Marantz CDR420 User manual

Model CDR420 User Guide
Recordable
®
CLASS 1 LASER PRODUCT
LOUKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
HD/CD Recorder

- 2 -
Warnings and Cautions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
The lightning fl ash with arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of un-insulated “dangerous voltage” within the
product’s enclosure that may be of suffi cient magnitude to constitute a risk of electric
shock to persons.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
LASER SAFETY
This unit employs lasers. Only a qualifi ed service person should remove the cover or at-
tempt to service this device, due to possible eye injury.
CAUTION
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURE OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNINGS FOR LASER RADIATION
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN, DO NOT STARE INTO BEAM.
DANGER: INVISIBLE LASER RADIATION WHEN OPEN, AVOID DIRECT EXPOSURE TO BEAM.
VAROI: AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTINANAYMÄTTÖMÄALLE
LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.
VARNING! OSYNLIGH LASERSTÄLNING NÄR DENNA DEL ÄR ÖPPNAD OCH SPÄRREN ÄR URKOPP-
LAD. BETRAKTA EJ STRALEN.

NOTE TO CATV SYSTEM INSTALLER:
This reminder is provided to call the CATV (Cable-TV)
system installer’s attention to Article 820-40 of the NEC,
which provides guidelines for proper grounding and, in par-
ticular, specifi es that the cable ground shall be connected to
the grounding system of the building, as close to the point of
cable entry as practical.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential instal-
lation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and re-
ceiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
NOTE:
Changes or modifi cations may cause this unit to
fail to comply with Part 15 of the FCC Rules and may void
the user’s authority to operate the equipment.
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION
810-20)
GROUNDING
GROUNDING
CONDUCTORS
CONDUCTORS
(NEC SECTION
(NEC SECTION
810-21)
810-21)
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMPS
GROUND CLAMPS
POWER SERVICE
POWER SERVICE
GROUNDING
GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
FIGURE 1
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
- 3 -
NEC - NATIONAL ELECTRICAL CODE
WARNINGS
• Do not expose the equipment to rain or moisture.
• Do not remove the cover from the equipment.
• Do not insert anything into the equipment
through the ventilation holes.
• Do not handle the mains lead with wet hands.
• Do not cover the ventilation with any items such
as tablecloths, newspapers, curtains, etc.
• No naked fl ame sources, such as lighted candles,
should be placed on the equipment.
• When disposing of used batteries, please comply
with governmental regulations or environmen-
tal public instruction’s rules that apply in your
country or area.
• Do not place anything about 0.1 meter above the
top panel.
• Make a space of about 0.1 meter around the unit.
• No objects fi lled with liquids, such as vases,
shall be placed on the apparatus.
• When the switch is in the OFF position, the
equipment is not completely switched off from
MAINS.
When setting up the recorder ensure that:
• it will not be exposed to interference from exter-
nal equipment.
• it will not be exposed to electrostatic discharges.
• it will not be exposed to direct sunlight.
• heavy objects are not placed on the recorder.
Equipment mains working system
This product complies with household power and
safety requirements in your area. US units are supplied
with power units that can be powered by 120 V AC
only.
This Class A digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la Classe A est conforme
á la norme NMB-003 du Canada.
Copyright
Recording and playback of any material may require
consent. For further information refer to the following
US ordinances:
• Copyright act of 1956
• Dramatic and Musical Performance Act 1958
• Performers Protection Acts 1963 and 1972
• any subsequent statutory enactments and orders

- 4 -
Important Safety Instructions
READ BEFORE OPERATING EQUIPMENT
This product was designed and manufactured to meet strict
quality and safety standards. There are, however, some
installation and operation precautions which you should be
particularly aware of.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in ac-
cordance with the manufacture’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
groundingtype plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fi t into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specifi ed by the
manufacturer.
12. Use only with the cart, stand,
tripod, bracket, or table speci-
fi ed by the manufacturer, or
sold with the apparatus. When
a cart is used, use caution
when moving the cart/ap-
paratus combination to avoid
injury from tip-over.
Additional Safety Information!
• This product should not be placed in a built-in installa-
tion such as a bookcase or rack unless proper ventila-
tion is provided or the manufacturer’s instructions have
been adhered to.
• Apparatus shall not be exposed to dripping or splash-
ing and that no objects fi lled with liquids, such as
vases, shall be placed on the apparatus.
• When the switch is in the OFF position, the apparatus
isn’t completelyswitched-off from the MAINS.
Precautions - installation
• Do not expose the CDR420 to excessive heat, excessive
cold, rain, moisture, or dust this may cause damage to the
unit.
• If a foreign object or water does enter the unit, contact
your nearest dealer or service center.
• All players produce some heat during operation and this
heat must be allowed to dissipate freely. Do not close any
ventilation openings and be sure there is adequate venti-
lation space behind, beside and above the player so air is
allowed to circulate freely around the unit.
• Be sure ventilation holes are not covered.
• Prevent extra heat from reaching the unit. Never put the
CDR420 in direct sunlight or near a heat source.
• Do not expose the CDR420 to electrostatic discharges.
• Do not place heavy objects on the unit.
• Be sure the CDR420 is placed on a vibration-free surface.
Precautions - connection
• Unplug the power adapter from the AC outlet or turn off
the POWER switch before making any connection.
• Connect one cable at a time observing the ‘input’ and
‘output’ labeling. This will avoid any cross connections
between channels and signal inputs and outputs.
• Insert plugs securely. An incomplete connection may
result in noise.
• Before connecting other audio or video equipment to the
CDR420, please read their owner’s manuals.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualifi ed service personnel. Ser-
vicing is required when the apparatus has been dam-
aged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has
been dropped.

Specifi cations
Digital Audio System
System
.........................................................................................................................................
Hard Disk Recorder
Recording media
...............................................................................................................................
2.5” 20GB HDD
Burning CD media
.....................................................................................................................
CD-R, CD-RW discs
Recording audio format
MP3 (.mp3)
..................................................................................................
MPEG Audio Layer 3 compression
WAVE (.wav)
...........................................................................................................................
16 bit linear PCM
Recording bit rate
MP3 Stereo
.........................................................................................................
320, 256, 160, 128, 80, 64 kbps
MP3 Mono
..............................................................................................................
160, 128, 80, 64, 40, 32 kbps
Sampling frequency
......................................................................................................................................
44.1 kHz
Number of channels
.....................................................................................................................
2 (stereo), 1 (mono)
Frequency response
......................................................................................................................
20,000 Hz (-0.5dB)
Inputs/Outputs
MIC/LINE IN L/R
Type
..................................................................................................................
XLR (1:GND, 2:HOT, 3:COLD)
¼” T-R-S phone jack
Line level
Input sensitivity/Impedance
................................................................................................
500 mVrms/2k ohms
Signal-to-Noise ratio (IEC-A weighted)
.....................................................................................................
80 dB
Total Harmonic Distortion (0dB, PCM)
.....................................................................................................
0.05%
MIC level
Input Sensitivity/Impedance
....................................................................................................
1 mVrms/2k ohms
Signal-to-Noise ratio (IEC-A weighted)
.....................................................................................................
60 dB
Total Harmonic Distortion (0dB, PCM)
.......................................................................................................
0.2%
AUX IN L/R
Input Sensitivity/Impedance
.....................................................................................................
1 Vrms/23k ohms
Signal-to-Noise ratio (IEC-A weighted)
.....................................................................................................
87 dB
Total Harmonic Distortion (0dB, PCM)
.....................................................................................................
0.05%
LINE OUT L/R
Type
.......................................................................................................................................................
RCA jack
Standard level/Impedance
..........................................................................................................
1 Vrms/2k ohms
MIX OUT L/R
Type
.......................................................................................................................................................
RCA jack
Standard level/Impedance
..........................................................................................................
1 Vrms/2k ohms
DIGITAL IN/OUT
Type
.......................................................................................................................................................
RCA jack
Standard output level/Impedance
.............................................................................................
0.5 Vp-p/75 ohms
Sampling frequency
................................................................................................................................
44.1 kHz
KEYBOARD
........................................................................................................................................................
PS2
USB
.........................................................................................................................................................
USB Type B
General
Headphone Output (10% THD)
........................................................................................................
70 mW/32 ohms
Speaker Output
......................................................................................................................................
Speaker Output ......................................................................................................................................Speaker Output
1.7 W/8 ohms
Phantom power
.......................................................................................................................................
Phantom power .......................................................................................................................................Phantom power
+48V, 10mA
Power requirement
.............................................................................................................
Power requirement .............................................................................................................Power requirement
AC100V-240V, 50/60 Hz
Power consumption (maximum)
.................................................................................................................
12V, 1.4A
continues
- 5 -

- 6 -
Introduction
The CDR420 HD/CD Recorder is a professional
recorder. You record directly to the built-in Hard Disc
(HD) from digital or analog inputs.
Recording to the built-in Hard Disc (HD) provides a
number of advantages:
• Over 30 hours (PCM) or 1400 hours (MP3) of
recording storage capacity permits long recording
times.
• Recordings on the HD are in digital form and can
be transferred to your computer for editing.
• Recordings can be edited in the CDR420 itself.
• More stable than directly recording to a CD.
(If recording is done directly to a CD-R a disc error can inter-
rupt the recording session.)
• Automatically records the time and date.
• Automatically names the recording fi le by the time
and date recording begins.
• You can change the fi le name later if desired, or
while recording using an attached keyboard.
• PCM recordings on the CDR420 can be burned to
an AUDIO CD (CD-DA).
• A multi-session CD (EXTRA) can also record
fi le information tags (text fi les-.txt) that can be
read by your computer.
• PCM and/or MP3 recordings on the CDR420 can
be burned to a DATA CD.
• Unattended Record Timer lets you preset the date
and time for a recording to begin and how long to
record.
Editing on the CDR420
The CDR420 enables you to “assemble” a CD from
audio fi les recorded on the HD.
The CDR420 can convert PCM tracks to MP3.
You can scrub (forward and reverse over a portion of a
track to locate and mark the beginning and end points
of a passage) to select a passage for editing. Editing
audio on the HD
models
the common procedures used
to edit text in a word processing application: mark an
audio passage (highlight text), cut (cut text) [delete
the audio segment and move it to the clipboard], copy
(copy text) [non-destructively copy the audio segment
to the clipboard], and paste (paste text) [copy the audio
segment on the clipboard to a new location within the
track].
When your edited fi le is complete you can write the
fi le to a standard CD or MP3 data disc.
Specifi cations continued
Dimensions (maximum)
Width
...........................................................................................................................................
279 mm (11.0”)
Height
............................................................................................................................................
Height ............................................................................................................................................ Height
102 mm (4.0”)
Depth
.............................................................................................................................................
229 mm (9.0”)
Weight
...........................................................................................................................................
Weight ...........................................................................................................................................Weight
2.5 kg (5 lbs. 8 oz.)
Included accessories
AC adapter
...........................................................................................................................................................
AC adapter ........................................................................................................................................................... AC adapter
1
Stereo audio cable
...............................................................................................................................................
2
User Guide
...........................................................................................................................................................
1
Optional accessories**
Rechargeable Lead Acid battery system
..................................................................................................
RPS420
Additional rechargeable Lead Acid battery pack
....................................................................................
Additional rechargeable Lead Acid battery pack .................................................................................... Additional rechargeable Lead Acid battery pack
RB4200
Carrying bag
............................................................................................................................................
PRC300
Attaché carrying case
................................................................................................................................
CA300
**See
www.d-mpro.com
for details.
*Specifi cations subject to change without notice.

Table of Contents
Topic page
Warnings and Cautions
.........................................
2
Laser Safety
.....................................................
2
Important Safety Instructions
..............................
4
Specifi cations
.......................................................
5
Introduction
..........................................................
6
Table of Contents
.................................................
7
Package contents
...................................................
8
Basic Operation
....................................................
8
Features
..............................................................
10
Connections
........................................................
11
Connect Microphones or Instruments
............
11
Connect computer
..........................................
11
Connect analog equipment
.............................
11
Connect digital equipment
.............................
12
Connect keyboard
..........................................
12
Power on sequence
.............................................
12
Controls, Display (top)
1 Speaker
.....................................................
14
2 Built-in microphone
....................................
14
3 Tone controls
............................................
14
4 Control buttons
4a FILE DIR button
..................................
14
4b INFO button
........................................
15
4c JUMP button
.......................................
16
4d PHANTOM button
...............................
17
4e CD/HD button
.....................................
17
4f MARK button
.....................................
17
4g UTILITY MENU button
.....................
17
4h UNDO button
......................................
18
4i REDO button
........................................
18
4j EDIT MENU button
............................
18
5
Display
.....................................................
18
a Record icon
.......................................
18
b Pause icon
..........................................
18
c Play icon
..........................................
19
d FILES label
...........................................
19
e EDIT label
.............................................
19
f MENU label
..........................................
19
g BUILD label
.........................................
19
h IN label
.................................................
19
i OUT label
.............................................
19
j UTILITY label
......................................
19
k Level meter scale
..................................
19
l L (left) level meter
................................
19
m R (right) level meter
...............................
m R (right) level meter ............................... m R (right) level meter
19
n ? label
....................................................
19
o MP3 label
..............................................
19
p PCM label
.............................................
20
q Working label
.......................................
20
r HD label
................................................
20
s CD label
.................................................
20
t REC label
...............................................
20
u Timer label
............................................
20
v Total label
.............................................
20
w Select label
............................................
20
x Elapsed label
.........................................
20
y Remaining label
....................................
20
z Alphanumeric display
...........................
20
- 7 -
6 POWER switch
..........................................
20
7 STANDBY light
........................................
20
8 Jog Wheel (SELECT, PUSH ENTER)
......
21
9 IN button
...................................................
21
How to jump to an IN mark
.......................
21
10 OUT button
................................................
21
How to jump to an OUT mark
...................
22
11 REC button light
.....................................
22
12 Fast Reverse button
.............................
23
13 Fast Forward button
.............................
23
14 Play/Pause button
................................
23
15 Stop button
.............................................
23
Controls, Connections (front)
1 PHONE/SPEAKER LEVEL control
.........
24
2 PHONE SELECTOR
.................................
24
3 MIC/LINE controls and input jacks
.........
24
3a Left XLR or 1/4” input jack
.................
24
3b Right XLR or 1/4” input jack
...............
3b Right XLR or 1/4” input jack ...............3b Right XLR or 1/4” input jack
24
3c LINE MIC INT switch
..........................
24
3d Left level control
...................................
24
3e L/R L+R switch
...................................
24
4 INPUT ANALOG/DIGITAL switch
..........
25
5 REC LEVEL switch
.....................................
25
5
6 MIC/LINE ATT switch
...............................
25
7 SPEAKER OFF/ON switch
.........................
25
8 EJECT button
.............................................
25
9 Eject button
................................................
25
10 CD light
.....................................................
25
11 CD slot
.......................................................
25
12 PHONES jack
.............................................
12 PHONES jack ............................................. 12 PHONES jack
25
13 LINE OUT level control
.............................
25
Controls, Connections (rear)
1 MIX OUT jacks
.........................................
26
2 LINE OUT jacks
........................................
26
3 AUX IN jacks
............................................
26
4 DIGITAL IN and OUT jacks (SPDIF)
.......
26
5 I/O jack (computer)
.....................................
26
6 KEYB jack (keyboard)
..............................
26
7 DC IN
.........................................................
26
8 DCIN pinout
...............................................
8 DCIN pinout ............................................... 8 DCIN pinout
26
How To
REC LEVEL adjustment
.....................................
REC LEVEL adjustment .....................................REC LEVEL adjustment
27
REC FORMAT
..................................................
27
How to set or change the
REC FORMAT to be recorded
......................
27
Stereo or Mono recording
...................................
28
How to set or change the
CHANNEL to be recorded
.............................
28
KBPS
.................................................................
29
How to set or change the
BITRATE to be recorded
...............................
29
Auto Track Increment
........................................
29
How to set or change
A. TRK INC HD
...........................................
30
Record Timer
.....................................................
31
How to set the
RECORD TIMER
.........................................
31
continues
Topic page

- 8 -
Table of Contents continued
Topic page
UTILITY MENU - NEW CD PROJECT
..........
33
How to do a CD project
...................................
How to do a CD project ................................... How to do a CD project
33
AUDIO
.......................................................
33
DATA
.........................................................
33
EXTRA
......................................................
33
Add all tracks
.............................................
33
How to add a track to a CD Project
............
How to add a track to a CD Project ............ How to add a track to a CD Project
34
How to delete a track from a CD Project
....
How to delete a track from a CD Project .... How to delete a track from a CD Project
34
How to change a track in a CD Project
......
34
How to burn your CD Project to a CD
......
35
Display messages during CD burning
.......
35
How to Copy a CD
.............................................
36
How to Rip a CD
.................................................
37
How to RIP an Entire CD
................................
37
How to RIP a single track
...............................
38
Date and Time
.....................................................
40
How to SET DATE/TIME
...............................
40
Filters
..................................................................
41
How to set Filters
............................................
41
PLAYBACK MODE
..........................................
43
How to set the Playback Mode
.......................
43
USER SETTINGS
.............................................
44
AUTO MAKE CD
...........................................
44
AUTO TRK INC CD
.......................................
45
A. TRK TIME
.................................................
45
CD TYPE
.........................................................
46
ALLOW FORMAT
.........................................
47
COPY B4 EDIT
...............................................
47
LOCK EDITING
.............................................
48
LOCK REC. SET
...........................................
49
PRE-ROLL TRK
.............................................
49
REQ.CONFIRM
..............................................
50
RST DEFAULTS
...........................................
51
FORMAT HDD
...............................................
52
How to EDIT AUDIO
........................................
52
How to navigate within the track
....................
53
How to mark an audio segment
......................
53
Precise Editing (navigation)
............................
54
Clipboard play
.................................................
54
How to Insert Silence
.....................................
54
How to Cut, Copy or Delete
............................
55
How to Exit Edit Execute Mode
......................
56
How to EDIT TAGS
...........................................
57
DELETE TRACK
............................................
58
DELETE ALL TRK
........................................
59
COPY TRACK
................................................
59
SPLIT TRACK
................................................
59
CONVERT TO MP3
.......................................
60
Firmware Update
...............................................
61
Keyboard
............................................................
62
About Compact Discs
........................................
63
Optional battery supply
.......................................
64
LIMITED WARRANTY
...................................
65
Package contents
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
• CDR420
unit
• Audio cable (2)
(stereo pair)
(3’ 3”, 100cm)
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
a, b, c.
Connect.
d.
The red STANDBY
light will be lit.
2.
Slide the POWER
switch to the right and
release. The display will
document the power up
sequence, then display the
date and time.
a
b
c
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
d
STANDBY
POWER
2
• Power pack
• Power supply
cord
Basic operation
Install on a table or other fl at, stable, surface.
1.
Plug in.
continues
Date and time
are displayed
when the
CDR420 is idle
HD
(example shown).

IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
RIGHT
MIC LIN
E
3
3.
Insert a blank (8x or greater) CD (optional).
4.
Press and release the REC button
. The Play/
Pause button
(5) will be fl ashing.
5.
Press and release the fl ashing Play/Pause button
to begin recording.
While recording both the red REC button
and the green Play/Pause button
are lit and
steady.
To pause recording press and release the Play/
Pause button
. Press and release the Play/
Pause button
again to resume recording.
6.
Press and release the Stop button
to stop re-
cording.
4
5
- 9 -
7a. To exit without making a CD press and release
the Jog Wheel.
The CDR420 will ask
you if you want to
MAKE a CD NOW?
If not, INS. BLANK
CD is displayed.
7b.To immediately burn
a CD of the recording
you just made turn the
Jog Wheel so MAKE CD NOW? Y is displayed,
then press and release the Jog Wheel.
If a non-blank CD is in the drive it is ejected.
When you insert a blank CD it is automatically
prepared, burned, fi nalized, ejected, and you are
asked if you want to make another copy.
Answer N (no), or press and release the Stop but-
ton
to exit.
NOTEs
• If your recorded track is longer than will fi t on a single CD,
the CDR420 will tell you how many blank CDs are needed.
• Whether or not a CD is made, the recording remains on the
HD.
The CDR420 checks for a blank CD in the CD
drive.
?
HD
?
HD
HD
MENU
UTILIT
Y
REC

F
eatures
The CDR420 records directly to the Hard Drive (HD).
Immediate CD
At the end of a recording session (a recording session
or track ends when you press and release the Stop but-
ton
) you can immediately and easily burn a CD of
that track. The track remains on the HD if you burn a
CD or not.
The CDR420 incorporates a suite of professional fea-
tures for audio recording, editing and CD burning.
HD (Hard Drive)
• Direct to HD recording is more stable
(CD-R disc errors can interrupt recording.)
• Long recording time
• Over 30 hours of WAV (PCM)
• 1400 hours of MP3
• Automatically names fi les by date and time record-
ed for easy fi le location and recall
• Allows you to easily change fi le names
• Non destructive editing lets you relocate or re-
move unwanted audio segments
• Allows simple fi le conversion previously available
only via computer
• Allows you burn a CD in CDA or MP3 format
• Provides USB output for fi le transfer and hard disc
backup
• Provides connection for your PS-2 keyboard per-
mitting easier editing and CD Text entry
Record Functions
• Records MP3 and PCM mono and stereo
• Recordable bit rates
Mono: 32, 40, 64, 80, 128, 160
Stereo: 64, 80, 128, 160, 256, 320
• Records PCM 44.1 kHz
• Automatic time/date stamp at start of recording
• Accepts Digital or Analog input
• Unattended Record Timer can power up the
CDR420 and begin recording at the time/date you
select
- 10 -
Playback functions
Includes playback functions that let you check your
recording.
• One button (CD/HD button) toggles between CD
and HD playback operation
• Play
• Stop
• Pause
• Audio search Fast Forward (3 speeds)
• Audio search Fast Reverse (3 speeds)
• Next track
• Previous track
File/Track Editing functions
• Scrub
• Cut
• Delete
• Insert
• Erase
• Insert silence
• Save as new fi le
• Name fi le (track)
Conversion and Make CD functions
• Assemble project (assemble tracks to make a CD)
• Make audio CD
• Recording date/time
• PCM 44.1 kHz
• length and fi le size
• CD Spanning (if project is too long to fi t on one
CD)
• Make a data CD (MP3/WAV)
• name
• recording date/time
• bit rate
• fi le size
Utilities
• Delete fi le (track)
• Set time/date
• Setup record defaults
• Copy a CD
• Make audio CD
• Make MP3 CD
• Rip CD to HD
• Show available disc space
• Format HD
• Download fi le via USB
• Split long fi les into smaller, more manageable fi les
• Back up HD via USB

- 11 -
Connections*
*Except for power, all input and output connections are optional.
Connect Microphones or Instruments
L R
L + R
L/R
MIC/LINE
PUSH
MIC/LINE RIGHT
PUSH
LEFT
INT
LINE
MIC
Left and Right microphones or instruments via phone
or XLR plugs are input via the MIC/LINE jacks.
1. Plug microphone or instrument to be recorded on
the LEFT channel into the LEFT jack.
2. Plug microphone or instrument to be recorded on
the RIGHT channel into the RIGHT jack.
NOTE:
a
Set the LINE MIC INT switch to LINE for line level input(s)
or MIC for microphone level input(s).
• For microphone(s) requiring Phantom power, press the
PHANTOM button on the top of the CDR420.
• To mix two microphones from the front inputs with a stereo
line input, use the AUX input jacks on the rear for the stereo
line input.
b
Set the L/R L+R switch to L/R for stereo recording. Set to
L+R to record both left and right inputs to both channels.
• Use the L
(c)
and R
(d)
level controls to adjust left and/or
right recording levels.
Connect computer
(optional)
Plug the supplied I/O cable in here and connect the
other end to your computer (PC or MAC).
LEFT
MIC/LINE
RIGHT
1 2
LINE
a c b d
L/R
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
If the CDR420 is on, slide and release the POWER
switch to connect to your computer.
KEYB
KEYB
I / 0
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
MIX LINE
L
R
INPUT
Amp, Mixer/Pre-Amp, CD-R, etc.
LINE
OUT
MIX
OUT
R
L
L
R
INPUT
Amp, Mixer/Pre-Amp, CD-R, etc.
IN
R
AUX
IN
L
R
OUTPUT
Amp, Mixer/Pre-Amp, CD-R, etc.
R
L
The connection makes it easy to copy audio fi les
between the CDR420 HD and your computer's hard
drive. The I/O connection can only be made active
when the CDR420 is off (neither recording or during
playback).
To disconnect, put the CDR420 hard drive away* on
your computer, then disconnect the I/O cable.
*It is a common and safe practice to "stop" or "eject" an external
hard drive before disconnecting it from your computer. Failure to
do this could damage fi les on the CDR420 or the HD itself. Refer
to your computer's operating system "help" section for instructions
on using the "Safely Remove Hardware" tool (PC).
Connect Analog equipment
(optional)
Connect CD/HD output to analog equipment for play-
ing (or recording).
Output:
Connect Right and Left RCA audio cables to
MIX OUT and/or LINE OUT and then connect to the
input of an amplifi er, preamplifi er, receiver or other
recording device.
Use this connection for record-
ing or to mix line level input with
microphone or instrument inputs
If the CDR420 is off, it
will automatically connect.
USB 2.0 MSD is displayed on the CDR420
and the CDR420 HD appears as a volume on your
computer.
LINE OUT signal is available only while playing or
recording.
MIX OUT signal is available while playing or re-
cording and passes input signals through while the
CDR420 is not playing or recording.
Input:
Connect Right and Left RCA audio cables to
AUX IN and then connect to the line level output of an
amplifi er, mixer, receiver or other audio device.
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
OUT
MIX LINE
OUT

IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
- 12 -
Connect Digital equipment
Connect CD/HD input and/or output to digital equip-
ment for playing or recording*.
*The CDR420 can only accept S/PDIF digital signals at the
Sample Frequency of 44.1 kHz.
Connect 2 coaxial digital cables to DIGITAL IN and/
or DIGITAL OUT and then to output and/or input of
your digital device.
L
DIGITAL
OUTPUT
digital device
IN
OUT
INPUT
DIGITAL OUT
Signal is available only while playing.
DIGITAL IN
Use this connection for recording. Digital input cannot
be mixed with microphone or instrument inputs on the
front of the CDR420, or line level input via the AUX
IN jacks.
NOTE:
Digital In:
The CDR420 can only receive and record a 16 bit,
44.1kHz digital audio signal. Should you input any other format of
digital audio, the display will read "NO SPDIF LOCK" and
recording is not possible.
Digital Out:
The CDR420 is only capable of playing back fi les
that have been recorded at 44.1kHz. If you place a fi le on the HDD
that is any other frequency than 44.1kHz, playback will cease and
the display will read "44.1KHZ ONLY".
Monitoring:
The CDR420 is not capable of monitoring audio by
any analog means, other than the level meters, when recording
digitally. Please monitor the audio at the source.
Connect keyboard
Connect your standard PS/2 PC keyboard for direct
keyboard control of the CDR420.
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
KEYB
Power on sequence
1. Connect power
pack plug at DC
IN
2. Connect power
cord to power
transformer.
IN
OUT
DIGITAL
MIX LINE AUX
R
L
R
L
INOUT
OUT
DC IN
KEYB
I / 0
DC IN
1
2
3
3. Plug in.
NOTE:
• The Power supply switching adapter can accept 120 VAC 60
Hz (US standard) or 230 VAC 50 Hz (European standard)
power.
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
POWER
2 4 4
2 4 4
2 4 4
STANDBY
4. The red STANDBY
light will be lit.
5. Slide the POWER switch to the right and release.
The display will document the power up se-
quence.
All elements of the
display are briefl y lit.
All elements of the
display are briefl y off.
continues
Working
Timer
Elapsed
Select
Total
REC
Remaining
Elapsed
Remaining
Elapsed
CD
?
HD
OVER
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
MENU
OUT
IN -
Build
EDI
T
FILES
UTILITY
PCM
MP3
See page 62 for keyboard operation.

- 13 -
The model name and fi rm-
ware version are displayed
briefl y.
CPU TEST: PASS is
displayed briefl y when the
CPU passes.
CPU TEST is displayed* while the Central Processing
Unit is being tested.
*The CPU TEST is normally so fast you won't see the pass mes-
sage unless you are watching for it.
Working
HDD TEST: PASS then
CDR TEST: PASS are
briefl y displayed while the
Hard Drive Disc and CDR
are being tested and pass.
The amount of remain-
ing free space on the Hard
Disc is briefl y displayed.
Example display
The CDR420 checks the
CD drive for a disc and
briefl y displays the result.
Example display
When the Power on
sequence is complete the
display shows the date and
time.
HD
Example display
The date and time are displayed when the CDR420 is
idle and ready to receive commands.
NOTE:
If a power on test fails an error procedure is followed. See page 64.
Working
Working

FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
Controls, Display (top)
- 14 -
1 2
ANDBY
JUMP
UNDO
3 4 Jog Wheel
TREBLE
MID
BASS
FILE DIR
4a
1. Speaker
The built in full range speaker allows listening to a re-
cording without having to connect to other equipment
for amplifi cation.
2. Built in microphone
The built in microphone (internal mic) is near the top
right corner.
3. Tone controls
Turning a knob
controls the level of
the corresponding
frequency range of
the recording being played. Level adjustments apply
to the internal speaker, PHONES jack and LINE OUT
output. Turn clockwise to boost the frequency and
counterclockwise to attenuate it. Level adjustments do
not apply to MIX OUT.
TREBLE
High frequencies (18 kHz)
MID
Middle frequencies (2 kHz)
BASS
Low frequencies (150 Hz)
4. Control buttons
Select
HD
FILES
4a FILE DIR button
Press and release to select the File Di-
rectory. Turn the Jog Wheel to select a
fi le (track):
To play
press and release the Jog
tory.
b
'Select' tells you to turn the Jog Wheel to select the
fi le to display.
c
The fi le name is displayed.
NOTE:
• If the fi le was recorded recently the fi le name can be confused
with the date. For example, if it was 9:20 am on September
2 when you pressed FILE DIR and the fi le name is SEP 02
0820AM. Look for the "FILES" icon (a above) in the display
to be sure you are in the File Directory.
Turn the Jog Wheel to scroll through the File Direc-
tory.
Wheel or Play/Pause button
while the track name
is displayed.
To view fi le information
press and release the INFO
button while the track name is displayed.
To edit the fi le
press and release the EDIT MENU
button while the track name is displayed. See How to
EDIT AUDIO, page 52.
FILE DIR
Select
HD
PCM
FILES
b c
When FILE DIR is
pressed:
a
FILES is displayed
indicating that the dis-
play is the fi le direc-
a
Example
display
d
The audio fi le format
is displayed.
• If a fi le name is longer
d
than 14 characters, after about two seconds the fi le
name scrolls across the display.
• All audio recordings on the Hard Disc are pre-
sented in order, from most recent to oldest.
• Turn the Jog Wheel forward or backward to scroll
through the fi les in the File Directory.
Press and release the Play/Pause button
to play
the track, press and release the INFO button for full
information about the track, press and release the
EDIT MENU button to edit the track, or press and
release the Stop button
to exit the File Directory.
Example display

- 15 -
INFO
HD
4. Control buttons continued
From the idle screen
showing the current date
and time, or playback the
fi rst press and release of
In the example the full track name is "SEP 06
1053AM_01.WAV"
Press and release the INFO button to tab through the
track information displays.
NOTE:
• An information display is only displayed briefl y. If the next
information display is not selected the CDR420 returns to idle
mode.
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
INFO
4b 4c
HD
PCM
Example display
HD
PCM
After the track name the
date and time the record-
ing was begun is dis-
played.
NOTE:
If you have changed the track name the date and time of the re-
cording is thus still available.
INFO is available from idle, playback or recording.
the INFO button switches the display to the currently
selected track.
In the example that track
was recorded a couple of
days earlier.
Example idle screen display
After about one second
the track name scrolls
across the display.
Example display
HD
PCM
Example display
The length of the track in
minutes and seconds is
displayed.
HD
PCM
Example display
The fi le type and bitrate/
sample frequency are
displayed.
The CHANNEL(s) re-
corded (Stereo or Mono)
is displayed.
The artist is displayed.
The genre is displayed.
The album is displayed.
HD
PCM
HD
PCM
HD
PCM
HD
PCM
HD
PCM
If a comment tag has been entered it is displayed.
During
recording
press and release the INFO button
to tab through the name, type and channel.
During
recording
you can also press and hold the
INFO button for 2 seconds to switch from elapsed
record time to remaining record time on the HD.
4b INFO button
Press and release repeatedly to tab
through the currently selected fi le's
(TRACK's) properties.
JUMP
During playback press and hold for 2 seconds to
switch the playing time display between elapsed and
remaining time.
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD
PCM
Remaining
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
HD
PCM
Elapsed Remaining
Track INFO

- 16 -
4. Control buttons continued
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
4c
JUMP
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD
PCM
JUMP
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
Select
HD
PCM
4c JUMP button
Press and release to JUMP, advance or
reverse to a specifi c time, during play-
back, play/pause or during editing.
When fi rst pressed the display prompts JUMP and the
largest time fl ashes.
Example display
In the example, playback
was paused 4 seconds into
the track.
Turn the Jog Wheel to
select the hour you want
to jump to, then press and
release the Jog Wheel.
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD
PCM
Example display
In the example, jumping to a point within the fi rst hour
was selected.
Turn the Jog Wheel to se-
lect the minute you want
to jump to, then press and
release the Jog Wheel.
Example display
In the example, jumping to minute two of the record-
ing was selected.
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD
PCM
Turn the Jog Wheel to
select the second you want
to jump to, then press and
release the Jog Wheel.
In the example, jumping to the 36th second was
selected. When playback is resumed from play/pause
playback will begin at 2 minutes and 36 seconds into
the recording.
• Jump cannot be used to jump past the beginning or
end of a track.
Example display
• Jump backwards is available if audio is cued
within the audio track and at least one second of
audio has elapsed.
During playback when you press and release the
JUMP button the track time is frozen while playback
continues. That makes it easy for you to return to that
point in playback, or adjust the point by a second or
two.

- 17 -
4. Control buttons continued
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
PHANTOM
d e
4d PHANTOM button
PHANTOM provides a power sup-
ply for condenser microphone(s)
plugged into the MIC/LINE jack(s).
Example display
CD/HD
4f MARK button
Press and release to begin the
process of marking a location of
playback as the beginning "IN" or ending "OUT" point
of a segment of audio. SET MARK AS . . . appears in
the display.
Example display
f g
Example display showing
an IN- mark set, and no
OUT mark set yet.
When correct, wait, the display will automatically
return to the previous display after about 2 seconds.
4e CD/HD button
Press and release to toggle between
the CD drive and the Hard drive.
Press and release to turn PHANTOM microphone
power on or off. The display will show the new state
of PHANTOM power.
PHANTOM
CD/HD
MARK
HD
HD
CD
Example display
Example display
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
Select
HD
PCM
If playing, playing contin-
ues, if paused, play pause
continues.
While SET MARK AS? is displayed press and release
either the IN or OUT button.
IN -
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
Select
HD
PCM
IN
-
NOTE:
• IN and/or OUT marks are not remembered if you change the
selected track.
• After an IN and/or OUT mark is present, you can jump to the
IN or the OUT mark by pressing and releasing the IN or OUT
button.
• You can mark an audio segment during playback or in Edit
Mode. If during normal playback, you can switch to Edit
Mode with the IN and/or OUT marks if you don't change the
selected track.
• A marked audio segment can be copied, cut, deleted, or pasted
in Edit Mode.
4g UTILITY MENU button
Press and release to enter the Utility/
Setup menu.
Press and release to tab through the menu categories:
UTILITY MENU
RECORD SETTING
HD
MENU
UTILITY
CDR FUNCTIONS
and
PRODUCT SET-
HD
MENU
UTILITY
HD
MENU
UTILITY
UP.
NOTE:
• Turning the Jog Wheel also tabs through the menu categories.
• Utility Menu mode times out if there is no activity for one
minute.
To set or change a menu parameter:
1. Press and release the UTILITY MENU button to
select a menu category.
2. Turn the Jog Wheel to select a menu parameter,
then press and release the Jog Wheel to confi rm.
3. Turn the Jog Wheel to change the value of the
parameter,
4. then press and release the Jog Wheel to confi rm
and switch to the next Utility Menu category.
5. Edit the next menu item or press and release the
Stop button
to exit the UTILITY MENU.
Descriptions of the menu items and how to set or
change them are on the following pages:
RECORD SETTING
..................................
page
• TRACK TYPE (PCM or MP3)
...................
27
• CHANNEL (Stereo or Mono)
......................
28
• BITRATE (if MP3)
......................................
29
• A. TRK INC HD
(auto track increment)
..................................
29
• RECORD TIMER
.......................................
31

IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
g h i j
- 18 -
4. Control buttons continued
Example display
NOTE:
• Turning the Jog Wheel also tabs through the Edit Menu cat-
egories.
• Edit Menu mode times out if there is no activity for one min-
ute.
Descriptions of the Edit Menu items and how to set or
change them are on the following pages:
EDIT MENU
...............................................
page
• EDIT AUDIO
..............................................
52
• EDIT TAGS
.................................................
57
• DELETE TRACK
........................................
58
• DELETE ALL TRK
....................................
59
• COPY TRACK
............................................
59
• SPLIT TRACK
............................................
60
• CONVERT TO MP3
....................................
60
Press and release the UNDO button to undo one edit
step.
UNDO
4i REDO button
Reverses UNDO. During audio fi le
editing (4j) press and release to se-
quentially redo edits that were undone
by UNDO. All current undoes can be
redone.
Example display
REDO
4j EDIT MENU button
Press and release to select the Edit
Menu.
Press and release the EDIT MENU
button, or turn the Jog Wheel to tab
through the Edit Menu choices:
EDIT MENU
HD
MENU
EDI
T
HD
MENU
EDI
T
HD
MENU
EDI
T
HD
MENU
EDI
T
HD
MENU
EDI
T
HD
MENU
EDI
T
4g UTILITY MENU button continued
CDR FUNCTIONS
.....................................
page
• NEW CD PROJECT
....................................
33
• COPY CD
....................................................
36
• RIP CD
.........................................................
37
PRODUCT SETUP
....................................
page
• SET DATE/TIME
........................................
40
• RECORD FILTERS
.....................................
41
• PLAYBACK MODE
....................................
43
• USER SETTINGS
.......................................
44
• AUTO MAKE CD
...................................
44
• A.TRK INC CD
........................................
45
• A. TRK TIME
.........................................
45
• CD TYPE
.................................................
46
• ALLOW FORMAT
.................................
47
• COPY B4 EDIT
.......................................
47
• LOCK EDITING
......................................
48
• LOC REC.SET
.........................................
49
• PRE-ROLL TRK
......................................
49
• REQ.CONFIRM
.......................................
50
• RST DEFAULTS
....................................
51
• FORMAT HDD
........................................
52
4h UNDO button
During audio fi le editing (4j) press
and release to sequentially undo
edits. Unlimited undo's are pos-
sible.
EDIT AUDIO
EDIT TAGS
DELETE
TRACK
DELETE ALL TRK
COPY TRACK
SPLIT TRACK
HD
MENU
EDI
T
CONVERT TO MP3
MENU
EDI
T
PCM
MP3
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD
MENU
EDI
T
PCM
MP3
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
Elapsed
HD

- 19 -
5 Display
j UTILITY label
Displayed when in UTILITY MENU mode.
FILES
EDIT
MENU
BUILD
IN-
OUT
UTILITY
OVER
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
5 Display
Labels, icons, meters and
alphanumeric messages com-
municate the status of the
CDR420.
a
Record icon
The red record icon is lit when in record
mode.
b
Pause icon
The Pause icon appears when the CDR420
is in playback pause, or record pause.
c
Play icon
The Play icon appears when the CDR420 is
in playback or recording.
d
FILES label
Displayed after the FILE DIR button is
pressed. When present display information
refers to a track in the fi le directory.
e
EDIT label
Displayed when in EDIT MENU mode.
f
MENU label
Displayed when in a Menu mode.
g BUILD label
Displayed when in CD Build mode.
h
IN- label
Displayed when an IN point is set.
i
OUT label
Displayed when an OUT point is set.
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
a b c d e f g
a b c d e f g
Working
Timer
Elapsed
Select
Total
REC
Remaining
Elapsed
Remaining
Elapsed
CD
?
HD
OVER
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
0
R
L
MENU
MENU
OUT
IN -
Build
Build
EDI
T
FILES
UTILITY
PCM
MP3
FILES
EDI
MENU
MENU
Build
Elapsed
Remaining
Elapsed
Remaining
Elapsed
?
IN -
Remaining
OUT
MP3
UTILITY
PCM
h i j
j k l m
Working
Timer
Elapsed
Select
Total
REC
Remaining
Elapsed
Remaining
Elapsed
CD
?
HD
OVER
0
-4
-8
-1
2
-1
6
-2
2
-3
0
dB -5
dB -5
0
0
R
L
L
MENU
OUT
IN -
Build
EDI
T
FILES
UTILITY
PCM
MP3
-4
Elapsed
Remaining
Elapsed
Remaining
Elapsed
?
Remaining
n o p
Build
UTILITY
l
L (left) level meter
Lit rectangles provide a visual display of
the level of the left channel during play-
back or recording. The red OVER block
on the left is displayed when the level of
the left channel clips or is over 0 dB.
m
R (right) level meter
Lit rectangles provide a visual display of
the level of the right channel during play-
back or recording. The red OVER block
on the right is displayed when the level of
the right channel clips or is over 0 dB.
n
? label
Lit when the CDR420 is waiting for your
input.
o
MP3 label
Displayed when the fi le being recorded,
played back, or being viewed in the File
Directory is in MP3 format.
p
PCM label
Displayed when the fi le being recorded,
played back, or being viewed in the File
Directory is in PCM (standard audio CD
format).
L
R
?
MP3
k
Level meter scale
k Level meter scalek
The Level meter scale is in decibels (dB).
Displayed when in Record or Playback.
OVER is displayed when the level clips
or is over 0 dB.
PCM
PCM

s
CD label
The CD label appears when the CD drive
is selected/active.
t
REC label
The REC label appears when the CDR420
is in record mode.
u
Timer label
Displayed when a preset time for recording
has been set.
v
Total label
Displayed when the alphanumeric display
shows the total time for the selected track
(fi le).
w
Select label
Displayed when the CDR420 expects you
to make a choice.
7 Display continued
r s t
Timer
Elapsed
Select
Total
Remaining
Elapsed
Remaining
Elapsed
HD
OVER
0
-4
-8
-1
2
-1
6
u
v
w
x
y
HD
CD
REC
Timer
Total
Elapsed
Remaining
Select
x
Elapsed label
Displayed when the alphanumeric
display shows the elapsed time (time
from the beginning) of the selected
track (fi le). Default
y
Remaining label
Press and hold the INFO button for 2
seconds so the alphanumeric display
shows the remaining time (time to
the end) of the selected track (fi le) or
the remaining record time on the HD.
z
- 20 -
CD
HD
Remaining
Elapsed
Select
Total
Timer REC
Working
q
Working label
Flashing when the CDR420 is processing
information. The Alphanumeric display
bars show progress of the operation. Wait
for the operation to be completed. Press-
ing and releasing Stop
will cancel some
operations.
r
HD label
The HD label appears when the Hard
Drive is selected/active.
q
z
Alphanumeric display
Displays a variety of information
including remaining recording time,
menu settings, etc. Displays of more
than 14 characters may scroll.
IN OUT
REC
SELEC T
PUSH ENTER
POWER STANDBY
TREBLE
MID
BASS
FILE DIR INFO JUMP PHANTOM CD/HD
MARK UNDO REDO EDIT MENUUTILITY MENU
HD/CD RFECORDER CDR420
6 7
POWER
STANDBY
HD
6 POWER switch
Slide the POWER switch to the
right to turn power on or off.
When power is ON the display is lit and the
STANDBY light is off.
7 STANDBY light
Lit when in STANDBY MODE.
When power is
switched off STAND-
BY MODE is briefl y
displayed.
STANDBY MODE retains the state of the record
timer.
