Introduction to clicker 2 for FT90x
Clicker 2 for FT90x is a
compact dev. kit with two
mikroBUS™sockets for click™
board connectivity. You can
use it to quickly build your
own gadgets with unique
functionalities and features.
It carries the FT900, a 32-bit
FT32 core microcontroller, two
indication LEDs, two general
purpose buttons, a reset
button, an on/o switch, a
li-polymer battery connector,
a USB Mini-B connector and
two mikroBUS™ socket. A
mikroProg connector and a
2x26 pinout for interfacing
with external electronics are
also provided. The mikroBUS™
connector consists of two
1x8 female headers with SPI,
I2C, UART, RST, PWM, Analog
and Interrupt lines as well as
3.3V, 5V and GND power lines.
Clicker 2 for FT90x board can
be powered over a USB cable.
power supply
via USB cable (5V DC)
board dimensions
60.4 x 81 mm (2.4 x 3.2 inch)
weight
26 g (0. 057 lbs)

Page 5
Key features 112
13
14
15
2
3
4
5
6 6
7 7
8 8
9 9
10
11
1ON/OFF switch
2Pads for connecting external ON/OFF switch
3FT900Q
432.768 kHz crystal oscillator
512 mHz crystal oscillator
62x26 connection pads
7mikroBUS™ sockets 1 and 2
8Pushbuttons
9Additional LEDs
10 LTC3586 USB power manager IC
11 Power and Charge indication LEDs
12 RESET button
13 USB mini-B connector
14 Li-Polymer battery connector
15 Programmer connector

Page 6
C8
100nF
VCC-3.3V
C9
100nF
VCC-3.3V
C10
100nF
VCC-3.3V
R8
470
LD3
VCC-3.3V
VCC-3.3V
C13
100nF
VCC-BAT
CN1
BATT
CONN
VCC-BAT
C36
10uF
C26
10nF
FP2
FERRITE
R24 100 1
2
3
4
5GND
ID
D+
D-
VBUS
CN2
USB MINIB
R25
1M
USB-D_N
USB-D_P
VCC-USB
USB-DET
C38
10uF
VCC-1.2V
C39
100nF
VCC-1.2V
C41
4.7uF
VCC-1.2V
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
2
SPIM_SCK-GPIO27
SPIM_MISO-GPIO30
SPIM_MOSI-GPIO29
UART0_TX-GPIO48
UART0_RX-GPIO49
ADC1-GPIO6
GPIO33-MB2_CS
PWM2-GPIO58-MB2
GPIO5-MB2_RST GPIO4-MB2_INT
I2C0_SCL-GPIO44
I2C0_SDA-GP IO45
1
2
3
4
5
6
SW1
JS202011AQN
PWR-EN
C18
100nF
LDO3V3
R17
1K
AN
INT
VCC-3.3V
SCK
SDI
SDO
VSYS
HDR1
M1X26
SPIM_SCK-GPIO27
SPIM_MISO-GPIO30
SPIM_MOSI-GPIO29
ADC7-GPIO12
ADC6-GPIO11
ADC5-GPIO10
ADC4-GPIO9
ADC3-GPIO8
ADC2-GPIO7
ADC1-GPIO6
GPIO16-INT-CAN
GPIO15-INT-CAN
GPIO14-INT-DAC
GPIO13-INT-DAC
GPIO19-SD
GPIO20-SD
GPIO21-SD
GPIO22-SD
GPIO23-SD
GPIO24-SD
GPIO25-SD
GPIO26-SD RX
TX
SDA
SCL
PWM
VCC-3.3V
RESET#
HDR2
M1X26
UART0_TX-GPIO48
UART0_RX-GPIO49
PWM4-GPIO52
PWM5-GPIO53
PWM6-GPIO54
PWM7-GPIO55
PWM0-GPIO56
I2C0_SCL-GPIO44
I2C0_SDA-GPIO45
GPIO40
GPIO42
GPIO43
GPIO17
GPIO65-I2S
GPIO66-I2S
GPIO63-I2S
GPIO64-I2S
GPIO61-I2S
GPIO62-I2S
GPIO60-I2S
R3
10K
VCC-3.3V
C1
100nF
R4
220
RSTRESET#
T1
T2 T3
R5
10K
R6
10K
VCC-3.3V VCC-3.3V
R1
2K2
R2
2K2
GPIO2-T3 GPIO34-LD1 GPIO35-T2 GPIO18-LD2
R14
4K7
R12
4K7
VCC-BAT
R13
4K7
C33
100nF
M1
DMP2305U
R10
1M
R11
1K
VCC-BAT
ADC2-GPIO7
GPIO31-SENSEL
AN
RST
CS
SCK
MISO
MOSI
3.3V
GND
PWM
INT
RX
TX
SCL
SDA
5V
GND
VCC-3.3V VCC-5V
1
SPIM_SCK-GPIO27
SPIM_MISO-GPIO30
SPIM_MOSI-GPIO29
UART0_TX-GPIO48
UART0_RX-GPIO49
I2C0_SCL-GPIO44
I2C0_SDA-GPIO45
PWM1-GPIO57-MB1
GPIO28-MB1_CS
GPIO1-MB1_INT
ADC3-GPIO8
GPIO47_MB1_RST
ILIM0
1
ILIM1
2
LDO3V3
3
CLPROG
4
NTC
5
VOUT4
6
VOUT4
7
SW4
8
MODE
9
FB4
10
FB3
11
VC3
12
SWAB3 13
VIN3 14
VIN3 15
VOUT3 16
VOUT3 17
EN3 18
SWCD3 19
EN2 20 EN1 21
VIN4 22
FB2 23
VIN2 24
SW2 25
SW1 26
VIN1 27
FB1 28
PROG 29
CHRG# 30
GATE 31
BAT
32
EN4
33
VOUT
34
VBUS
35
VBUS
36
SW
37
FAULT#
38
LTC3586
U2
LTC3586-1
L1 3.3uH
L2 2.2uH
M2
DMP2305U
R15
2K2
C22
22uF
C31
22uF
VCC-USB
VCC-USB
C32
10uF
VCC-3.3V
C23 10pF
R21
15K
C24
300pF
R19
324K
R22
105K
C14
22uF
C21
33pF
VCC-3.3VVCC-3.3V
VCC-3.3V
C19
2.2uF
L3
2.2uH
R27
16K9
C29
10pF
C30
22uF
VCC-5V
VCC-5V VCC-5V VCC-5V
R18
3K3
R26
88K7
C25
100nF
R23
1K69
LD4B
RED
LDO3V3
C17
1uF
LDO3V3
PWR-ENPWR-EN
C20
2.2uF
VCC-BAT
R20
10K
C15
1uF
VCC-3.3V
C27
1uF
VCC-5V
C28
10nF
VCC-5V
C16
10nF
VCC-3.3V
R16
10K
LDO3V3LDO3V3
VCC-USB
VSYS
VSYS VSYS
VSYS
LDO3V3
GPIO50-STAT
FAULT
C5
100nF
VCC-1.2V
RESET#
6
8
109
7
5
1 2
3 4
CN3
DBG
VPP
SPIS0-SS
SPIS0-MOSI SPIS0-MISO
SPIS0-SCK
C4
100nF
VSYS
R32
X1
32.768KHz
C2
10pF
C3
10pF
RTC_X1
RTC_X2
C7
18pF
C6
18pF
X2
12MHz
X1
X2
VCC-3.3V
75
74
73
72
71
70
69
68
67
66
64
65
63
62
61
60
59
58
57
56
55
54
53
52
51
50 49
48
47
46
45
44
43 42 41 40
39
38
37
36
35 34 33 32 31
30
29
28
27 26
9
11
12
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
25
76
FTDI
81
82
83
84
85
86
87
88
89
90
91
92
93
94 95 96
97
98
99
100
STESTRESTN RESETN VPP FSOURCE GPIO52 GPIO51
GPIO21
GPIO22
GPIO23
GPIO24
D_DM
VCC3V3
VCC1V2
GPIO0
GPIO54 GPIO53
GPIO63
GPIO64
GPIO65
GPIO66
GPIO55 GND
GPIO10
GPIO9 GPIO8
GPIO12
GPIO7 GPIO6
RTC_XIO
TXON
GPIO20
GPIO19
GPIO14 GPIO13
DAC_REFP
VCC3V3
AGND
GPIO11
GPIO28
GPIO44
GPIO39
GPIO38
GPIO37
GPIO36
GPIO35
GPIO34
DRREF
D_DP
GPIO62
GPIO61
GPIO30
GPIO27
GPIO26
GPIO48
GPIO15 GPIO16
GPIO17
GPIO18
GPIO43 GPIO42
GPIO41
GPIO40
GPIO57 GPIO58
XIO
GPIO4
VCC3V3 GPIO56
GPIO1
GPIO49
GPIO2
GPIO5
NC
GPIO33
GPIO32
GPIO31
DEBUG GPIO50
GPIO3
XI/CLKIN
RTC_XI/RTC_CLKIN
GPIO47 GPIO46 GPIO45
GPIO29
GPIO25
VCC1V2
VCC3V3
H_DM
RREFSET
VCC3V3
H_DP
AGND
HRREF
VCC1V2 VCC3V3
RXIP
RXIN
TXOP
GPIO60
FT900Q
0
TP
U1
R9
R7
SPIM_SCK-GPIO27
SPIM_MISO-GPIO30
SPIM_MOSI-GPIO29
I2C0_SCL-GPIO44 I2C0_SDA-GPIO45 UART0_TX-GPIO48 UART0_RX-GPIO49 PWM4-GPIO52 PWM5-GPIO53 PWM6-GPIO54 PWM7-GPIO55 PWM0-GPIO56 PWM1-GPIO57-MB1 PWM2-GPIO58-MB2
ADC7-GPIO12 ADC6-GPIO11 ADC5-GPIO10
ADC4-GPIO9 ADC3-GPIO8 ADC2-GPIO7 ADC1-GPIO6
RTC_X2 RTC_X1
RESET#
R30
VCC-1.2V
USB-D_N
USB-D_P
USB-DET
R28
R29
GPIO28-MB1_CS
GPIO33-MB2_CS
GPIO16-INT-CAN GPIO15-INT-CAN GPIO14-INT-DAC GPIO13-INT-DAC
DBG
SPIS0-SS
SPIS0-MOSI
SPIS0-MISO
SPIS0-SCK
FSRC
VPP
GPIO1-MB1_INT
GPIO42
GPIO43
GPIO40
GPIO19-SD
GPIO20-SD
GPIO21-SD
GPIO22-SD
GPIO23-SD
GPIO24-SD
GPIO25-SD
GPIO26-SD
GPIO5-MB2_RST
GPIO4-MB2_INT
GPIO2-T3
R35
10K
R36
10K
VCC-3.3V
C42
100nF
GPIO17
GPIO65-I2S
GPIO66-I2S
GPIO63-I2S
GPIO64-I2S
GPIO61-I2S
GPIO62-I2S
GPIO60-I2S
GPIO34-LD1
GPIO35-T2
GPIO18-LD2
GPIO31-SENSEL
GPIO47_MB1_RST
GPIO50-STAT
0Ω
clicker 2 for FT90x schematic

Page 7
1. Power supply
You can supply power to the board with a Mini-B USB cable provided
in the package. On-board voltage regulators provide the appropriate
voltage levels to each component on the board. Power LED (GREEN)
will indicate the presence of power supply.
You can also power the board using a Li-Polymer battery, via
on-board battery connector. On-board battery charger circuit
enables you to charge the battery over USB connection. LED
diode (RED) will indicate when battery is charging. Charging
current is ~300mA and charging voltage is 4.2V DC.
Battery power supplyUSB power supply
Figure 1-1:
Connecting USB power supply
Figure 1-2: Connecting
Li-Polymer battery
click™boards that use a 3.3V power supply can draw up to 750 mA of current, which is more current than a USB can supply (500 mA);
In those cases you would need to use the battery as the power supply, or the vsys pin on the side of the board.
NOTE

Page 8
Figure 1-3: Power supply schematic
R8
470
LD3
VCC-3.3V
VCC-BAT
CN1
BATT
CONN
VCC-BAT
C36
10uF
C26
10nF
FP2
FERRITE 1
2
3
4
5GND
ID
D+
D-
VBUS
CN2
USB MINIB
1
2
3
4
5
6
SW1
JS202011AQN
PWR-EN
C18
100nF
LDO3V3
R17
1K
AN
INT
VCC-3.3V
VSYS
HDR1
PWM
VCC-3.3V
HDR2
R14
4K7
R12
4K7
VCC-BAT
R13
4K7
C33
100nF
M1
DMP2305U
R10
1M
R11
1K
VCC-BAT
ADC2-GPIO7
GPIO31-SENSEL
ILIM0
1
ILIM1
2
LDO3V3
3
CLPROG
4
NTC
5
VOUT4
6
VOUT4
7
SW4
8
MODE
9
FB4
10
FB3
11
VC3
12
SWAB3 13
VIN3 14
VIN3 15
VOUT3 16
VOUT3 17
EN3 18
SWCD3 19
EN2 20 EN1 21
VIN4 22
FB2 23
VIN2 24
SW2 25
SW1 26
VIN1 27
FB1 28
PROG 29
CHRG# 30
GATE 31
BAT
32
EN4
33
VOUT
34
VBUS
35
VBUS
36
SW
37
FAULT#
38
LTC3586
U2
LTC3586-1
L1 3.3uH
L2 2.2uH
M2
DMP2305U
R15
2K2
C22
22uF
C31
22uF
VCC-USB
VCC-USB
C32
10uF
VCC-3.3V
C23 10pF
R21
15K
C24
300pF
R19
324K
R22
105K
C14
22uF
C21
33pF
VCC-3.3VVCC-3.3V
VCC-3.3V
C19
2.2uF
L3
2.2uH
R27
16K9
C29
10pF
C30
22uF
VCC-5V
VCC-5V VCC-5V VCC-5V
R18
3K3
R26
88K7
C25
100nF
R23
1K69
LD4B
RED
LDO3V3
C17
1uF
LDO3V3
PWR-ENPWR-EN
C20
2.2uF
VCC-BAT
R20
10K
C15
1uF
VCC-3.3V
C27
1uF
VCC-5V
C28
10nF
VCC-5V
C16
10nF
VCC-3.3V
R16
10K
LDO3V3LDO3V3
VCC-USB
VSYS
VSYS VSYS
VSYS
LDO3V3
GPIO50-STAT
FAULT
6
8
109
7
5
1 2
3 4
CN3
VSYS

Page 9
2. FT900 microcontroller
The FT90x clicker development tool comes with the
FT900Q microcontroller. This 32-bit FT32 Core high
performance microcontroller executes instructions
from Shadow RAM, achieving true zero wait states at
up to 100mHz, resulting in 310 DMIPS of performance.
∫ 310 DMIPS/ 100mHz, 32-bit FT32 Core
∫ 256kB Flash memory
∫ 64kb Data memory
∫ 256kB Shadow program memory
∫ 67 I/O pins
∫ SPI, I2C, I2S, A/D, UART, Eternet, DAC, CAN, SD
∫ 16-bit, 32-bit Digital Timers
∫ Camera parallel interface
∫ RTCC, one wire debugger, etc.
Key microcontroller features
¬256kB Flash memory
¬Control Logic
¬Debugger Core with Security
¬256kB Program SRAM
¬64kb Data memory
¬FT32 Core
System 32-Bit I/O Bus
System 32-Bit I/O Bus
UART 0/1 SD Host
EFUSE BCD BCD
SPI 0/1
Slave(s) USB HostCAN 0/1 USB
peripheral
I2S Master
/Slave
I2C Master
/Slave(s)
Camera
Timers/
Watchdog
10-bit
DAC 0/1
10-bit
ADC 1/7 PWM/PCM RTC
One-Wire
Debug I/F
SPI Master Ethernet
Interrupt

Page 10
The microcontroller can be programmed in three ways:
1 Using USB HID mikroBootloader,
2 Using external mikroProg™ for FT90x programmer
3. Programming the microcontroller
Figure 3-1:
FT900Q
microcontroller

Page 11
1
3.1 Programming with mikroBootloader
You can program the microcontroller with a
bootloader which is preprogrammed by default.
To transfer .hex le from a PC to MCU you need
bootloader software (mikroBootloader USB HID)
which can be downloaded from:
www.mikroe.com/downloads/get/2230/
clicker_2_ft90x_bootloader.zip
After the mikroBootloader software is downloaded,
unzip it to desired location and start it.
Figure 3-2: USB HID mikroBootloader window
step 1 – Connecting clicker 2 for FT90x
To start, connect the USB cable, or if already connected press the Reset button
on your clicker 2 for FT90x. Click the Connect button within 5s to enter the
bootloader mode, otherwise existing microcontroller program will execute.
clicker_2_ft90x_bootloader.zip
WinRAR ZIP archive
clicker_2_ft90x_bootloader
File folder
Software
File folder
mikroBootloader USB HID.exe
Bootloader tool for mikroElektron...
mikroElektronika
Clicker 2 FT90x USB HID Bootloader
v1.300.hex
HEX File
Firmware
File folder
1

Page 12
step 3 – Selecting .HEX le step 2 – Browsing for .HEX le
1 Click the Browse for HEX button and from a pop-up
window (Figure 3.4) choose the .HEX le which will be
uploaded to MCU memory.
1 Select .HEX le using open dialog window.
2 Click the Open button.
Figure 3-3: Browse for HEX
Figure 3-4: Selecting HEX
1
1
2

Page 13
Figure 3-5: Begin uploading Figure 3-6: Progress bar
1 To start .HEX le bootloading click the
Begin uploading button.
1 Progress bar enables you to monitor .HEX le uploading.
step 4 – Uploading .HEX le
11

Page 14
Figure 3-7: Restarting MCU Figure 3-8: mikroBootloader ready for next job
1 Click OK button after the uploading process is nished.
2Press Reset button on clicker 2 for FT90x board and wait
for 5 seconds. Your program will run automatically.
step 5 – Finish upload
1

The microcontroller can be
programmed with external
mikroProg™for FT90x
programmer and mikroProg
Suite™ for FT90x®software.
The external programmer is
connected to the development
system via 2x5 connector
Figure 3-9. mikroProg™is a
fast USB 2.0 programmer with
hardware debugger support.
It supports all FT90x devices
in a single programmer.
Outstanding performance,
easy operation and elegant
design are its key features.
Figure 3-8:
mikroProg™ connector
3.2 Programming with mikroProg™
programmer
Page 15

Page 16
A standalone programming software utility called mikroProg Suite™for FT90x is available as an
alternative to programming the MCU directly from the FT90x compiler. This software is used for
programming of all supported FT90x microcontrollers. The software has an intuitive interface and
SingleClick™ programming technology. To begin, rst locate the installation archive on our web site:
www.mikroe.com/downloads/get/2215/mikroprog_suite_ft90x_v100.zip
After downloading, extract the package and double click the executable setup le, to start the installation.
Figure 3-10:
mikroProg Suite™for
FT90x window
Quick guide
mikroProg Suite™for FT90x software
1
2
3
4
Click the Detect MCU button in order to recognize the device ID.
Click the Read button to read the entire microcontroller memory.
You can click the Save button to save it to the target HEX le.
If you want to write the HEX le into the microcontroller, rst
make sure to load the target HEX le using the Load button. Then
click the Write button to begin programming.
Click the Erase button to clear the microcontroller memory.

Page 17
C8
100nF
VCC-3.3V
C9
100nF
VCC-3.3V
C10
100nF
VCC-3.3V VCC-3.3V
C13
100nF
C39
100nF
VCC-1.2V
C41
4.7uF
VCC-1.2V
C38
10uF
VCC-1.2V
C5
100nF
VCC-1.2V
X1
32.768KHz
C2
10pF
C3
10pF
RTC_X1
RTC_X2
C7
18pF
C6
18pF
X2
12MHz
X1
X2
VCC-3.3V
75
74
73
72
71
70
69
68
67
66
64
65
63
62
61
60
59
58
57
56
55
54
53
52
51
50 49
48
47
46
45
44
43 42 41 40
39
38
37
36
35 34 33 32 31
30
29
28
27 26
9
11
12
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
25
76
FTDI
81
82
83
84
85
86
87
88
89
90
91
92
93
94 95 96
97
98
99
100
STESTRESTN RESETN VPP FSOURCE GPIO52 GPIO51
GPIO21
GPIO22
GPIO23
GPIO24
D_DM
VCC3V3
VCC1V2
GPIO0
GPIO54 GPIO53
GPIO63
GPIO64
GPIO65
GPIO66
GPIO55 GND
GPIO10
GPIO9 GPIO8
GPIO12
GPIO7 GPIO6
RTC_XIO
TXON
GPIO20
GPIO19
GPIO14 GPIO13
DAC_REFP
VCC3V3
AGND
GPIO11
GPIO28
GPIO44
GPIO39
GPIO38
GPIO37
GPIO36
GPIO35
GPIO34
DRREF
D_DP
GPIO62
GPIO61
GPIO30
GPIO27
GPIO26
GPIO48
GPIO15 GPIO16
GPIO17
GPIO18
GPIO43 GPIO42
GPIO41
GPIO40
GPIO57 GPIO58
XIO
GPIO4
VCC3V3 GPIO56
GPIO1
GPIO49
GPIO2
GPIO5
NC
GPIO33
GPIO32
GPIO31
DEBUG GPIO50
GPIO3
XI/CLKIN
RTC_XI/RTC_CLKIN
GPIO47 GPIO46 GPIO45
GPIO29
GPIO25
VCC1V2
VCC3V3
H_DM
RREFSET
VCC3V3
H_DP
AGND
HRREF
VCC1V2 VCC3V3
RXIP
RXIN
TXOP
GPIO60
FT900Q
0
TP
U1
RTC_X2 RTC_X1
RESET#
R30
VCC-1.2V
USB-D_N
USB-D_P
R28
R29
DBG
SPIS0-SS
SPIS0-MOSI
SPIS0-MISO
SPIS0-SCK
RESET#
6
8
109
7
5
1 2
3 4
CN3
DBG
VPP
SPIS0-SS
SPIS0-MOSI SPIS0-MISO
SPIS0-SCK
C4
100nF
VSYS
R32
FSRC
VPP
R35
10K
R36
10K
VCC-3.3V
C42
100nF
0Ω
Before attaching
the programming
connector, you
have to solder
the provided 2x5
male header to the
connection pads.
Figure 3-13: mikroProg™connection schematic
NOTE

Page 18
Figure 4-1:
Two LEDs, two buttons
and a reset button
The board also contains a 1reset
button and a pair of 2buttons and 3
LEDs, as well as an ON/OFF switch.
The Reset button is used to
manually reset the
microcontroller — it
generates a low
voltage level on the
microcontroller’s reset
pin. LEDs can be used for visual
indication of the logic state on
two pins (P34 and P18). An active
LED indicates that a logic high (1) is
present on the pin. Pressing any of the two
buttons can change the logic state of the
microcontroller pins (P35 and P2) from
logic high (1) to logic low (0). In addition to
the onboard ON/OFF switch, two pins allow
you to connect your own external switch
(located beneath the switch).
4. Buttons and LEDs
123

Page 19
Figure 4-2: Other modules connection schematic
R3
10K
VCC-3.3V
C1
100nF
R4
220
RSTRESET#
T1
T2 T3
R5
10K
R6
10K
VCC-3.3V VCC-3.3V
R1
2K2
R2
2K2
GPIO2-T3 GPIO34-LD1 GPIO35-T2 GPIO18-LD2
X1
32.768KHz
C2
10pF
C3
10pF
RTC_X1
RTC_X2
C7
18pF
C6
18pF
X2
12MHz
X1
X2
VCC-3.3V
75
74
73
72
71
70
69
68
67
66
64
65
63
62
61
60
59
58
57
56
55
54
53
52
51
50 49
48
47
46
45
44
43 42 41 40
39
38
37
36
35 34 33 32 31
30
29
28
27 26
9
11
12
4
3
78
77
24
23
18
17
16
15
14
13
5
6
7
8
10
79
80
1
2
22
21
20
19
25
76
FTDI
81
82
83
84
85
86
87
88
89
90
91
92
93
94 95 96
97
98
99
100
STESTRESTN RESETN VPP FSOURCE GPIO52 GPIO51
GPIO21
GPIO22
GPIO23
GPIO24
D_DM
VCC3V3
VCC1V2
GPIO0
GPIO54 GPIO53
GPIO63
GPIO64
GPIO65
GPIO66
GPIO55 GND
GPIO10
GPIO9 GPIO8
GPIO12
GPIO7 GPIO6
RTC_XIO
TXON
GPIO20
GPIO19
GPIO14 GPIO13
DAC_REFP
VCC3V3
AGND
GPIO11
GPIO28
GPIO44
GPIO39
GPIO38
GPIO37
GPIO36
GPIO35
GPIO34
DRREF
D_DP
GPIO62
GPIO61
GPIO30
GPIO27
GPIO26
GPIO48
GPIO15 GPIO16
GPIO17
GPIO18
GPIO43 GPIO42
GPIO41
GPIO40
GPIO57 GPIO58
XIO
GPIO4
VCC3V3 GPIO56
GPIO1
GPIO49
GPIO2
GPIO5
NC
GPIO33
GPIO32
GPIO31
DEBUG GPIO50
GPIO3
XI/CLKIN
RTC_XI/RTC_CLKIN
GPIO47 GPIO46 GPIO45
GPIO29
GPIO25
VCC1V2
VCC3V3
H_DM
RREFSET
VCC3V3
H_DP
AGND
HRREF
VCC1V2 VCC3V3
RXIP
RXIN
TXOP
GPIO60
FT900Q
0
TP
U1
RTC_X2 RTC_X1
RESET#
R30
VCC-1.2V
FSRC
GPIO2-T3
R35
10K
R36
10K
VCC-3.3V
C42
100nF
GPIO34-LD1
GPIO35-T2
GPIO18-LD2
0Ω
C8
100nF
VCC-3.3V
C9
100nF
VCC-3.3V
C10
100nF
VCC-3.3V VCC-3.3V
C13
100nF
C39
100nF
VCC-1.2V
C41
4.7uF
VCC-1.2V
C38
10uF
VCC-1.2V
C5
100nF
VCC-1.2V

Page 20
Clicker 2 for FT90x features LTC®3586, a
highly integrated power management and
battery charger IC that includes a current
limited switching PowerPath manager.
LTC®3586 also enables battery charging
over a USB connection.
Figure 5-2: power
management and
battery charger IC
5. Power management and battery charger
