MIMAKI JV330 Series User manual

You can also download the latest manual from official website.
MIMAKI ENGINEERING CO., LTD.
https://mimaki.com/ D203599-11
Original instructions

TABLE OF CONTENTS
2
Introduction ..................................................................................... 7
To ensure safe use ......................................................................... 9
Symbols ................................................................................................ 9
Usage Precautions ............................................................................. 10
Ink or any Other Liquid Used with the Machine ............................ 14
Ink Specifications................................................................................ 15
Restrictions concerning the product ................................................... 15
Installation Precautions................................................................. 17
Installation Space ............................................................................... 18
When Relocating This Machine .......................................................... 18
Safety Interlocks ........................................................................... 19
Warning Label............................................................................... 20
Chapter 1 Before Use
1.1 Part Names and Functions ..................................................... 24
Front ................................................................................................... 24
Rear and Right Side View................................................................... 26
Ink supply unit..................................................................................... 27
Carriage .............................................................................................. 27
Capping station................................................................................... 27
Pinch Rollers and Grit Rollers............................................................. 28
Platen.................................................................................................. 29
Media sensor ...................................................................................... 29
Power supply switch ........................................................................... 29
Operating panel .................................................................................. 31
1.2 Connecting the Power Cable .................................................. 34
Turning On the Power......................................................................... 34
Turning Off the Power......................................................................... 35
1.3 Connecting a PC to the Product ............................................. 37
Using a LAN Cable ............................................................................. 37
Using a USB Cable............................................................................. 38
1.4 System Configuration ............................................................. 39
Installing the Mimaki Driver................................................................. 40
Installing RIP Software ....................................................................... 40
Obtaining Color Profiles...................................................................... 40
Setting Up RIP Software..................................................................... 41
1.5 Ink Replacement Method........................................................ 43
When Ink Near End is Displayed ........................................................ 43
When Ink End is Displayed................................................................. 43
Replacing Ink ...................................................................................... 44
Chapter 2 Printing
2.1 Print Process .......................................................................... 50
2.2 Adjust print head height. ......................................................... 53

3
2.3 Adjusting the Pinch Roller Positions (CJV)............................. 54
1,600 mm size .................................................................................... 55
1,300 mm size .................................................................................... 56
2.4 Loading the Media .................................................................. 57
Media .................................................................................................. 57
Take-up unit........................................................................................ 58
Feed unit (JV/CJV) ............................................................................. 61
Loading the Roll Media ....................................................................... 62
Loading the Leaf Media (CJV) ............................................................ 69
Registering the Media......................................................................... 72
2.5 Setting the Pressure and Number of Pinch Rollers to Use (CJV)
...................................................................................................... 74
2.6 Setting the Heater Temperature ............................................. 75
2.7 Test Printing............................................................................ 76
Changing the Layout Direction for Test Printing ................................. 76
Printing Defects .................................................................................. 77
2.8 Head Cleaning ........................................................................ 78
2.9 Feed Correction ...................................................................... 79
Feed Correction Procedure ................................................................ 79
2.10 Correcting the Drop Position................................................. 81
Drop Position Correction Procedure ................................................... 81
2.11 Preparing RIP Data............................................................... 83
2.12 Printing.................................................................................. 85
Changing the Origin............................................................................ 85
Starting Printing .................................................................................. 85
Stopping Printing (Data Clear)............................................................ 86
2.13 Cutting the Media.................................................................. 87
V-shaped cutting................................................................................. 87
Chapter 3 Cutting
3.1 Cutting Process ...................................................................... 90
3.2 Installing Cutting Tools ........................................................... 92
Using the Cutter.................................................................................. 92
Using a Pen ........................................................................................ 96
3.3 Setting the Cutting Conditions .............................................. 100
3.4 Test Cutting .......................................................................... 101
3.5 Cutting the Cutting Data ....................................................... 102
Changing the Origin.......................................................................... 102
Starting Cutting ................................................................................. 102
Stopping Cutting (Data Clear)........................................................... 103
Retracting the Cutter Unit ................................................................. 103
Chapter 4 Cutting Data with Register Marks
4.1 Process for Cutting Data with Register Marks ...................... 106

4
4.2 Creating Register Marks ....................................................... 108
Register Marks.................................................................................. 108
Register Mark Size ........................................................................... 109
Spacing Between Register Marks..................................................... 109
Reading Range of Register Marks.................................................... 110
No-Plotting Areas Around Register Marks........................................ 112
Combined Operations of Printing and Cutting .................................. 112
4.3 Setting Mark Detection Conditions ....................................... 113
4.4 Detecting the Position of the Register Mark Origin............... 114
4.5 ID Cut Process...................................................................... 115
Chapter 5 Using the XY Slitter
5.1 Slitting Process ..................................................................... 118
Slitting Simultaneously With Printing ................................................ 118
Clamp lever of the XY slitter ............................................................. 119
X cutter ............................................................................................. 120
Media chute ...................................................................................... 121
5.2 Loading the Media ................................................................ 122
5.3 Printing Guide (Slit) Line....................................................... 127
5.4 Mounting the X Cutter........................................................... 130
5.5 Placing the Media Chute....................................................... 134
5.6 Printing RIP Data .................................................................. 135
Starting Printing ................................................................................ 135
5.7 Troubleshooting .................................................................... 137
If a media jam occurs in the XY slitter .............................................. 137
If the Y slit position is offset .............................................................. 138
Chapter 6 Settings
6.1 Media Setting Menu.............................................................. 140
6.2 Maintenance menu ............................................................... 142
Registering nozzle recovery ............................................................. 144
Nozzle check .................................................................................... 145
6.3 Function Setting Menu.......................................................... 146
6.4 Environment Setting Menu ................................................... 149
6.5 Machine Status Menu ........................................................... 150
6.6 Cutting Menu ........................................................................ 151
Copying the last data ........................................................................ 154
Preventing uncut media .................................................................... 154
Chapter 7 Maintenance
7.1 Maintenance Precautions ..................................................... 158

5
7.2 Maintenance Items and Timing............................................. 159
Items Required for Maintenance....................................................... 159
7.3 Maintenance Methods .......................................................... 160
Ink Maintenance ............................................................................... 160
Cap Rubber Cleaning ....................................................................... 160
Carriage Underside Cleaning ........................................................... 161
Cloth Wiper Area Cleaning ............................................................... 162
NCU Cleaning................................................................................... 163
Automatic Correction Sensor (DAS) Cleaning.................................. 164
Ink Discharge Channel Cleaning ...................................................... 165
Media Sensor Cleaning .................................................................... 166
Media Cutter Cleaning ...................................................................... 166
Media Holder Cleaning ..................................................................... 168
Jam Sensor Detecting Plate Cleaning .............................................. 168
Platen Cleaning ................................................................................ 169
Cover (Exterior) Cleaning ................................................................. 170
Blowing Fan Filter Cleaning.............................................................. 170
When this printer is left unused for a long time................................. 171
7.4 Consumable Item Replacement ........................................... 174
Cloth Wiper Replacement................................................................. 174
Cap Replacement ............................................................................. 176
Replace absorbent material around carriage.................................... 177
Exhaust Fan Filter Replacement ...................................................... 180
Blowing Fan Filter Replacement....................................................... 181
Pinch Roller Replacement ................................................................ 182
Media Holder Replacement .............................................................. 183
Media Cutter Replacement ............................................................... 185
XY Slitter Y Cutter Replacement (JV/CJV) ....................................... 186
XY Slitter X Cutter Replacement (JV/CJV) ....................................... 187
Media Edge Guide Film Replacement (TS) ...................................... 190
Ink supply unit ink absorber replacement ......................................... 191
Waste Ink Tank Replacement........................................................... 192
About the Media Cutter (CJV)........................................................... 195
Pen Line Replacement (CJV) ........................................................... 195
Chapter 8 Troubleshooting
8.1 Troubleshooting .................................................................... 198
The power does not turn on.............................................................. 198
Printing is not possible...................................................................... 198
The media jams or the media is dirty................................................ 198
Image defects occur. ........................................................................ 199
The heater temperature does not rise to the specified value............ 200
The ink has leaked out...................................................................... 201
Cutting Related (CJV)....................................................................... 201
8.2 Problems Causing Messages to Appear .............................. 207
Warning Messages ........................................................................... 207
Ink error ............................................................................................ 208
Error message .................................................................................. 209
SYSTEM HALT................................................................................. 218

6
Chapter 9 Appendix
9.1 Specifications........................................................................ 220
9.2 Specifications (Cutting)......................................................... 224
9.3 Specifications (XY Slitter) ..................................................... 225
9.4 Relay Box ............................................................................. 226
9.5 LICENSE Library .................................................................. 227

Introduction
7
Introduction
Thank you for purchasing the Inkjet printer 330 series.
Read this operating manual (“this document” hereinafter) thoroughly and make sure you understand its
contents to ensure safe and correct use of the product.
Please note that the illustrations contained in this manual are intended to show functions, procedures, or
operations and may sometimes differ slightly from the actual machine.
Adobe, the Adobe logo, Acrobat, Illustrator, Photoshop, and PostScript are the trademarks or registered
trademarks of Adobe Incorporated in the United States and other countries.
RasterLink is the trademark or registered trademark of MIMAKI ENGINEERING CO., LTD. in Japan and in
other countries.
Other company and product names mentioned herein are the trademarks or registered trademarks of the
respective companies in Japan and in other countries.
Unauthorized reproduction of any portion of this document is strictly prohibited.
© 2022 MIMAKI ENGINEERING Co., Ltd.
lDISCLAIMERS
• MIMAKI ENGINEERING ACCEPTS NO LIABILITY FOR DAMAGES ARISING DIRECTLY OR
INDIRECTLY FROM THE USE OF THE 330 series ("THIS MACHINE" HEREINAFTER), WHETHER OR
NOT THE PRODUCT IS FAULTY. MIMAKI ENGINEERING REJECTS ALL LIABILITY FOR DAMAGES,
DIRECT OR INDIRECT, RESULTING FROM THE USE OF THIS MACHINE.
• MIMAKI ENGINEERING REJECTS ALL LIABILITY FOR DAMAGES, DIRECT OR INDIRECT,
ATTRIBUTABLE TO MATERIALS CREATED WHILE USING THIS MACHINE.
• USING THIS MACHINE IN CONJUNCTION WITH DEVICES OTHER THAN THOSE RECOMMENDED
BY MIMAKI ENGINEERING MAY RESULT IN FIRE OR ACCIDENTS. SUCH INCIDENTS ARE NOT
COVERED BY THE PRODUCT WARRANTY. MIMAKI ENGINEERING REJECTS ALL LIABILITY FOR
DAMAGES, DIRECT OR INDIRECT, ARISING FROM SUCH INCIDENTS.
• USE ONLY GENUINE MIMAKI ENGINEERING INK AND MAINTENANCE LIQUID. USE OF OTHER
PRODUCTS MAY RESULT IN FAILURES OR REDUCE PRINT QUALITY. SUCH INCIDENTS ARE
NOT COVERED BY THE PRODUCT WARRANTY. MIMAKI ENGINEERING REJECTS ALL LIABILITY
FOR DAMAGES, DIRECT OR INDIRECT, ARISING FROM SUCH INCIDENTS.
• DO NOT ATTEMPT TO REFILL THE INK PACKS WITH UNAUTHORIZED INK. SUCH INCIDENTS ARE
NOT COVERED BY THE PRODUCT WARRANTY. MIMAKI ENGINEERING REJECTS ALL LIABILITY
FOR DAMAGES, DIRECT OR INDIRECT, ARISING FROM SUCH INCIDENTS.
lTV and radio interference
• This product emits high-frequency electromagnetic radiation while operating. Under certain
circumstances, this may result in TV or radio interference. We make no guarantee that this
machine will not affect special radio or TV equipment.
If radio or TV interference occurs, check the radio or TV reception after turning off this machine. If the
interference disappears when the power is turned off, this machine is likely to be the cause of the
interference.
Try any of the following solutions or combinations of these solutions:
• Change the orientation of the TV or radio antenna to find a position where interference does not occur.
• Move the TV or radio away from this machine.
• Plug the TV or radio into a power outlet on a power circuit other than the power circuit to which this
machine is connected.

Introduction
8
lFCC (Federal Communications Commission) regulations
This product has been tested and certified to comply with restrictions applying to Class A digital devices
under Part 15 of the FCC regulations. These restrictions are designed to provide suitable protection from
harmful interference when the printer is used in commercial environments.
This product may generate, use, or emit radio frequency energy and may cause harmful interference with
radio communications if not installed or used in accordance with the operating manual.
Use of this product in residential areas may cause harmful interference. If so, the user is responsible for
rectifying such interference.
• Use only the cables recommended by Mimaki Engineering when connecting to this product. Use
of other cables may cause the product to exceed the restrictions stipulated by FCC regulations.
To maintain compliance with FCC regulations, use the cables recommended by Mimaki
Engineering.

To ensure safe use
9
To ensure safe use
Symbols
In this manual, the symbols indicate and explain precautions. Make sure you fully understand the meaning of
each symbol and use the machine safely and correctly.
Explanation
Warning Indicates a potential hazard that may result in death or serious injury
if handled improperly or if instructions are disregarded.
Caution Indicates a potential hazard that may result in minor or moderate
injury if handled improperly or if instructions are disregarded.
Notice Indicates a potential hazard that may result in property damage if
handled improperly or if instructions are disregarded.
Warning sign Indicates something that requires attention. Warning specifics are
drawn inside the symbol.
Mandatory action
sign
Indicates an action that must be carried out. The specifics of the
mandatory action are drawn inside the symbol.
Prohibition sign Indicates a prohibited action. The specifics of the prohibited action
are drawn inside the symbol.
Important Indicates important information related to use of this machine.
Tip Indicates useful reference information.
Reference
information
Indicates the corresponding page for related information.

To ensure safe use
10
Usage Precautions
lIn the event of abnormal conditions
• In the event of abnormal conditions such as smoke or unusual odor, turn off the main power
immediately and unplug the power cable. Continuing to use the product under these conditions
may result in failure, electric shock, or fire. Once you have confirmed that smoke is no longer
being emitted, contact your local dealer or our service office. Never attempt to repair the product
yourself. Doing so is hazardous.
• Immediately wipe off any ink, maintenance liquid, waste ink, or other liquid used with the
product that comes into contact with your skin. Then wash using soap, and rinse with plenty of
water. Failure to wash off ink may result in skin inflammation. If your skin becomes irritated or
painful, seek medical attention immediately.
• If ink, maintenance liquid, waste ink, or any other liquid used in the product comes into contact
with your eyes, rinse immediately with plenty of clean water. Rinse for at least 15 minutes. If you
wear contact lenses and they can be easily removed, remove after rinsing for at least 15
minutes with clean water. Be sure to also rinse the undersides of your eyelids. Failure to rinse
off ink may result in blindness or impaired vision. If your eyes become irritated or painful, seek
medical attention immediately.
• If ink, maintenance liquid, waste ink, or any other liquid used in the product enters your mouth or
is swallowed, gargle with water immediately. Do not induce vomiting. Seek medical attention
promptly. Inducing vomiting may cause liquid to enter the airway.
• If a large amount of vapor is inhaled, move to a well-ventilated area, keep warm, and rest in a
posture that allows easy breathing. If the condition does not improve, seek medical attention
promptly.
• If an ink leak occurs, turn off the main power immediately and unplug the power cable. Then,
contact your local dealer or our service office.

To ensure safe use
11
lPower supply precautions
• Use the power cable provided. Otherwise there is a risk of failure, electric shock, or fire. Do not
use the power cable with other electronic devices.
• Always grasp the plug when unplugging the power cable. Pulling on the power cable itself may
damage the cable and result in failure, electric shock, or fire.
• Do not use the power plug with dust on it. Otherwise there is a risk of failure, electric shock, or
fire.
• Avoid touching the blade of the power plug with a metal object. Otherwise there is a risk of
failure, electric shock, or fire.
• Do not attempt to modify the cable. Avoid damaging the cable. Avoid placing heavy objects on
the power cable or pulling on or exposing the cable to heat. Doing so may damage the cable,
resulting in electric shock or fire.
• Do not use extension cords or multi-outlet extension cords. Otherwise there is a risk of failure,
electric shock, or fire.
• Do not use if the power cable appears to be damaged or the core wire has an exposed or
broken core. Otherwise there is a risk of failure, electric shock, or fire.
• Do not handle the power plug with wet hands. There is a risk of electric shock.
• Plug the power cable plug into a grounded power outlet. Otherwise there is a risk of failure,
electric shock, or fire.
• When installing electrical outlets, perform grounding work to prevent electric shock. All electrical
work (Class C grounding work; formerly Type 3 grounding work) must be handled by a licensed
electrician.
• Do not turn off the main power supply. Turning off the main power supply will disable the
automatic maintenance function (including nozzle clogging prevention function and ink
discharge channel cleaning function). This will increase the risk of print defects (e.g., nozzle
clogging, deflection).
• Use this machine with a power supply that meets specifications.
• Be sure to plug the power cable into a power outlet close to the machine. Insert the power plug
blade securely.
• When connecting the power cable, check the input voltage of the power outlet and the capacity
of the breaker. Also, connect each cable to a separate power source with an independent
breaker. Connecting to power outlets linked with the same breaker may trip the breaker.

To ensure safe use
12
lCaution regarding moving parts
• Keep parts of the body such as the face and hands away from moving parts. Also keep clothing
(e.g., loose clothing and accessories) that may impede work away from the machine. Failure to
do so may result in injury.
• Long hair should be tied back. Failure to do so may result in injury.
lDo not disassemble or repair
• Do not attempt to disassemble or repair this machine. Otherwise there is a risk of failure, electric
shock, or fire.
lHandling the cutter
• Avoid touching the cutter blade. Failure to do so may result in injury.
• Do not shake or swing the cutter holder. Doing so may cause the blade to come off.
lHeater
• The heater becomes extremely hot. Do not touch with bare hands.
• Condensation may form on the print head nozzle surface depending on the ambient
temperature and humidity. The formation of condensation may cause printing defects (e.g.,
nozzle clogging or deflection). Perform head cleaning if any printing defects (e.g., nozzle
clogging or deflection) occur during printing. "Head Cleaning"(P. 78)
Set the platen heater to a temperature not exceeding 35 °C, and ensure that the ambient
temperature is within the permissible operating temperature range (20 to 30 °C). "Installation
Precautions"(P. 17)
lOther usage precautions
• Keep children away from this machine.
• Printing may show through from the underside depending on the media type and media storage
method after printing (such as the load due to placing flat media that have been rolled up).
Perform a test beforehand to check that print does not show through from the underside.

To ensure safe use
13
lDisposing of the product
• Please contact your local retailer or service agent.
• When disposing of the product yourself, contact an industrial waste disposal operator or dispose
of the product in accordance with local laws and regulations.

Ink or any Other Liquid Used with the Machine
14
Ink or any Other Liquid Used with the
Machine
Precautions regarding ink, maintenance liquid, or other liquids used with this machine are indicated on the
containers. Thoroughly read them and make sure you understand the contents.
• Take steps to prevent leakage into natural water systems or domestic wastewater. Some
constituents are toxic to aquatic life.
• Be sure to read the safety data sheet (SDS) before use. https://mimaki.com/supply/sds/
• Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when
handling ink, maintenance liquid, waste ink, or other solutions used with this machine. Leaking
ink may adhere to the skin or get into the eyes or mouth.
• Do not subject Ink eco-case to strong shocks or violent shaking. Do not attempt to refill the ink.
Leaking ink may adhere to the skin or get into your eyes or mouth.
• Do not disassemble Ink eco-case. Leaking ink may adhere to the skin or get into your eyes or
mouth.
• Avoid storing this product in locations accessible to children.
• When disposing of the product, contact an industrial waste disposal operator or dispose of the
product in accordance with the local laws and regulations.
• Do not use ink, maintenance liquid, or other liquids used with this machine with other printers.
Disregarding this precaution may result in damage to the printer.
• Do not touch the metal parts of the ink IC chip. Static electricity may damage the ink IC chip,
and dirt or damage may make the ink IC chip unreadable.
• Store in a low place no higher than 1 m above the floor. Dropping this machine may result in
splashing ink.
• Store in sealed containers.
• Store in a cool and dark place.
(1) Store ink in an environment where it will not freeze. Note that using thawed ink may affect
printing quality due to ink degradation.
(2) When moving ink from cold to warm locations, allow to stand for at least three hours before
use in the same conditions as the machine.
(3) Open the ink before use and use up as quickly as possible. Print quality may degrade if the
bottles are left open for extended periods.

Ink or any Other Liquid Used with the Machine
15
• Printing is disabled if a different ink IC chip is used.
• Do not expose ink, maintenance liquid, and other liquids used with the machine to direct
sunlight.
• Do not store ink, maintenance liquid, or other liquids used with the machine in environments
where cutting fluid or other volatile substances (such as amines or modified amine alcohol) are
present in significant quantities. Storage in such places increases the risk of failure or printing
defects (e.g., nozzle clogging, deflection).
Ink Specifications
Item JV330 Series, CJV330 Series TS330-1600
Type Special solvent ink (MIMAKI product) Sublimation transfer ink (MIMAKI product)
Color*1 Cyan (C)
Magenta (M)
Yellow (Y)
Black (K)
Light cyan (Lc)
Light magenta (Lm)
Light black (Lk)
Orange (Or)
White (W)
Blue (BL)
Magenta (M)
Yellow (Y)
Black (K)
Light blue (Lbl)
Light magenta (Lm)
Light black (Lk)
Fluorescent pink (FP)
Fluorescent yellow (FY)
Form Aluminum pack Aluminum pack (2,000 ml) / ink tank
(10,000 ml)
Ink capacity*1 2,000 ml, 1,000 ml, 500 ml 2,000 ml, 10,000 ml
Expiration date As indicated on the ink pack. However,
within three months after opening, even
before the expiration date
As indicated on the ink pack. However,
within one month after opening, even
before the expiration date
Storage
temper
ature
When
stored
10 to 35 °C (daily mean temperature)*
• However, not more than 1 month at 30
°C
• Ink quality may deteriorate if stored
outside these conditions.
10 to 35 °C (daily mean temperature)
• Ink quality may deteriorate if stored
outside these conditions.
During
transpo
rtation
1 to 40 °C
• However, not more than 120 hours at
60 °C, and not more than 1 month at
40 °C
• Where possible, avoid storing in cold
locations below 0 °C and hot locations
above 40 °C.
• Ink quality may deteriorate if stored
outside these conditions.
0 to 40 °C
• Ink quality may deteriorate if stored
outside these conditions.
*1. Depending on ink type
Restrictions concerning the product
The ink expiration date is indicated on the Ink pack. Expired ink may cause printing defects or alter the color
tone. Printing is possible even if the ink has passed its expiration date. Nevertheless, we recommend
replacing with new ink or using up as quickly as possible.
Example: When the expiration date is April 2023

Ink or any Other Liquid Used with the Machine
16
• May: Replace with new ink or use up as quickly as possible. Printing is possible.
• June: Replace with new ink or use up as quickly as possible. Printing is possible.
• July: Printing is not possible.
• The message appears on the display.

Installation Precautions
17
Installation Precautions
• Do not install this machine in environments where flammable substances are present (e.g.,
gasoline, flammable spray, alcohol, thinner, lacquer, or powder). This machine is not explosion-
proof. The product poses a risk of explosion.
• Do not install this machine in locations where open flames are present. The ink may ignite.
• Do not place vases, pot plants, cups, cosmetics, containers of chemicals or water, or small
metal objects on top of this machine. There is a risk of failure, electric shock, or fire if liquids or
items drop inside the machine.
• Do not install this machine in humid locations or locations where it may be exposed to splashing
water. Otherwise there is a risk of failure, electric shock, or fire.
• Avoid installing this machine in locations accessible to children.
• A ventilation system must be provided if this machine is installed in a poorly ventilated area or
sealed room.
• Be sure to observe the following points when installing an extractor outlet:
(1) The extractor outlet must be installed in accordance with applicable local EHS
(environmental, health, and safety) guidelines.
(2) If the extractor outlet is fitted with a shutoff valve, the valve must be open when this machine
is in use.
• Do not install this machine in locations where dust or powder is present. Failure or printing
defects may result (e.g., nozzle clogging, deflection) if dust gets inside this machine.
• Do not install this machine in locations exposed to drafts (e.g., from air conditioning).
Disregarding this precaution may result in dust or powder getting inside this machine.
• Do not install this machine in unstable locations or locations subject to vibration. This will
increase the risk of failure or printing defects (e.g., nozzle clogging, deflection).
• Do not install this machine in locations exposed to direct sunlight.
• Do not install this machine in locations subject to sudden temperature changes. This will
increase the risk of failure or printing defects (e.g., nozzle clogging, deflection).
• Do not install this machine in locations exposed to excessive noise from large machinery.
• Do not install this machine in locations where photographic fixing agents generate vapor or acid
gas (e.g., acetic acid, hydrochloric acid) or locations filled with metal working fluids or highly
volatile substances (e.g., amines, amine-modified alcohols). Malfunctions or printing defects
may result (e.g., nozzle clogging, deflection) as print head ink is more likely to harden under
such environments.
• Operating conditions: 20 °C to 30 °C (68 °F to 86 °F), 35 %RH to 65 %RH (no condensation)
• Guaranteed accuracy temperature range: 20 °C to 25 °C (68 °F to 77 °F)

Installation Precautions
18
Installation Space
Provide the following space around the machine to allow safe and proper replacement of ink and media:
Item JV330-130 CJV330-130 JV330-160 CJV330-160 TS330-1600
Width*1 At least 3,920 mm (2,920 mm) At least 4,170 mm (3,170 mm)
Depth*1 At least 4,050 mm (2,050 mm*2)At least 2,820 mm
(820 mm)
Height*
1
(1,305 mm)
Weight 358 kg 363 kg 368 kg 373 kg 240 kg
*1. The figures in parentheses indicate machine dimensions.
*2. Including the media chute
Installation space (width)
Installation space (depth)
1000 mm or more
1000 mm or more
500 mm or more
500 mm or more
When Relocating This Machine
Contact your local dealer or our service office. Attempting to handle relocation yourself may result in failure
or damage.

Safety Interlocks
19
Safety Interlocks
This machine is equipped with interlocks to ensure safety during use.
Printing will abort if you open the covers while printing is underway. If so, you will need to resend the RIP
data.
• Safety interlock locations

Warning Label
20
Warning Label
Make sure you fully understand the details indicated on the various warning labels.
If any of the warning labels becomes dirty and illegible or peel off, contact your local dealer or our service
office to request new warning labels.
2
3
3
4
5
9
7
3
8
10
10
4
11
11
6
6
12
