Mimer X-Link Instruction Manual

Page 1/4
Connect a Jotron TR7750 to Mimer X-Link
Interface Power Supply
+12VDC / max 0,3A.
See wiring diagram on the following page.
Radio setup
The interface is pre-set for the following radio default settings:
•Rx Config/Audio/Line Output Level/0.0dBm
•Rx Config/Squelch/RxBusyOutput: Closed when busy (default)
•Tx Config/Audio/Input Source/Auto
•Tx Config/Audio/Line Sensitivity/-10dBm
•Tx Config/Keying/Source/Txgnd
See screen shots on following pages.
The radio is connected through one RJ45 to the Tx: REM port.
Jotron TR7750 A www.lse.se REE

Page 2/4
Settings in the X-Link interface
Select the proper settings for Radio A or Radio B depending on your
connection.
•Radio with squelch output for Rx detect
Part of the Configuration software window
Check/adjust the audio levels in both directions in the interface so
that the users hears the X-Link with the same level as when listening
to other radios.
See the X-Link setup manual for details on setting the audio level.
Jotron TR7750 A www.lse.se REE

Page 3/4
Radio Settings Screen shots
Select Mic, TxKey and Txgnd.
Unselect Line.
Jotron TR7750 A www.lse.se REE

Page 4/4
Connection Cable:
Select the proper configuration below depending on if your radio will
be connected as Radio A or Radio B to the X-Link interface.
Jotron TR7750 A www.lse.se REE
