milliard 3-in-1 Kids Play Table and Chair Set with... User manual

TABLE
CHAIRS
&
for kids!for kids!
PRODUCT MANUAL

Milliard Enterprises LLC
1980 Swarthmore Ave
Lakewood, NJ 08701 USA
MADE IN CHINA
Congratulations on the purchase of your new Milliard 3-in-1 Play Table!
Now your kids have their own furniture to work and play on, as well as
spill, paint and, of course, eat. It’s sized just for them, with lots of storage
drawers to hold all their treasures where no grownups are allowed, and
you can rest easy that your family’s heirloom furniture in the rest of the
house is safe. Win – win for everyone! Enjoy Milliard products and be sure
to check out our other great items!
DISCLAIMER: Milliard™ assumes no liability or responsibility for accidents or injuries to persons or properties
associated with the improper use of this product, nor does Milliard condone prohibited or unlawful uses. This
product must be used as directed and all safety precautions must be followed at all times in accordance to federal
and local laws or regulations. Buyer assumes all risks and liability from misuse of this product and Milliard shall not
be held liable beyond the initial purchase cost of the product for any damages arising from its misuse.
Did your product arrive damaged or missing parts?
WE’RE HERE TO HELP.
Our team of dedicated customer care professionals are ready to help you
with any questions or concerns. For immediate attention, call us.
Or you can leave a voicemail or email and we guarantee you will hear back
from us within one business day.
Phone: [phone] Email: [email protected]
WARNING: REVIEW ALL WARNINGS AND INSTRUCTIONS TO
REDUCE THE RISK OF SERIOUS INJURY OR DEATH.
The table and chairs must be assembled by an adult.
Carefully inspect the table and chairs after assembly to ensure that they
are stable and that there are no exposed screws or other sharp parts.
To avoid falls or strangulation, do not place the table near a window or a
corded window treatment.
Do not allow children to climb on the table. The table may tip over or
break, which could lead to serious injury or death.
Do not allow children to remove the table top without adult assistance.
To avoid choking hazards, do not allow children under the age of three to
play with toys that contain small parts.
!

1
RIGHT CHAIR SIDE
(X2)
2
LEFT CHAIR SIDE
(X2)
3
CHAIR BACK
(X2)
4
CHAIR SEAT
(X2)
5
CHAIR SHELF
(X2)
6
SEAT SUPPORT
(X4)
7
CHAIR SHELF END
(X2)
8
SMALL BASKET
(X2)
9
SMALL BASKET
INSERT (X2)
10
LEFT TABLE
SIDE (X1)
11
RIGHT TABLE
SIDE (X1)
12
BOTTOM TABLE
SHELF (X1)
13
MIDDLE TABLE
SHELF (X2)
14
TABLE BACK
(X1)
15
TABLETOP BASE
(X1)
16
TABLETOP INSERT
(X1)
18
LARGE BASKET
INSERT (X3)
17
LARGE BASKET
(X3)
19
BASKET DIVIDER
(X3)
PARTS

ASSEMBLY
PARTS
A
BOLT
(X36)
B
DOWEL NUT
(X36)
C
DOWEL PEG
(X40)
D
LARGE SCREW
(X4)
E
CAM FASTENER
(X4)
F
CAM SCREW
(X1)
G
ANGLE FASTENER
(X4)
H
SMALL SCREW
(X4)
I
HEX/PHILIP KEY
(X1)
1
Lay one chair side (1) on a level surface. Prep it by
inserting dowel pegs (C) into all holes that do not
go through and through.
Prep the chair back (3), chair seat (4), two seat
supports (6), and the chair shelf (5) by inserting
dowel nuts (B) into all large holes on the wide sides.
Attach the chair back, chair seat, 2 seat supports
and the chair shelf in the appropriate places as
shown. (Make sure that the dowel nuts are facing
down or back, so they will not be seen from the
front when the chair is upright.)
START BY ASSEMBLING THE CHAIRS
B
C
5
3
4
6
1

ASSEMBLY
2
Insert dowel nuts into the chair back, chair seat, 2 seat supports and the chair
shelf in all holes that do not go through and through.
Attach the second chair side (2) on top by inserting the bolts (A).
Carefully turn over the chair and insert bolts into the holes on the other side.
3
Attach the chair shelf end (7)
to the chair shelf with the 2 large
screws (D).
Repeat for the second chair.
4
Place the small basket insert
(9) into the small basket (8).
B
A
A
2
C
7
D
9
8

ASSEMBLY
NOW ASSEMBLE THE TABLE
5
Lay one table side (10) on a level surface.
Prep it by inserting dowel pegs (C) into
all holes that do not go through and
through.
Prep the shelves (12) (13) by inserting
dowel nuts into all large holes on the
wide sides.
Attach the shelves, making sure to put
the bottom shelf (12) at the bottom. 10
B
C
12
13
13
6
Insert dowel pegs into all the shelf holes that do not go through and through.
Attach the second table side (11) on top by inserting the bolts.
Carefully turn over the table and insert bolts into the holes on the other side.
7
Turn the table upright and slide in the
table back (14).
C11
B
A
A
14

ASSEMBLY
8
Insert cam fasteners (E) into the
holes at the top of the table sides
with the arrows pointing upwards.
Prep the tabletop base (15) by
inserting dowel pegs into the inner
holes and screwing cam screws (F)
into the outer holes.
Turn the table upside down and
attach it to the tabletop base by
turning the cam fasteners 90
degrees, clockwise.
9
Attach the angle fasteners (G)
with the small screws (H).
E
F
C
15
G
H
10
Insert the large basket
inserts (18) into the baskets
(17). Then insert the basket
dividers (19).
17
19
18

ASSEMBLY
8
Turn the table upright. Place the
tabletop insert (16) in the tabletop.
Place the baskets on the shelves.
JOB WELL DONE!
PAT YOURSELF ON THE BACK!
16
