Miele PW 6065 OS User manual

Operating and installation instructions
for washer-extractor
PW 6065 OS
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 09 757 910
en - EXP

Disposing of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure that they
are offered for recycling.
Disposal of your old machine
Electrical and electronic machines
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your machine.
Please do not therefore dispose or it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person.
Energy saving tips
Energy and water consumption
–Water consumption and energy
usage are determined by the size of
the load.
To make the most out of your
machine load the maximum dry load
for the programme you are using.
– If smaller loads are washed using the
Cottons programmes, the automatic
load recognition system will reduce
the amount of water, time and energy
used.
Detergent
– Do not exceed the amounts of
detergent recommended by the
manufacturer on the packaging.
–Reduce the amount of detergent for
smaller loads.
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the washer-extractor .....................................14
Control panel .....................................................14
Display ..........................................................15
Commissioning the machine .......................................17
Notes and tips on laundry care .....................................22
1. Sort the laundry .................................................22
2. Load the drum ..................................................23
3. Select a programme .............................................23
Pre-wash ......................................................23
Spin..........................................................23
Payment system ................................................23
Garment care label symbols .........................................24
Short instructions ................................................25
Programme chart .................................................28
Note for test institutes: Standard programme in accordance with EN 60456 . 30
Changing the programme sequence .................................33
Anti-crease ....................................................33
To interrupt a programme ...........................................33
To alter a programme ..............................................33
To cancel a programme ............................................33
Adding or removing laundry after a programme has started ................34
Detergent .......................................................35
Water softeners ...................................................35
Washing with several components ....................................35
Colour run and dye removers/dyes ....................................35
Fabric conditioners and liquid starch ..................................36
Automatic dispensing of fabric conditioner or liquid starch to laundry
at the end of a programme ........................................36
External dispensing system..........................................37
Empty sensor ..................................................38
Cleaning and care ................................................39
Cleaning the machine ..............................................39
Cleaning the water inlet filters ........................................41
Contents
3

Problem solving guide ............................................42
The programme does not start .......................................42
General problems .................................................43
An unsatisfactory wash result ........................................44
The drum door cannot be opened by pressing the abutton ...............45
To continue a programme after an interruption to the power supply ..........45
Opening the drum door in the event of a blocked drain outlet and/or
power failure .....................................................46
After sales service ................................................49
PC / Optical interface...............................................49
Optional accessories ...............................................49
Installation and connection ........................................50
Front view........................................................50
Rear view ........................................................51
Installing the machine ..............................................52
Installation surface.................................................53
Removing the transit bars ...........................................53
Re-fitting the transit bars ............................................55
Levelling the machine ..............................................55
Screwing out and adjusting the feet .................................55
Securing the machine to prevent it slipping ...........................56
Washer-dryer stack ................................................57
Installation on a raised plinth .........................................57
Payment system...................................................57
Plumbing ........................................................58
Connection to the cold water supply ................................58
Connection to the hot water supply .................................59
Water drainage ...................................................60
Dump valve version .............................................60
Machines with a drain pump ......................................60
Electrical connection ...............................................61
Single phase AC 230 V - country variant .............................62
Technical data ...................................................63
Changing default settings..........................................65
Settings menu J..................................................66
To open the Settings menu ..........................................66
Language J...................................................66
Contents
4

Settings/Supervisor level menu .....................................67
To open the Settings/Supervisor level menu .............................67
Language J......................................................69
Sort languages....................................................69
Suds cooling .....................................................69
Supervisor level ...................................................70
Display contrast / Display brightness ..................................70
Standby .........................................................71
Temperature unit ..................................................71
Language menu...................................................72
Auto load control ..................................................72
Main wash water ..................................................73
Rinse water ......................................................73
Low water pressure ................................................73
Water level Cottons ................................................74
Water level Min. iron ...............................................74
PW temp. Cottons .................................................74
PW duration Cottons ...............................................74
Wash time Cottons.................................................74
Wash time Min. iron ................................................74
No. of programmes ................................................75
Pre-wash ........................................................75
No. rinses Cottons .................................................75
No. rinses Min. iron ................................................75
No. rinses Disin....................................................75
Pre-rinse Cottons ..................................................75
Pre-rinse Min. iron .................................................76
Anti-crease.......................................................76
Spin free of charge ................................................76
Coin mechanism lock ..............................................76
Demo programme .................................................77
Temp. reduction...................................................77
Controls .........................................................77
Settings which can only be changed during the commissioning process ......78
Payment system ................................................78
Supervisor level code ............................................78
Contents
5

This machine conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the machine,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, use and
maintenance.
Keep these instructions in a safe place and ensure that they are
made available to new users. They must be made aware of these
warning and safety instructions.
Pass them on to any future users/owners of the machine.
Correct application
~Only use the machine to wash items which are specified by the
manufacturer to be machine-washable on the wash-care label, and
textiles composed of hand-washable wool or wool blend fabrics as
well as satin, lace, silk and other hand-washable garments. Any
other applications may be dangerous. The manufacturer cannot be
held liable for damage resulting from incorrect or improper use of
the machine.
~This machine must be used as described in these operating
instructions and must be checked on a regular basis to make sure it
is functioning correctly. Maintenance must be carried out when
necessary.
~This machine is not intended for outdoor use.
Warning and Safety instructions
6

~This machine can only be used by people with reduced physical,
sensory or mental capabilities, or lack of experience or knowledge, if
they are supervised whilst using it or have been shown how to use it
in a safe way and understand the hazards involved.
~Children 8 years and older may use, clean or maintain the
washing machine without supervision only if they have been shown
how to do so in a safe way and understand the hazards involved.
~Children under 8 years of age must be kept away from the
machine unless they are constantly supervised.
~The washing machine is not a toy! To prevent the risk of injury, do
not allow children to play with it or near it, or to play with the
controls.
Warning and Safety instructions
7

Technical safety
~Before setting up the machine, check it for any externally visible
damage.
Do not install or use a damaged machine.
~The electrical safety of this machine can only be guaranteed
when continuity is complete between it and an effective earthing
system which complies with local and national safety regulations. It
is most important that this basic safety requirement is present and
regularly tested, and where there is any doubt the on-site wiring
system should be inspected by a qualified electrician. The
manufacturer cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician. If this is not
done, any resultant damage will not be covered by the guarantee.
Ensure current is not supplied to the machine until after
maintenance or repair work has been carried out.
~Do not make any alterations to the machine, unless authorised to
do so by Miele.
~In the event of a fault or for cleaning purposes, the machine is
only completely isolated from the electricity supply when:
–it is switched off at the wall socket and the plug is withdrawn, or
–it is switched off at the isolator switch, or
–it is switched off at the mains, or
–the mains fuse has been withdrawn, or the screw-out fuse is
removed (in countries where this is applicable).
Warning and Safety instructions
8

~This machine must only be connected to the on-site water supply
using a new hose kit. Old hoses must not be re-used. Check the
hose regularly for signs of wear. Change in good time to avoid the
risk of leaks and subsequent damage.
~Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can the safety
standards of the machine be guaranteed.
~Do not connect the machine to the mains electricity supply by an
extension lead or a multi-socket unit. These do not guarantee the
required safety of the machine (e.g. danger or overheating).
~The appliance may only be operated when the following
conditions are met:
– the ship’s hull is longer than 28 metres.
– the list of the vessel is not more than 2°.
– any external vibration is no more than 150 Hz at an amplitude of
0.35 mm.
The safe operation and correct functioning of the appliance can only
be guaranteed if the above conditions are met.
~The appliance may not be operated on an open deck.
~Appliances without the "CSA C/US"- safety certificate are built to
comply with european safety regulations.
They must not be used in the USA.
Warning and Safety instructions
9

~A risk assessment of the installation must be carried out by a
suitably qualified engineer before this appliance is installed or used.
Installation must only be carried out by a suitably qualified engineer.
~The appliance must be fixed in position when it is installed.
Failure to do this could result in personal injury and damage to
property.
~If this machine is being used in a commercial environment please
ensure that all relevant health and safety regulations are obeyed.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the machine and its
surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the guarantee.
~Please observe the instructions in "Installation and connection"
and "Technical data".
~The socket must be easily accessible after installation in order to
disconnect the washing machine from the electricity supply.
~For hard-wired machines, the all-pole isolator provided on-site
must be easily accessible after installation in order to disconnect the
washing machine from the electricity supply.
Warning and Safety instructions
10

Correct use
~The maximum load of dry laundry for this machine is 6.5 kg. See
the "Programme chart" for the maximum recommended loads in
individual programmes.
~Do not install your machine in rooms where temperatures below
freezing may occur. Frozen hoses may burst or split. The reliability
of the electronic control unit may be impaired at temperatures below
freezing point.
~Before using the machine for the first time, check that the transit
bars at the rear of the machine have been removed (see section on
"Installation and connection"). During spinning, a transit bar which is
still in place may result in damage to both the machine and adjacent
furniture or appliances.
~Turn off the stopcock if the machine is to be left for any length of
time (e.g. holiday), especially if there is no floor drain (gully) in the
immediate vicinity.
~Flooding danger.
If hooking the drain hose into a wash basin, check that the water can
drain off quickly enough to prevent the sink from overflowing. Make
sure the drain hose is secure, so that the force of the water flowing
out of the hose does not dislodge it.
~Take care to ensure that foreign objects (e.g. nails, pins, coins,
paper clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds
container, drum), which in turn can result in damage to the laundry.
Warning and Safety instructions
11

~If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
the machine only use proprietary non-corrosive descaling agents
and strictly observe the instructions on the packaging. A special
descaling agent is available to order from your Miele Dealer or the
Miele Spare Parts Department.
~Textiles which have been pre-treated in solvent based cleaning
agents must be thoroughly rinsed in clean water before being
washed in the machine.
~Never use solvent based cleaning agents, e.g. those containing
benzine, in this machine, as this may result in damage to component
parts and create toxic fumes. Such agents also pose a fire and
explosion hazard.
~Benzine, petrol, paraffin, or any easily flammable liquid must not
be stored or used near the machine. Fire and explosion risk!
~Only use dyes specified by the manufacturer as being suitable for
use in a washing machine. Always observe the manufacturer's
instructions carefully.
~Colour run and dye removers contain sulphur compounds which
can cause damage such as corrosion. Do not use these products in
this machine.
Warning and Safety instructions
12

~Avoid contact of stainless steel surfaces (front, lid, casing) with
liquid cleaning and disinfecting agents which contain chlorine or
sodium hypochlorite. These agents can have a corrosive effect on
stainless steel.
Aggressive vapours containing chlorine bleach can also be
corrosive. Do not store open containers of these agents near the
machine.
~Do not use a high pressure cleaner or hose to clean the machine.
~It is particularly important to observe the manufacturer's
instructions when using a combination of cleaning agents and
special application products. Products must only be used for
applications approved by the manufacturer to avoid any material
damage or the occurrence of strong chemical reactions
Accessories
~Accessory parts may only be fitted when expressly approved by
Miele. If other parts are used, guarantee, performance and product
liability claims will be invalidated.
~A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory).
~If installing the machine on a Miele plinth, (available as an
optional accessory), please make sure you order the right one for
this washing machine.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
13

Control panel
aDisplay
See the following pages for more information.
bStart button
cPC/Optical interface
This is used by Miele service technicians during servicing work for testing
purposes.
dMulti-function selector
This is used to select menu options (by turning it) and to confirm your selection
(by pressing it).
eOn-Off button s
To save energy, the machine will switch off automatically 15 minutes after the
end of the programme/anti-crease phase or after being switched on, if no other
selection is made.
fabutton
Opens the machine door.
Operating the washer-extractor
14

Display
Entry menu
The machine is on standby if the display remains dark when
you switch the machine on. Press the multi-function selector.
Welcome
Please select
Programme selection... Language F...
The entry menu will appear with Programme selection
highlighted. Press the multi-function selector. The Programme
selection menu will appear.
Programme selection menu
Cottons Hygiene 95°C Minimum iron 40°C
Cottons Uni. 60°C Minimum iron 30°C
Cottons Uni. 40°C Denim 40°C
Minimum iron 60°C Delicates 30°C H
If you do not make a selection within approx. 20 seconds,
the display will revert to the entry menu.
Multi-function selector
Turning the multi-function selector moves the highlighting to
the next option.
Pressing the multi-function selector selects the highlighted
option.
You can use the multi-function selector to select any
programme. The highlighting will move up or down
depending on the direction the multi-function selector is
turned in. The HVarrows on the right of the display,
indicate further options. Pressing the multi-function selector
takes you to the main menu of the wash programme selected.
Operating the washer-extractor
15

Wash programme main menu
Cottons Uni. 60°C 1400 rpm
Duration 0:47 h
Pre-wash Back A
The main menu shows the temperature and spin speed for
the wash programme selected. The Pre-wash extra option is
highlighted. Press the multi-function selector to deselect /
select Pre-wash.
To return to the Programme selection menu turn the
multi-function selector to highlight Back and then press the
multi-function selector to confirm your selection.
Settings menu
The Settings menu is used to alter the washing machine's
electronics to suit different requirements. See "Settings menu"
for more details.
Operating the washer-extractor
16

Before using for the first time
,Before commissioning the machine, ensure that it is
correctly installed and connected. See "Installation and
connection". Also check that the drain filter is securely
tightened to prevent the risk of water leaks during use.
,Commissioning must be completed to determine the
settings for daily operation.
Certain settings can be altered during the commissioning
process. After that, these can only be changed by a Miele
service technician.
Setting the language J
Settings
Language F#eština
dansk
deutsch
english H
^Turn the multi-function selector to highlight the language of
your choice.
^Press the multi-function selector to confirm your choice of
language.
Use this language?
OK Back A
^Turn the multi-function selector to select OK, and confirm
by pressing the multi-function selector.
If you wish to select a different language:
^Select and confirm back.
Commissioning the machine
17

Each of these settings must now be
confirmed (and altered if required).
More details about the settings are
given under "Settings menu".
Place a cross in the box 8to
indicate your selection, or fill in the
gaps _____ as required.
Pre-wash water
This setting establishes the temperature
of the water for the pre-wash.
^Select:
8Cold
The washer-extractor is only
connected to a cold water supply. Or
8Hot
The washer-extractor is connected to
hot and cold water supplies.
Main wash water
This setting establishes the temperature
of the water for the main wash.
^Select:
8Cold
The washer-extractor is only
connected to a cold water supply. Or
8Hot
The washer-extractor is connected to
hot and cold water supplies.
See "Installation and connection -
Plumbing".
Set contrast
The contrast for the display can be set
in 10 steps.
^Select the contrast for the display.
Step _____ (1 to 10)
Set brightness
The brightness for the display can be
set in 10 steps.
^Select the brightness for the display.
Step _____ (1 to 10)
Payment system
Setting for coin-operated machines.
^Select the option you require.
8No coin box
The Lock setting for operating the
machine with a coin box is skipped.
8Programme operation
The machine is operated using a
coin box.
8Timed operation
The machine is coin operated using
a time meter.
Commissioning the machine
18

8IK6
Serial interface RS 232 for Interface
card 6 is active in coin operation
mode (an IK6 module must be fitted).
8RS 232
Serial interface RS 232 is active
when the machine is operated with
coins (an RS 232 module must be
fitted).
Coin mechanism lock
The Lock setting determines when the
door is locked after the start of the
programme, when operated with a coin
box.
^Select the option you want.
8Immediately
The machine locks straight away.
8in 3 minutes
The machine will lock after a period
of 3 minutes (default setting)
8As soon as cancelled
The machine locks straight away.
Cancel will appear in the display if
the start button is held in for 4
seconds. You can then cancel the
programme in the next 3 minutes.
83 min. after cancelling
The machine will lock after a period
of 3 minutes. Cancel will appear in
the display if the start button is held
in for 4 seconds. You can then
cancel the programme in the next 3
minutes.
Supervisor level code
The Settings/Supervisor level menu can
be locked with a code to prevent it
being accessed by unauthorised
personnel (the Language Jsetting can
still be altered).
^Select the option you want.
8Code not required
Only some of the settings can be
changed (temporary Language
setting, Suds cooling, Time of day,
Display contrast, Display brightness,
Standby, Memory and Temperature
unit).
These settings can be changed by
any user.
Other settings can only be changed
by a Miele Service Technician.
8Code required
A code (000) must be entered in
order to change the settings. All
settings (see Settings menu) can be
changed.
Select this option if you want users to
only be able to change settings via a
code.
The Language setting can be
changed temporarily by any user.
Commissioning the machine
19

Transit bars
A message will appear in the display to remind you to remove
the transport bars.
^Remove them (if this has not already been done by your
fitter). Then press the multi-function selector to confirm that
this has been done.
To repeat the commissioning process
If you are not certain that all of the settings are correct, you
will need to repeat the commissioning process.
Set up successful
i
OK Back A
^Select Back and confirm your selection.
The commissioning process must then be repeated.
To finish the commissioning process
–1. Confirm
If you are sure that all of the settings are correct.
Set up successful
i
OK Back A
^Confirm with OK.
Commissioning the machine
