Miele EGW 6210 User manual

Operating and installation instructions
Plate warming drawer
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
M.-Nr. 09 572 130en-GB

Guide to the appliance .............................................3
Warning and Safety instructions .....................................4
Caring for the environment.........................................11
Before using for the first time.......................................12
Operation .......................................................13
Opening and closing the drawer ......................................13
Controls .........................................................13
How to operate the drawer ..........................................14
Select a temperature ...............................................14
Heating up times ..................................................15
Capacity.........................................................16
Cleaning and care ................................................17
Appliance front and interior ..........................................17
Anti-slip mat ......................................................18
Problem solving guide ............................................19
Optional accessories..............................................20
Safety instructions for installation...................................21
Building-in dimensions ...........................................22
Installing the appliance ............................................23
Aligning the front of the plate warming drawer ........................24
Electrical connection..............................................25
After sales service, data plate, guarantee .............................27
Contents
2

aOn/Off switch (lights up)
bTemperature control
cWarming drawer
dAnti-slip mat
eIn-operation indicator
fWarning sticker (Caution: Danger of burning on the heating element)
Guide to the appliance
3

This appliance complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before installation and
before using it for the first time. They contain important notes on
installation, safety, use and maintenance.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Warning and Safety instructions
4

Correct application
~The appliance is not designed for commercial use. It is intended
for use in domestic households and similar working and residential
environments.
~The appliance is not intended for outdoor use.
~It is intended for domestic use only as described in these
operating instructions.
Any other usage is not supported by the manufacturer and could be
dangerous.
~The appliance can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, if they are supervised whilst using it, or have been
shown how to use it in a safe way and understand the hazards
involved.
Warning and Safety instructions
5

Safety with children
~Children under 8 years of age must be kept away from the
appliance unless they are constantly supervised.
~Children 8 years and older may only use the appliance
unsupervised if they have been shown how to use it in a safe way
and recognise and understand the consequences of incorrect
operation.
~Children must not be allowed to clean the appliance
unsupervised.
~Please supervise children in the vicinity of the appliance and do
not let them play with it.
~This appliance is not a toy! To prevent the risk of injury, do not
allow children to play with the appliance or its controls.
~The appliance gets hot when in use and remains hot for quite a
while after it has been switched off. Keep children well away from
the appliance until it has cooled down and there is no danger of
burning.
~Danger of suffocation. Packaging, e.g. plastic wrappings, must
be kept out of the reach of babies and children. Whilst playing,
children could become entangled in packaging, or pull it over their
head and suffocate.
Warning and Safety instructions
6

Technical safety
~Installation, maintenance and repairs may only be carried out by
a Miele authorised service technician. Installation, maintenance and
repairs by unqualified persons could be dangerous.
~A damaged appliance can be dangerous. Before installation,
check the appliance for visible signs of damage. Do not use a
damaged appliance.
~The electrical safety of this appliance can only be guaranteed
when correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician.
~To avoid the risk of damage to the appliance, make sure that the
connection data (frequency and voltage) on the data plate
corresponds to the household supply, before connecting the
appliance to the mains supply.
Consult a qualified electrician if in any doubt.
~Do not connect the appliance to the mains electrical supply by a
multi-socket adapter or extension lead. These are a fire hazard and
do not guarantee the required safety of the appliance.
~For safety reasons, this appliance may only be used when it has
been built in.
~This appliance must not be used in a non-stationary location (e.g.
on a ship).
Warning and Safety instructions
7

~Do not open the casing of the appliance.
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
~While the appliance is under guarantee, repairs should only be
undertaken by a service technician authorised by Miele. Otherwise
the guarantee is invalidated.
~Miele can only guarantee the safety of the appliance when
original Miele replacement parts are used. Faulty components must
only be replaced by genuine Miele original spare parts.
~If the plug is removed from the connection cable or if the
appliance is supplied without a plug, the appliance must be
connected to the electrical supply by a suitably qualified electrician.
~If the connection cable is damaged, it must be replaced by a
suitably qualified electrician with a specialist connection cable of
type H 05 VV-F ( (pvc insulated), available from the Miele.
~The appliance must be disconnected from the mains electricity
supply during installation, maintenance and repair work. Ensure that
power is not supplied to the appliance until after it has been
installed or until any maintenance or repair work has been carried
out.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the guarantee.
Warning and Safety instructions
8

Correct use
~You could burn yourself on the hot drawer or crockery. Protect
your hands with heat-resistant pot holders or gloves when handling
hot dishes. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
~Do not store any plastic containers or inflammable objects in the
warming drawer. They could melt or catch fire when the appliance is
switched on, causing a fire hazard.
~Due to the high temperatures radiated, objects left near the
appliance when it is in use could catch fire. Do not use the
appliance to heat up the room.
~Never replace the anti-slip mat supplied with the appliance with
paper kitchen towel or similar.
~If you overload the drawer, or sit or lean on it, the telescopic
runners will be damaged. The telescopic runners can support a
maximum load of 15 kg.
~If the appliance is installed behind a kitchen furniture door, it may
only be used with the furniture door open.
Only close the door if the appliance is switched off.
~Moisture in the food or drinks could cause corrosion damage to
the drawer. Do not use the appliance to reheat, cook or keep food or
drinks warm.
Warning and Safety instructions
9

~Depending on the temperature selected and the length of time
the appliance is being used, the inside of the drawer can get
extremely hot during use, and remain hot for some time after being
switched off. Be careful not to touch it when the drawer is open.
~To minimise the risk of burning yourself on the inside of the
drawer, always pull it out as far as it will go before removing
crockery.
Cleaning and care
~Do not use a steam cleaning appliance to clean this appliance.
The steam could reach electrical components and cause a short
circuit.
Warning and Safety instructions
10

Disposal of the packing
material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre or contact your dealer for
advice. Please ensure that it presents
no danger for children while being
stored for disposal.
Caring for the environment
11

Please stick the extra data plate for the appliance supplied
with this documentation in the space provided in the "After
sales service, data plate, guarantee" section of this booklet.
Cleaning and heating up for the first time
^Remove any protective foil.
^Remove the anti-slip mat from the drawer, and wipe the
mat with warm water and a little washing-up liquid. Dry
using a soft cloth.
^Wipe the appliance inside and out with a damp cloth only,
and then dry with a soft cloth.
^Replace the anti-slip mat in the drawer.
^Then heat the empty drawer for at least two hours. Set the
temperature control to maximum (see "Selecting a
temperature").
The metal components have a protective coating which may
give off a slight smell when heated up for the first time.
The smell and any vapours will dissipate after a short time,
and do not indicate a faulty connection or appliance.
Ensure that the kitchen is well ventilated.
Before using for the first time
12

Do not use the appliance to reheat, cook or keep food or
drinks warm. Condensation from the food or drinks could
lead to corrosion in the appliance.
Always use oven gloves to remove heated crockery from
the drawer.
The maximum load bearing capacity of the appliance is
15 kg.
The base of the drawer is fitted with an anti-slip mat which
stops crockery sliding about when the drawer is opened and
closed.
Opening and closing the drawer
The drawer can be opened and closed by pressing lightly in
the middle of the drawer front.
Controls
The controls consist of a temperature dial and an On/Off
switch. These are only visible when the drawer is open.
When the drawer is closed, you can tell when the appliance is
switched on because the On/Off switch illuminates through a
hole in the front of the drawer.
Operation
13

How to operate the drawer
^Place the crockery inside the drawer.
^Select the temperature required.
^Switch on the appliance (j).
The switch lights up.
^Close the drawer.
Switch the appliance off (k) before removing the heated
crockery.
Pull the drawer out to its full extent before unloading it.
Select a temperature
The temperature dial allows you to select any temperature
between approx. 30 and 50 °C.
The temperature selector must only be turned in a
clockwise direction as far as it will go and then back
again.
Otherwise it will be damaged.
When the temperature is reached, the heating element
switches itself off. When the temperature falls below that
selected, the heating element switches on again
automatically.
The optimum temperature for warming cups is approx. 40 °C.
Drinks poured into warmed cups do not cool down so
quickly, but cups are still not too hot to handle.
Operation
14

Heating up times
Various factors will affect the heating up times:
–the material and thickness of the crockery
–maximum capacity
–how the crockery is arranged
–the temperature setting.
It is therefore not possible to state precise times.
However, the following information can be used as a guide:
At a temperature setting of approx. 50 °C, it takes approx.
30-40 minutes to heat crockery through to an even
temperature.
As you use the plate warmer, you will get to know which
setting suits your own needs best.
Operation
15

Capacity
The quantity that can be loaded will depend to a great extent
on the type and size of your own crockery.
Example
–25 Cappuccino cups, C88 mm
or
–56 Espresso cups, C60 mm
Place cups and glasses upside down in the drawer so that
they warm through evenly.
The maximum load bearing capacity of the appliance is
15 kg.
Operation
16

,Danger of injury.
Do not use a steam cleaning appliance to clean this
appliance. The steam could reach electrical components
and cause a short circuit.
Danger of damage.
Unsuitable cleaning agents can damage the surfaces of
the appliance. Only use domestic washing-up liquid to
clean the appliance.
Appliance front and interior
Remove any soiling immediately.
If this is not done, it might become impossible to remove
and could cause the surfaces to alter or discolour.
Clean all surfaces with a clean sponge and a solution of hot
water and washing-up liquid. Then dry with a soft cloth.
A clean, damp microfibre E-cloth without cleaning agent can
also be used.
All surfaces are susceptible to scratching. Scratches on
glass surfaces could even cause a breakage.
Contact with unsuitable cleaning agents can alter or
discolour the surfaces.
Cleaning and care
17

To avoid damaging the surfaces of your appliance, do not
use:
–cleaning agents containing soda, ammonia, acids or
chlorides,
–cleaning agents containing descaling agents,
–abrasive cleaning agents, e.g. powder cleaners and cream
cleaners,
–solvent-based cleaning agents,
–stainless steel cleaning agents,
–dishwasher cleaner,
–oven sprays,
– glass cleaning agents,
– hard, abrasive sponges and brushes, e.g. pot scourers,
– sharp metal scrapers.
Anti-slip mat
The anti-slip mat can be removed for cleaning.
^Only clean the anti-slip mat by hand using a solution of hot
water and a little washing up liquid, and then dry with a
cloth.
Do not put the anti-slip mat back into the drawer until it is
completely dry.
Do not wash the anti-slip mat in a dishwasher or washing
machine.
Never place the anti-slip mat in the oven to dry.
Cleaning and care
18

With the help of the following notes, minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be put right
without contacting the Service Department.
,Installation work and repairs to electrical appliances must only be carried
out by a suitably qualified person in strict accordance with current local and
national safety regulations. Repairs and other work by unqualified persons
could be dangerous. The manufacturer cannot be held liable for unauthorised
work.
Problem Possible cause Remedy
The appliance does not heat
up.
The appliance is not correctly
plugged in and switched on at
the mains socket.
Insert the plug and switch on at
the socket.
The mains fuse has tripped. Reset the trip switch in the mains
fuse box (minimum fuse rating -
see data plate).
If, after resetting the trip switch in
the mains fuse box and switching
the appliance back on, the
appliance will still not heat up,
contact a qualified electrician or
the Miele Service Department.
The crockery is not warm
enough.
The temperature setting is too
low.
Select a higher temperature.
The crockery has not been
allowed to heat up for a
sufficiently long time.
Various factors will affect how
long the crockery will take to heat
up (see "Heating up times").
The crockery is too hot. The temperature control is faulty. Switch the appliance off and call
an electrician or the Miele Service
Department.
The On/Off switch does not
light up when the appliance
is switched on.
The indicator light for the switch
is defective.
Switch the appliance off and call
an electrician or the Miele Service
Department.
Problem solving guide
19

Miele offer a range of useful accessories as well as cleaning
and conditioning products for your Miele appliances.
These can be ordered online at:
or from Miele (see back of manual for contact details)
Anti-slip mat
The anti-slip mat keeps crockery securely in place.
E-cloth (microfibre cloth)
Removes finger marks and light soiling.
Optional accessories
20
