Minco Heat ME83 User manual

M 83Heating Thermostat Manual
Application
Power Key : Press the On / Off key to turn the system on or off.
User Operation
Mode Key :You can select “period control mode” or “manual mode” by this key
Up / Down key：Press the Up and Down keys to set the temperature and adjust
system parameters. And press Up and Down simultaneously and hold for 5 seconds
to enter lock key function.
Clock key: You can adjust the time and the week by this key.
Technical data
1. Temperature sensor : NTC 2. Temperature accuracy : ±1℃
3.Power consumption : <170uW4.Voltage:
5. Load current : 3A 6.Temperature setting : 5~90℃
V
V
Manual mode: Set the temperature manually by this key.
Automatic mode： Adjust to the automatic mode, the thermostat will work cyclically
by week programming.
Programming: 6 –event time and temperature
In the shutdown state, long press mode key " " and the clock key " " for 5 seconds
to enter programming mode. you can switch parameters by mode key. After entering the
programming mode， press mode key to adjust " hour" ,then press mode key to adjust
"minute".Press the mode key again to adjust temperature.
1 .Wake-up 2. Leave 3 Return(am) 4.Leave(pm) 5.Return(pm) 6.Sleep
Advanced setting (qualified person preferred)
Press" "and" "at the same time to enter the mode of advanced setting immediately
when thermostat is turned off. The following seven functions can be chosen by" M "key.
Anti-frozen function
When the room temperature is below 5℃. when the room temperature is above 7℃, the
thermostat will turn off the heating device automatically.
In the state of shutdown, the thermostat will turn on the heating device automatically
E
1
2
3
4
-2
1℃
ON
Symbol Setting Default value or
Temperature
Switching
Anti-frozen
Adjust measured temperature range:-9-9°C
Adjust switching differential range:1-5℃
Turn ON/OF Anti-frozen function
calibration
differential
function
of time mode
7
01
Kinds of periods
5
6
protection
Overheating 60℃
Adjust range:5℃~60℃
8
Max . temperature
40
Set the lower limit
of temperature
10
Reset to factory
settings
7. Protection Class : IP20
20℃
15℃
15℃
15℃
22℃
15℃
Key Event Symbol Time Default value
01
02
03
04
05
06
01
02
Week day Weekend
M
06: 00
08:00
11:30
12:30
17:00
22:00
08:00
23:00
Set time
15℃
22℃
Set temperature
01:5+2 day mode
02:6+1 day mode 03:7 +0day mode
OF : Close
Adjust range:30℃~90℃
Adjust range:5℃~20℃
3
The thermostat is recommended for control of electric heating devices or on/off valve
actuator used in water-based system.

Mounting steps
Mounting Location Recommended
The heating thermostat should be mounted on the wall with air flowing freely around.
Warning: The mounting location should not be influenced by other heat source(e.g.
sunlight), air flow through doors& windows or temperature of outer wall.
Common failure handling
Failure Handling
LCD display garbled
Display normal No output
Remote failure Check if the remote control battery has enough power , if not replace the battery.
Temperature display error Adjust the panel temperature display by the first option in the Advanced tab.
1.The shell is deformed after installation,can be reinstalled.
1. Check whether the wiring between the MPU and the power board is damaged.
2.Check whether the null line of live line is connected wrong.
Wiring diagram
1-6 Period
Icon description :
Time
Week
Room Temp
Press key
Setting Temp
Locking key
Heating
Manual/Automatic
Dimension
28mm
M
86mm
86mm
M
3-3.5
59
No power on 1.Check whether the battery is reversed.2.Check if the power button is working.
