Mini Crosser M1 Cabin User manual

User Manual Mini Crosser M1 Cabin
P9-0151-B ver. 3.0.4 - October 2017 GB
medemagroup

User guide P9-0151-B 2 of 64 Version 3.0.4 - 2017
Medema A/S
Serial number: ___-______________-______-_______
Delivery date: ________________ Year 20______
This vehicle was supplied by: Date: /

User guide P9-0151-B 3 of 64 Version 3.0.4 - 2017
Medema A/S
Contents
Symbols.................................................................................. 5
Warning! ................................................................................. 5
Contagion!.............................................................................. 5
Help for the visually impaired .............................................. 6
FSN (Field Safety Notice)...................................................... 6
Introduction............................................................................ 7
Declaration of conformity..................................................... 8
Medema A/S Warranty........................................................... 9
Control panel ......................................................................... 10
Preparations / Adjustments prior to use ............................. 13
Seat rotation........................................................................... 16
Steering column .................................................................... 17
Serial number......................................................................... 18
Driving the Mini Crosser M1 Cabin...................................... 19
Specic driving situations.................................................... 24
Long hills/difcult ground .................................................... 26
Anti-tilt wheels / stabilisers .................................................. 27
General care and maintenance ............................................ 28
Insurance................................................................................ 29
Batteries ................................................................................. 30
Charging................................................................................. 30
Battery disposal..................................................................... 32
Storage ................................................................................... 32
Cleaning ................................................................................. 32
Fuel for heater........................................................................ 33
Heater ..................................................................................... 33
Windscreen wiper / washer .................................................. 34
Replacing the wiper blade .................................................... 35
Replacing the bulb - headlight ............................................. 35
Changing the wheels............................................................. 37
Fuses ...................................................................................... 39
Brakes..................................................................................... 41
Disengagement...................................................................... 42
Transporting........................................................................... 42
Securing to vehicle oor with belts..................................... 43
Transporting by plane........................................................... 45
Towing .................................................................................... 45
Dimensioned drawing, Mini Crosser M1 Cabin.................... 46
Introduction to the Ergo Standard seat............................... 47
Introduction to the Ergo2 seat ............................................. 49
Introduction to the EBLO seat.............................................. 55
Troubleshooting .................................................................... 57

User guide P9-0151-B 4 of 64 Version 3.0.4 - 2017
Medema A/S
Programming ......................................................................... 60
Technical data........................................................................ 60
Weight of the seats................................................................ 63

User guide P9-0151-B 5 of 64 Version 3.0.4 - 2017
Medema A/S
Symbols
Used in the manual to indicate sections describing situations
where extra care is required owing to the risk of personal injury.
Used to indicate sections on electromagnetic compatibility
(EMC).
Warning!
For safety reasons the vehicle must not be lent to persons who
are not completely familiar with it. The vehicle is designed for
one person only.
The Mini Crosser M1 Cabin has been designed for users weig-
hing max. 175 kg. The vehicle can be specially adapted at the
factory for users weighing up to 200 kg.
Contagion!
Note!
The tires can sometimes rub off on oor coverings, particularly
linoleum. Medema Production assumes no responsibility in
case of contagion.
To prevent this, we recommend that you protect delicate oors
with some sort of driving surface.

User guide P9-0151-B 6 of 64 Version 3.0.4 - 2017
Medema A/S
Help for the visually impaired
If you have difculty reading small print in the user manual, we
recommend that you visit our website, where you can read this
manual in PDF format. You can enlarge the PDF manual on
your PC monitor to suit your needs and preferences.
If you nd it difcult to understand the manual and have general
questions about the product, please feel free to contact us. You
can nd our contact info on last pagesof this user manual.
FSN (Field Safety Notice)
All information concerning safety can be found at www.me-
dema.com, which is always updated with the latest safety infor-
mation. In the event of important safety-related changes, we will
notify our customers directly (FSN).

User guide P9-0151-B 7 of 64 Version 3.0.4 - 2017
Medema A/S
Introduction
Congratulations on your new Mini Crosser M1 Cabin electric
mobility Mini Crosser.
You have now taken possession of an electric mobility Mini
Crosser developed for outdoor driving by active users. It is what
is called a Class C vehicle in accordance with the European
classication of electric Mini Crossers.
For optimum enjoyment of this vehicle - and to avoid breakdowns
and accidents - we recommend that you read this User Manual
carefully. As a new user, you should pay particular attention to
the section entitled “Driving the Mini Crosser M1 Cabin”.
The Mini Crosser M1 Cabin is designed for safe travel for at least
10 years, up to a max. of 5,000 hours, provided it is serviced and
safety-checked every year, corresponding to 500 hours of opera-
tion. The service must be carried out by an authorised workshop.
IMPORTANT! For safety reasons it is of the outmost importance
that service and safety check intervals are complied with, as
this minimises the risk of brake failure and short-circuits in the
wiring, which could generate heat and cause a re.
We offer a wide range of accessories for the Mini Crosser
M1 Cabin that can make everyday life easier for you. You are
always welcome to contact us for further information on special
accessories and adaptations.
Medema A/S is not responsible for any damage or injuries
caused by inappropriate or unsafe use of the Mini Crosser M1
Cabin.
If you have any further questions about the Mini Crosser M1
Cabin or this User Manual, you are always welcome to get in
touch. Our contact details are as follows:
Medema A/S
Tel: [phone]
Email: [e-mail]
Internet: www.minicrosser.dk
NB: Errors and omissions excepted. We reserve the right to
update this manual as required.

User guide P9-0151-B 8 of 64 Version 3.0.4 - 2017
Medema A/S
Declaration of conformity
Medema A/S hereby declares that:
Machine: Mini Crosser
Use: (Prescribed use in
User Manual)
Model No: M1 Cabin
Complies with the Medical Device Directive 93/42/EEC
The product is made in accordance with the harmonized stan-
dard EN 12184 - Electrically powered wheelchairs, Mini Cros-
sers and their chargers.
The product is risk analysed in accordance with the harmonized
standard DS/EN ISO 14971:2007-04-10 2. edition - Medical
devices - Application of risk management to medical devices.
The Mini Crosser can, for a fee, be taken to the nearest dealer
for disposal in accordance with current environmental regulati-
ons.
Manufacturer: Medema A/S
Address: Enggårdvej 7, DK-7400 Herning
Tel./Fax [phone] [phone]
Date: 01.05.2014 Signature: _____________________

User guide P9-0151-B 9 of 64 Version 3.0.4 - 2017
Medema A/S
Medema A/S Warranty
1:
There is a 2-year warranty, with the exception of worn parts
such as tires, hoses, fuses, light bulbs, bushings and brake
pads.
2:
If you want to make a claim for a part under the warranty, it
must be intact. The warranty will be void if the product has been
removed or appears to have been mishandled.
3:
There is a 5-year warranty against breakage and corrosion of
the undercarriage.
4:
For the warranty to cover batteries, the charger used must be
sold by Medema A/S.
The fabric, type and serial number must be indicated on the
warranty specication, otherwise, warranty coverage may be
denied.
5:
Items returned under a warranty claim must be suitably packa-
ged to prevent damage during transport. Items damaged during
transport due to poor packaging will not covered by the war-
ranty.
6:
The warranty does not cover freight costs.
7:
The warranty requires annual inspection and maintenance of
the Mini Crosser by authorised professionals.

User guide P9-0151-B 10 of 64 Version 3.0.4 - 2017
Medema A/S
Control panel
Avoid subjecting the control panel to jarring and knocks. Take
care when driving and avoid hitting obstacles.
The manufacturer accepts no liability in respect of the unautho-
rised opening, adjustment or modication of the control panel.
Lever for adjusting the angle of the
handlebars
Charging socket
Key switch
Indicator lights, R/L
Horn
Accelerator
(four-nger control)
Indicator lights,
R/L
Horn
Speed selector
Hazard warning lights
Battery indicator
Handbrake
Light switch

User guide P9-0151-B 11 of 64 Version 3.0.4 - 2017
Medema A/S
Accelerator
(four-nger control)
Air channel
Windscreen wiper + washer
Heat regulation.
See the included manual for
EasyStart Select.

User guide P9-0151-B 12 of 64 Version 3.0.4 - 2017
Medema A/S
Designation Description
Key switch To start the vehicle:
Turn the key to driving position (1) When the Mini Crosser is
turned on, the control system performs a safety check of the
electrical system. The check lasts half a second. If the accelera-
tor is operated during this time, the Mini Crosser will not be able
to move until you have turned the key to 0 and back to 1.
Speed selector The tortoise in minimum position indicates the lowest speed
range. 0-6 km/h
The hare in maximum position indicates the highest speed
range. Up to 15 km/h
Battery indicator Lights up when the key is turned. Indicates, after half a
second, the battery charge level. It gives a more precise indi-
cation after approx. 1 minute of driving. When the red, amber
and green sections are lit, the batteries are fully charged.
When the indicator is at the bottom of the amber section, the
batteries should be charged as soon as possible. If only the
red section is lit or ashing, the batteries must be charged
immediately.
Handbrake Acts on the rear wheel and should only be used as an extra
/emergency brake and parking brake. It can be secured in
locked position. Also available as a foot brake.
Accelerator
Activate the arm at the front slowly and the Mini Crosser will
start to move forwards. The more the arm is pressed, the faster
the Mini Crosser will move. When the arm is released, it will
ip back to starting position of its own accord and the Mini
Crosser will stop. Activating the rear arm will cause the Mini
Crosser to reverse. The magnetic brake on the rear wheels will
engage when the Mini Crosser is stationary and is equivalent
to the parking brake on a car. The accelerator can also be used
to control speed downhill. In this case the motor will act as a
brake.
Light switch Turns on the front and rear lights. The key switch must be in
position 1 (driving position).
Hazard warning
lights
Turns on all the indicator lights at once. Also works when the
key is removed or turned to position 0 (stop position).
Indicator switch
Left arrow: indicator, left-hand side. Right arrow: indicator, right-
hand side. Activate the same switch to turn the indicators off.
Horn Powerful electric horn. Press the horn switch to activate.
Charging socket Turn off the key switch during charging. Please note that it is
not possible to drive the Mini Crosser while the batteries are
char-ging. See also the section entitled “Batteries and char-
ging”.
Windscreen wiper Starts the windscreen wiper. Notice the variable speed ajust-
ment.
windscreen wa-
sher
Spraying washer uid on the front window.
Heat regulation Adjustable heat in the cabin. Note: Heat can be turned on
even if the key is not in the key switch. Heating ribs should
NOT be covered.
REMEMBER! turn off the heat when you leave the vehicle.
Otherwise the batteries may be at the next time you want to
use it.

User guide P9-0151-B 13 of 64 Version 3.0.4 - 2017
Medema A/S
Preparations / Adjustments prior to use
Adjusting the height of the seat
Lift the seat off. Pull the release out and adjust the seat tube to
the desired position. See the picture on the next page. Check
that the seat height is correct and let go of the release. Move
the seat tube up/down until the release clicks into a hole.
Make sure you keep your back straight when lifting the seat,
which is very heavy. (See below.)
Lift the seat off the seat tube.
Hight adjustment seat post standard

User guide P9-0151-B 14 of 64 Version 3.0.4 - 2017
Medema A/S
The resease button pressed in. Press
the button out to release the seat tube.
Resease button pressed out. Now the
seat tube can be moved up/down to the
hight you wish. Press the release button
again and make sure it is tted in one of
the 5 holes in the seat tube.
Loosen the counter nut.
Use spanner, 17 mm.
Loosen the screw.
Adjust the seat post to the desired position.
The seat post is marked with a ring at each centimeter.
Tighten the screw, here after the counter nut.
Mount the seat. Adjust the lining if necessary.
Hight adjustment seat post with position bolt (option)

User guide P9-0151-B 15 of 64 Version 3.0.4 - 2017
Medema A/S
Seat tube in top position. There are ve
holes for adjusting the seat tube. The
release must be in a hole for the seat to
be stable.
Seat tube
Release

1
2
User guide P9-0151-B 16 of 64 Version 3.0.4 - 2017
Medema A/S
Seat rotation
It is only possible to rotate the seat in a Mini Crosser with Cabin
if both dors are open.
Pull the release lever back. The seat can be rotated 90° to
either side. When the lever is released, it engages with the seat
and holds it in place at 45° intervals.
Other seats that can be supplied for the Mini Crosser work on
similar principles. The release lever is normally mounted on the
right, but can be put on the left if so wished.
IMPORTANT!
The Mini Crosser is most stable when the seat is in its lowest
position.
Take extra care when lowering the seat on a Mini Crosser using
electric seat adjustment. Make sure that nothing is trapped in
the space between the seat and the chassis.
Avoid trapping anything when
lowering the seat.
1. Release lever for seat rotation.
2. Release lever for seat forward/back.

User guide P9-0151-B 17 of 64 Version 3.0.4 - 2017
Medema A/S
Steering column
Can be adjusted forward/back with the release lever. Pull down
on the lever and pull the handlebars closer for a good driving
position. Use the lever again and push the steering column for-
ward to make it easier to get out.
The height of the steering column can be adjusted approx. 11
cm up/down. First remove the rubber plug covering the Allen
screw. Adjust the height using a 4 mm Allen key.
Adjusting the height of
the handlebars.
Lever for adjusting the angle of
the handlebars
Adjusting the height of
the handlebars.
Allen screw for height
adjustment

User guide P9-0151-B 18 of 64 Version 3.0.4 - 2017
Medema A/S
Serial number
All vehicles have a serial number plate showing the year of pro-
duction, month and serial number. The same serial number can
also be found on the front of the User Manual.
Please quote this number when making inquiries about servi-
cing, spare parts, etc.
Maximum user weight
Vehicle’s unladen weight inc.
batteries and seat
Position of serial number plate on vehicle.
Serial number
Model description
Year of production
Max. speed

User guide P9-0151-B 19 of 64 Version 3.0.4 - 2017
Medema A/S
Driving the Mini Crosser M1 Cabin
Getting in and out
It is important to learn a safe technique for getting in and out of
the Mini Crosser.
In general the following method should be followed:
• Make sure that the Mini Crosser M1 Cabin is off (switch turned to
0) when getting in and out, otherwise the Mini Crosser could start
if the accelerator was touched inadvertently.
• Make sure that the brake is on. (Lever for disengaging motor in
top position.)
• Put the steering column in vertical position.
• If necessary, raise the armrest.
Note! - Do NOT use the dors as support, when entering or get-
ting out of the vehicle.
For some users the assistance of an attendant can be re-
commended. The attendant should:
• Take care not to injure him/herself when lifting/lowering/supporting
the user.
• Make sure that the Mini Crosser is stable and unable to move.
Turn off the Mini Crosser and check that the brake is on.
• Make sure that the seat the user is being moved to is stable.
Turn the Mini Crosser off, return the
steering column to upright position and
raise the armrest.
IMPORTANT!
The Mini Crosser will turn itself
off automatically after it has
been stationary for 10 mi-
nutes even if the key has been
turned to driving position. The
battery indicator ashes with
6 lamps at a rate of about 3
seconds.
To restart the vehicle, the key
must be turned to stop po-
sition (0) and then to driving
position (1).

User guide P9-0151-B 20 of 64 Version 3.0.4 - 2017
Medema A/S
General safety advice
Make sure that the backrest is upright and the seat is as low as
possible.
Positioning belts are recommended if the user is unable to
maintain a good driving posture independently.
Adjust your driving to road conditions. Take account of light,
trafc and weather. Be particularly careful when driving in the
dark or in bad weather, such as rain or snow. Avoid driving on
gradients with poor surfaces, such as: snow, ice, new-mown
grass, wet grass and wet leaves.
Never drive when under the inuence. This applies not only to
alcohol, but also to drugs and medicines.
Reduce speed immediately if you feel you are losing control.
Always use the indicators when changing direction.
Check that lights and indicators are working before driving off.
Use your lights when driving after lighting-up time.
As far as possible, grip the handlebars rmly with both hands.
Take care not to have anything in the basket at the front that
might inadvertently operate the accelerator.
WARNING! Do not lower the handlebars so far that the acce-
lerator can hit you on the leg when you turn the vehicle and so
be operated in advertently. If the handlebars need to be very
low, a twist grip accelerator is recommended. This is particularly
relevant if leg supports are being used.
ALWAYS switch the Mini Crosser off when it is not in use. Turn
the key to 0.
Driving
Even though the Mini Crosser is very stable, it can tip over.
Avoid sudden changes of speed and direction when travelling at
high speed, on poor surfaces and, not least, on slopes.
For short distances the Mini Crosser can drive up steeper
