National Instruments NI 9866 User manual

NI-9866 Getting
Started
2022-07-06

Contents
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines for Hazardous Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Wiring the NI 9866. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Cabling Requirements for the NI 9866. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cable Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cable Lengths. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Number of LIN Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Termination Resistors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
NI 9866 Hardware Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
NI-9866 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
LIN Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Power Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Physical Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety Compliance and Hazardous Locations Standards. . . . . . . . . . . . . . . . . . . . 8
Environmental. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Shock and Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electromagnetic Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CE Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Product Certifications and Declarations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Environmental Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
电子信息产品污染控制管理办法（中国 RoHS）. . . . . . . . . . . . . . . . . . . . . . . . . . . 11
NI Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ni.com
2
NI-9866 Getting Started

Overview
This document explains how to connect to the NI-9866.
Note Before you begin, read the NI-9866 Safety, Environmental, and
Regulatory Information document on ni.com/manuals and complete the
soware and hardware installation procedures in your chassis
documentation.
Note The guidelines in this document are specific to the NI-9866. The
other components in the system might not meet the same safety ratings.
Refer to the documentation for each component in the system to
determine the safety and EMC ratings for the entire system.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation.
Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises
en garde de la documentation d'utilisation. L'utilisation du produit de
toute autre façon que celle spécifiée risque de l'endommager et de
compromettre la protection de sécurité intégrée.
Safety Guidelines for Hazardous Locations
The NI-9866 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous
locations; Class I, Zone 2, AEx nA IIC T4 Gc and Ex nA IIC T4 hazardous locations; and
nonhazardous locations only. Follow these guidelines if you are installing the
NI-9866 in a potentially explosive environment. Not following these guidelines may
result in serious injury or death.
© National Instruments 3
NI-9866 Getting Started

Caution Do not disconnect I/O-side wires or connectors unless power has
been switched o or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched o or
the area is known to be nonhazardous.
Caution Substitution of components may impair suitability for Class I,
Division 2, or Zone 2.
Caution The system must be installed in an enclosure certified for the
intended hazardous (classified) location, having a tool secured cover/door,
where a minimum protection of at least IP54 is provided.
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The NI-9866 has been evaluated as Ex nA IIC T4 Gc equipment under
DEMKO 07ATEX 0626664X and is IECEx UL 14.0089X certified. Each NI-9866 is marked
II 3G and is suitable for use in Zone 2 hazardous locations, in ambient
temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9866 in Gas Group IIC
hazardous locations, you must use the device in an NI chassis that has been
evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value of 85 V at the supply
terminals to the equipment.
Caution The system shall only be used in an area of not more than
Pollution Degree 2, as defined in IEC/EN 60664-1.
ni.com
4
NI-9866 Getting Started

Caution The system shall be mounted in an ATEX/IECEx-certified
enclosure with a minimum ingress protection rating of at least IP54 as
defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the
use of a tool.
Wiring the NI 9866
The NI-9866 has one 9-pin male D-Sub connector that provides connections to a LIN
bus.
The port has two common pins (COM) that are internally connected to the module’s
isolated reference and serve as the reference ground for LIN signal. You can connect
the LIN bus reference ground to one or both COM pins. The port also has an optional
shield pin, SHLD, that you can connect to a shielded LIN cable. Connecting SHLD
may improve signal integrity and EMC performance in a noisy environment.
Caution You must use a UL listed ITE power supply marked LPS with the
NI-9866.
The NI-9866 requires an external power supply of +8 to +18 V to operate. Supply
power to the NI-9866 VSUP pin from the LIN bus.
Note Power on VSUP is required for LIN operation.
The NI-9866 pinout is listed in Table 1.
Connector Pin Signal Name
1 No Connection (NC)
2 NC
3 COM
4 NC
5 SHLD
6 COM
© National Instruments 5
NI-9866 Getting Started

Connector Pin Signal Name
7 LIN
8 NC
9 VSUP
Table 1. Pin Assignments for the NI-9866
Cabling Requirements for the NI 9866
This section deals with cabling specifications, termination resistors, cable lengths,
and the number of LIN nodes that can exist in a system.
Cable Specifications
LIN cables should meet the physical medium requirement of a bus RC time constant
of 5 µs. For detailed formulas for calculating this value, refer to the Line
Characteristics section of the LIN specification. Belden cable (3084A) and other
unterminated CAN/Serial quality cables meet these requirements and should be
suitable for most applications.
Cable Lengths
The maximum allowable cable length is 40 m, per the LIN specification.
Number of LIN Devices
The maximum number of devices on a LIN bus is 16, per the LIN specification.
Termination Resistors
LIN cables require no termination, as nodes are terminated at the transceiver. Slave
nodes typically are pulled up from the LIN bus to VBat with a 30 kΩ resistance and a
serial diode. This termination usually is integrated into the transceiver package. The
master node requires a 1 kΩ resistor and serial diode between the LIN bus and VBat.
On NI-XNET LIN products, master termination is soware selectable; you can enable
it in the API with the NI-XNET Session Interface:LIN:Termination property.
ni.com
6
NI-9866 Getting Started

NI 9866 Hardware Overview
The NI-9866 has one full-featured LIN port that is isolated from the other modules in
the system. The port has a LIN controller that is fully compliant with the LIN
1.3/2.0/2.1/2.2 Specification. The port also has an NXP TJA1028 LIN transceiver that
is fully compatible with the LIN 1.3/2.0/2.1/2.2 and SAE J2602 standard and supports
baud rates up to 20 kbps.
Figure 1. NI-9866 Hardware Overview
Ext Pwr
Supply
Required
Rx
Tx
LIN
Controller LIN
LIN
Transceiver
Rx
Tx
COM
Vsup
+
_
NI-9866 Specifications
The following specifications are typical for the range -40 °C to 70 °C unless otherwise
noted.
LIN Characteristics
Transceiver NXP TJA1028
Max baud rate 20 kbps
LIN bus lines voltage -40 to +40 VDC
Supply voltage range (VSUP)+8 to +18 VDC normal operation, -0.3 to +40 V absolute limits
MTBF Contact NI for Bellcore MTBF or MIL-HDBK-217F specifications
Power Requirements
Power consumption from chassis 1 W maximum (active mode)
Thermal dissipation (at 70 °C) 1.25 W maximum (active mode)
© National Instruments 7
NI-9866 Getting Started

Physical Characteristics
Dimensions Visit ni.com/dimensions and search by module number.
Weight Approx. 144 g (5.0 oz)
Safety Voltages
Connect only the voltages that are within these limits:
Supply voltage range (Vsup) +8 V DC to +18 V DC
Maximum voltage
Port-to-COM -40 V DC to +40 V DC maximum, Measurement Category I
Isolation
Port-to-earth ground
Withstand 1,000 V RMS, verified by a 5 s dielectric withstand test
Continuous 60 V DC, Measurement Category I
Safety Compliance and Hazardous Locations Standards
This product is designed to meet the requirements of the following electrical
equipment safety standards for measurement, control, and laboratory use:
■IEC 61010-1, EN 61010-1
■UL 61010-1, CSA C22.2 No. 61010-1
■EN 60079-0, EN 60079-7
■IEC 60079-0, IEC 60079-7
■UL 60079-0, UL 60079-7
■CSA C22.2 No. 60079-0, CSA C22.2 No. 60079-7
ni.com
8
NI-9866 Getting Started

Note For safety certifications, refer to the product label or the Product
Certifications and Declarations section.
Hazardous Locations
U.S. (UL) Class I, Division 2, Groups A, B, C, D, T4; Class I, Zone 2, AEx nA IIC T4 Gc
Canada (C-UL) Class I, Division 2, Groups A, B, C, D, T4; Class I, Zone 2, Ex nA IIC T4
Europe (DEMKO) Ex nA IIC T4 Gc
Environmental
Refer to the manual for the chassis you are using for more information about
meeting these specifications.
Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C
Storage temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 85 °C
Ingress protection IP40
Operating humidity (IEC 60068-2-30) 10% RH to 90% RH, noncondensing
Storage humidity (IEC 60068-2-30) 5% RH to 95% RH, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m
Indoor use only.
Shock and Vibration
To meet these specifications, you must panel mount the system.
Operating vibration
Random 5 g RMS, 10 Hz to 500 Hz
Sinusoidal 5 g, 10 Hz to 500 Hz
© National Instruments 9
NI-9866 Getting Started

Operating shock 30 g, 11 ms half sine; 50 g, 3 ms half sine; 18 shocks at 6 orientations
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for electrical
equipment for measurement, control, and laboratory use:
■EN 61326 (IEC 61326): Class A emissions; Basic immunity
■EN 55011 (CISPR 11): Group 1, Class A emissions
■AS/NZS CISPR 11: Group 1, Class A emissions
■FCC 47 CFR Part 15B: Class A emissions
■ICES-001: Class A emissions
Note For the standards applied to assess the EMC of this product, refer to
the Online Product Certification section.
Note For EMC compliance, operate this product according to the
documentation.
CE Compliance
■2014/34/EU; Potentially Explosive Atmospheres (ATEX)
Product Certifications and Declarations
Refer to the product Declaration of Conformity (DoC) for additional regulatory
compliance information. To obtain product certifications and the DoC for NI
products, visit ni.com/product-certifications, search by model number, and click the
appropriate link.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally
responsible manner. NI recognizes that eliminating certain hazardous substances
from our products is beneficial to the environment and to NI customers.
ni.com
10
NI-9866 Getting Started

For additional environmental information, refer to the Engineering a Healthy
Planet web page at ni.com/environment. This page contains the environmental
regulations and directives with which NI complies, as well as other environmental
information not included in this document.
EU and UK Customers
• Waste Electrical and Electronic Equipment (WEEE)—At the end of the product life
cycle, all NI products must be disposed of according to local laws and regulations.
For more information about how to recycle NI products in your region, visit ni.com/
environment/weee.
电子信息产品污染控制管理办法（中国 RoHS）
•
540
e
中国 RoHS— NI 符合中国电子信息产品中限制使用某些有害物质指令
(RoHS)。关于 NI 中国 RoHS 合规性信息，请登录 ni.com/environment/
rohs_china。(For information about China RoHS compliance, go to ni.com/
environment/rohs_china.)
NI Services
Visit ni.com/support to find support resources including documentation,
downloads, and troubleshooting and application development self-help such as
tutorials and examples.
Visit ni.com/services to learn about NI service oerings such as calibration options,
repair, and replacement.
Visit ni.com/register to register your NI product. Product registration facilitates
technical support and ensures that you receive important information updates from
NI.
NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX,
78759-3504, USA.
© National Instruments 11
NI-9866 Getting Started
© 2022 National Instruments Corporation.
