Mini Gadgets BB3Fan User manual

1 Version 1.1
BushBaby3 Fan
SKU: BB3Fan

2 Version 1.1
THANK YOU FOR PURCHASING BUSH BABY 3 FAN WITH
HIDDEN CAMERA
Please read this manual before operating the camera and keep
it handy.
This fully working fan not only improves air circulation in the
room, but it also provides extra security by concealing a state of
the art hidden camera. Like all BushBaby products. Even if the
camera is handled by someone curious, the electronics are
sealed inside and blend in perfectly with the fan's own
electronics. It records HD quality 1280 x 720p video.
Either record continuously or use the motion detection
setting. No need to worry about battery life since the camera is
powered by the same AC adapter that powers the fan.
Your purchase should include:
1 x Bush Baby 3 Fan
1 x USB Cable
1 x Manual
1 x Remote Control

3 Version 1.1
GET FAMILIAR WITH THE BB3FAN HIDDEN CAMERA
Camera
Indicator Light
USB Port

4 Version 1.1
OPERATING THE BUSHBABY 3 CAMERA
IMPORTANT NOTICE: Allow the device to charge overnight before using.
HOW TO TURN ON THE BUSHBABY3
1. Press the A button
The red indicator light will turn on
oThe Bush Baby is now in standby
mode
1. Disconnect the battery connector that is connecting the
battery to the circuit board. Be careful not to pull on the
wires as that could damage them.
HOW TO TAKE PHOTOGRAPHS
1. Press the B button
The red indicator light will blink once
oThe Bush Baby has taken a
photograph
HOW TO RECORD VIDEO
1. Press the C button
The red indicator light will blink twice and
then turn off
oThe Bush Baby is now recording live
video

5 Version 1.1
HOW TO USE MOTION DETECTION
1. Press the D button
The red indicator light will blink twice and
then turn off
oThe BushBaby will only record video
when it detects motion
HOW TO SET THE TIME AND DATE STAMP
1. Visit http://time.mgidownloads.com
2. Choose “All Bush Baby 2/Bush Baby 3”
3. Select your time zone
4. Click “Download”
5. Connect your device to your computer as described in
the “How to Retrieve The Files” section of this manual
or use an external card reader to access the memory of
the SD Card.
6. The appropriate text file with the current time will
download to your computer’s downloads folder.
Navigate there and copy and paste the TXT file to the
root directory of the device’s SD card.
7. Disconnect the device from your computer and do a
test recording to confirm that date/time settings was
successful.

6 Version 1.1
HOW TO RETRIEVE THE FILES
Locate the USB port on the product. You can find the USB port
on the back of the coffee maker—the same place where the
indicator light is located—and is the same connection as the
charging port.
1. Plug the device into your PC using the USB cable
2. Locate “Removable Disk” inside the (My) Computer
folder
AutoPlay Removable Disk > Open folder to
view files
Or…
Go to Start > Computer > Removable Disk
3. Open the Removable Disk drive
4. Open the DCIM folder
5. Double click the file you want to view
VLC Player is recommended for watching
videos
IMPORTANT NOTICE: It is required that the product’s power cord
be plugged into an AC outlet to operate the DVR. The DVR will
not run on USB power alone.

7 Version 1.1
TROUBLESHOOTING
Question:
What happens if the memory fills up?
Answer:
If the memory fills up while recording video, the oldest
file on the card will be deleted and a new file will be
created. Video recording will not stop once the card is
full.
Question:
Why does the red light flash on the device when it is in Motion
Detection mode?
Answer:
The red light will flash 2 times to indicate that motion
has been detected. This denotes a new 3 minute cycle
of recording.
OTHER PROBLEMS
Call our technical support at 770–694–6923

8 Version 1.1
SPECIFICATIONS
Resolution
720p HD (1280*720) @ 30fps
Video Format
.AVI
Photo Resolution
4032*3024
Photo Format
.JPG
Vision Angle
62°
Minimal Illumination
1LUX
Remote Operating Distance
25 meters
Scope for Sound (optional)
40 meters
Supported Operating
Systems
Windows XP & Up
Mac OSX 10.5 & Up
Video Recording Files
Full Video: 20 minute files
Motion Video: 3 minute files
Memory
MicroSD Card or Internal
Storage
SD Card Format
FAT32
Recommended Speed
Class 6 or above
Time Consumed of Storage
1GB/20 minutes
Charging Time
Approx. 4 hours

9 Version 1.1
QUALITY CONTROL CHECKLIST
☐Remote
☐USB Cable
☐AC Adapter
☐MicroSD Card ____GB
☐Bush Baby 3 Fan
QC Tech: ___________________________________
Date: ______________________________
