Milwaukee M18 FUEL FHACOD32 User manual

OPERATOR'S MANUAL
PLUS
Cat. No.
M18 FHACOD32
WARNING
To reduce the risk of injury, user must read and understand operator's manual.
M18 FUEL™ 32MM (1-1/4") SDS PLUS D-HANDLE ROTARY
HAMMER WITH ONE-KEY™

2
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING
Read all safety warnings, instruc-
-
•
•Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
•
tions provided with this power tool. Failure to
follow all instructions listed below may result in
Save all
warnings and instructions for future reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-oper-
ated (cordless) power tool.
WORK AREA SAFETY
ELECTRICAL SAFETY
Do not operate power tools in explosive atmo-
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep children and bystanders away while operat-
ing a power tool. Distractions can cause you to lose
control.
PERSONAL SAFETY
•Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adaptor plugs with earthed (grounded) power
tools.
reduce risk of electric shock.
•Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
•Do not expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
•Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
•When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
•
•Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A
moment of inattention while operating power tools
may result in serious personal injury.
•Use personal protective equipment. Always
wear eye protection. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions
will reduce personal injuries.
•Prevent unintentional starting. Ensure the switch
source and/or battery pack, picking up or carrying
the tool.
the switch or energising power tools that have the
switch on invites accidents.
POWER TOOL USE AND CARE
•Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
•Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
•
•If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
•Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
taking into account the working conditions and
the work to be performed. Use of the power tool
result in a hazardous situation.
BATTERY TOOL USE AND CARE
•Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
manufacturer. A charger that is suitable for one type
with another battery pack.
battery packs. Use of any other battery packs may
•Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which
it was designed.
•Do not use the power tool if the switch does not turn
Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
•Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
•Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
•Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
have the power tool repaired before use. Many ac-
cidents are caused by poorly maintained power tools.
•Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
•Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
If operating a power tool in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of a RCD reduces
the risk of electric shock.
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.

3
SERVICE
Safety instructions for all operations
SPECIFIC SAFETY RULES FOR
ROTARY HAMMER
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
•Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
•Wear ear protectors.Exposure to noise can cause
hearing loss.
•Use auxiliary handle(s), if supplied with the tool.
Loss of control can cause personal injury.
•Hold the power tool by insulated gripping sur-
faces, when performing an operation where the
cutting accessory may contact hidden wiring.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and
could give the operator an electric shock.
•Keep hands away from all cutting edges and
moving parts.
Safety instructions when using long drill bits
•Always start drilling at low speed and with the
bit tip in contact with the workpiece. At higher
speeds, the bit is likely to bend if allowed to rotate
freely without contacting the workpiece, resulting
in personal injury.
•Apply pressure only in direct line with the bit
and do not apply excessive pressure. Bits can
bend, causing breakage or loss of control, resulting
in personal injury.
•
WARNING
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals known to
cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
•Chemical Burn Hazard. Keep coin cell battery
away from children.
•lead from lead-based paint
•crystalline silica from bricks and cement and other
masonry products, and
•arsenic and chromium from chemically-treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
as those dust masks that are specially designed to
SPECIFICATIONS
Cat. No........................................
Volts............................................................
Battery Type .................................................
Charger Type................................................
No Load RPM................................................
BPM............................................................
Type..........................................................
Capacities
Drill Only*
Steel ..............................................
Rotary Hammer (Concrete)
Wood ..........................................
Carbide Tipped Percussion Bit ...
Recommended Ambient
Core Bit.............................................
*Requires chuck adaptor kit
Operating Temperature...................
•When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal
to another. Shorting the battery terminals together
•Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact ac-
cidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
•
•
•
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause
explosion.
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
WARNING
To reduce the risk of injury, when
working in dusty situations, wear
appropriate respiratory protection or use a
suitable dust extraction solution.
Cut embedded rebar only if this operation does
not affect the integrity of the building. If in
doubt, consult a structural engineer. Tool
operator fully responsible for adverse
structural effects.
M18 FHACOD32
18 V DC
M18™
M18™
0 - 810
0 - 4,650
SDS Plus
13 mm (1/2")
32 mm (1-1/4")
32 mm (1-1/4")
76 mm (3")
-17°C to 51°C
•
•
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE®service facility for a
replacement.
Always use common sense and be cautious
when using tools. It is not possible to anticipate
every situation that could result in a dangerous
outcome. Do not use this tool if you do not
understand these operating instructions or you feel
the work is beyond your capability; contact
MILWAUKEE®Tool or a trained professional for
additional information or training.
WARNING
Do not charge non-rechargeable
batteries.
WARNING
T
injury
o reduce
, and product damage
the risk of fire, personal
due to
a short circuit, never immerse your tool, battery
pack or charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a
short circuit.
ADDITIONAL BATTERY SAFETY RULES

SYMBOLOGY
Volts
Direct Current
No Load Revolutions per Minute (RPM)
BPM
Blows per Minute (BPM)
Anti-vibration System
4
Setting the Depth Gauge
1.
2.
Drilling Depth
Press in the clamping lever.
Slide the depth gauge rod backward or forward
until it is set for the desired depth.
NOTE: The drilling depth is the distance between
the tip of the bit and the tip of the depth gauge rod.
3. Release the clamping lever.
WARNING
Always remove
changing or removing accesso
battery pack before
-
-
mended for this tool. Others may be hazardous.
Installing Drill Bits and Chisels
NOTE: Only use accessories with SDS or SDS Plus
shanks.
Be sure that the shank of the bit is clean. Dirt particles
may cause the bit to line up improperly. Do not use
bits larger than the maximum recommended capacity
of the drill because gear damage or motor overload-
ing may result. For best performance, be sure that
the bit is properly sharpened and the shank is lightly
greased before use.
FUNCTIONAL DESCRIPTION
1. Side handle
2. Clamping lever
3. Depth gauge rod
4. SDS Plus bit
holder
5. Release collar
6. Mode selector
7. Trigger
1
2
3
45
6
7
8
9
12 11
10
8. Forward/reverse swtich
9. Handle
10.AUTOSTOP™ indicator
LED
11. ONE-KEY™ indicator
LED
12.Dust extractor
connection
2. Rotate the side handle to the desired position.
3. Tighten the side handle grip securely.
For use with the Dust Extractor
Adjusting the Side Handle Position
1. Loosen the side handle by unscrewing the side
handle grip until the side handle rotates freely.
Read operator's manual.
Regulatory Compliance Mark (RCM).
This product meets applicable
regulatory requirements.
Do not dispose of electric tools
together with household waste
material. Electric tools and electronic
equipment that have reached the end
of their life must be collected
separately and returned to an
environmentally compatible recycling
facility.
ASSEMBLY
WARNING
Inserting/ Removing the Battery
WARNING
the battery pack
Always lock the trigger or remove
any time the tool
is not in use.
WARNING
reco
Only use
mmended
accessorie
for thi
s
s tool. Others
may be hazardous.
To reduce the risk of injury, always use a side
handle when using this tool. Always brace or
hold securely.
Recharge only with the charger
specified for the battery. For
specific charging instructions, read the
operator’s manual supplied with your charger
and battery.
To insert the battery, slide the pack into the body of
the tool. Make sure it latches securely into place.
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
V
The MILWAUKEE®M18 FDDEL32 32mm
Dedicated Dust Extractor plugs directly into the
32mm SDS PLUS Rotary Hammer. For Dust
Extractor assembly and operation, refer to the Dust
Extractor manual.

1. Insert the bit or chisel into the nose of the tool.
2. Rotate bit slowly until it aligns with the locking
mechanism.
3. Push bit into tool until it locks.
4.
5. To remove bits and chisels, pull bit holder release
collar toward the rear of tool and remove bit.
ONE-KEY™ Indicator
Solid Blue
Blinking Blue
Wireless mode is active and ready
app.
Tool is actively communicating with
the ONE-KEY™ app.
ONE-KEY™
Blinking Red Tool is in security lockout and can
be unlocked by the owner via the
ONE-KEY™ app.
WARNING
Do not touch the drill bits or
chisels with bare hands
immediately after drilling; they may be hot and
could burn skin.
Check that the bit is locked properly; it should be
possible to pull the bit back and forth slightly
(about 6.3mm (1/4")).
5
OPERATION
WARNING
To reduce the risk of injury, keep hands away
from the bit and all moving parts.
Always use a side handle when using this tool.
Always brace or hold securely.
Selecting Action
1. For rotation only, rotate the
mode selector so the arrow
on the lever points to the twist
drill symbol.
2. For rotary hammering, rotate
the mode selector so the ar-
row points to the hammer and
twist drill symbol.
3. For hammering only, rotate
the mode selector so the arrow points to the ham-
mer symbol.
4. To freely rotate the bit to the desired angle for
hammering only, rotate the mode selector to the
Starting, Stopping and Controlling Speed
symbol. Then, follow step 3.
NOTE:To engage the hammering mechanism, main-
tain pressure on the bit. When pressure on the bit is
released, the hammering action will stop.
Using the Forward/Reverse Switch
1.
2.
3.
Operating
Always remove battery pack
before changing or removing
accessories. Only use accessories specifically
recommended for this tool. Others may be
hazardous.
Always use personal protective equipment.
Always wear eye protection marked to comply
with AS/NZS 1337.1.
When working in dusty situations, wear
appropriate respiratory protection or use a
suitable dust extraction solution.
The forward/reverse switch may be set to three
positions: forward, reverse and lock. Always allow
the motor to come to a complete stop before using
the forward/reverse switch to avoid damage to the
tool.
For forward (clockwise) rotation, push in the
forward/ reverse switch from the right side of the
tool. Check the direction of rotation before use.
For reverse (anticlockwise) rotation, push in the
forward/reverse switch from the left side of the tool.
Check direction of rotation before use.
To lock the trigger, push the forward/reverse switch
to the centre position. The trigger will not work while
the forward/reverse switch is in the centre locked
position. Always lock the trigger or remove the
battery pack any time the tool is not in use.
For operation when using the Dust Extractor, refer
to the Dust Extractor manual.
To start the tool, grasp the handle(s) firmly and
pull the trigger.
NOTE: An LED is turned on when the trigger is
pulled and will go off shortly after the trigger is
released.
To vary the speed, increase or decrease the
pressure on the trigger. The further the trigger is
pulled, the greater the speed.
To stop the tool, release the trigger. Ensure the
tool has come to a complete stop before laying
the tool down.
Position the tool, grasp the handles firmly and pull
the trigger. Always hold the tool securely using both
handles to maintain control. This tool has been
designed to achieve top performance with only
moderate pressure. Let the tool do the work.
If the speed begins to drop off when drilling large or
deep holes, pull the bit partially out of the hole while
the tool is running to help clear dust. Do not use
water to settle the dust since it will clog the bit flutes
and tend to make the bit bind in the hole. If the bit
should bind, a built-in, non-adjustable slip clutch
prevents the bit from turning. If this occurs, stop the
tool, free the bit and begin again.
The AUTOSTOP™ control feature senses a bind
and when the tool turns too much in a bind up
situation, the electronics shut the tool off. There is
an onboard light that will blink when AUTOSTOP™
activates.
NOTE: Applying greater pressure does not
increase the tool's effectiveness. If the applied
working pressure is too high, the shock absorber
will be pushed together making the vibrations to the
handle noticeably stronger.
To learn more about the ONE-KEY™ functionality
for this tool, go to
https://www.milwaukeetool.com.au/innovation/one-
key/
To download the ONE-KEY™ app, visit the App
Store or Google Play from your smart device.

6
APPLICATIONS
WARNING
T
check work area for hidden
o reduce the risk of electric shock,
pipes
and wires before drilling.
Selecting Bits
When selecting a bit, use the right type for your job.
For best performance, always use sharp bits.
Drilling
1. Before drilling, be sure the workpiece is clamped
securely. Use backing material to prevent damage
to the workpiece during breakthrough.
2.
3. Always apply pressure in line with the bit. Use
enough pressure to keep the drill biting, but do
not push hard enough to stall the motor.
4. Reduce pressure and ease the bit through the last
part of the hole. While the tool is still running, pull
the bit out of the hole to prevent jamming.
Drilling in Wood, Composition Materials
and Plastic
(Use chuck adaptor kit)
ONE-KEY™
WARNING
Chemical Burn Hazard.
This device contains a
lithium button/coin cell battery. A new
or used battery can cause severe in-
ternal burns and lead to death in as
little as 2 hours if swallowed or enters the body.
Always secure the battery cover. If it does not
close securely, stop using the device, remove the
batteries, and keep it away from children. If you
think batteries may have been swallowed or en-
tered the body, seek immediate medical attention.
Internal Coin Cell Battery
An internal coin cell battery is used to facilitate full
ONE-KEY™ functionality.
To replace the coin cell battery:
1. Remove the battery pack. The coin cell battery
door is located under the battery pack.
2. Remove the screw(s) and open the coin cell bat-
tery door.
3. Remove the old coin cell battery, keep it away from
children, and dispose of it properly.
4. Insert the new coin cell battery (3V CR2032), with
the positive side facing up.
5. Close the battery door and tighten the screw(s)
securely.
Too little Correct Too much
force force force
Operator Force
The Anti-Vibration System provides the operator
with comfort without sacrificing power or
performance. Ideal operator force compresses the
bellows slightly and allows the tool to work
aggressively while the handle remains steady.
Excessive force compresses the bellows
significantly and reduces vibration dampening.
Users will be able to feel the difference and should
adjust the force to the handle accordingly.
-
Maintaining Tool
MAINTENANCE
WARNING
To reduce the risk of injury,
always unplug the charger and
remove the battery pack from the charger or
tool before performing any maintenance. Never
disassemble the tool, battery pack or charger.
Contact a MILWAUKEE®service facility for ALL
repairs.
Keep your tool, battery pack and charger in good
repair by adopting a regular maintenance program.
Inspect your tool for issues such as undue noise,
misalignment or binding of moving parts, breakage
of parts, or any other condition that may affect the
tool operation. Return the tool, battery pack, and
charger to a MILWAUKEE®service facility for repair.
After six months to one year, depending on use,
return the tool, battery pack and charger to a
MILWAUKEE®service facility for inspection.
If the tool does not start or operate at full power with
a fully charged battery pack, clean the contacts on
the battery pack. If the tool still does not work
properly, return the tool, charger and battery pack,
to a MILWAUKEE®service facility for repairs.
WARNING
Use only recommended accesso-
ries. Others may be hazardous.
Cleaning
Repairs
For repairs, return the tool, battery pack and charger
to the nearest nearest authorised service centre.
ACCESSORIES
Clean dust and debris from vents. Keep handles
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain
cleaning agents and solvents are harmful to plastics
and other insulated parts. Some of these include
petrol, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and
household detergents containing ammonia. Never
use flammable or combustible solvents around
tools.
For a complete listing of accessories, go online to
milwaukeetool.com.au / milwaukeetool.co.nz or
contact a distributor.
When drilling in wood, composition materials and
plastic, start the drill slowly, gradually increasing
speed as you drill. When drilling into wood, use
wood augers or twist drill bits. Always use sharp
bits. When using twist drill bits, pull the bit out of the
hole frequently to clear chips from the bit flutes. To
reduce the chance of splintering, back work with a
piece of scrap wood. Select low speeds for plastics
with a low melting point.
When starting a hole, place the drill bit on the
work surface and apply firm pressure. Begin
drilling at a slow speed, gradually increasing the
speed as you drill.
Cut embedded rebar only if this operation does
not affect the integrity of the building. If in
doubt, consult a structural engineer. Tool
operator fully responsible for adverse structural

961016371-01(A)
WARRANTY - AUSTRALIA and NEW ZEALAND
SERVICE - AUSTRALIA and NEW ZEALAND
MILWAUKEE®prides itself in producing a premium quality product that is Nothing But Heavy DutyTM.
Your satisfaction with our products is very important to us! If you encounter any problems with the
operation of this tool, please contact your authorised MILWAUKEE®dealer.
For a list of MILWAUKEE®dealers, guarantee or service agents please contact MILWAUKEE®
Customer Service or visit our website.
(Australia Toll Free Telephone Number 1300 645 928)
(New Zealand Toll Free Telephone Number 0800 645 928)
or visit milwaukeetool.com.au/milwaukeetool.co.nz.
Please refer to Australian and New Zealand warranty supplied with tool. This warranty applies only to
product sold by authorised dealers in Australia and New Zealand.
DESIGNED BY MILWAUKEE ELECTRIC TOOL CORP.
PROFESSIONALLY MADE IN CHINA
PRINTED IN CHINA
Milwaukee Electric Tool Corporation
13135 West Lisbon Road, Brookfield, Wisconsin U.S.A. 53005
Milwaukee Tool (Australia)
26 - 40 Nina Link, Dandenong South,
Victoria, 3175, Australia
Milwaukee Tool (New Zealand)
274 Church Street, Penrose,
Auckland, 1061, New Zealand
