Millenium LST-310 User manual

LST-310
lighting stand
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
20.05.2016, ID: 186230

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 6
3 Features.......................................................................................................................................................... 9
4 Operating.................................................................................................................................................... 10
5 Technical specifications....................................................................................................................... 16
6 Protecting the environment.............................................................................................................. 17
Table of contents
LST-310
3

1 General notes
This user manual contains important information on the safe operation of the product. Read
and follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this product. If you sell the product to another user, be
sure that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.Symbols and signal words
General notes
lighting stand
4

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General notes
LST-310
5

2 Safety instructions
This light stand is intended to be used for the stable mounting and height-adjustable posi‐
tioning of spotlights. Use the device only as described in this user manual. Any other use or use
under other operating conditions is considered to be improper and may result in personal
injury or property damage. No liability will be assumed for damages resulting from improper
use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
lighting stand
6

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are properly disposed of and are not in
the reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the product. They could swallow the pieces and choke!
Never let children play unattended with the product.
CAUTION!
Danger of tipping when transported under load
If the stand is moved without having removed the installed device, the stand may
tip over and cause injuries and property damage.
Remove the installed device before transporting the stand.
Safety
Safety instructions
LST-310
7

CAUTION!
Danger of tipping on unsuitable surfaces
When the speaker stand is installed on soft or uneven ground, the stand may tip
over and cause injuries and property damage.
Install the stand only on even and solid surfaces.
CAUTION!
Danger of tipping due to overload
In case of overload, the stand may tip over and cause injuries and property
damage.
Never exceed the maximum load capacity specified for the stand.
Safety instructions
lighting stand
8

3 Features
Special characteristics:
nMetal construction with crossbar for up to four spotlights
nGS certified
nExtension tubes with internal chains to prevent that the tubes are pulled too far apart
nExtension tubes secured by safety bolt and cotter pin
nMounting for crossbar with TV spigot
nCrossbar: 1.20 m
nMaximum weight-bearing capacity: 18 kg
nMinimum height: 1.77 m
nMaximum height: 3.10 m
nMaximum vertical lift: 1.33 m
nWeight: 11 kg
Features
LST-310
9

4 Operating
Unpack and check carefully there is no transportation damage before using the product. Keep
the equipment packaging. To fully protect the product against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
CAUTION!
Danger of tipping when transported under load
If the stand is moved without having removed the installed device, the stand may
tip over and cause injuries and property damage.
Remove the installed device before transporting the stand.
Operating
lighting stand
10

CAUTION!
Danger of tipping on unsuitable surfaces
When the speaker stand is installed on soft or uneven ground, the stand may tip
over and cause injuries and property damage.
Install the stand only on even and solid surfaces.
CAUTION!
Danger of tipping due to overload
In case of overload, the stand may tip over and cause injuries and property
damage.
Never exceed the maximum load capacity specified for the stand.
Operating
LST-310
11

NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC floor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad
floor protectors or a carpet.
Operating
lighting stand
12

1. Unfold the feet of the tripod until the cross braces are in a horizontal position.
2. Fix this position with the safety screw on the slider to which the three feet are attached.
3. Loosen the two safety screws on the crossbar mounting at the upper end of the stand,
attach the crossbar and tighten it with the two safety screws on the mounting.
4. Pull out the two safety bolts and loosen the two safety screws on the extension tubes.
5. Pull out the upper extension tube to the desired height, insert the safety pin through the
appropriate grid holes and slide the safety cotter through the hole in the safety bolt.
6. Fix the position of the upper extension tube with the safety screw on the upper tube
clamp.
7. Pull out the lower extension tube to the desired height, insert the safety pin through the
appropriate grid holes and slide the safety cotter through the hole in the safety bolt.
8. Fix the position of the lower extension tube with the safety screw on the lower tube
clamp.
9. Tighten the Allen screws on the upper and lower tube clamps with the supplied Allen
key.
Setting up
Operating
LST-310
13

10. Attach up to four spotlights to the crossbar. Observe the instructions of the respective
manufacturers. The maximum load capacity of the truss of 18 kg must not be exceeded.
Operating
lighting stand
14

1. Remove the spotlight(s).
2. Loosen the Allen screws on the upper and lower tube clamp using the suplied Allen key.
3. Loosen the safety cotter and pull out the safety bolt on the lower extension tube.
4. Loosen the safety screw on the lower tube clamp and slide the lower extension tube all
the way down.
5. Tighten the safety screw on the lower tube clamp.
6. Loosen the safety cotter and pull out the safety bolt on the upper extension tube.
7. Loosen the safety screw on the upper tube clamp and slide the lower extension tube all
the way down.
8. Tighten the safety screw on the upper tube clamp.
9. Loosen the two safety screws on the crossbar mounting and detach the crossbar.
10. Loosen the safety screw on the slider to which the three feet are attached.
11. Fold up the feet of the tripod.
12. Pack all parts of the system in their original package, as possible, and store the package
in a dry place protected against moisture.
Dismounting
Operating
LST-310
15

5 Technical specifications
Crossbar 1.20 m
Minimum height 1.77 m
Maximum height 3.10 m
Maximum vertical lift 1.33 m
Maximum weight-bearing capacity 18 kg
Weight 8 kg
Colour Black
Technical specifications
lighting stand
16

6 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that
they are collected for recycling. Please follow the notes and markings on the packaging.
Disposal of the packaging mate‐
rial
Protecting the environment
LST-310
17

Notes
lighting stand
18

Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
