.
~This appliance may only be installed in mobile installations
such as ships if a risk assessment of the installation has been
carried out by a suitably qualified engineer.
When building in the combination appliance, it is essential
to follow the instructions given in the operating and
installation instructions supplied with the combination
appliance.
All dimensions in this instruction booklet are given in mm.
Safety instructions for installation
19

Possible combinations
Coffee machine
* Appliances with glass front
** Appliances with metal front
Steam oven
Building-in dimensions
20
