Miele WCD660 WCS User manual

Operating instructions
for washing machines
To avoid the risk of accidents or damage to the machine, it is
essential to read these instructions before it is installed and used for
the first time.
en-SG M.-Nr. 11 613 230

Contents
2
Caring for the environment .............................................................................. 6
Warning and Safety instructions ..................................................................... 7
Operating the washing machine ...................................................................... 14
Control panel....................................................................................................... 14
How the control field works................................................................................. 15
Before using for the first time .......................................................................... 16
Miele@home ........................................................................................................ 17
1. Remove the transit bars .................................................................................. 18
2. Setting up Miele@home .................................................................................. 18
3. Commissioning TwinDos ................................................................................ 19
4. Starting the calibration programme................................................................. 20
Washing environmentally and economically .................................................. 21
1. Prepare the laundry....................................................................................... 22
2. Select a programme...................................................................................... 23
3. Load the washing machine........................................................................... 24
4. Select programme settings .......................................................................... 25
5. Add detergent ................................................................................................ 26
Degree of soiling of the laundry .......................................................................... 27
Replacing detergent cartridges ........................................................................... 27
Detergent dispenser drawer ................................................................................ 28
CapDosing........................................................................................................... 30
6.Starting the programme ............................................................................... 32
Adding laundry during a programme sequence (AddLoad) ................................ 32
7.End of programme ........................................................................................ 33
Spinning.............................................................................................................. 34
 Delay start/SmartStart................................................................................. 35
Programme chart .............................................................................................. 37

Contents
3
Extra options...................................................................................................... 40
Short.................................................................................................................... 40
Pre-ironing........................................................................................................... 40
The following extra options can be selected in addition to the programmes ..... 40
Garment care label symbols............................................................................. 41
Programme sequence....................................................................................... 42
Changing the programme sequence .............................................................. 44
Changing a programme (safety lock) .................................................................. 44
Cancelling a programme ..................................................................................... 44
Detergent ........................................................................................................... 45
The correct detergent.......................................................................................... 45
Water softeners ................................................................................................... 45
Dispensing aids ................................................................................................... 45
Fabric conditioner and liquid starch.................................................................... 45
Recommended Miele detergents ........................................................................ 46
Recommended detergents in accordance with Directive (EU) Nr. 1015/2010.... 47
Cleaning and care ............................................................................................. 48
Cleaning the external casing and the control panel ............................................ 48
Cleaning the detergent dispenser drawer ........................................................... 48
Hygiene info(Cleaning the drum) ......................................................................... 50
Cleaning the water inlet filter............................................................................... 50
TwinDos maintenance ......................................................................................... 51
Problem solving guide ...................................................................................... 52
The programme does not start............................................................................ 52
The programme is cancelled and a fault indicator light lights up
in the control panel.............................................................................................. 53
During the programme sequence, a symbol appears in the time display........... 54
At the end of the programme, an indicator light lights up in the control panel ... 55
Messages or faults with the TwinDos system ..................................................... 56
General problems with the washing machine ..................................................... 57
An unsatisfactory wash result ............................................................................. 59
The door will not open......................................................................................... 60
Opening the door in the event of a blocked drain outlet and/or power cut ........ 61

Contents
4
Service................................................................................................................ 63
Contact in the event of a fault ............................................................................. 63
Optional accessories........................................................................................... 63
Guarantee............................................................................................................ 63
Installation.......................................................................................................... 64
Front view ............................................................................................................ 64
Rear view............................................................................................................. 65
Installation surface .............................................................................................. 66
Transporting the washing machine to its installation site.................................... 66
Removing the transit bars ................................................................................... 67
Fitting the transit bars ......................................................................................... 69
Levelling the machine.......................................................................................... 70
Screwing out and adjusting the feet............................................................... 70
Installing under a continuous worktop ........................................................... 71
Washer-dryer stack ........................................................................................ 71
The water protection system............................................................................... 72
Connection to the water supply .......................................................................... 72
Water drainage .................................................................................................... 74
Fitting the elbow............................................................................................. 74
Direct connection to a sink drain outlet.......................................................... 75
Electrical connection .......................................................................................... 76
Technical data.................................................................................................... 77
Consumption data............................................................................................. 78
Note for test institutes ......................................................................................... 78
Selecting test programmes ................................................................................. 78
Programmable functions .................................................................................. 79
Choosing and selecting a programmable function ............................................. 79
Editing and saving a programmable function...................................................... 80
Exit programming level........................................................................................ 80
 Sensor tone ................................................................................................... 80
 Lock code...................................................................................................... 81
 Control panel switch-off status .................................................................... 81
 Memory ........................................................................................................ 82
 Longer pre-wash Cottons ............................................................................ 82
 Gentle action ................................................................................................ 82
 Reduce temperature..................................................................................... 82
 Maximum rinse level..................................................................................... 83
 Suds cooling ................................................................................................. 83
 Anti-crease ................................................................................................... 83

Contents
5
 Low water pressure...................................................................................... 83
 Backlight brightness dimmed ...................................................................... 84
 TwinDos........................................................................................................ 84
 UltraPhase1 dispensing quantity ................................................................ 84
 UltraPhase2 dispensing quantity................................................................. 84
 TwinDos maintenance .................................................................................. 85
 Degree of soiling .......................................................................................... 85
Networking .......................................................................................................... 86
 Remote control ............................................................................................. 86
 SmartGrid..................................................................................................... 86
 RemoteUpdate............................................................................................. 87
Switching off WiFi................................................................................................ 88
Copyrights and licences for the communication module.................................... 88
Detergents and care products ......................................................................... 89
Detergent............................................................................................................. 89
Specialist detergents.................................................................................... 90
Fabric care.................................................................................................... 91
Additives....................................................................................................... 91
Machine care....................................................................................................... 91

Caring for the environment
6
Disposing of the packaging
material
The packaging material is used for
handling and protects the appliance
from transport damage. The packaging
material used is selected from materials
which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material
reduces the use of raw materials. Use
material-specific collection points for
valuable materials and take advantage
of return options. Your Miele dealer will
take the packaging material away.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances, or contact your dealer or
Miele for advice. You are also
responsible (by law, depending on
territory) for deleting any personal data
that may be stored on the appliance
being disposed of. Please ensure that
your old appliance poses no risk to
children while being stored prior to
disposal.

Warning and Safety instructions
7
This washing machine complies with all current local and national
safety requirements. However, inappropriate use can lead to
personal injury and damage to property.
Read the operating instructions carefully before using the washing
machine. They contain important information on safety,
installation, use and maintenance. This prevents both personal
injury and damage to the washing machine.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in the
chapter on installing the washing machine as well as the safety
instructions and warnings.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
Correct application
 This washing machine is intended for use in domestic households
and similar working and residential environments.
 The washing machine is not intended for outdoor use.
 It must be used only as a domestic appliance to wash items which
are specified by the manufacturer as being washable on the wash
care label. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.

Warning and Safety instructions
8
 The washing machine can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are supervised whilst using it or have been shown
how to use it safely and recognise and understand the
consequences of incorrect operation.
Safety with children
 Children under 8 years of age must be kept away from the
washing machine unless they are constantly supervised.
 Children 8 years and older may only use the washing machine
unsupervised if they have been shown how to use it safely and
recognise and understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the washing
machine unsupervised.
 Please supervise children in the vicinity of the washing machine
and do not let them play with it.
Technical safety
 Please observe the instructions in “Installation” and “Technical
data”.
 Before setting up the washing machine, check it for any externally
visible damage. Do not install or use a damaged machine.
 Before connecting the washing machine, ensure that the
connection data on the data plate (fuse rating, voltage and
frequency) match the mains electricity supply. If in any doubt,
consult a qualified electrician.

Warning and Safety instructions
9
 Temporary or permanent operation on an autonomous power
supply system or a power supply system that is not synchronised
with the mains power supply (e.g. island networks, back-up systems)
is possible. A prerequisite for operation is that the power supply
system complies with the specifications of EN50160 or an
equivalent standard.
The function and operation of the protective measures provided in
the domestic electrical installation and in this Miele product must
also be maintained in isolated operation or in operation that is not
synchronised with the mains power supply, or these measures must
be replaced by equivalent measures in the installation. As described,
for example, in the current version of BS OHSAS 18001–2 ISO
45001.
 The electrical safety of this washing machine can only be
guaranteed when correctly earthed.
It is essential that this standard safety requirement is met. If in any
doubt, please have the wiring system of the building tested by a
qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
 Do not connect the washing machine to the mains electricity
supply by a multi-socket adapter, extension lead or similar. These do
not guarantee the required safety of the machine (fire hazard due to
the risk of overheating).
 Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can Miele
guarantee the safety standards of the machine.
 The electrical socket must be easily accessible after installation so
that the machine can be disconnected from the electricity supply if
necessary.

Warning and Safety instructions
10
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
should only be undertaken by a Miele authorised service technician,
otherwise any subsequent damage will not be covered by the
warranty.
 While the washing machine is under warranty, repairs should only
be undertaken by a Miele authorised service technician. Otherwise
the warranty will be invalidated.
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 The machine must be isolated from the electricity supply when
cleaning and maintaining the machine and in the event of a fault.
 The machine must only be connected to the on-site water supply
using a new hose kit. Old hose kits must not be re-used. Check the
condition of the hoses regularly so that you can replace them in
good time and avoid the risk of any water damage.
 The water flow pressure must be at least 100kPa and should not
exceed 1000kPa.
 In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the machine and its
surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the warranty.
 The machine must not be used in a non-stationary location (e.g.
on a ship).
 Do not make any alterations to the machine, unless authorised to
do so by Miele.

Warning and Safety instructions
11
Correct use
 Do not install the washing machine in a room where there is a risk
of frost. Frozen hoses may burst or split. The reliability of the
electronic control unit may be impaired at temperatures below
freezing point.
 Before using the machine for the first time, check that the transit
bars at the rear of the machine have been removed (see “Installation
- Removing the transit bars”). During spinning, a transit bar which is
still in place may result in damage to both the machine and adjacent
furniture or appliances.
 Turn off the stopcock if the machine is to be left for any length of
time (e.g. holiday), especially if there is no floor drain (gully) in the
immediate vicinity.
 Flooding danger.
If hooking the drain hose into a wash basin, check that the water can
drain off quickly enough to prevent the sink from overflowing. Make
sure the drain hose is secure, so that the force of the water flowing
out of the hose does not dislodge it.
 Take care to ensure that foreign objects (e.g. nails, pins, coins,
paper clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds
container, drum), which in turn can result in damage to the laundry.
 Take care when opening the drum door after using the steam
function. Danger of burning due to escaping steam and the high
temperature of the surface of the drum as well as the porthole glass.
Stand back away from the machine and wait until the steam has
dissipated.

Warning and Safety instructions
12
 The maximum load for this washing machine is 8.0 kg (dry
weight). See the “Programme chart” for the maximum recommended
loads for individual programmes.
 If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
it, only use a proprietary natural citric acid based descaling agent.
Miele recommends using Miele descaling agent which is available to
order from your Miele dealer. Strictly observe the instructions on the
packaging.
 Textiles which have been pre-treated in solvent based cleaning
agents must be thoroughly rinsed in clean water before being
washed in the machine.
 Do not use solvent based cleaning agents, e.g. those containing
benzine, in this machine, as this may result in damage to component
parts and create toxic fumes. Such agents also pose a fire and
explosion hazard.
 Do not use solvent based cleaning agents, e.g. those containing
benzine, to clean the surfaces of the machine. They can cause
damage to plastic surfaces.
 Only use dyes specified by the manufacturer as being suitable for
use in a domestic washing machine. Always observe the
manufacturer's instructions carefully.
 Colour run and dye removers contain sulphur compounds which
can cause damage such as corrosion. Do not use these products in
this machine.

Warning and Safety instructions
13
 If detergent comes into contact with the eyes, rinse them
thoroughly with lukewarm water immediately. If swallowed, seek
medical assistance immediately and retain the packaging or label for
reference. Those with skin problems or sensitive skin should avoid
their skin coming into contact with detergent.
Accessories
 Only use original Miele accessories and spare parts. If other parts
are used, warranty, performance and product liability claims will be
invalidated.
 A Miele tumble dryer can be stacked on top of a Miele washing
machine using the appropriate stacking kit (available as an optional
accessory). Please make sure you order the correct one for the Miele
washing machine and Miele tumble dryer.
 If installing the machine on a Miele plinth, (available as an optional
accessory, depending on country), please make sure you order the
correct one for this washing machine.
 Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the
discontinuation of your washing machine.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Operating the washing machine
14
Control panel

     
aControl field
The control field consists of a time
display and various sensor controls.
The individual sensor controls are
explained in the following sections.
bSensor controls – temperature
for selecting the temperature.
cSensor controls – spin speeds
for selecting the spin speed.
dSensor controls for TwinDos and
extra options
You can activate TwinDos
dispensing for a wash programme
and add extra options to the
programme.
When a wash programme is
selected, the sensor controls for the
TwinDos dispensing option and extra
options light up dimly.
eIndicator lights
Lights up if there are faults
affecting the water inlet and
drainage.
Lights up if excess detergent
was used.
Lights up together with  in the
time display as a reminder
about hygiene information.
Lights up together with  in the
time display as a reminder
about TwinDos cleaning.
The Add laundry function
cannot be selected.
fSensor controls – CapDosing
CapDosing of fabric care
products (e.g. fabric
conditioner, proofing agent)
CapDosing of additives (e.g.
detergent enhancer)
CapDosing of detergent (for the
main wash only)

Operating the washing machine
15
gTime display
After the programme has started, the
programme duration will appear in
the display in hours and minutes.
When Delay start is being used, the
programme duration will appear after
the Delay start time has elapsed.
hSensor controls  
The Delay start time selected will
appear in the time display.
After the programme has started, the
Delay start time will begin to count
down.
Once the Delay start time has
elapsed, the programme begins and
the estimated programme duration
appears on the time display.
After touching the sensor
control, a later start time for the
programme (Delay start) can be
selected. Once selected, 
lights up brightly.
The duration of the Delay start
period is increased by touching
the sensor control.
The duration of the Delay start
period is reduced by touching
the sensor control.
iStart/Add laundrysensor control
The programme can be started
as soon as the sensor control
is flashing on and off. Touching
theStart/Add laundry sensor
control starts the selected
programme. The sensor control
lights up constantly.
Once the programme has been
started, theStart/Add laundry
sensor control allows you to
add laundry.
jOptical interface
This is used by the Service
department as a transmission point.
kProgramme selector
for selecting programmes and for
switching off the appliance. The
washing machine is switched on
when you select a programme, and
switched off by turning the
programme selector to the 
position.
How the control field works
The , , , ,  and sensor
controls react to fingertip contact. If a
sensor control is illuminated, it can be
selected.
If a sensor is brightly lit, this means:
currently selected
If a sensor is dimly lit, this means: it can
be selected

Before using for the first time
16
Damage resulting from incorrect
installation and connection.
Installing and connecting the
washing machine incorrectly will
cause serious property damage.
See “Installation”.
Removing the protective foil
and stickers
Remove:
- Any protective film from the door
- Any stickers from the front and the lid
Please do not remove any labels
(e.g. the data plate) which are visible
when you open the door.
Remove the detergent
cartridges and the drain hose
elbow from the drum
Two detergent cartridges for automatic
detergent dispensing and an elbow
piece for the drain hose are stored in
the drum.
Reach under the door grip and pull
the door open.
Take the two cartridges and the
elbow piece out of the drum.
Shut the door with a gentle swing.
This washing machine has undergone
a complete functional test at the
factory and there will be some residual
water in the drum from this process.

Before using for the first time
17
Miele@home
Your washing machine is equipped
with an integrated WiFi module.
In order to use it you need:
- a WiFi network
- the Miele@mobile App
- a Miele user account. The user
account can be created via the
Miele@mobile App.
The Miele@mobile App will guide you
as you connect your washing machine
to your home WiFi network.
Once your washing machine is
connected to your WiFi network you
can use the App, for example, to carry
the following activities:
- Operate your washing machine
remotely
- Access information about the
operating status of your washing
machine
- Access information about a
programme sequence on your
washing machine
Connecting your washing machine to
your WiFi network will increase energy
consumption, even when the washing
machine is switched off.
Before installing the washing
machine in its final location, ensure
the signal strength is sufficient for
your WiFi network.
Availability of the WiFi connection
The WiFi connection shares a frequency
range with other appliances (including
microwave ovens and remote control
toys). This can give rise to sporadic or
even complete connection failures.
Therefore, the availability of featured
functions cannot be guaranteed.
Miele@home availability
The ability to use the Miele app
depends on the availability of the
Miele@home service in your country.
The Miele@home service is not
available in every country.
For information about availability,
please visit www.miele.com.
Miele App
The Miele App is available to download
free of charge from the Apple App
Store® or from the Google Play Store™.

Before using for the first time
18
1. Remove the transit bars
Damage resulting from failure to
remove the transit bars.
Failure to remove the transit bars can
result in damage to the washing
machine and to adjacent cabinetry or
appliances.
Remove the transit bars as described
in “Installation and connection”.
2. Setting up Miele@home
There are 2 ways of connecting:
1. Via the Miele app (default)
2. Via WPS
Logging in via the Miele app
Turn the programme selector to the
MobileStart programme.
 appears on the time display and
the timeout starts to count down from
10minutes. The Miele app will guide
you through the remaining steps.
When you have successfully connected,
 will appear on the time display.
Logging in via WPS
Turn the programme selector to the
MobileStart programme.
Touch the sensor control until 
appears on the time display and a
short keypad tone appears.
The timeout then starts to count down
from 3minutes on the time display.
When you have successfully connected,
 will appear on the time display.
Tip: If the connection has not been set
up when the timeout has finished
counting down, repeat the process.

Before using for the first time
19
3. Commissioning TwinDos
The TwinDos system can only be
operated with the Miele UltraPhase1
and UltraPhase2 detergent cartridges.
It is not possible to use any other
detergent in the TwinDos system.
The dispensing quantities for
UltraPhase1 and UltraPhase2 are
preset for water hardness levelI in the
default settings.
You can change the dispensing
quantity. See the “Programmable
functions” chapter, “TwinDos” section.
Open the access panel for TwinDos.
Remove the film from the detergent
cartridges.
Push the detergent cartridge for
UltraPhase1 into compartment 1 and
the detergent cartridge for
UltraPhase2 into compartment 2.
Close the TwinDos access panel.

Before using for the first time
20
4. Starting the calibration
programme
For optimum water and energy
consumption and excellent wash
results, it is important to calibrate the
washing machine.
To do this, the Cottonsprogramme
must be run without laundry and
without detergent.
Open the stopcock.
Turn the programme selector to the
Cottons position.
The washing machine is now switched
on and the temperature 40 and spin
speed 1400 light up.
Touch theStart/Add laundry sensor
control.
The wash programme will start.
After 10minutes, the indicators dim.
Opening the door at the end of the
programme
The door remains locked during the
anti-crease phase. The control field
lights up for the first 10minutes. The
control field then goes out and
theStart/Add laundry sensor control
flashes.
Turn the programme selector to the
position.
 appears on the timer display and
the indicator light goes out.
The door unlocks.
Tip: After the anti-crease phase, the
washing machine will have switched off
and the door unlocked automatically.
The control field will be completely
dark.
Reach under the door grip and pull
the door open.
Tip: Leave the door slightly open to
allow the drum to dry.
Initial commissioning is now complete.
