SHANGRI-LA SLNS2DREWA User manual

2 DRAWER NIGHT STAND
EDINBURGH COLLECTION
SLNS2DREWA, SLNS2DREBA

No
Dimensions (mm)
Qty
No
Dimensions (mm)
Qty
1
530 x 400 x 15
1
7
530 x 230.5 x 20
1
2
530 x 400 x 15
1
8
530 x 230.5 x 20
1
3
399 x 380 x 15
1
9
350 x 150 x 12
2
4
399 x 380 x 15
1
10
350 x 150 x 12
2
5
508 x 390 x 3
1
11
449 x 186 x 12
2
6
370 x 220 x 80
2
12
459 x 347 x 3
2
COMPONENTS

Hardware
Aø6x35mm (x12)
Bø15x9mm (x12)
CM4x35mm (x4)
Dø8x30mm (x8)
EM4x30mm (x8)
F(x2)
G (x2)
H(x2)
I (x2)
JM3.5x12mm (x24)
K M3.5x12mm (x4)
L(x4)
MM6x12mm (x8)
N(x2)
O(x1)

Step 1: Using a Phillips head screwdriver (not supplied), secure F and G rails to parts 3 and 4
respectively with J screws.
Insert A into parts 1,7,and 8 as shown below.
A (x12)
F (x2)
G (x2)
J(x12)
ASSEMBLY

Step 2: Using a Phillips head screwdriver, secure parts 9,10, and 11 with E screws. Slide part
12 along the grooves on parts 9,10 and 11.
Secure H and I rails onto the assembly with J screws. Align part 7with the assembly.
Ensuring the arrows on each Bpiece are pointing to the corresponding Apiece, insert B
pieces into parts labelled 9and 10 then secure Bto A. Attach the Nhandle with Kscrews.
Repeat the whole process using part 8 to complete two drawer assemblies.
B (x8)
E (x8)
H (x2)
I (x2)
J (x12)
K (x4)
N (x2)
x2

Step 3:
B (x4)
D (x4)

Step 4:
Step 5:
C (x4)
D (x4)

Step 6:
M(x8)
O(x1)

Step 7:
L(x4)
Step 8:

Assembly complete.

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
